EC650C: Setup Guide and Data Variables

ii SETUP GUIDE AND DATA VARIABLES May 2023 www.eaton.com
DISCLAIMER OF WARRANTIES AND LIMITATION OF LIABILITY
The information, recommendations, descriptions and safety notations in this document are based on Eaton
Corporation’s (“Eaton”) experience and judgment and may not cover all contingencies. If further information is required,
an Eaton sales office should be consulted. Sale of the product shown in this literature is subject to the terms and condi-
tions outlined in appropriate Eaton selling policies or other contractual agreement between Eaton and the purchaser.
THERE ARE NO UNDERSTANDINGS, AGREEMENTS, WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING WARRANTIES
OF FITNESS FOR A PARTICULAR PURPOSE OR MERCHANTABILITY, OTHER THAN THOSE SPECIFICALLY SET OUT IN ANY
EXISTING CONTRACT BETWEEN THE PARTIES. ANY SUCH CONTRACT STATES THE ENTIRE OBLIGATION OF EATON. THE
CONTENTS OF THIS DOCUMENT SHALL NOT BECOME PART OF OR MODIFY ANY CONTRACT BETWEEN THE PARTIES.
In no event will Eaton be responsible to the purchaser or user in contract, in tort (including negligence), strict liability or
other-wise for any special, indirect, incidental or consequential damage or loss whatsoever, including but not limited to
damage or loss of use of equipment, plant or power system, cost of capital, loss of power, additional expenses in the
use of existing power facilities, or claims against the purchaser or user by its customers resulting from the use of the
information, recommendations and descriptions contained herein. The information contained in this manual is subject
to change without notice.
DO NOT CONDUCT A FACTORY RESET – Conducting a factory reset will clear all pre-set parameters, void the warranty and leave the device
inoperable with Eaton fire systems

iii
EC650C: Setup Guide and Data Variables
SETUP GUIDE AND DATA VARIABLES May 2023 www.eaton.com
Contents
1.1 SETUP GUIDE .......................................................2
Equipment Requirements.................................................2
Wiring Instructions .......................................................2
Configuration Instructions ................................................3
1.2 LED INDICATIONS ...................................................3
1.3 DATA VARIABLES ....................................................4
EC650C Webpage........................................................4
Command Variables......................................................4
Event Variables ..........................................................4

1
EC650C: Setup Guide and Data Variables
SETUP GUIDE AND DATA VARIABLES May 2023 www.eaton.comv
1.1 Setup Guide
1.1.1 Equipment Requirements
• DF6000/CF3000 with LON Network card
• EC650C
• Laptop / Desktop PC
• Null Mode Cable
• Ethernet Cable
• Network Cable
1.1.2 Dimensions

2
EC650C: Setup Guide and Data Variables
SETUP GUIDE AND DATA VARIABLES May 2023 www.eaton.com
1.1.3 Wiring Instructions
• Connect “A” of Panel LON network card to input “8” on the EC650C.
• Connect “B” of Panel LON network card to input “7” on the EC650C.
• Connect “+” of Panel 24V output to input “2” on the EC650C.
• Connect “-“of Panel 24V output to input “1” on the EC650C.
• Connect the Ethernet cable to the Ethernet input of the EC650C and to the Ethernet port of the laptop
Connectors
POWER 1
2
Power supply input MINUS
Power supply input PLUS
TP/FT-10
CEA-709
6
7
8
not connected (NC)
Input B
Input A

3
EC650C: Setup Guide and Data Variables
SETUP GUIDE AND DATA VARIABLES May 2023 www.eaton.comv
1.1.1 Conguration Instructions
Obtain the IP of the Laptop / Desktop PC used for monitoring BACnet.
• Launch Windows
• Click “Start” button
• Click “All Programs”
• Click “Accessories”
• Click “Command Prompt” wait for the command window to open.
• Type “ipconfig” then press enter.
• Make a note of the “IP Address”
• Close the command window.
Configuring EC650C
• Click “Start” button
• Click “All Program”
• Click “Accessories”
• Click “Communications”
• Click “HyperTerminal” (if you are running Windows 7 then HyperTerminal will need to be downloaded from the
Internet)
• At the “Connection Description” window enter a name, i.e. EC650C, then click OK.
• At the “Connect To” window select the COM port for the PC serial port.
• At the “COM # Properties” window select the following settings then click OK.
• a) Baud Rate = 38400
• b) Data Bits = 8
• c) Parity = None
• d) Stop Bits = 1
• e) Flow Control = None
• Press “Enter” key to display the configuration menu of the EC650C.
• Press “5” key to open the IP configuration menu.
• Press “2” key to open the IP address entry screen.
• Enter the IP address of the Laptop/Desktop PC changing the last 3 digits to a different number, for example if the IP
address of the Laptop is 192.168.24.1 set the IP address of the EC650C to 192.168.24.100.
• Press the “x” key to save the settings and return to the configuration menu.
• Press the “0” (zero) key to reset the EC650C.
• Close HyperTerminal
The EC650C has all other parameters pre-set by the Supplier at manufacture.

4
EC650C: Setup Guide and Data Variables
SETUP GUIDE AND DATA VARIABLES May 2023 www.eaton.com
1.2 LED Indications
1.3 Data Variables
1.3.1 EC650C Webpage
• Launch Internet Explorer (or any other internet browser)
• In the address bar type the IP address of the EC650C (i.e. 192.168.24.100). The webpage of the EC650C will load.
• Click “Config” on the left hand column (if not already selected). Click “Data Points” on the left hand column.
• Click “BACnet Port” in the tree view (if not already selected) Click “Datapoints” in the tree view (if not already selected)
1.3.2 Command Variables
• Click “2” or “Next” at the bottom of the webpage.
1.3.2.1 Soft Reset
• Click “nvoReset” to load the variable data.
• Click the test box next to the Value field.
• Enter “1” and click the “Set” button. This will soft reset all Panels on the network.
• Click “Back” to return to the data points list.
1.3.2.2 Silence
• Click “nvoSilence” to load the variable data.
• Click the test box next to the Value field.
• Enter “1” and click the “Set” button. This will silence the sounders for all Panels on the network.
• Click “Back” to return to the data points list
1.3.2.3 Evacuate
• Click “nvoEvacuate” to load the variable data.
• Click the test box next to the Value field.
• Enter “1” and click the “Set” button. This will evacuate all Panels on the network.
• Click “Back” to return to the data points list.
1.3.3 Event Variables
• Default page, otherwise click “2” or “Next” at the bottom of the webpage.
Status LEDs
FT GREEN flashing fast
GREEN flashing 1 Hz
RED permanent
RED flashing fast
Traffic on CEA-709 port
Not commissioned
CEA-709 port damaged
CEA-709 traffic overload
Variable Name Description
RxPanelData_CmdStatus On = Status
Off = Command
RxPanelData_PanelNumber Panel Network Number
RxPanelData_CmdStatusNumber See table below
RxPanelData_Address This is the loop address of the device
RxPanelData_Analogue This is the analogue value of the device
RxPanelData_Zone This is the zone number the device is in

5
EC650C: Setup Guide and Data Variables
SETUP GUIDE AND DATA VARIABLES May 2023 www.eaton.comv
1.3.3.1 ASCII Table
This table can be used to convert the decimal values listed for the Location1 through 25 in the data points into
characters.
Variable Name Description
RxPanelData_Loop This is the loop number the device is on
RxPanelData_Always_1 Not required
RxPanelData_TypeID This is the type ID of the device
RxPanelData_Location_Location1…25 Device Text (use ASCII table for conversion to characters)
Decimal Hexadecimal Character Decimal Hexadecimal Character
32 20 Space 81 51 Q
33 21 !82 52 R
34 22 "83 53 S
35 23 #84 54 T
36 24 $85 55 U
37 25 %86 56 V
38 26 &87 57 W
39 27 ‘88 58 X
40 28 ( 89 59 Y
41 29 )90 5A Z
42 2A *91 5B [
43 2B +92 5C \
44 2C ,93 5D ]
45 2D -94 5E ^
46 2E .95 5F _
47 2F /96 60 `
48 30 097 61 a
49 31 198 62 b
50 32 299 63 c
51 33 3100 64 d
52 34 4101 65 e
53 35 5102 66 f
54 36 6103 67 g
55 37 7104 68 h
56 38 8105 69 i
57 39 9106 6A j
58 3A :107 6B k
59 3B ;108 6C l
60 3C <109 6D m
61 3D =110 6E n
62 3E >111 6F o

6
EC650C: Setup Guide and Data Variables
SETUP GUIDE AND DATA VARIABLES May 2023 www.eaton.com
Decimal Hexadecimal Character Decimal Hexadecimal Character
63 3F ?112 70 p
64 40 @113 71 q
65 41 A114 72 r
66 42 B115 73 s
67 43 C116 74 t
68 44 D117 75 u
69 45 E118 76 v
70 46 F119 77 w
71 47 G120 78 x
72 48 H121 79 y
73 49 I122 7A z
74 4A J123 7B {
75 4B K124 7C |
76 4C L125 7D }
77 4D M126 7E ~
78 4E N
79 4F O
80 50 P
1.3.3.2 Type ID List
This table can be used to decode the Type ID data point values.
Type ID Device Type
1Optical Detector
2Ion Detector
3Heat A1R
4Opto/Heat Detector
5Heat BS Detector
6Heat CS Detector
7Carbon Monoxide Detector
8Sounder / Beacon
9Sounder Control Unit
10 Voice Annunciator
11 I/O Unit
12 Call Point
13 Repeater
14 Zone/Shop Monitor
15 Beam Detector
16 Addressable RF Hybrid

7
EC650C: Setup Guide and Data Variables
SETUP GUIDE AND DATA VARIABLES May 2023 www.eaton.comv
1.3.3.3 Network Packets & Payloads
Type ID Device Type
17 Zonal RF Hybrid
18 Emergency Lighting Module
19 4-20mA Interface Unit
20 SP40S
21 Fan Controller
22 Technical Input
23 Technical Timer
24 Non Fire Input
25 Supervisor Interface
26 Chinese Output
27 MCIM
DISCLAIMER: Some device types may no longer be supported or support may be retracted without prior notice.
Event Cmd
Status
Panel
Number
Cmd Status
Number
Address Analogue Zone Loop Type
ID
Location
1…25
Dec Hex
Global Evacuate Off Panel 10x01 0 0 0 0 0 Panel
Text
Global Silence Off Panel 20x02 0 0 0 0 0 Panel
Text
Global Reset Off Panel 30x03 0 0 0 0 0 Panel
Text
Global Disable Zones
in Fire Off Panel 40x04 0 0 0 0 0 Panel Text
Global Disable
Addresses in Fire Off Panel 50x05 0 0 0 0 0 Panel Text
Global Mute Buzzer Off Panel 80x08 0 0 0 0 0 Panel
Text
Global Reset Outputs Off Panel 14 0x0e 0 0 0 0 0 Panel
Text
Global Disable I/O Off Panel 16 0x10 I/O 0 0 0 0 Panel
Text
Global Enable I/O Off Panel 17 0x11 I/O 0 0 0 0 Panel
Text
Global Disable Sounders Off Panel 18 0x12 I/O 0 0 0 0 Panel
Text
Global Enable Sounders Off Panel 19 0x13 I/O 0 0 0 0 Panel
Text
Start Zone Test Off Panel 28 0x1c 0 0 Zone 0 0 0
Request Disables Off Panel 33 0x21 0 0 0 0 0 0
Get Zone Text Off Panel 34 0x22 0 0 Zone 0 0 0
Disable I/O Off Panel 48 0x30 I/O 0 0 0 0 0
Enable I/O Off Panel 49 0x31 I/O 0 0 0 0 0
Disable Sounders Off Panel 50 0x32 0 0 0 0 0 0
Enable Sounders Off Panel 51 0x33 0 0 0 0 0 0

8
EC650C: Setup Guide and Data Variables
SETUP GUIDE AND DATA VARIABLES May 2023 www.eaton.com
1.3.3.3 Network Packets & Payloads
Event Cmd
Status
Panel
Number
Cmd Status
Number
Address Analogue Zone Loop Type
ID
Location
1…25
Dec Hex
Address Fault Off Panel 90x09 Address-1 Value Zone-1 Loop-1 Type Address
Text
Fire Off Panel 10 0x0a Address-1 Value Zone-1 Loop-1 Type Address
Text
Test fire Off Panel 11 0x0b Address-1 Value Zone-1 Loop-1 Type Address
Text
Dual Address Off Panel 12 0x0c Address-1 Value Zone-1 Loop-1 Type Address
Text
Pre-alarm Off Panel 14 0x0d Address-1 Value Zone-1 Loop-1 Type Address
Text
Network Fault Off Panel 25 0x19 Panel 0 0 0 0 0
Mains Fault On Panel 60x06 0 0 0 0 0 Panel
Text
Loop Driver Fault On Panel 70x07 0 0 0 Loop-1 0 Panel
Text
Charger Fault On Panel 80x08 0 0 0 0 0 Panel
Text
Relay Fault On Panel 90x09 0 0 0 0 0 Panel
Text
Battery Fault On Panel 10 0x0a 0 0 0 0 0 Panel
Text
Sounder 2 Fault On Panel 15 0x0f 0 0 0 0 0 Panel
Text
Earth Fault On Panel 16 0x10 0 0 0 0 0 Panel
Text
Sounder 1 Fault On Panel 17 0x11 0 0 0 0 0 Panel
Text
FRE Fault On Panel 23 0x17 0 0 0 0 0 Panel
Text
FPE Fault On Panel 24 0x18 0 0 0 0 0 Panel
Text
New device On Panel 28 0x1c Address 0 0 Loop-1 Type 0
Type Changed On Panel 29 0x1d Address 0Zone Loop-1 Type Address
Text
Short Middle Fault On Panel 32 0x20 0 0 0 Loop-1 0 Panel
Text
Event Cmd
Status
Panel
Number
Cmd Status
Number
Address Analogue Zone Loop Type
ID
Location
1…25
Disable Zone Off Panel 52 0x34 0 0 Zone 0 0 0
Enable Zone Off Panel 53 0x35 0 0 Zone 0 0 0
Disable Address Off Panel 54 0x36 Address 0 0 Loop-1 0 0
Enable Address Off Panel 55 0x37 Address 0 0 Loop-1 0 0
Disable Outputs Off Panel 56 0x38 0 0 0 0 0 0
Enable Outputs Off Panel 57 0x39 0 0 0 0 0 0
Disable All Off Panel 58 0x3a 0 0 0 0 0 0
Enable All Off Panel 59 0x3b 0 0 0 0 0 0
Analogue Value Off Panel 235 0xeb Address 0 0 Loop-1 0 0

9
EC650C: Setup Guide and Data Variables
SETUP GUIDE AND DATA VARIABLES May 2023 www.eaton.comv
Event Cmd
Status
Panel
Number
Cmd Status
Number
Address Analogue Zone Loop Type
ID
Location
1…25
Open Address On Panel 33 0x21 Address-1 0Zone-1 Loop-1 Type Address
Text
Open Positive Fault On Panel 34 0x22 0 0 0 Loop-1 0 Panel
Text
Open Negative Fault On Panel 35 0x23 0 0 0 Loop-1 0 Panel
Text
Short Far Fault On Panel 36 0x24 0 0 0 Loop-1 0 Panel
Text
Short Near Fault On Panel 37 0x25 0 0 0 Loop-1 0 Panel
Text
Watchdog Reset On Panel 39 0x27 0 0 0 0 0 Panel
Text
FRE Active On Panel 47 0x2f 0 0 0 0 0 Panel
Text
I/O Disabled On Panel 48 0x30 I/O 0 0 0 0 Panel
Text
I/O Enabled On Panel 49 0x31 I/O 0 0 0 0 Panel
Text
Sounders Disabled On Panel 50 0x32 0 0 0 0 0 Panel
Text
Sounders Enabled On Panel 51 0x33 0 0 0 0 0 Panel
Text
Zone Disabled On Panel 52 0x34 0 0 0 0 0 Panel
Text
Zone Enabled On Panel 53 0x35 0 0 Zone 0 0 Panel
Text
Address Disabled On Panel 54 0x36 Address 0Zone Loop-1 Type Address
Text
Address Enabled On Panel 55 0x37 Address 0Zone Loop-1 Type Address
Text
Outputs Disabled On Panel 56 0x38 0 0 0 0 0 Panel
Text
Outputs Enabled On Panel 57 0x39 0 0 0 0 0 Panel
Text
All Disabled On Panel 58 0x3a 0 0 0 0 0 Panel
Text
All Enabled On Panel 59 0x3b 0 0 0 0 0 Panel
Text
Supervisory On Panel 216 0xd8 Address Value Zone Loop-1 Type Address
Text
Zone Text On Panel 217 0xd9 0 0 Zone 0 0 Zone
Text
Zone Test Fire On Panel 231 0xe7 Address Value Zone Loop-1 Type Address
Text
Analogue Value On Panel 235 0xeb Address Value 1 Value
2Loop-1 Type Address Text
Extinguisher On On Panel 238 0xee 0 0 0 0 0 Panel
Text
Battery Fault On Panel 248 0xf8 Address Value 1 Zone Loop-1 Type Address
Text
Clear Address Fault On Panel 251 0xfb Address Value 1 Zone Loop-1 Type Address
Text
DISCLAIMER: Some commands may not be in use or additional commands may be added with no prior notice.
DO NOT CONDUCT A FACTORY RESET – Conducting a factory reset will clear all pre-set
parameters, void the warranty and leave the device inoperable with Eaton fire systems.
NOTES: Where the data has -1 in it this means that the value is 1 less than indicated at the Panel so an offset of
1 should be added to this field.

Eaton
EMEA Headquarters
Route de la Longeraie 7
1110 Morges, Switzerland
Eaton.eu
© 2023 Eaton
All Rights Reserved
Printed in XXX
Publication No. 25-17510-A
May 2023
Eaton is a registered trademark.
All trademarks are property
of their respective owners.
Changes to the products, to the information contained in this
document, and to prices are reserved; so are errors and omissions.
Only order confirmations and technical documentation by Eaton is
binding. Photos and pictures also do not warrant a specific layout or
functionality. Their use in whatever form is subject to prior approval
by Eaton. The same applies to Trademarks (especially Eaton, Moeller,
and Cutler-Hammer). The Terms and Conditions of Eaton apply, as
referenced on Eaton Internet pages and Eaton order confirmations.
