BRVISION BR-704WS-BM User manual

1
7”digital wireless system
BR-704WS-BM
Our vision is improve yours!
Please read this manual completely before operating the SYSTEM
BRvision technology co. ltd.
ADD:No.901,Building3,Hanhaida，Science
and Technology Innovation Park, No.7
Industrial，Zone,Yulu Community, Yutang Street
Guangming District ShenzhenChina,518132
www.brvision.com

2
Thank you for your purchase of our BRvision Rear View Systems.BR-704WS
-AHD is designed to deliver you years of trouble-free operation. This manual
contains important information required to properly install and operate the unit.
quick installation by trained professionals in proper installation environments.
Our designs are based on decades of working experience in this field.
DO NOT OPEN ANY COMPONENT.
There are no serviceable parts inside any of the components of the products.
Opening the product will break the tamper indicators and void the warranty.
Contact our tech support if a problem should arise 86 0755 2713 3048. For
faster response, please send email to su[email protected]
CAUTION
* To avoid damage to the electronic circuit, stop using this product while doing
welding work to the vehicle and/or trailers.
* Never immerse any component in water, and do not employ spray cleaners.
When cleaning,use a damp lint-free cloth only.
* Connect this unit only to other compatible devices.
* Although our products have built-in surge and cross polarity protection, make
sure all cables are connected properly; improper cable connections may
damage the camera and the monitor.
* Cables should not be allowed to touch hot or rotating parts, such as the
engine, ventilator,etc.
* Do not locate the monitor near heat generating vents or devices.
* Monitors are not designed to be waterproof. (Our BR-704WS-AHD
waterproof monitor is the exception.)Exposure to water, such as rain, may
damage the units.

3
MONITOR SPECIFICATIONS
Screen size: 7-inch digital screen (16:9)
Long Life High Resolution: 1024 × 600 Pixel (RGB)
Contrast: 400:1
Brightness: 520cd/m2
Power supply: DC 12V~35V
Operation temperatures: -30~80℃
Storage temperature: -40~85℃
Input: 2-channels video input with2 reversing cable
Features: HD sunshade, auto light sensor dimming for buttons and LCD
screen, LED blue light buttons, high quality processor, in-line waterproof fuse:
(for side cameras) Mirror/Normal image,
multi-language, NEW!
SENSOR SPECIFICATIONS
Sensor:AHD720P
TV System:NTSC/PAL
Resolution:1080*720
IR LED:20
Viewing angle: 120°
Aluminum housing.
Waterproof: IP69K
Shockproof: 10G
Operating temperature: -30°C to +80°C
Power supply: 12V DC (powered by monitor)

4

5
This monitor can be mounted on the dash and can be mounted on horizontal
surfaces. Make sure the view is suitable to the driver to observe the images.
Take care not to block any necessary viewing area when mounting. Before
mounting the system, permanently hook up all connections to ensure proper
operation.
1. After determining the monitor location, position the monitor support bracket,
mark the bolt hole location, and then drill the holes. Be careful not to drill into
any other surface that may be hidden.
2. Attach monitor bracket. Mount the monitor to the support bracket with
supplied 4 angle adjustment screws.
3. If don’t want to screw installation,the bracket also support 3M adhesive.
This camera can be mounted on the back and side,After determining the
camera location, position the camera support bracket, mark the bolt hole
location, and then drill the holes to mount the camera.
How to Mate
Steps1: Turn on the monitor--select channel 1--enter into Menu--select
interface to Mate on(press “up” button for On/Off.)--signal waiting
Step2: Press the camera’s signal match button,to mate with the monitor.
Step3: Successful.

6
7-Inch HD monitor Infrared Weatherproof Came
Wireless battery slice 3M antenna
Monitor power cable Monitor sucker stand
power adapter AC Adapter ADAPTOR Car charger
Antenna*2 Wrench
SYSTEM COMPONENTS
