Bsd Ba-9800 User manual

Professional Waistband Amplifier with USB/SD Card Reader

User ManualUser Manual

www.audio.com.sg

Made in Taiwan

BA-9800

7.Troubleshooting & Solutions7.Troubleshooting &Solutions

Problem

No Output from

Microphone

Troubleshooting

1. Check batteries are fully charged.

2. Check power ON/OFF switch.

3. Check mic input jack is inserted at“▲” mic input.

Feedback

(howling)

1. Check mic is worn correctly.

2. Check volume is set at appropriate level.

3. Check tone control is set at appropriate level.

4. Adjust distance between the main unit & mic.

No signal when

Power ON

1. Main unit comes with low voltage protection circuit. When voltage is

below safe level, power will be cut-off to prevent damage to batteries.

Charge batteries if LED indicator does not illuminate.

Troubleshooting & Solutions

1. Adjust USB / SD Card Output Volume using Power/Vol

Control Switch or Vol+/Vol- buttons.

1. Check USB /SD Card is inserted properly.

2. Check MP3 “ON” button is switched on.

3. Check the light indicator “PLAY” is on and blinking, to

indicate USB /SD Card is being read. Red light indicates

USB input, green light indicates SD Card input.

1~4

5~6

USB /SD Card

Output Volume

too soft

No output from

USB /SD Card

Contents

Table of Contents

.......................................

.............................................................

..................................................................

...........................................................

.................................................................

........................................................

(1)Foreward & Parts Description

(2)Functions

(3)Features

(4)Specifications

(5)Instructions

(6)Basic Set

(7)Troubleshooting

Specifications subject to change without notification.

1.Forward

Thank you for selecting BSD Professional Waistband Amplifier. Before using,

please read this instruction manual in order to achieve the best performance.

1.Forward

2.Parts Description2.Parts Description

2.1Host structure2.1Host structure

Forward & Parts Description Instructions & Basic Set

Front View

Control Panel

SD Card

Input Slot

Rear View

Battery Compartment

5.2 MP3/USB/SD Card Function5.2 MP3/USB/SD Card Function

(1) Insert SD Card into the SD Card Input slot (Fig. 2). When reading/playing the

MP3/ USB/ SD Card, the “PLAY” button (Fig.1-12) will illuminate and continue

blinking. Red light indicates MP3/USB input (Fig. 2-1), green light indicates SD

Card input (Fig. 2-2).

(2) Adjust MP3/ USB / SD Card Output Volume using Power/Vol Control Switch

(Fig. 1-1) or Vol+/Vol- buttons (Fig. 1-6 and Fig. 1-7).

(3) When playing MP3, press “reverse” (Fig. 1-6) or “forward” (Fig. 1-7) buttons to

select the desired track. Press “play” or “pause” button (Fig. 1-8) to play or

pause the desired track.

(4) Press “ON” button (Fig. 1-5) to turn off MP3/USB/SD Card function, and the

light indicator on “PLAY” button (Fig. 1-12) will go off.

6.Basic Set6.Basic Set

(1)Main Unit

(2)Headset Microphone

(3)Belt

(4) 3.5mm ConnectorΦ

1PC

(5)Switching Power Supply (9V 1A)

(6)User Manual

1PC

Functions Functions & Features

Note:

Pls adjust the gooseneck until the microphone is

approx. 2-3cm away from the lips. Do not turn on

power / volume before microphone is securely worn.

2.5 Headset Mic2.5 Headset Mic

(1) Microphone capsule

(2) Bending Gooseneck

(3) Headset

(4) 3.5 JackΦ

3 Features.3 Features.

(1) USB port & SD card reader.

(2) Latest Digital Circuit Design for higher output & lower power consumption.

(3) Rechargeable lithium batteries prolong life span of main unit.

(4) Neodymium magnet provides better sound quality.

(5) Compact, lightweight & portable.

(6) Amplifies inputs from MP3, PC, etc

(7) Power is cut-off automatically when batteries are fully charged.

↓

↑

2~3cm

2.3 MP3/USB / SD Card Function2.3 MP3/USB /SD Card Function

Fig. 2

(1) (2)

(1)

2.4 Battery Compartment2.4 Battery Compartment

(1) When reading/playing the MP3/ USB/ SD Card,

the “PLAY” button will illuminate and continue

blinking. Red light blinking indicates main unit

is reading MP3/USB input.

(2) Green light blinking indicates main unit is

reading SD Card input.

(1) 3.7V / 1500MA high capacity rechargeable

lithium battery 2 nos.

To prolong battery life, pls fully charge the lithium

batteries after every use for the first few times.

Note: If MP3/USB is inserted, and SD Card is

inserted later, the main unit will read the SD

Card, as it is inserted later.

Supported File Format: MP3 format.

Supported USB/SD Card : Max. 32G(Version 2.0)

Note: For optimum performance & safety reasons,

pls use original lithium batteries provided by

manufacturer.

(1)

(2)

(3)

(4)

Fig. 3

Fig. 4

Fig.5

Specifications & Instructions

(1) Power Output : RMS 10W

(2) AF Response : 100Hz-13KHz

(3)Battery:3.7Vx2nos.

(4) Battery Type: Rechargeable

Lithium Batteries

(5) Speaker : 3-inch speaker x 1

(6) Input Signal : Mic/MP3/USB/SD Card

(7) Charging Time : 7-8 hrs

(8) Usage Time : 12-15 hrs per charge

(1) Please use the original headset microphone for best performance. Insert headset

mic input jack (Fig. 4-4) into the mic input on the main unit (Fig. 1-2), adjust the

(2) When main unit is turned on (Fig. 1-1), green “POWER” indicator (Fig. 1-10) light

denotes main unit is powered on. Red “POWER” indicator (Fig. 1-10) light indicates

battery level is low. When charging, “RECHARGE” indicator turns red (Fig. 1-11).

“RECHARGE” indicator (Fig. 1-11) turns green when main unit is fully charged.

(3) Adjust Power/Vol Control Switch (Fig. 1-1) to set desired volume for headset mic

output.

(4) If feedback (howling) occurs, check volume (Fig. 1-1) is set at appropriate level.

gooseneck (Fig.4-2) until the microphone is approx. 2-3cm away from the lips (Fig. 5).

Functions

2.2 Control Panel Functions2.2 Control Panel Functions

(1) Power On/Off & Volume Control Switch

(2) Mic Input

(3) DC 9V Power Input

(4) AUX IN Input

(5) MP3 ON/OFF Button

(6) MP3 Volume Control - Press &

hold to lower MP3 volume, quick

press to select previous track.

(7) MP3 Volume Control Press & hold

to increase MP3 volume, quick

press to select next track.

(8) “PLAY” or “PAUSE” button

(9) Eyelet for Belt

(10) Power LED Indicator

(11) Power Recharge Indicator

(12) MP3 LED Indicator. When reading MP3/ USB/ SD Card, the “PLAY” button will illuminate

and continue blinking. Red light indicates MP3/USB input, green light indicates SD Card

input.

(1)

(2)(3)(4)(5)(6)(7)(8)

(9)

(10)(11)(12)

(9)

Fig. 1

5.1 Headset Mic5.1 Headset Mic

4. Specifications4. Specifications

5 Instructions.5 Instructions.

BSD BA-9800 User manual
