BT BT3660 Specification sheet

BT3660
with nuisance call blocking
and answer machine
Quick Set-up and User Guide
Digital Cordless Phone with Answer Machine
You’ll need a Caller Display service from your network provider to use
Call Blocking and other Caller Display enabled features, including accessing
your Calls list. Charges may apply.

2
Important – please read rst
• Only use the line cord, power
supply and rechargeable batteries
that come with your phone.
• Make sure the power supply is
connected to a socket that you
know works.
• Connect your phone to the power
supply and let the batteries charge
for 16 hours before connecting your
phone to the phone socket.
• The base should always be plugged
in to the mains power supply.

3
If you need some help, call us on 0800 145 6789 or go to bt.com/bt3660
Check the box contents
Handset
If you bought more than one
handset you’ll also get:
• Extra handset
• Charger with mains power
adaptor (item code 094096)
• Two rechargeable batteries,
AAA NiMH 300mAh
Important
Only use the mains power adaptors.
Cables and rechargeable batteries
supplied in this box or this product
might not work. Any replacement
rechargeable batteries must be of
the same type. BT accepts no
responsibility for damage caused to
your BT3660 if you use any other
type of batteries.
Base
Phone line (this comes
already installed)
Mains power adaptor
(item code 094096)
Two rechargeable
batteries, AAA NiMH
300mAh

4
Quick set-up guide
Where to put your phone
• Place the base within
2 metres of a mains power
socket and 1.8 metres of a
phone socket so the cables
will reach.
• Make sure it’s at least a
metre away from other
electrical appliances to avoid
interference.
• Don’t place the phone or
base in a bathroom or other
humid area.
• The product works by
sending radio signals between
the handset and base. The
strength of the signal depends
on where you position the
base. Putting it as high as
possible can help give you the
best signal.
1. Plug in
1. Plug the mains power adaptor
into the base, with the cable clipped
in the groove provided.
2. Plug the other end of the power
adaptor into the wall power socket
and switch on.
The phone line cord is pre-installed
but don’t plug the other end into
the wall socket yet.
Important
• Don’t connect the phone line to
a phone socket until the handset is
fully charged.
• The base station should be
plugged into the mains power socket
all the time.
1
2

Quick set-up guide
5
If you need some help, call us on 0800 145 6789 or go to bt.com/bt3660
1.Slideothebatterycoverfrom
the back of the handset and insert
the two batteries supplied. Note the
‘+’ and ‘-’ markings inside the
battery compartment. Then slide
the battery cover back into place.
2. The handset will check for a link
with the base station. Once found,
you’ll need to set the time and date,
but you can then press the [back]
button to skip any further options
until setup is complete (you can
always set these up later).
3. Place the handset on the base
and leave to charge for 16 hours.
Important
Charge the handset batteries for
16 hours or your phone might
not work.
Talk/Standby time
Under ideal conditions, the
handset batteries should give
up to 10 hours talk time or
100 hours standby on a single
charge. (This doesn’t mean you
can unplug the base or leave
the handset for this length of
time without charge).
Please note that new Ni-MH
rechargeable batteries don’t
reach full capacity until
they’ve been in normal use
for several days.
Battery low warning
Battery low warning
You will hear a warning beep
every 2 minutes during a call
and the iconwillash.
You must recharge the
handset batteries before you
can use the handset. If the
charge completely runs out
thehandsetwillswitcho.
Place the handset on the
base or charger to charge.
2. Charge

Quick set-up guide
6
4. After 16 hours, plug the phone
line cord into the phone wall socket.
Battery performance
• To keep the batteries in
the best condition, leave the
handsetothebasefora
few hours at a time.
• Running the batteries right
down at least once a week
will help them last as long
as possible.
• After charging your handset
forthersttime,subsequent
charging time for the batteries
is approximately 8 hours.
• The charge capacity of
rechargeable batteries will go
down over time, which will
reduce the talk and standby
time. Eventually they’ll need
replacing. For details on how
to get replacement batteries,
call Discom on 0800
9808 999*.

Quick set-up guide
7
If you need some help, call us on 0800 145 6789 or go to bt.com/bt3660
Set up for additional handsets
(multipacks only)
1. For additional handsets and
chargers: plug the mains power
adaptor into the mains wall socket
and switch on the power.
2. Insert the batteries as explained
on page 5. If you set the time and
dateonthersthandsetthenitwill
be shared with all other handsets
in your multi pack once you insert
the batteries.
3. Place the handset on the charger
to charge for 16 hours.
Using your BT3660 on a line
with broadband?
To avoid problems with your
broadband or noise on your
phone line, you might need to
plug your telephone line cord
into the wall socket via a
microlter(notsupplied).
If your main phone socket has
a single socket, you do need
tousemicrolters,likethis:
You’llneedamicrolterfor
every phone socket where
you’vegotequipment
plugged in – up to a
maximum of four per line –
including alarm sytems and
digital TV boxes.
You can get BT ADSL micro
ltersfrombt.com/shop
You don’t need to use
microltersifyourmain
phone socket has two
separate sockets, like these:
Tip
If you need to take the batteries out,
slide the battery cover down, then
gently take the batteries out.

Quick set-up guide
8
Your BT3660 is now ready for
you to use
• For instructions on making a call,
go to page 17.
• For help personalising your phone’s
settings, go to page 33.
• For instructions on using the
answer machine, go to page 28.
• For instructions on Call Blocking,
go to page 21.
Or,youmayndtheanswerin
the Help section on page 41 or see
ouronlinefrequentlyasked
questionsatbt.com/bt3660
If you need to call the Helpline,
please read the Help section on
pages41-43rst.Itcontains
troubleshooting tips for common
problemsandfrequentlyasked
questions.Ifyoustillneedsome
help, call the Helpline on
0800 145 6789*.
3. Go!
Tip
If you call the Helpline for advice, it’s
a good idea to call using another
phone so you can follow any
instructions using your BT3660.
* Calls made from within the UK mainland
network and mobile networks are free.
International call costs may vary.

9
If you need some help, call us on 0800 145 6789 or go to bt.com/bt3660
Contents
4 Quick set-up guide
12 Getting to know your phone
- Handset buttons
14 Handset display
15 Finding your way around
your phone
16 Base buttons
17 Using the phone
17 Switching the handset on
ando
- Making an external call
- Preparatory dialling
- Ending a call
- Call timer
- Receiving a call
18 Mute
- Incoming speech /
Handsfree volume
- Handsfree
- Answer a call using handsfree
- Switching to handsfree during
a call
- Redial
- Redialling the last number
- Viewing and dialling a number
in the redial list
19 Saving a redial number to the
phonebook
- Deleting a number from the
redial list
- Deleting the entire redial list
- Do Not Disturb
 -TurningDoNotDisturbo
20 Turning the handset ringer up,
downoro
- Finding your handset (paging)
21 Call block
- Blocking calls by type
- Blocking a number
22 Viewing the Blocked list
- Editing a number in the
blocked list
- Deleting a number from the
blocked list
- Deleting all of your blocked
numbers
23 Phonebook
-Store a phonebook entry
-Storequickdialnumbersin
buttons 1 and 2
24Dialaquickdialmemorynumber
-Viewing/dialling a phonebook
entry

10
Contents
-Searching alphabetically for
a phonebook entry
25 Editing a phonebook entry
-Adding a pause to a saved
number
-Deleting a phonebook entry
-Deleting the entire phonebook
26 Caller display and the calls list
-The calls list
-Viewing or dialling an entry in
the calls list
27 Saving a calls list entry to
your phonebook
- Deleting an entry in the calls list
- Deleting all of the calls list
- Adding a calls list number to the
blocked list
28 Answer machine
- Switch the answer machine on
oroandsettheanswermode
- Outgoing messages
- Answer & Record
- Answer only
- Recording your own outgoing
message
29 Playing the current outgoing
message
- Recording a memo
- Setting the answer mode
30 Setting the answer delay
- Playing messages using the
handset
25 Message playback
- Deleting all old played messages
- Using the answer machine
from the base
- Switching the answer machine
onoroatthebase
- Playing messages using the base
- Message playback on the base
- Deleting all played messages
32 Remote access
- Setting or changing the remote
access PIN
 -Turningremoteaccessonoro
- Operating your answering
machine remotely
