Bruker HYPERION User manual

HYPERION
User Manual
I 24319

3rd edition 2017, publication date March 2017
© 2017 BRUKER OPTIK GmbH, Rudolf-Plank-Straße 27
D-76275 Ettlingen, www.brukeroptics.com
All rights reserved. No part of this manual may be reproduced or transmitted in any form
or by any means including printing, photocopying, microfilm, electronic systems etc. wit-
hout our prior written permission. Brand names, registered trademarks etc. used in this
manual, even if not explicitly marked as such, are not to be considered unprotected by
trademarks law. They are the property of their respective owner.
This manual is the original documentation for the FT-IR microscope HYPERION.

1
Bruker Optik GmbH HYPERION - User Manual
Table of Contents
Table of Contents
1 Safety..............................................................................................................5
1.1 General safety information.................................................................................... 5
1.2 Classification of the safety notes ......................................................................... 5
1.3 Overview of possible types of hazard .................................................................. 6
1.3.1 Possible hazards during installation, operation, maintenance and repair ................ 6
1.3.2 Possible hazardous sample materials...................................................................... 7
1.4 Intended use ........................................................................................................... 8
1.5 Service contact data............................................................................................... 8
2 Installation......................................................................................................9
2.1 General information ............................................................................................... 9
2.2 Inspecting the packaging ...................................................................................... 9
2.3 Transporting the microscope................................................................................ 9
2.4 Scope of delivery.................................................................................................. 10
2.5 Site requirements ................................................................................................. 11
2.6 Connecting the microscope to the power supply ............................................. 13
2.6.1 General information................................................................................................ 13
2.6.2 Safety note ............................................................................................................. 13
2.6.3 Procedure............................................................................................................... 14
2.7 Cable connections ............................................................................................... 15
2.7.1 Overview of the connection sockets....................................................................... 15
2.7.2 Connecting the motorized microscope stage ......................................................... 17
2.7.3 Connecting the joystick .......................................................................................... 18
2.7.4 Connecting the video camera................................................................................. 18
2.7.5 Connecting the MCT detector(s) ............................................................................ 19
2.7.6 Connecting the FPA detector ................................................................................. 20
2.7.7 Connecting the microscope to the spectrometer.................................................... 22
2.8 Connecting the microscope to the purge gas supply line ............................... 23
2.8.1 General information................................................................................................ 23
2.8.2 Procedure............................................................................................................... 23
3 Overview.......................................................................................................25
3.1 Microscope variants............................................................................................. 25
3.2 Complete overview - operating elements & components................................. 26
3.3 Operating panel .................................................................................................... 29
3.4 Brightness control and brightness indicator .................................................... 30
3.5 Microscope stages ............................................................................................... 31
3.5.1 Overview ................................................................................................................ 31
3.5.2 Manual stage.......................................................................................................... 32
3.5.3 Focus control elements .......................................................................................... 33
3.5.4 Motorized stage ...................................................................................................... 34
3.5.5 Joystick-controlled stage movement ...................................................................... 35

2HYPERION - User Manual Bruker Optik GmbH
Table of Contents
3.6 Condenser............................................................................................................. 36
3.7 Apertures............................................................................................................... 37
3.7.1 Overview................................................................................................................. 37
3.7.2 Installation locations of the apertures ..................................................................... 39
3.7.3 Manual knife-edge aperture.................................................................................... 40
3.7.4 Iris aperture for setting the Koehler illumination ..................................................... 41
3.8 Light path selector lever ...................................................................................... 42
3.9 Revolving nosepiece and objectives.................................................................. 43
3.10 Binocular ............................................................................................................... 45
3.11 LCD monitor.......................................................................................................... 46
3.12 Detectors ............................................................................................................... 47
3.12.1 Installation locations ............................................................................................... 47
3.12.2 Types of detector .................................................................................................... 48
3.13 Beam path ............................................................................................................. 49
3.14 Possible instrumental setups.............................................................................. 53
4 Operation......................................................................................................55
4.1 General information ............................................................................................. 55
4.2 Switching on / off the analysis system............................................................... 56
4.3 Preparing the microscope for a spectroscopic measurement......................... 58
4.4 Cooling the detector............................................................................................. 59
4.4.1 General information ................................................................................................ 59
4.4.2 Safety notes............................................................................................................ 59
4.4.3 Funneling liquid nitrogen in the detector................................................................. 60
4.5 Resetting the motorized stage ............................................................................ 62
4.6 Checking and correcting the condenser setting ............................................... 63
4.7 Checking the IR signal intensity ......................................................................... 66
4.7.1 Procedure in transmission mode ............................................................................ 66
4.7.2 Procedure in reflection mode.................................................................................. 68
4.7.3 Procedure with ATR objective ................................................................................ 72
4.8 Checking the detector saturation ....................................................................... 75
4.9 Viewing the sample and selecting the measurement area ............................... 77
4.10 Viewing and measuring a sample in transmission ........................................... 78
4.11 Viewing and measuring a sample in reflection.................................................. 82
4.12 ATR objective - Important operating notes ........................................................ 86
4.12.1 General handling instructions ................................................................................. 86
4.12.2 Cleaning the ATR crystal ........................................................................................ 86
4.12.3 Attaching the ATR objective at the revolving nosepiece......................................... 87
4.12.4 Setting the viewing mode / measuring mode at the ATR objective ........................ 88
4.12.5 Setting contact pressure levels............................................................................... 89
4.12.6 Focussing ............................................................................................................... 89
4.13 Measuring a sample with the ATR objective (single point measurement)...... 91
4.14 Measuring a sample with the ATR objective (mapping measurement) ........... 95

3
Bruker Optik GmbH HYPERION - User Manual
Table of Contents
4.15 GIR objective - Important operating notes......................................................... 99
4.15.1 General information................................................................................................ 99
4.15.2 Design of the mirror optics ................................................................................... 100
4.15.3 Setting the viewing mode (VIS) or measuring mode (GIR) .................................. 101
4.15.4 Images generated by the GIR objective ............................................................... 102
4.15.5 Checking the alignment of the GIR objective ....................................................... 103
4.15.6 Realigning the GIR objective................................................................................ 104
4.16 Measuring a sample with the GIR objective .................................................... 107
4.17 Purging the microscope .................................................................................... 110
5 Options and Accessories ......................................................................... 111
5.1 Optional objectives .............................................................................................111
5.1.1 Overview ...............................................................................................................111
5.1.2 Additional information about the GIR objective .....................................................112
5.2 Optional apertures ............................................................................................. 113
5.2.1 Overview ...............................................................................................................113
5.2.2 Installation location of the exchangeable apertures ..............................................114
5.3 Optional microscope stages and sample holders........................................... 116
5.3.1 Overview ...............................................................................................................116
5.3.2 Heating/freezing stage THMS 600 (Linkam) .........................................................117
5.3.2.1 General information...............................................................................................117
5.3.2.2 Controlling the temperature...................................................................................117
5.3.2.3 Safety notes ..........................................................................................................118
5.3.3 Heatable sample holder ........................................................................................118
5.3.3.1 General information...............................................................................................118
5.3.3.2 Safety notes ..........................................................................................................119
5.3.3.3 Controlling the temperature...................................................................................119
5.4 Polarizer .............................................................................................................. 120
5.4.1 General information.............................................................................................. 120
5.4.2 Safety notes ......................................................................................................... 120
5.4.3 Installation location............................................................................................... 121
5.4.4 Performing IR spectroscopic analyses using polarized light ................................ 122
5.5 External sample cabinet - IMAC........................................................................ 123
5.6 Compression cells ............................................................................................. 124
6 Repair and Maintenance ...........................................................................125
6.1 General information ........................................................................................... 125
6.2 Removing and installing the detector .............................................................. 125
6.2.1 General information.............................................................................................. 125
6.2.2 Removal and installation procedure of the MCT detector .................................... 125
6.2.3 Removal and installation procedure of the FPA detector ..................................... 128
6.3 Evacuating the detector dewar ......................................................................... 130
6.3.1 General Information.............................................................................................. 130
6.3.2 Evacuating the MCT detector dewar .................................................................... 130
6.4 Replacing a damaged ATR objective crystal ................................................... 135

4HYPERION - User Manual Bruker Optik GmbH
Table of Contents
6.4.1 General handling instructions............................................................................... 135
6.4.2 Checking the ATR crystal for damages ................................................................ 135
6.4.3 Replacing the ATR crystal assembly .................................................................... 136
6.4.4 Checking the ATR crystal position for centrality ................................................... 141
6.4.5 Aligning the ATR crystal centrically ...................................................................... 142
6.4.6 Checking the height setting of the ATR crystal..................................................... 143
6.4.7 Correcting the height setting of the ATR crystal ................................................... 144
7 Troubleshooting ........................................................................................147
7.1 General information ........................................................................................... 147
7.2 Problem - possible cause - solution ................................................................. 148
7.2.1 Sample viewing through the binocular: No field of view or dark field of view ....... 148
7.2.2 No video image is displayed on the LCD monitor and/or in OPUS ...................... 149
7.2.3 No IR signal is detected or the detected IR signal intensity is too low ................. 150
7.2.4 IR signal check in OPUS shows an unusual spectrum curve shape .................... 153
7.2.5 Problems regarding the motorized microscope stage .......................................... 154
7.2.6 Problems regarding the ATR objective ................................................................. 155
7.2.7 Problems regarding mapping measurements....................................................... 157
7.2.8 Problems regarding the FPA detector .................................................................. 158
A Specifications ............................................................................................161
A.1 HYPERION microscope...................................................................................... 161
A.2 Objectives ........................................................................................................... 161
A.3 Motorized microscope stage ............................................................................. 162
A.4 Manual microscope stage.................................................................................. 162
A.5 Detectors ............................................................................................................. 163
A.6 Heating / freezing sample stage THMS600 (Linkam)....................................... 164
A.7 Heatable sample holder ..................................................................................... 165
B Measurement parameters .........................................................................167
C Spare parts and consumables..................................................................171
D System diagram.........................................................................................173

5
Bruker Optik GmbH HYPERION User Manual
1 Safety
1.1 General safety information
1.2 Classification of the safety notes
Depending on the degree of hazard, important safety notes are classified in this manual
by signal words as follows:
➣Read carefully all instructions and safety notes in this manual before installing,
putting the microscope into operation or maintaining it. Keep this manual for future
reference available at any time.
➣Always observe the instructions and safety notes given in this manual. Failure to
do so can lead to personal injuries and/or property damage. Non-observance of
the instructions and safety notes will violate the intended use of the microscope.
(See section 1.4.)
➣It is the operator's duty to plan and implement all necessary safety measures and
to supervise their observance. Moreover, the operator must ensure that the micro-
scope is in proper condition and fully functioning.
➣A safe and trouble-free operation of the microscope is ensured only if all compo-
nents of the analysis system are installed and operated as well as maintained and
repaired according to the procedures described in this manual and in compliance
with all relevant safety standards and regulation.
➣The microscope should be operated only by authorized personnel which is trained
in operating the microscope and which is familiar with the relevant safety instruc-
tions. Never remove or deactivate any supporting safety systems during micro-
scope operation. Objects and/or material not required for the operation should be
kept outside the operating area of the microscope.
➣The microscope complies with the IEC/EN 61010-1 safety regulations.
WARNING
➣Indicates a hazardous situation which, if not avoided, could result in death or seri-
ous (possibly irreversible) injury and major property damage.
CAUTION
➣Indicates a hazardous situation which, if not avoided, may result in minor or mod-
erate (reversible) injury.
NOTE
➣Hazard, which could result in material damage if the appropriate safety instruc-
tions are not observed.

6HYPERION User Manual Bruker Optik GmbH
Safety 1
1.3 Overview of possible types of hazard
1.3.1 Possible hazards during installation, operation, maintenance and
repair
Hazards that can possibly occur during installing, operating and repairing the micro-
scope are indicated by the appropriate warning labels on the microscope. The following
warning labels indicate different dangerous situations which may be occur by an
improper use of the analysis system:
Important: All warning labels on the microscope must always be kept legible. Immedi-
ately replace a worn or damaged label!
Warning
symbol
Definition
General hazard
This warning symbol indicates a general hazard area. Consult the man-
ual and inform yourself about the concrete nature of the hazard in ques-
tion. Observe the safety instructions and follow the precautions
described in the manual to avoid personal injury and/or property dam-
age.
Electrical shock hazard
This warning symbol indicates an electrical hazard. It is located near
live parts or on housings behind which are live parts that represent an
accidental contact hazard.
Do not touch these parts. Do not remove any housing part for which you
are not authorized. Ensure that all live parts do not come into contact
with a conductive substance or liquid.
Crushing hazard due to moving parts
This warning symbol indicates a crushing hazard caused by a moving
part. It is located near or on the moving part in question. Keep your
hands and other parts of the human body away from moving parts.
Potential source of hazard: motorized microscope stage
Danger of frostbite in case of skin contact with cryogenic sub-
stances
Exposure to cryogenic substances or cooled components causes frost-
bite effects. Handle these substances with utmost care. Observe the
safety instructions for operating with cryogenic liquids. Do not touch
cold parts.
Potential source of hazard: liquid nitrogen used for cooling the MCT
detector and FPA detector; heating / freezing sample stage THMS600
(Linkam)
Hot surface
This warning symbol indicates a risk of burn injuries caused by compo-
nents and surfaces which can become very hot during operation. Do
not touch these components and surfaces. Be careful when operating
near hot components and/or surfaces.
Potential source of hazard: heatable sample holder and heating / freez-
ing sample stage THMS600 (Linkam)

7
Bruker Optik GmbH HYPERION User Manual
Safety 1
1.3.2 Possible hazardous sample materials
There can also be hazards caused by the sample material. The following list contains
some examples of hazardous substances:
Depending on the type of hazardous substances you work with, you have to observe the
specific substance-relevant safety instructions and regulations and take the correspond-
ing protective measures (e.g. wearing protective clothing, masks, gloves etc.). Affix the
corresponding warning label at the appropriate place at the microscope. The label must
be well legible and permanently discernible.
Waste disposal
Dispose all waste produced (chemicals, infectious and radioactively contaminated sub-
stances etc.) according to the prevailing laboratory regulations. Detergents and cleaning
agents must be disposed according to the special waste regulations.
Symbol Definition
Infectious material
Radioactive material
Corrosive substances

8HYPERION User Manual Bruker Optik GmbH
Safety 1
1.4 Intended use
The microscope HYPERION is intended for the microscopic examination and FT-IR
spectroscopic analysis of micro-samples, small sample areas and inhomogeneous sam-
ples. For the FT-IR spectroscopic analysis, the microscope needs to be coupled to a FT-
IR spectrometer of the TENSOR or VERTEX series. It is suited for all kinds of solid sam-
ples which absorb infrared light (radiation energy).
It is intended for the use in a laboratory under the environmental conditions specified in
appendix A.1.
The intended use includes also the compliance with the relevant standards and
regulations, especially:
• regional or national safety regulations
• regional or national accident prevention regulations
• generally recognized technical regulations
The intended use also includes the strict observance of all instructions given in this
manual, namely:
• safety instructions
• installation instructions,
• operation instructions
• repair and maintenance instructions
Use only components and accessories supplied by Bruker. For components and acces-
sories made by other manufacturers and used in conjunction with the microscope,
Bruker Optik GmbH does not assume any liability for safe operation and proper function-
ing.
1.5 Service contact data
In case you have questions about safety, installation and/or operation as well as repair
and maintenance of the analysis system or you need technical assistance in case of a
hardware and/or software problem, you can contact the Bruker service as follows:
• Service Hotline Hardware: [phone]
• Service Hotline Software: [phone]
• Fax: [phone]
• E-Mail: [e-mail]
[e-mail]
☞On our website www.bruker.com/about-us/offices/offices/bruker-optics you will
find also the current contact data of all Bruker Optics service offices worldwide.
WARNING
Health hazard because of unintended use of the microscope
Non-observance of the following safety instruction could result in injury and/or micro-
scope damage.
➣Do not take any actions that violate the intended use. The operational safety of
the microscope is ensured only if it is used as intended.

9
Bruker Optik GmbH HYPERION User Manual
2 Installation
2.1 General information
The installation of the complete analysis system (i.e. microscope plus FT IR spectrome-
ter plus data station plus possible accessories) as well as the initial start-up and the site
acceptance test are done by the Bruker service. The operating company has to provide
an installation site that meets the site requirements described in section 2.5.
☞See also the technical document Installation Requirements for IR-Microscope
HYPERION 1000 / 2000 / 3000 provided by Bruker Optik GmbH in advance of the
instrument delivery.
The installation of the microscope includes the following actions:
• connecting the microscope to the power supply
• connecting the microscope to the purge gas supply line (Not required, but highly
recommended.)
• connecting the microscope to a computer
• connecting the microscope to the FT IR spectrometer
☞For detailed information about how to connect the FT-IR spectrometer, the computer
and peripherals, refer to the corresponding manuals.
➣Important note: The operator can reconnect all cables if required, for example after
having relocated the analysis system. For information about the connections, refer
to the corresponding sections in this chapter.
2.2 Inspecting the packaging
After having received the microscope, inspect the packaging for damages. If there are
any signs of damage contact shipping company.
2.3 Transporting the microscope
CAUTION
Possible damage to the delivered microscope because of transport
damage
Non-observance of the following safety instructions could result in injury.
➣A microscope delivered in a damaged packaging may be damaged as well.
Therefore, in this case do not put the microscope into operation. Contact Bruker
instead. For the contact data, see section 1.5.
CAUTION
Injury and/or microscope damage due to an inadequate method of
transport
Non-observance of the following safety instructions could result in injury.
➣For a short-distance, the microscope can be carried by at least two persons.
➣For a long-distance, put the microscope on a wheeled table, for example. To avoid
damages, transporting the microscope in original packing is recommended.

10 HYPERION User Manual Bruker Optik GmbH
Installation 2
2.4 Scope of delivery
Standard components: The standard scope of delivery includes:
• Standard version of the HYPERION microscope vari-
antain question (including the user manual)
• External power supply unit with low-voltage cable,
country-specific power cord
• miscellaneous cables
• Tool case (The blue case includes miscellaneous
tools, sample preparation tools, spare lamp, pinhole,
mirrors, microscope slides)
• OPUS software, basic IR package (including the
OPUS Reference Manual as pdf file on the OPUS CD)
• Software package OPUS/VIDEO for video-assisted
measurements (including the OPUS/VIDEO Manual as
pdf file on the OPUS CD)
a. The HYPERION microscope is available in three different variants: HYPERION 1000, HYPERION 2000 and
HYPERION 3000. For information about the available microscope variants, see section 3.1.
Required components • PC compatible data system (Note: If desired, the PC
can also be provided by the operating company.)
• FT-IR spectrometer of the TENSOR or VERTEX series
Note: The microscope is an accessory which needs to
be coupled to a FT-IT spectrometer. In case the micro-
scope has been ordered at a later date, spectrometer
and PC are possibly already on site.
Optional
components:
The scope of delivery may also include following
optional components:
• Miscellaneous optional components and accessories
(e.g. objectives, detectors, polarizer etc.)
• Optional OPUS software packages (e.g. OPUS/3D)
including the corresponding manuals
• Fluorescence option

11
Bruker Optik GmbH HYPERION User Manual
Installation 2
2.5 Site requirements
The operating company has to provide an installation site that meets the following site
requirements:
Space requirements: Depending on the microscope model, the HYPERION
microscope has different dimensions:
•HYPERION 1000 and HYPERION 2000: 45 cm (w) x
60 cm (d) x 82 cm (h)
•HYPERION 3000: 55 cm (w) x 80 cm (d) x 92 cm (h)
• When preparing the installation site, take into account that
the ocular at the microscope front side is easily accessi-
bly.
• At the rear side, the microscope requires a clearance of at
least 25 cm (10“).
• Also take the installation site of the data station into
account. The distance between microscope and data sta-
tion should not exceed 2m.
• a stable and horizontal base which is rated for the weight
of the complete analysis system (HYPERION microscope
plus FT IR spectrometer plus data station possible acces-
sories)
Environmental
conditions:
• Ambient temperature range: 18°C - 30°C (64°F to 86°C)
• Ambient temperature variations: max. 1°C/h and max.
2°C/day (Temperature variations can impair the results of
long-term measurements.)
• Humidity (non-condensing): 70% (relative humidity)
Installation site: • a closed room, max. 2000m above sea level
• The microscope should not be installed near vibration
sources (e.g. ventilation hoods, air conditioners, motors
elevators) or in rooms with intense floor vibrations.
• The microscope should not be installed near sources of
potential inductive electrical interference (e.g. pumps,
switching motors, microwave ovens etc.), sources of high
energy pulses, and sources that might cause magnetic or
radio frequency interference. These devices can interfere
with the spectrometer and cause spectrometer malfunc-
tion. Ensure that these types of devices are not connected
to the same electrical circuit as the spectrometer.


12 HYPERION User Manual Bruker Optik GmbH
Installation 2
Power supply
requirements:
The microscope power supply is realized by the supplied
external power supply unit which has a wide input range.
This means that it is able to adapt itself to the most com-
mon public supply mains.
• Input range: 100 - 240 V AC, ~ 1,5V, 50 - 60 Hz
Connect the microscope only to a socket outlet with earth-
ing contact that complies with VDE 0620-1 or IEC!
The microscope is constructed for the connection to a
SELV (safety extra low voltage) circuit.
For safety reasons, make sure that the interfaces of electric
accessories connected to the spectrometer comply with
SELV (safety extra low voltage) circuit requirements. Nor-
mally, this condition is met if the accessory design is based
on the requirements described in EN 61010 or EN 60950.
If there are problems concerning main power supply (e.g.
brownouts, power surges, frequent thunderstorms or power
blackouts) use an UPS unit (Uninterruptible Power Supply)
to ensure an uninterruptible power supply and conse-
quently an operation without interruptions.
Possibilities of inter-
rupting the mains
power supply:
The mains power supply of the microscope can be inter-
rupted as follows:
• by disconnecting the safety plug
• by switching off the microscope using the ON / OFF
switch at the microscope rear side
• disconnecting the primary power receptacle
➣Important: When preparing the installation site, take
into account that the mains power supply connections
are easily accessible at any time.
Purge gas supply
requirements:
• dry air or nitrogen gas (dew point < -40°C corresponds to
a degree of dryness of 128ppm humidity)
• oil-free and dust-free purge gas
• max. pressure: 2 bar (29 psi)
• controllable flow rate (In case of continuous purging, the
recommended purge gas flow rate is 200 liters/hour. The
purge gas flow rate should not exceed 500 liters/hour.)

13
Bruker Optik GmbH HYPERION User Manual
Installation 2
2.6 Connecting the microscope to the power supply
2.6.1 General information
The microscope power supply is realized by an external power supply unit. The external
power supply unit plus power cord and low-voltage cable are included in the standard
delivery scope of the microscope.
☞For information about the power supply requirements, see section 2.5.
iDepending on the local conditions, the original power cord may need to be exchanged
for a power cord that complies with the standards of the country in question. Ensure that
the installed power cord has the approval of the local authority (e.g. UL for US, CSA for
Canada or VDE for Europe).
2.6.2 Safety note
CAUTION
Injury and/or property damage due to non-observance of the following
safety instructions regarding the external power supply unit
To ensure a safe operation of the external power supply unit, observe the following
safety instructions:
➣If the external power supply unit is damaged disconnect it instantly from the sup-
ply circuit. Never put a damaged external power supply unit into operation! Only
authorized technicians are allowed to repair the external power supply unit!
➣Operate the external power supply unit only in a dry environment.
➣Make sure that the external power supply unit is not exposed to direct sunlight.
Avoid temperatures above +50 °C. Provide for sufficient air circulation.
➣Position the external power supply unit in such a way that it does not present a trip
hazard.
➣Do not put heavy objects on the external power supply unit.
➣Do not place the external power supply unit on a hot surface.

14 HYPERION User Manual Bruker Optik GmbH
Installation 2
2.6.3 Procedure
1 Make sure that the spectrometer is
switched off. To do this, check the setting
of the ON/OFF switch ①.
Switch position in off-state: O
2Connect the power cord ①to the C5
connector of the external power supply
unit ②.
3Connect the low-voltage cable ①to the
low-voltage socket ②at the microscope
rear side.
4Connect the power plug ①of the power
cord to the mains socket outlet ②.
Important note: Connect the power cord
only to a socket outlet with earthing con-
tact. Make sure that the socket complies
with IEC.
①
①②
①
②
①
②

15
Bruker Optik GmbH HYPERION User Manual
Installation 2
2.7 Cable connections
In case you intend to relocate the analysis system, this section provides information
about the cable connections. For connecting the data station, monitor etc., refer to the
corresponding computer manual.
2.7.1 Overview of the connection sockets
Microscope rear side - total view
A
C
D
E
F
B
Microscope rear side - detail view
Spectrometer rear side - detail view
(For example purposes, it is a spectrome-
ter of the TENSOR series.)
Rear side of the supplied PCs
Figure 2.1: Relevant connection sockets at the microscope (upper images), spectrometer (lower left image) and PC
(lower right image)
I
J
K
L
H
G

16 HYPERION User Manual Bruker Optik GmbH
Installation 2
Microscope
Spectrometer
PC
☞Regarding the PC and the spectrometer, the description in this manual is restricted
to only those sockets which are of relevance for connecting the microscope compo-
nents. For detailed information about the other sockets, refer to the corresponding
manual.
Fig. 2.1 Connection socket
AZ-IN: socket for connecting the cable which comes from the stage motor
which drives the motorized stage in z-direction
➣This cable is factory-connected to the stage motor.
BZ-OUT: socket for connecting the cable which is used for controlling the
motorized stage movement in z-direction
➣The cable for controlling the motorized stage movement in z-direction
comes from the PC.
CACC.CONTROL 1, 2, 3: CAN BUS sockets for connecting the spectrome-
ter and possibly additional accessories (e.g. HTS-XT module)
DDET.A: socket for connecting the signal transmission cable of the detector
in the left detector compartment (detector A).
➣The detector signal is transmitted to the spectrometer.
EDET.B: socket for connecting the signal transmission cable of the detector
in the right detector compartment (detector B).
➣The detector signal is transmitted to the spectrometer.
FEXT.SYNC.: socket for connecting the signal cable which comes from the
A/D converter box (A/D converter for detector signals)
➣If the signal cable is connected to the EXT.SYNC socket and the
parameter External synchronization is activated in OPUS then the
user can start a spectroscopic measurement by pressing the START
button (H in fig. 3.4) on the control panel of the microscope.
Fig. 2.1 Connection socket
G external detector
H CAN bus socket (for connecting the microscope)
Fig. 2.1 Connection socket
I FPA detector
J Video signal cable
K Joystick
L motorized microscope stage

17
Bruker Optik GmbH HYPERION User Manual
Installation 2
2.7.2 Connecting the motorized microscope stage
By default, the motorized microscope stage is equipped with two motors which allow for
a computer-controlled or a joystick-controlled stage movement in x- and y-direction.
Optionally, the stage can be equipped with a third motor which allows for a computer-
controlled or a joystick-controlled stage movement in z-direction.
The required cables are included in the delivery scope.
1 Connect the cables labeled Xand Yto
the corresponding connectors ①at the
right side of the motorized stage.
Important: Make sure that the labeling of
the cables corresponds with the labeling
of the stage connectors.
2 In case the stage is equipped with two
motors, skip this step. In case the stage
is equipped with an third motor, proceed
as follows:
[1] Connect the cable, which is already
factory-connected to stage, to the Z-
IN socket ③at the microscope rear
side.
[2] Connect the cable labeled Zto the Z-
OUT socket ②at the microscope
rear side.
3 At the other cable end, the cables labeled
X, Yand possibly Zare pooled together
into one D-sub plug.
Insert this plug in the corresponding D-
sub socket ④at the PC.
①
②
③
④

18 HYPERION User Manual Bruker Optik GmbH
Installation 2
2.7.3 Connecting the joystick
➣Attention: Before connecting the joystick cable, make sure that the PC is switched
off. If the PC is switched on, connecting the joystick can cause unintentional stage
movements!
2.7.4 Connecting the video camera
1Connect the 15-pole D-sub connector ①
of the joystick cable to the corresponding
male socket ②at the PC.
②
①
1Connect the video signal cable ①of the
video camera to the S-VHS socket ②of
the converter box.
Connect the USB cable ③of the con-
verter box to an USB port ④at the PC.
①
③
④
②
