SoundwebTM London
BLU-102 Installation Guide
18-0771-B

2
WARNING FOR YOUR PROTECTION
READ THE FOLLOWING:
KEEP THESE INSTRUCTIONS
HEED ALL WARNINGS
FOLLOW ALL INSTRUCTIONS
THE APPARATUS SHALL NOT BE EXPOSED TO DRIPPING OR SPLASHING
LIQUID AND NO OBJECT FILLED WITH LIQUID, SUCH AS VASES, SHALL
BE PLACED ON THE APPARATUS
CLEAN ONLY WITH A DRY CLOTH.
DO NOT BLOCK ANY OF THE VENTILATION OPENINGS. INSTALL IN
ACCORDANCE WITH THE MANUFACTURER’S INSTRUCTIONS.
DO NOT INSTALL NEAR ANY HEAT SOURCES SUCH AS RADIATORS, HEAT
REGISTERS, STOVES, OR OTHER APPARATUS (INCLUDING AMPLIFIERS)
THAT PRODUCE HEAT.
ONLY USE ATTACHMENTS/ACCESSORIES SPECIFIED BY THE MANU-
FACTURER.
UNPLUG THIS APPARATUS DURING LIGHTNING STORMS OR WHEN
UNUSED FOR LONG PERIODS OF TIME.
Do not defeat the safety purpose of the polarized or grounding-type plug.
A polarized plug has two blades with one wider than the other. A grounding
type plug has two blades and a third grounding prong. The wide blade or
third prong are provided for your safety. If the provided plug does not fit your
outlet, consult an electrician for replacement of the obsolete outlet.
Protect the power cord from being walked on or pinched particularly at
plugs, convenience receptacles, and the point where they exit from the
apparatus.
Use only with the cart stand, tripod bracket, or table specified by the
manufacture, or sold with the apparatus. When a cart is used, use caution
when moving the cart/apparatus combination to avoid injury from tip-over.
Refer all servicing to to qualified service personnel. Servicing is required
when the apparatus has been damaged in any way, such as power-supply
cord or plug is damaged, liquid has been spilled or objects have fallen into
the apparatus, the apparatus has been exposed to rain or moisture, does
not operate normally, or has been dropped.
POWER ON/OFF SWITCH: For products provided with a power switch, the
power switch DOES NOT break the connection from the mains.
MAINS DISCONNECT: The plug shall remain readily operable. For rack-
mount or installation where plug is not accessible, an all-pole mains switch
with a contact separation of at least 3 mm in each pole shall be incorporated
into the electrical installation of the rack or building.
FOR UNITS EQUIPPED WITH EXTERNALLY ACCESSIBLE FUSE RECEPTACLE:
Replace fuse with same type and rating only.
MULTIPLE-INPUT VOLTAGE: This equipment may require the use of a differ-
ent line cord, attachment plug, or both, depending on the available power
source at installation. Connect this equipment only to the power source
indicated on the equipment rear panel. To reduce the risk of fire or electric
shock, refer servicing to qualified service personnel or equivalent.
If connected to 240V supply, a suitable CSA/UL certified power cord shall
be used for this supply.
SAFETY INSTRUCTIONS
NOTICE FOR CUSTOMERS IF YOUR UNIT IS EQUIPPED WITH A POWER CORD.
WARNING: THIS APPLIANCE SHALL BE CONNECTED TO A MAINS SOCKET OUTLET
WITH A PROTECTIVE EARTHING CONNECTION.
The cores in the mains lead are coloured in accordance with the following code:
GREEN and YELLOW - Earth BLUE - Neutral BROWN - Live
As colours of the cores in the mains lead of this appliance may not correspond
with the coloured markings identifying the terminals in your plug, proceed
as follows:
•The core which is coloured green and yellow must be connected to
the terminal in the plug marked with the letter E, or with the earth
symbol, or coloured green, or green and yellow.
•The core which is coloured blue must be connected to the terminal
marked N or coloured black.
•The core which is coloured brown must be connected to the terminal
marked L or coloured red.
This equipment may require the use of a different line cord, attachment
plug, or both, depending on the available power source at installation.
If the attachment plug needs to be changed, refer servicing to qualified
service personnel who should refer to the table below. The green/yel-
low wire shall be connected directly to the units chassis.
CONDUCTOR WIRE COLOR
Normal Alt
LLIVE BROWN BLACK
NNEUTRAL BLUE WHITE
EEARTH GND GREEN/YEL GREEN
WARNING: If the ground is defeated, certain fault conditions in the unit
or in the system to which it is connected can result in full line voltage
between chassis and earth ground. Severe injury or death can then
result if the chassis and earth ground are touched simultaneously.
The symbols shown above are internationally accepted symbols
that warn of potential hazards with electrical products. The
lightning flash with arrowpoint in an equilateral triangle means
that there are dangerous voltages present within the unit. The
exclamation point in an equilateral triangle indicates that it is
necessary for the user to refer to the owner’s manual.
These symbols warn that there are no user serviceable parts inside
the unit. Do not open the unit. Do not attempt to service the
unit yourself. Refer all servicing to qualified personnel. Opening
the chassis for any reason will void the manufacturer’s warranty.
Do not get the unit wet. If liquid is spilled on the unit, shut it off
immediately and take it to a dealer for service. Disconnect the
unit during storms to prevent damage.
IMPORTANT SAFETY INSTRUCTIONS

3
IMPORTANT SAFETY INSTRUCTIONS
ELECTROMAGNETIC
COMPATIBILITY
This device complies with part 15 of the FCC Rules
and the Product Specifications noted on the
Declaration of Conformity. Operation is subject
to the following two conditions:
•
this device may not cause harmful interference,
and
•
this device must accept any interference received,
including interference that may cause undesired
operation.
Operation of this unit within significant
electromagnetic fields should be avoided.
•
use only shielded interconnecting cables.
U.K. MAINS PLUG WARNING
A molded mains plug that has been cut off from the cord is unsafe. Discard
the mains plug at a suitable disposal facility. NEVER UNDER ANY
CIRCUMSTANCES SHOULD YOU INSERT A DAMAGED OR CUT
MAINS PLUG INTO A 13 AMP POWER SOCKET. Do not use the
mains plug without the fuse cover in place. Replacement fuse covers can be
obtained from your local retailer. Replacement fuses are 13 amps and MUST
be ASTA approved to BS1362.
DECLARATION OF CONFORMITY
Manufacturer’s Name: BSS Audio
Manufacturer’s Address: 8760 S. Sandy Parkway
Sandy, Utah 84070, USA
declares that the product:
Product name(s): BLU 102
 Note:ProductnamemaybesufxedbytheEU.
Product option: None
conformstothefollowingProductSpecications:
 Safety:  IEC60065-01+Amd1
 EMC:  EN55022:2006
   EN55024:1998
   FCCPart15
Supplementary Information:
The product herewith complies with the requirements of the:
 LowVoltageDirective2006/95/EC
 EMCDirective2004/108/EC.
 RoHSDirective2002/95/EC
 WEEEDirective2002/96/EC
 WithregardtoDirective2005/32/ECandECRegulation1275/2008of
 17December2008,thisproductisdesigned,produced,andclassiedas
 ProfessionalAudioEquipmentandthusisexemptfromthisDirective.
 Vice-PresidentofEngineering
8760 S. Sandy Parkway
Sandy, Utah 84070, USA
 Date:August23,2010
EuropeanContact: YourlocalBSSAudioSalesandServiceOfceor
Harman Music Group
8760 South Sandy Parkway
Sandy, Utah 84070, USA
 Ph:(801)566-8800
 Fax:(801)568-7583
If you want to dispose this product, do not mix it with general household waste. There is a
separate collection system for used electronic products in accordance with legislation that
requires proper treatment, recovery and recycling.
Private household in the 25 member states of the EU, in Switzerland and Norway may return their used
electronic products free of charge to designated collection facilities or to a retailer (if you purchase a similar
new one).
For Countries not mentioned above, please contact your local authorities for a correct method of disposal.
By doing so you will ensure that your disposed product undergoes the necessary treatment, recovery and
recycling and thus prevent potential negative effects on the environment and human health.
Finland, Norway and Sweden
Apparatet skal tilkoples jordet stikkontakt.
Caution
Certified 26 AWG telephone wires to be used for
connection to telecommunication network.

4
Regulatory information
An example of this equipment has been tested and found to comply with the following European
and international Standards for Electromagnetic Compatibility and Electrical Safety:
Radiated Emissions (EU): EN55022:2006
Immunity (EU): EN55024:1998
Electrical Safety (EU): IEC60065-01 + AMD1
Electrical safety (USA): UL60065-06
Telecom:
AS/ACIF: S002:2005
Industry Canada: CS-03
U.S. FCC Part 68 TIA-968-B
TIA-1096-A
Mechanical installation
Important user information
Do not remove covers. No user serviceable parts inside, refer servicing to qualied service
personnel. For continued compliance with international EMC regulations, it is important that all
cables be screened, and connected as follows: Audio cable screens to their BLU-Device connector
ground. Control cable screens to the ground screws adjacent to the connector. Network cables
should be of type Cat 5, tted with a clip-on ferrite sleeve (STEWART TYPE 28A2029-0A0) near
the network socket end. This equipment must be earthed. It should not be necessary to remove
any protective earth or signal cable shield connections to prevent ground loops. Any such
disconnections are outside the recommended practice of BSS Audio, and will render the EMC or
safety certicate void.
If the unit is likely to undergo extreme vibration through extensive road trucking and touring, the
unit must be supported at the rear and/or sides to lessen the stress on the front mounting ange.
Rear rack supports are provided to reduce stress on front mounting ange. Damage caused by
insufcient support is not covered by the warranty. To prevent cosmetic damage to the front panel
nish, use protective plastic cups under the rack mounting bolts.
124 312 214 3124 32 14 3
CONTROL
ETHERNET
LOCATE
OUTPUTS INPUTS
S + S + S + S + S + S + S + S + S + S +S + S + S + S + S + S + S + S +
ABCDE
RS232
IN
OUT
BLU link
THIS EQUIPMENT MUST BE EARTHED
100-240V ~ 50/60Hz, 50W
MANUFACTURED IN THE USA BY BSS AUDIO
TEL

5
Front panel
Input/Output channel monitoring
Each channel has the following LED indicators:
Clip
Indicates clipping in the analogue domain for each input or output channel. The LED will
illuminate at +18.5dB.
Signal
The Signal LED will illuminate for each input or output channel when the signal reaches
or exceeds the signal threshold of -20dB.
Input channels have a third indicator:
48V
(Input channels only) Illuminates to indicate +48V phantom power has been activated
for the relevant input channel. Phantom power cannot be applied to the “In” and “Out”
telephone channels, and therefore indication of phantom power is not necessary for these
channels. Instead, they have “OH” (short for “off hook”) LEDs which illuminate when the
phone is off hook.
Other indicators
COM (Communications)
The COM LED turns green to indicate a normal linked condition. The COM LED blinks
green if data is being transferred on the Ethernet or RS232 port. The LED turns yellow if a
link is established but no IP address has been established.
STAT (Status)
The STAT LED turns green when a valid design file is loaded and running. The STAT
LED turns yellow when the design is paused. The STAT LED turns red when the design is
stopped.
ERR (Error)
The ERR LED is normally off. It turns red in the case of a critical or fatal error.
PWR (Power)
The PWR LED turns blue when the device is powered on. It blinks during locate
operations (both when pressing the locate button on the rear of the device and also when
locating the device from within the software).
