BT Studio User manual

BT Studio ~ 7th Edition ~ 14th May ’02 ~ 4408
User
Guide
BT Studio / Studio Twin
Digital Cordless Telephone
This equipment is not designed for ma ing emergency telephone calls
when the power fails. Alternative arrangements should be made for
access to emergency services.
This product is intended for connection to analogue public switched
telephone networ s and private switchboards in the United Kingdom.
This product is not DECT
GAP compatible. It cannot
be registered to any other
DECT GAP telephone and
it is not possible to register
additional handsets.

Please open this page for an ‘At a glance’
guide to your BT Studio.
BT Studio ~ 7th Edition ~ 14th May ’02 ~ 4408

BT Studio ~ 7th Edition ~ 14th May ’02 ~ 4408 BT Studio ~ 7th Edition ~ 14th May ’02 ~ 4408
1 2
Handset display
Displays the status
of your handset.
Red light
Indicates that the phone
is ringing or in use.
Talk button
Use to make, receive
and end calls.
Int button
Use to make an internal call or
to transfer a call to the BT Studio
additional handset (feature only
available if you have purchased
the BT Studio Twin).
Recall button
For use with a switchboard/PBX
and some BT Select Services.
Also use to exit the Calls list.
Quickdial button
Use to store up to 10 numbers
that can then be dialled at the
touch of two buttons.
Keypad
Delete/Secrecy button
Use to delete digits entered
incorrectly and numbers in the
Calls list. Also used to mute a call
so the caller cannot hear you talk
to someone close by.
Calls list button
Press to enter the Calls list, to
view the last 10 calls/most recent
calls. Also use to scroll up and
down through the Calls list.
Volume button
In idle mode use to adjust
the handset ringer volume.
During a call, use to adjust
the earpiece speech volume.
Redial/ ause button
Press to redial the last number
called. Also, press to dial or
store a pause in a number.
At a glance
S
e
c
r
e
c
y
Quickdial Redial Volu e
Calls
Del
䊱
䊲
123
456
789
0
RInt
P
BT Studio Handset

3
BT Studio ~ 7th Edition ~ 14th May ’02 ~ 4408
Power/
In use Charging
Charging
Additionally if you have purchased the BT Studio Twin
Charging light
Red light comes on when
the batteries are being
recharged.
Charging
light
Red light
comes on
when the
batteries
are being
recharged.
Power/In use light
Green light comes on
to indicate mains power.
Flashes when the line is
in use.
Use to page
a handset(s).
BT Studio Base
BT Studio Charger
S
e
c
r
e
c
y
Quic dial Redial Volume
Calls
Del


123
456
79
0
RInt
P

4
BT Studio ~ 7th Edition ~ 14th May ’02 ~ 4408
Quick guide to the
handset display icons
Batteries are charged
Batteries are exhausted and require charging
Batteries are being charged
Switches off when batteries are fully charged
Handset is in use
Flashes to indicate an external incoming call
Steady during an external call
Flashes to indicate an internal call
Indicates you are dialling or storing a
number in the Quickdial memory
Secrecy feature is switched on
Steady when viewing the Calls list
Flashes when a new call has been received
in the Calls list
Steady when handset is in range of the base
Flashes when the handset is out of range of
the base

5
BT Studio ~ 7th Edition ~ 14th May ’02 ~ 4408
In this guide
At a glance 1
Introduction 6
Unpacking 7
For your records 8
Safety information 9
Setting up 11
sing the telephone 18
Making and receiving calls 18
Secrecy 19
Last number redial 20
aging 20
Quickdial memory 21
Caller Display 23
Handset settings 25
sing the BT Studio additional
handset 26
Internal calls 26
Transferring calls 27
Help 28
General information 30
Guarantee 30
Technical information 31
Switchboard compatibility 31
Switchboard external line access code 32
Setting pauses 32
Recall 32
Index 33

6
BT Studio ~ 7th Edition ~ 14th May ’02 ~ 4408
Introduction
Your BT Studio is designed for ease of use and made to the
high standards set by BT.
You can expect your BT Studio to provide many years of
quality service. Please read the instructions carefully before
use and keep this user guide for future reference.
DECT
By purchasing the Studio you now own a product which
combines the advantages of cordless operation with the
performance of a high quality corded telephone. It complies
with the Digitally Enhanced Cordless Telecommunications
(DECT) standard and offers unparalleled quality and
features.
This user guide applies to both the Studio and Studio Twin
telephones. Please note the Studio range of telephones are
non GAP compatible. Please refer to page 26 for further
information.

7
BT Studio ~ 7th Edition ~ 14th May ’02 ~ 4408
Unpacking your BT Studio
or BT Studio Twin
Check that your BT Studio is complete. If anything is
missing, please contact your place of purchase immediately.
BT Studio handset
BT Studio base station
Power supply for the base station
Telephone line cord
2 x AAA rechargeable batteries
QuicdialRedialVolume
Calls
Clr


123
456
79
0
RInt
P
Studio
Digital Clarity
DECT
Page
Charging In Use
(Item code 872260)

8
BT Studio ~ 7th Edition ~ 14th May ’02 ~ 4408
Additionally if you have purchased the BT Studio Twin:
BT Studio Twin additional handset
BT Studio Twin charger
Power supply for the charger
2 x AAA rechargeable batteries
For your records
For guarantee purposes proof of purchase is required, so
please keep your receipt.
Date of purchase:
Place of purchase:
Serial number:
(on the underside of the base station)
Helpline
If you have problems with your phone, please call the BT
Studio Helpline on 0 706 05 047.
QuicdialRedialVolume
Calls
Clr


123
456
79
0
RInt
P
(Item code 003313)

9
BT Studio ~ 7th Edition ~ 14th May ’02 ~ 4408
General
Only use the power supply included with the product.
Using an unauthorised power supply will invalidate your
guarantee and may damage the telephone. The item
number for the base station is 872260. The item number
for the charger is 003313 (only applicable if you have
purchased the BT Studio Twin).
For the handset use only approved Nickel Metal
Hydride (NiMH) rechargeable batteries. Never use
other batteries or conventional alkaline batteries. They
could lead to a short circuit or destroy the battery
casing. Recommended batteries should have a power
rating of 550mAh 1.2V. Batteries are available from the
BT Studio Helpline 0 706 05 047.
Do not open the handset or base station. This could
expose you to high voltages or other risks. Contact the
helpline for all repairs.
Radio signals transmitted between the handset and base
may cause interference to hearing aids.
It is recommended that advice from a qualified expert
be sought before using this product in the vicinity of
emergency/intensive care medical equipment.
It is recommended that if you have a pacemaker fitted
you check with a medical expert before using this
product.
Never dispose of batteries in a fire. There is a serious
risk of explosion and/or the release of highly toxic
chemicals.
Safety information

10
BT Studio ~ 7th Edition ~ 14th May ’02 ~ 4408
Cleaning
Simply clean the handset and base station with a damp
(not wet) cloth, or an anti-static wipe.
Never use household polish as this will damage the
product.
Never use a dry cloth as this may cause a static shock.
Environmental
Do not expose to direct sunlight.
The product may heat up when the batteries are being
recharged. This is normal. However, we recommend
that you do not place the product on antique/veneered
wood to avoid damage.
Do not stand your product on carpets or other surfaces
which generate fibres, or place it in locations preventing
free flow of air over its surfaces.
Do not submerge any part of your product in water and
do not use it in damp or humid conditions, such as in
bathrooms.
Do not expose your product to fire, explosive or other
hazardous conditions.
There is a slight chance that your phone could be
damaged by an electrical storm. We recommend that
you unplug the power and telephone line cord for the
duration of the storm.

11
BT Studio ~ 7th Edition ~ 14th May ’02 ~ 4408
Setting up
Follow these steps to set up your BT Studio ready for use.
Plan the location
Situate your product close enough to the telephone and
mains power supply sockets so that the cables will reach.
Make sure the product is at least 1 metre away from other
electrical products to avoid interference.
Do not place your BT Studio in the bathroom or other
humid areas.
1Connect the power supply cable
Plug the power supply cable into the power socket
on your BT Studio base station (Item number
872260). The power light on the base will
come on.
Plug the power supply adaptor into
the wall socket

12
BT Studio ~ 7th Edition ~ 14th May ’02 ~ 4408
Warning
Do not connect the telephone line cord to the phone socket
until your handset is fully charged. This will prevent the
risk of the phone being answered before the batteries are
charged. Answering the phone before the batteries are fully
charged may prevent it from reaching its optimum capacity.
3Insert the batteries
Insert the two batteries supplied, as indicated on
the markings inside the battery compartment and
slide the battery compartment shut. The handset
display will show . This means one handset is
registered to the base. If you have purchased the
BT Studio Twin the handset will show -2- . See
page 15.

13
BT Studio ~ 7th Edition ~ 14th May ’02 ~ 4408
Warning
Under no circumstances should NiCad or non-rechargeable
batteries be used. Only use the approved batteries. Using
unapproved batteries will invalidate your guarantee and
may damage the telephone.
IMPORTANT
The handset must always be placed on the base
face up. The base station must be plugged into
the mains power socket at all times.
4Charge the handset batteries for at
least 16 hours
Before you use your BT Studio for the first time
it is important to have the handset batteries fully
charged. Place the handset on the base station.
You will hear a long beep. The red charging light
on the base will come on and the battery and
charging icon will be displayed. Leave the
handset to charge continuously for at least 16
hours to reach full charge.
The handset comes pre-registered but the icon
will flash to indicate that the handset is linking
up with the base. Once link up is successful the
icon will stop flashing and remain steady.
Once the handset is fully charged, the charging
icon will be switched off.

14
BT Studio ~ 7th Edition ~ 14th May ’02 ~ 4408
Battery levels
Battery low warning
If the handset battery symbol is empty, you will hear a
warning beep every 1 minute, you will need to recharge
your handset before you can use it. The handset will
only beep every minute when it is in use. In idle mode
the empty battery icon is displayed.
Out of range warning
When the handset is in use and you go out of range of
the base it will beep every 1 minute and the icon
will flash. Move closer to the base station.
Signal Strength
The BT Studio and BT Studio Twin have a range of up
to 300 metres outdoors and up to 50 metres indoors.
This is in ideal conditions.
Battery performance
Fully discharging the batteries at least once a week will
help them last as long as possible. However, the charge
capacity of rechargeable batteries will reduce with time
as they wear out, so reducing the talk/standby time of
the handset. Eventually they will need to be replaced.
New batteries can be obtained from the BT Studio
Helpline 0 706 05 047.
Note: Under ideal conditions, the handset batteries should
give about 14 hours talktime or 350 hours standby on a
single charge. Optimum times for talk and standby are
only achieved when the handset batteries are fully
charged.

15
BT Studio ~ 7th Edition ~ 14th May ’02 ~ 4408
5Insert the batteries into the
BT Studio Twin
Insert the batteries into your BT Studio Twin
handset as shown on page 12. The handset display
will show -2- as it is already pre-registered as
handset 2.
The following instructions are only applicable if you
have purchased the BT Studio Twin. If you purchased the
BT Studio please skip to instruction number 7.
6Connect and charge the BT Studio
Twin handset
Plug the power supply cable into the power socket
on your BT Studio charger (Item number 003313).
Plug the power supply adaptor into the wall socket.

16
BT Studio ~ 7th Edition ~ 14th May ’02 ~ 4408
Place the handset onto the charger. The red
charging light will come on and the charging icon
will be displayed while the batteries are charging.
Leave the handset to charge continuously for at
least 16 hours to reach full charge.
7Connect the telephone line cord to
the base station
Plug the telephone line cord into the line socket
on your base station.

17
BT Studio ~ 7th Edition ~ 14th May ’02 ~ 4408
Your BT Studio/Studio Twin is now ready for use.
Helpline
If you experience any difficulties installing or setting up
your BT Studio, please contact the BT Studio Helpline on
0 706 05 047.
8Connect the telephone line cord

18
BT Studio ~ 7th Edition ~ 14th May ’02 ~ 4408
sing the telephone
Making and receiving calls
To make an external call
Press the TALK button. You will hear the dial tone.
The icon and
EXT will be shown on the display
and the In use light on the base will flash.
Enter the telephone number you want.
Or
Preparatory dialling
Enter the telephone number first and then check
that it is correct on the display.
If you have made a mistake, press the DELETE
button to delete any incorrect digits.
When you have entered the number correctly,
press the TALK button to dial the number
automatically.
S
e
c
r
e
c
y
Del
Note
The first digit of a telephone number you enter or receive
via Caller Display will not be shown on the display. For
example the first 0 of 020 8123 4567 will not be displayed.

19
BT Studio ~ 7th Edition ~ 14th May ’02 ~ 4408
To receive a call
When the phone rings the EXT icon on the display
will flash and the LED on the handset will also
flash. If you subscribe to a Caller Display service
the caller’s telephone number will also be
displayed.
Press the TALK button to answer
the call.
To end a call
Press the TALK button.
The icon and
EXT will disappear from the
display and the In use light will stop flashing.
To switch secrecy on/off
During a call:
Press the SECRECY button. The display will show
the icon. Your caller cannot hear you.
Press the SECRECY button again to resume your
call.
Secrecy
When on a call you can talk to someone in the same room
without your caller hearing.
S
e
c
r
e
c
y
Del
S
e
c
r
e
c
y
Del
