Bryan Boilers UCG User manual

Form: 2405
Universal Communication Gateway Reference Manual Date: 01-25-2019
Revision: 8
Bryan Steam LLC, 783 North Chili Avenue, Peru, IN 46970 Web: www.bryanboilers.com
Phone: [phone] Fax: [phone] E-mail: [e-mail]
i
Universal Communication
Gateway Reference Manual
The Universal Communication Gateway (UCG) is an external, high performance Building
Automation multi-protocol gateway that is preconfigured to automatically communicate
between Bryan Steam’s products (hereafter called “device”) connected to the UCG and
automatically configures them for BACnet®MS/TP, BACnet IP, Metasys®N2 by JCI,
Modbus TCP/IP or LonWorks®. All Honeywell SOLA, Siemens RWF 40/55, Siemens LMV,
Honeywell RM7800 Series and the Precision Digital Trident PD765 boiler configurations
and Node-ID’s are selected through the UCG Web GUI Configurator for fast and easy
installation. A mix of multiple devices can be used on a single UCG. It is not necessary to
download any configuration files to support the required applications. The UCG is pre-
loaded with tested Profiles/Configurations for the supported devices. This document
provides the necessary information to facilitate installation of the UCG on BACnet
MS/TP, BACnet/IP, Metasys N2 and LonWorks network.
The UCG is provided as a 10” x 12” x 6” NEMA Type 1 control panel that must be
mounted and supplied with 120 VAC. Additional specifications can be found in Section
7.
Important
1. If your boiler is equipped with a Bryan Boilers Printed Circuit Board
(WD-857), devices should be pre-wired. See section 3.1.8.
2. Each boiler device Modbus settings must be configured to
communicate to the UCG.

Form: 2405
Universal Communication Gateway Reference Manual Date: 01-25-2019
Revision: 8
Bryan Steam LLC, 783 North Chili Avenue, Peru, IN 46970 Web: www.bryanboilers.com
Phone: [phone] Fax: [phone] E-mail: [e-mail]
2
CONTENTS
1How To Use This Manual ...............................................................7
2Mounting UCG ..............................................................................7
2.1 Mounting ........................................................................................................................... 7
2.2 Building Management System (BMS) Wiring .................................................................... 7
2.2.1 Modbus TCP/IP and BACnet/IP................................................................................... 7
2.2.2 BACnet MS/TP and Metasys N2.................................................................................. 8
2.2.3 LonWorks Network ..................................................................................................... 8
3Connect and Setup of Boiler Devices To UCG .................................8
3.1 Wiring Devices to the UCG ................................................................................................ 8
3.1.1 Honeywell SOLA.......................................................................................................... 9
3.1.2 Siemens RWF40 .......................................................................................................... 9
3.1.3 Siemens RWF55 .......................................................................................................... 9
3.1.4 Siemens LMV2…/LMV3… ............................................................................................ 9
3.1.5 Siemens LMV5…........................................................................................................ 10
3.1.6 Honeywell RM7800 Series ........................................................................................ 10
3.1.7 Precision Digital Trident PD765 Panel Meter ........................................................... 11
3.1.8 Boilers Equipped with Bryan Steam Printed Circuit Board (WD-857) ...................... 11
3.2 Device Modbus RTU COM Settings ................................................................................. 13
3.2.1 Honeywell Sola.......................................................................................................... 13
3.2.2 Siemens RWF40 ........................................................................................................ 15
3.2.3 Siemens RWF55 ........................................................................................................ 17
3.2.4 Siemens LMV2…/LMV3… .......................................................................................... 18
3.2.5 Siemens LMV5…........................................................................................................ 19
3.2.6 Honeywell RM7800 Series ........................................................................................ 20
3.2.7 Precision Digital Trident PD765 Panel Meter ........................................................... 22
4Setup UCG...................................................................................23
4.1 Devices and Point Count Availability............................................................................... 23
4.2 UCG Protocol Setup ......................................................................................................... 23
4.2.1 Configure the DIP Switches....................................................................................... 23
4.2.2 BACnet MSTP Setup .................................................................................................. 24
4.2.3 Modbus TCP/IP Setup ............................................................................................... 25
4.2.4 BACnet/IP Setup........................................................................................................ 25
4.2.5 Metasys N2 ............................................................................................................... 26
4.2.6 LonWorks .................................................................................................................. 27
4.3 Setup UCG via Web Configurator .................................................................................... 28
4.3.1 Connect the PC to the ProtoNode via the Ethernet Port ......................................... 28
4.3.2 Configure Profiles in ProtoNode’s Web Configurator .............................................. 29
4.3.3 Set IP Address for BACnet/IP via GUI........................................................................ 32

Form: 2405
Universal Communication Gateway Reference Manual Date: 01-25-2019
Revision: 8
Bryan Steam LLC, 783 North Chili Avenue, Peru, IN 46970 Web: www.bryanboilers.com
Phone: [phone] Fax: [phone] E-mail: [e-mail]
3
5Points Lists ..................................................................................34
5.1 Honeywell Sola Modbus RTU Mappings to BACnet, Metasys N2 and LonWorks........... 34
5.2 Seimens RWF55 Modbus RTU Mappings to BACnet, Metasys N2 and LonWorks.......... 36
5.3 Siemens LMV52 Modbus RTU Mappings to BACnet, Metasys N2 and LonWorks.......... 37
5.4 Honeywell RM7800 Modbus RTU Mappings to BACnet, Metasys N2 and LonWorks .... 38
5.5 Seimens LMV 36 Modbus RTU Mappings to BACnet, Metasys N2 and LonWorks......... 39
5.6 Precision Digital Trident PD765 Modbus RTU Mappings to BACnet, Metasys N2 and
LonWorks................................................................................................................................... 40
6Troubleshooting ..........................................................................41
6.1 LED Diagnostics for communications between the UCG and devices ............................ 42
6.2 Take Diagnostic Capture with the FieldServer Utilities................................................... 43
7Specifications ..............................................................................46
8Reference....................................................................................47
8.1 WD857 ............................................................................................................................. 47
8.2 Device RTU COM Settings................................................................................................ 47
8.3 Address DIP Switch Settings ............................................................................................ 48
8.4 Device Log........................................................................................................................ 55
9Index...........................................................................................56

Form: 2405
Universal Communication Gateway Reference Manual Date: 01-25-2019
Revision: 8
Bryan Steam LLC, 783 North Chili Avenue, Peru, IN 46970 Web: www.bryanboilers.com
Phone: [phone] Fax: [phone] E-mail: [e-mail]
4
FIGURES
Figure 1 - UCG Component Description.......................................................................................... 6
Figure 2 - Power Connection........................................................................................................... 7
Figure 3 - Ethernet Connection on the ProtoNode......................................................................... 7
Figure 4 - BACnet MS/TP and Metasys N2 BMS Connection.......................................................... 8
Figure 5 - LonWorks BMS connection............................................................................................. 8
Figure 6 - Honeywell S7999 Display and UCG Connection ............................................................. 9
Figure 7 - Siemens RWF40 and UCG Connection............................................................................ 9
Figure 8 - Siemens RWF55 and UCG Connection............................................................................ 9
Figure 9 - Siemens LMV2.../LMV3... and UCG Connection............................................................. 9
Figure 10 - LMV 5... And UCG Connection .................................................................................... 10
Figure 11 - Honeywell RM7800 with S7800 Keyboard Display..................................................... 10
Figure 12 - RM7800 with S7810M ModBus Module .................................................................... 10
Figure 13 - Precision Digital Trident PD765 to UCG Connection .................................................. 11
Figure 14 - Bryan Steam Communication PCB (WD-857) and Multi Boiler Connection............... 11
Figure 15 - End of Line Termination.............................................................................................. 12
Figure 16 - Siemens RWF55 Programing ...................................................................................... 17
Figure 17 - 7810M Address Switches and Baud Rate Jumper ...................................................... 20
Figure 18 – Honeywell RM7800 Display Setup Screen ................................................................. 21
Figure 19 - Modbus Activity on RM7800 ...................................................................................... 21
Figure 20 - S Bank DIP Switches.................................................................................................... 23
Figure 21 - B Bank DIP Switches.................................................................................................... 23
Figure 22 - A Bank DIP Switches (MAC Address) .......................................................................... 24
Figure 23 - A Bank DIP Switches (BACnet Address) ...................................................................... 25
Figure 24 - LonWorks Service Pin Location................................................................................... 27
Figure 25 - Sample of Fserver.XIF File Being Generated............................................................... 27
Figure 26 - ProtoNode Ethernet Port............................................................................................ 28
Figure 27 - Web Configurator Showing the Active Profiles to Select From.................................. 30
Figure 28 - Web Configurator Showing a Profile Selected ........................................................... 30
Figure 29 - Web Configurator Showing a Completed Profile Added............................................ 31
Figure 30 - Web Configurator Showing Completed Profiles Added ............................................. 31
Figure 31 - Default FS Web GUI Landing Page.............................................................................. 32
Figure 32 - Changing IP Address via FST Web GUI........................................................................ 33
Figure 33 - Diagnostic LEDs........................................................................................................... 42
Figure 34 - WD-857 Printed Circuit Board .................................................................................... 47

Form: 2405
Universal Communication Gateway Reference Manual Date: 01-25-2019
Revision: 8
Bryan Steam LLC, 783 North Chili Avenue, Peru, IN 46970 Web: www.bryanboilers.com
Phone: [phone] Fax: [phone] E-mail: [e-mail]
5
TABLES
Table 1 - UCG Component Description........................................................................................... 6
Table 2 - Modbus Registers........................................................................................................... 23
Table 3 - BMS Protocol Selection.................................................................................................. 23
Table 4 - Baud Rate ....................................................................................................................... 24
Table 5 Diagnostic LEDs ................................................................................................................ 42
Table 6 - Specifications ................................................................................................................. 46

Form: 2405
Universal Communication Gateway Reference Manual Date: 01-25-2019
Revision: 8
Bryan Steam LLC, 783 North Chili Avenue, Peru, IN 46970 Web: www.bryanboilers.com
Phone: [phone] Fax: [phone] E-mail: [e-mail]
6
Figure 1 - UCG Component Description
Item
Description
1
ProtoNode
2
UCG-PCB WD-856
3
Power Adapter 120Vac to 9 Vdc (only for Siemens AZL)
4
RJ45 Adapter (only for Siemens AZL)
5
UCG Power Switch
6
RS232 to RS485 Converter (only for Siemens AZL)
Table 1 - UCG Component Description
3
4
5
1
2
6

Form: 2405
Universal Communication Gateway Reference Manual Date: 01-25-2019
Revision: 8
Bryan Steam LLC, 783 North Chili Avenue, Peru, IN 46970 Web: www.bryanboilers.com
Phone: [phone] Fax: [phone] E-mail: [e-mail]
7
1HOW TO USE THIS
MANUAL
This manual may be used in its entirety or
as a reference. You may need to reference
your device’s manual for information not
covered in this UCG manual. The three
main sections are as follows:
Section 2: Mounting UCG – This section
is for mounting the UCG control panel,
connecting power and building
management connections.
Section 3: Connect and Setup for Boiler
Devices to the UCG – This section is for the
connections and set-up of each device for
the Modbus communication to the UCG.
Section 4: Setup for UCG – The section is
for the set-up of the UCG to communicate
to the devices (Modbus) and to your
building management system.
All other sections are supportive of the
sections above.
2MOUNTING UCG
2.1 MOUNTING
Mount the UCG in a suitable location that is
easy to access. Verify that the UCG power
switch is in the “off” position. Connect J1-
1(L1), J1-2(L2) and J1-3(G) of the UCG-PCB
WD-856 to a 120VAC power source.
120V
FROM
SEPARATE
POWER
SUPPLY
G
L1
L2
L2
1
2
3
Figure 2 - Power Connection
2.2 BUILDING MANAGEMENT
SYSTEM (BMS) WIRING
Building Management wiring is determined
by the protocol of the BMS.
MODBUS TCP/IP and BACnet/IP see
section 2.2.1
BACNET MS/TP and METYASYS N2
see section 2.2.2
LONWORKS see section 2.2.3
2.2.1 MODBUS TCP/IP AND
BACNET/IP
Use Cat5 cable to connect the field BMS
computer to the UCG via the Ethernet
(RJ45) connection of the ProtoNode inside
the UCG. See Figure 3. After BMS
connection, skip to section 3.
Figure 3 - Ethernet Connection on the ProtoNode

Form: 2405
Universal Communication Gateway Reference Manual Date: 01-25-2019
Revision: 8
Bryan Steam LLC, 783 North Chili Avenue, Peru, IN 46970 Web: www.bryanboilers.com
Phone: [phone] Fax: [phone] E-mail: [e-mail]
8
2.2.2 BACNET MS/TP AND
METASYS N2
Use CAT5 twisted pair cable to connect
from the field BMS computer to terminals
J2-1(GND), J2-2(Data -), and J2-3(Data +) of
the UCG-PCB WD-856 located inside UCG.
After BMS connection, skip to section 3.
+
-
G
GND
Data -
Data +
BMS (RS 485)
3
2
1GND
Data -
Data +
UCG-PCB WD-856
J2
Figure 4 - BACnet MS/TP and Metasys N2 BMS Connection
2.2.3 LONWORKS NETWORK
Use CAT5 twisted pair cable to connect the
field BMS computer to J2-2(-) and J2-3(+) of
the UCG-PCB WD-856 located inside UCG.
After BMS connection, skip to section 3.
J2
1
1
2
3
LONWORKS BUILDING
MANAGEMENT
TWISTED
PAIR
Figure 5 - LonWorks BMS connection
3CONNECT AND
SETUP OF BOILER
DEVICES TO UCG
3.1 WIRING DEVICES TO THE
UCG
If your boiler is equipped with a Bryan
Boilers Printed Circuit Board (WD-857), see
section 3.1.8. Otherwise connect all devices
directly to the UCG-PCB WD-856 located
inside UCG. The devices on this bus can be
wired in a daisy chain configuration. The
order of the interconnection is not
important.
HONEYWELL SOLA see section 3.1.1
SIEMENS RWF40 see section 3.1.2
SIEMENS RWF55 see section 3.1.3
SIEMENS LMV2…/LMV3… see
section 3.1.4
SIEMENS LMV5…see section 3.1.5
HONEYWELL RM7800 SERIES
KEYBOARD DISPLAY OR MODBUS
MODULE see section 3.1.6
PRECISION DIGITAL TRIDENT PD765
PANEL METER see section 3.1.7

Form: 2405
Universal Communication Gateway Reference Manual Date: 01-25-2019
Revision: 8
Bryan Steam LLC, 783 North Chili Avenue, Peru, IN 46970 Web: www.bryanboilers.com
Phone: [phone] Fax: [phone] E-mail: [e-mail]
9
3.1.1 HONEYWELL SOLA
Use shielded cable to connect the
Honeywell system display’s COM2 port to
terminals J3-1(GND), J3-2(Data -), and J3-
3(Data +) of the UCG-PCB WD-856 inside
the UCG. Up to 8 SOLA controls can be
controlled from one UCG. See Figure 6.
COM 2
S7999D1006 DISPLAY
COM 1
12345678
AB C A B C
24 VAC
(COM)
24 VAC
J3
1
2
3
UCG-PCB WD-
856
GND
DATA -
DATA +
Figure 6 - Honeywell S7999 Display and UCG Connection
3.1.2 SIEMENS RWF40
Use shielded cable to connect terminals CG,
CB, and CA of the Siemens RWF40 to
terminals J3-1(GND), J3-2(-), and J3-3(+) of
the UCG-PCB WD-856 inside the UCG. See
Figure 7.
Figure 7 - Siemens RWF40 and UCG Connection
3.1.3 SIEMENS RWF55
Use shielded cable to connect terminals R-,
and R+ of the Siemens RWF55 to terminals
J3-2(-), and J3-3(+) of the UCG-PCB WD-856
inside the UCG. See Figure 8.
Figure 8 - Siemens RWF55 and UCG Connection
3.1.4 SIEMENS LMV2…/LMV3…
Use shielded cable to connect the burner
mounted OCI412.10 RS-485 interface
terminals X20.1, X20.2, and X20.3 to
terminals J3-1(GND), J3-2(-), and J3-3(+) of
the UCG-PCB WD-856 inside the UCG.
Figure 9 - Siemens LMV2.../LMV3... and UCG Connection

Form: 2405
Universal Communication Gateway Reference Manual Date: 01-25-2019
Revision: 8
Bryan Steam LLC, 783 North Chili Avenue, Peru, IN 46970 Web: www.bryanboilers.com
Phone: [phone] Fax: [phone] E-mail: [e-mail]
10
3.1.5 SIEMENS LMV5…
Use CAT5 twisted pair cable to connect
from the RJ45 jack, COM2, of the Siemens
AZL to the RJ45 jack of the UCG Serial
Comm inside the UCG. See Figure 10.
Figure 10 - LMV 5... And UCG Connection
3.1.6 HONEYWELL RM7800
SERIES
The RM7800 Series flame safeguard
requires a Modbus compatible Display
Keyboard or Modbus Module. Please see
your flame safeguard manual for details.
3.1.6.1 S7800A1142 KEYBOARD
DISPLAY MODULE
Use shielded cable to connect terminals 1,
2, and 3 of the Honeywell keyboard display
to terminals J3-1(GND), J3-2(-), and J3-3(+)
of the UCG-PCB WD-856 inside the UCG.
(The 203541 Connector may be required for
connection)
Figure 11 - Honeywell RM7800 with S7800 Keyboard Display
3.1.6.2 S7810M MODBUS™ MODULE
Use shielded cable to connect terminals
6(GND), 7(+), and 8(-) of the Honeywell
S7810M ModBus Module to terminals J3-
1(GND), J3-2(-), and J3-3(+) of the UCG-PCB
WD-856 inside the UCG.
Figure 12 - RM7800 with S7810M ModBus Module

Form: 2405
Universal Communication Gateway Reference Manual Date: 01-25-2019
Revision: 8
Bryan Steam LLC, 783 North Chili Avenue, Peru, IN 46970 Web: www.bryanboilers.com
Phone: [phone] Fax: [phone] E-mail: [e-mail]
11
3.1.7 PRECISION DIGITAL
TRIDENT PD765 PANEL
METER
Use shielded cable to connect terminals
DO,DO
�
�
�
�
�
, I
�
�
�
and DI of the PDA7422 Trident
RS-485 Serial Adapter to terminals J3-
1(GND), J3-2(-), and J3-3(+) of the UCG-PCB
WD-856 inside the UCG. Connect the
PDA7420 modular cable to the serial port of
the meter and adapter.
Figure 13 - Precision Digital Trident PD765 to UCG Connection
3.1.8 BOILERS EQUIPPED WITH
BRYAN STEAM PRINTED
CIRCUIT BOARD (WD-857)
Boilers equipped with a Bryan Steam
Communication PCB (WD-857) can be
interconnected using the two RJ45 jacks
installed on the board. Standard CAT5 cable
wired as T-568A or T-568B straight through
can be used for the interconnection
between the devices that are factory wired
to the Bryan Steam Communication PCB
(WD-857) and P1 of the UCG-PCB WD-856
inside the UCG.
The Bryan Steam Communication PCB does
not need to be wired in sequential order as
this will be handled in the device
addressing.
Figure 14 - Bryan Steam Communication PCB (WD-857) and Multi
Boiler Connection
3.1.8.1 END OF LINE TERMINATION
SWITCH
Long RS-485 cabling runs of 20ft. or more
should be properly terminated at each end.
If needed a 120Ω terminating resistor
should be between J3-7 and J3-8 of the
UCG-PCB WD-857 on each end of the trunk
(See Figure 12, Boiler #3). If the UCG is
placed at one of the ends of the trunk, the
blue RS-485 End-of-Line Terminating switch
inside the UCG will need to be moved to the
ON position. Remove the cover of the
ProtoNode and move the Modbus RS-485
EOL Switch to the ON position.

Form: 2405
Universal Communication Gateway Reference Manual Date: 01-25-2019
Revision: 8
Bryan Steam LLC, 783 North Chili Avenue, Peru, IN 46970 Web: www.bryanboilers.com
Phone: [phone] Fax: [phone] E-mail: [e-mail]
12
Figure 15 - End of Line Termination
Always leave the single Red Jumper in the
A position.
On short cabling runs which most
applications are, the EOL switch does not
need to be turned ON. The default setting
for this Blue EOL switch is OFF.

Form: 2405
Universal Communication Gateway Reference Manual Date: 01-25-2019
Revision: 8
Bryan Steam LLC, 783 North Chili Avenue, Peru, IN 46970 Web: www.bryanboilers.com
Phone: [phone] Fax: [phone] E-mail: [e-mail]
13
3.2 DEVICE MODBUS RTU COM
SETTINGS
All devices connected to the UCG MUST
HAVE the same Baud Rate, Data Bits, Stop
Bits, and Parity. Refer to the UCG
configuration sheet or the multi-device
wiring drawing (generally shipped with
boiler) for the appropriate address and
baud rate settings for each device.
Section 7.1 defines the installed default
serial port settings for each device.
If your boiler device has a Bryan Steam
ModBus Address label (Form 2445)
attached to the boiler device, it has been
set up and will have the address written on
the label.
Set Modbus Node-ID for each of the devices
attached to UCG. The Modbus Node-IDs
need to be uniquely assigned between 1
and 255. Use the table in section 8to
record boilers, devices and Node-ID.
•The Modbus Node-ID’s assigned are
used for designating the Device
Instance for BACnet/IP and BACnet
MS/TP.
•The Metasys N2 and Modbus TCP/IP
field protocol Node-IDs are
automatically set to be the same
value as the Node-ID of the Modbus
RTU device.
Select the device below:
Honeywell SOLA see section 3.2.1
Siemens RWF40 see section 3.2.2
Siemens RWF55 see section 3.2.3
Siemens LMV2…/LMV3… see section
3.2.4
Siemens LMV5…… see section 3.2.5
Honeywell RM7800 Series see
section 3.2.6
Trident Model PD765 Universal
Input Meter section 3.2.7
3.2.1 HONEYWELL SOLA
3.2.1.1 SET SOLA ADDRESS
If you are prompted for a Passcode use
Bryan.
Each individual SOLA will now need its own
unique address. Follow these steps to setup
the addressing for each SOLA:
•Select the SOLA controller
•Select Configure
•System Identification and Address
•Scroll to the bottom
•Change MB1 and MB2 to the same
Modbus address.
•Press the Home button
•Select Setup
•Select Display Diagnostics
•Select Display Reset
•Repeat for each boiler. Numbering
them accordingly.

Form: 2405
Universal Communication Gateway Reference Manual Date: 01-25-2019
Revision: 8
Bryan Steam LLC, 783 North Chili Avenue, Peru, IN 46970 Web: www.bryanboilers.com
Phone: [phone] Fax: [phone] E-mail: [e-mail]
14
3.2.1.2 SOLA BMS ACTIVATION
3.2.1.2.1 TOUCH SCREEN S7999B
The S7999B display’s Modbus gateway must
be enabled for BAS control. From the
S7999B home screen follow these steps to
enable the Modbus gateway.
•Setup
•Advanced Setup
•User Preferences
•Com 2 Tab
Check the “Enable Modbus Gateway” box.
3.2.1.2.2 TOUCH SCREEN S7999D
Before powering on any of the boilers make
sure that all communication wires are
disconnected from each boiler and BMS.
Apply power to all boilers. From the S7999D
home screen follow these steps to enable
the Modbus gateway for each SOLA:
•Setup
•Display Setup
•COM2 Tab
“Enable COM2 port”
•Check that Modbus baud rate is set
at 38400 bps
•Select the Gateway tab
“Enable Modbus gateway”
•Select “Gateway on COM2 port”
•Select Save
Return to the home screen by pressing the
home button in the upper left corner of the
screen.
Reconnect all communication wires back to
the boilers and BMS.

Form: 2405
Universal Communication Gateway Reference Manual Date: 01-25-2019
Revision: 8
Bryan Steam LLC, 783 North Chili Avenue, Peru, IN 46970 Web: www.bryanboilers.com
Phone: [phone] Fax: [phone] E-mail: [e-mail]
15
3.2.2 SIEMENS RWF40
Each RWF40 device will need to be setup
with its own unique address. The decimal
place, unit, and Baud rate will need to be
setup the same on all devices.
Modbus settings
Press and hold for 3
seconds, and then release to
access the parameter level.
From the parameter level, advance to the
configuration level by pressing again,
holding for 3 seconds, and release.
Press and release it, to
advance to C112, press again
and release it, to advance to C113.
Changing Values
Select the desired digit that needs adjusted
by pressing once and releasing it.
(Each time is pressed and released it
will cycle, thru each digit, right-to-left and
back again)
To change the value of the flashing digit,
press and release it.
(Pressing and releasing will cycle up
thru the allowable values, and back again.)
Once the desired value is displayed and
flashing, accept it by pressing once
and release it. If no keys are pressed for 30
seconds, at any time, the controller will
automatically return to the basic display.
Unit Address
Address 0
0
0
Address 1
0
1
…
…
Address 99
9
9
Decimal place, unit, Baud rate
No decimal place, degrees Celsius,
9600 Bd
0
One decimal place, degrees Celsius,
9600 Bd
1
No decimal place, degrees
Fahrenheit, 9600 Bd
2
One decimal place, degrees
Fahrenheit, 9600 Bd
3
No decimal place, degrees Celsius,
19200 Bd
4
One decimal place, degrees Celsius,
19200 Bd
5
No decimal place, degrees
Fahrenheit, 19200 Bd
6
One decimal place, degrees
Fahrenheit, 19200 Bd
7
No decimal place, degrees Celsius,
4800 Bd
8
One decimal place, degrees Celsius,
4800 Bd
9
No decimal place, degrees
Fahrenheit, 4800 Bd
A
One decimal place, degrees
Fahrenheit, 4800 Bd
b
Signal for out-of-range
Limit comparators OFF
0
Limit comparators ON
1
Address 1, no decimal, ᵒF,
9600 BAUD, compare off
0
1
2
0
Press and release, to immediately return
to the basic display.

Form: 2405
Universal Communication Gateway Reference Manual Date: 01-25-2019
Revision: 8
Bryan Steam LLC, 783 North Chili Avenue, Peru, IN 46970 Web: www.bryanboilers.com
Phone: [phone] Fax: [phone] E-mail: [e-mail]
16
The Remote Detection Timer setting is
defaulted to 30 seconds. This setting will check
for a signal from building management. If there
is no signal, the controller will revert back to
local control. To disable this set dtt equal to 0.
ConF IntF dtt

Form: 2405
Universal Communication Gateway Reference Manual Date: 01-25-2019
Revision: 8
Bryan Steam LLC, 783 North Chili Avenue, Peru, IN 46970 Web: www.bryanboilers.com
Phone: [phone] Fax: [phone] E-mail: [e-mail]
17
3.2.3 SIEMENS RWF55
Figure 16 - Siemens RWF55 Programing
•From the basic display, press so
that 0Pr appears
•Press so that PArA appears
•Press so that ConF appears
•Press so that the first parameter
of the ConF level is displayed
•Press until IntF appears
•Press and r485 appears. Press
again and the first parameter bdrt
appears.
Note: The baud rate will need to be the
same on all devices connected to the UCG.
•Press again and the bdrt will
begin to flash.
•Use the to choose the following:
o1 for 9600 Baud
•Press so that the bdrt stops
flashing.
•Press and Adr is displayed.
•Press again and the Adr will begin
to flash.
Note: The device address will need to be
different on all devices connected to the
UCG. Refer to the UCG configuration sheet
(generally shipped with boiler) for the
appropriate address and baud rate settings
for each device.
•The device address can be set from
0-254.
•Use the arrow keys to choose the
device address.
•Press and the RWF55 Setup is
complete.
•The Remote Detection Timer setting is
defaulted to 30 seconds. This setting
will check for a signal from building
management. If there is no signal, the
controller will revert back to local
control. To disable this set dtt equal to
0.
ConF IntF dtt

Form: 2405
Universal Communication Gateway Reference Manual Date: 01-25-2019
Revision: 8
Bryan Steam LLC, 783 North Chili Avenue, Peru, IN 46970 Web: www.bryanboilers.com
Phone: [phone] Fax: [phone] E-mail: [e-mail]
18
3.2.4 SIEMENS LMV2…/LMV3…
3.2.4.1 PASSCODE
The Passcode can be dependent on the
burner manufacturer. The LMV2…/LMV3…
passcode is “2345” or “Entry”. If the
passcode is incorrect, check inside the
burner control box panel. You may need to
contact the burner manufacturer for the
correct passcode.
•Hold simultaneously for 3
seconds, Co d E will momentarily be
displayed
•Press to adjust for each
digit of the password
•Press after each correct
character is displayed
•Press again after the password
is complete
•PA r A is momentarily displayed,
press simultaneously
•400: S E t should be displayed, press
until 100:PArA is
displayed
•Press
3.2.4.2 ADDRESS
Each LMV2.../LMV3... device will need to be
setup with its own unique address. Refer to
the UCG configuration sheet (generally
shipped with boiler) for the appropriate
address and baud rate settings for each
device.
•Press until 145: 0 is
displayed, press
•Press to change 145: 0 to
145: (*), press
•Press simultaneously
*This is the address of the individual device.

Form: 2405
Universal Communication Gateway Reference Manual Date: 01-25-2019
Revision: 8
Bryan Steam LLC, 783 North Chili Avenue, Peru, IN 46970 Web: www.bryanboilers.com
Phone: [phone] Fax: [phone] E-mail: [e-mail]
19
3.2.5 SIEMENS LMV5…
3.2.5.1 PASSCODE
You may need a passcode. The passcode
can be dependent on the burner
manufacturer. The LMV5… passcode is
“9876” or “WES”. If the passcode is
incorrect, check inside the burner control
box panel. You may need to contact the
burner manufacturer for the correct
passcode.
3.2.5.2 BMS ACTIVATION
Activation takes place with the AZL5 menus.
•Operation
•OptgModeSelect
•GatewayBASon
When GatewayBASon is activated, plant
operation and diagnostics via the AZL… are
still possible.
The internal load controller must be turned
on for controlling the load with BMS. Use
the display menus as shown to activate the
internal load controller.
•Params&Display
•LoadController
•Configuration
•LC_OptMode
•IntLCbus
3.2.5.3 ADDRESS
The address can be selected via the AZL
menu.The address can be set between 1
and 247.
•Params&Display
•AZL
•Modbus
•Address
3.2.5.4 TRANSMISSION PARAMETERS
The Baud Rate can be set via the AZL menu.
This can be set to 9600 bit/s or 19200 bit/s.
•Params&Display
•AZL
•Modbus
•Baud Rate
The Parity can also be setup via the AZL
menu.
•Params&Display
•AZL
•Modbus
•Parity
This can be set to “none”, “even”, or “odd”
3.2.5.5 TIMEOUT COMMUNICATION
FAILURE
The AZL will timeout when there is no
communication from the BMS. The time can
be set from 0 to 7200 seconds. When this
time has elapsed the BMS control mode will
change from remote to local control. This
can be changed via the AZL menu.
•Params&Display
•AZL
•Modbus
•Timeout

Form: 2405
Universal Communication Gateway Reference Manual Date: 01-25-2019
Revision: 8
Bryan Steam LLC, 783 North Chili Avenue, Peru, IN 46970 Web: www.bryanboilers.com
Phone: [phone] Fax: [phone] E-mail: [e-mail]
20
3.2.5.6 REMOTE/LOCAL
The AZL has an internal remote / local
switch. This switch can only be operated
from the display menus.
•ManualOperation
•Auto/Manual/Off
There are three settings for this switch.
Off – Manually turn the boiler off. All set
points are ignored.
Manual – Operates in manual based on the
operator’s inputted value. All set points are
ignored. Normally used for commissioning
the boiler.
Auto – Allows the boiler to be controlled by
the BMS.
3.2.5.7 BMS OPERATING MODE
When the BAS remote / local switch is
active and set to remote, control of the
boiler is based on the operating mode
selection.
There are three operating modes:
Off – The burner will remain off regardless
of set point.
On – The burner will be controlled based on
the fuel rate register #45. (Remote Firing
Rate Control)
Auto – The burner will be controlled based
on external set point register #44. (Remote
Set point)
3.2.6 HONEYWELL RM7800
SERIES
There are two types of modules that can be
used to set up communication on the
RM7800.
Keyboard Display Module S7800A
see section 3.2.6.2
Modbus Module S7810M see
section 3.2.6.1
3.2.6.1 MODBUS MODULE S7810M
Figure 17 - 7810M Address Switches and Baud Rate Jumper
Assign a device address number from 01 to
99. “00” is not an acceptable address
number and will not work.
The default baud rate is 9600. To change
the baud rate to 19.2K, use needle nose
pliers to remove the jumper. See Fig. 17.
