Bticino 346812 User manual

1
1
2
3
4
1
2
3
4
1
2
3
4
MOD
346812
15/10/2013BT00653-a-
Description
4 key accessory for handsets 344032, and video handsets 344102, 344122, .
It must be installed inside the handset, in the preset location.
It can be used to perform the listed functions, based on the type of conguration set:
- Intercom call among various system devices and apartments (max. 5)
- control of actuators for additional door locks
- control of actuators for general uses and auto-switching on of the entrance panel
- mixed activations
- paging function through the 2 WIRE sound system
- enabling/disabling of home automation scenarios
- apartment intercom in two-family system Legend
1- Key 1
2- Key 2
3- Key 3
4- Key 4
PIVOT 4 key
handset accessory
Conguration
Conguration
The device must be congured sicamente per stabilirne la operating mode:
M - Operating mode
It sets the operating mode allocated to the individual keys of the accessory block.
The mode changes depending on whether the apartment interface, 346850, has been
installed or not.
MODE FUNCTION OF KEYS WITHOUT 346850 FOR MULTI-FAMILY SYSTEMSWITHINTHE APARTMENTWITH 346850
MOD= Direct switching on of the EPs
Direct switching on of the EPs congured with P+1
Direct switching on of the EPs congured with P+2
Direct switching on of the EPs congured with P+3
Direct switching on of the EPs congured with P+4
Control of the actuator for generic loads (346200)
346200 congured with MOD=9 and P=P+1
346200 congured with MOD=9 and P=P+2
346200 congured with MOD=9 and P=P+3
346200 congured with MOD=9 and P=P+4
MOD= 1Intercom among the apartment with N-1-5 Intercom among Handsets with N=1-5
MOD= 2 Intercom among apartments with interface 346850 – N=1-4 Intercom among apartments congured with N=1-4
4
3
2
1
4
3
2
1
Selection of MOD congurators
2 WIRE Video Door Entry system
EN

2
346812
15/10/2013BT00653-a-
Conguration
Selection of MOD congurators
MODE FUNCTION OF KEYS WITHOUT 346850 FOR MULTI-FAMILY SYSTEMSWITHIN THE APARTMENT WITH 346850
MOD = 31Auto-switching on of EPs congured with P+1 1Auto-switching on of local entrance panels
2Door lock control for EPs congured with P+1 2Door lock control for the local EP (direct mode)
Keys
3
and
4
for intercom among the handsets Keys 3and 4for intercom among the handsets of the
of dierent apartments cong. with N=1-3 apartment congured with N=1-3
MOD = 5Control of door lock relay with:
Actuator for generic loads (346200)
1346200 congured with MOD=5 and P=P+1
2346200 congured with MOD=5 and P=P+2
3346200 congured with MOD=5 and P=P+3
4346200 congured with MOD=5 and P=P+4
Door lock actuator (346230 - 346260)
1Actuator congured with P=1
2Actuator congured with P=2
3Actuator congured with P=3
4Actuator congured with P=4
MOD = 6Keys
1, 2and 3for intercom among handsets
congured with N=1 - 4
4Paging function
MOD = 71Intercom among apart. devices (general call)
(two-family 2Intercom with devices of other apart. (general call)
installations) 3Door lock control for EPs cong. with P+1
Door lock control for EPs cong. with P+2
MOD = 71Intercom within the same apartment
(multy-family 2NOT USED
installations 3Door lock control for EPs cong. with P+1
cong. with N = 3)
4
Door lock control for EPs cong. with P+2
MOD = 9Scenario central unit control (F420) A=0 and PL=1
1Activate scenario 1
2Activate scenario 2
3Activate scenario 3
4Activate scenario 4
PIVOT 4 key
handset accessory
EN

3
346812
15/10/2013BT00653-a-
Conguration
Example 1 - MOD = 0
Activation of general use actuators
Direct auto-switching on of the second entrance panel and activation of general use actuators
PIVOT 4 key
handset accessory
EN
PS
BUS
TK
BUS
PI
2
14
3
6
58 7
NC NO
C
2
2
2
1
2
3
4
O
1
346830
2
14
3
6
58 7
NC NO
C
2
2
14
3
6
58 7
NC NO
C
3
2
14
3
6
58 7
NC NO
C
4
BUS 2 1
230V a. c. 230V a. c. 230V a. c. 230V a. c.
BUS
MOD=0
346200 346200 346200
MOD=9 P=1 MOD=9 P=3 MOD=9 P=4
Main
PE
Power supply 346000 346200
MOD=9 P=2
230V a.c.
BUS BUS
IP30
PRI
PRI 230V~ 50 - 60 Hz 260 mA
346000
}
BUS
2 - 1 27V 1,2A
CEBEC
N
N
F
230V a.c.
PS
BUS
TK
BUS
PI
2
2
2
1
2
3
4
1346830
2
14
3
6
58 7
NC NO
C
230V a. c.
2
2
14
3
6
58 7
NC NO
C
230V a. c.
3
2
14
3
6
58 7
NC NO
C
230V a. c.
4
BUS 2 1
2
O
BUS
MOD=0
346200 346200 346200
MOD=9 P=2 MOD=9 P=3 MOD=9 P=4
BUS BUS
P=0 P=1
Main
PE
Secondary (P+1)
PE
Power supply 346000
IP30
PRI
PRI 230V~ 50 - 60 Hz 260 mA
346000
}
BUS
2 - 1 27V 1,2A
CEBEC
N
N
F

4
346812
15/10/2013BT00653-a-
N=5
N=4
N=3
N=2
N=1
N=5
N=4
N=3
N=2
N=1
PIVOT 4 key
handset accessory
EN
Conguration
Example 2 - MOD = 1
Example 3 - MOD=2
Example 4 - MOD = 5
The handset keys call in succession the handsets congured from 1 to 5 in N, excluding
themselves.
Example: If the call is made from the Handset congured with N=3
- Key 1 calls the handset congured with N=1
- Key 2 calls the handset congured with N=2
- Key 3 calls the handset congured with N=4
- Key 4 calls the handset congured with N=5
In multi-family systems, the use of the accessory 346812, appropriately congured
(MOD=1) enables intercommunication among up to 5 system users. Inside the
apartment building there may only be one group of up to 5 users that may be
able to use the intercommunicating function. For this purpose, the 5 users of the
intercommunicating function must be entered in the pushbutton panel as shown below.
In multi-family systems with apartment interface 346850, the item accessory 346812
congured with (MOD=2) allows a maximum of 4 users to intercommunicate among
themselves (intercom external to the apartment).
The handset keys call in succession the apartments congured with N=1 – N=2-
N=3-N=4.
Activation of additional door locks
Handset with N=1 Call to the
Pushbutton 1 1Handset 2
Pushbutton 2 2Handset 3
Pushbutton 3 3Handset 4
Pushbutton 4 4Handset 5
Handset with N=2 Call to the
Pushbutton 1 1Handset 1
Pushbutton 2 2Handset 3
Pushbutton 3 3Handset 4
Pushbutton 4 4Handset 5
Handset with N=3 Call to the
Pushbutton 1 1Handset 1
Pushbutton 2 2Handset 2
Pushbutton 3 3Handset 4
Pushbutton 4 4Handset 5
Handset with N=4 Call to the
Pushbutton 1 1Handset 1
Pushbutton 2 2Handset 2
Pushbutton 3 3Handset 3
Pushbutton 4 4Handset 5
Handset with N=5 Call to the
Pushbutton 1 1Handset 1
Pushbutton 2 2Handset 2
Pushbutton 3 3Handset 3
Pushbutton 4 4Handset 4
Example:
- Key 1 calls the apartment congured with N=1
- Key 2 calls the apartment congured with N=2
- Key 3 calls the apartment congured with N=3
- Key 4 calls the apartment congured with N=4
230V a.c.
PS
BUS
TK
BUS
PI
PS
BUS
TK
BUS
PI
2
14
3
6
58 7
NC NO
C
230V a. c.
2
2
2
1
2
3
4
O
1
346830
2
14
3
6
58 7
NC NO
C
2
2
14
3
6
58 7
NC NO
C
3 4
BUS 2 1
346230
BUS
MOD=5
346200 346200 346200
MOD=5 P=1 MOD=5 P=3 P=4
Main
PE
Power supply 346000
BUS BUS
MOD=5 P=2
230V a. c. 230V a. c.
IP30
PRI
PRI230 V~ 50 - 60 Hz 260 mA
346000
}
BUS
2- 1 27V 1,2A
CEBEC
N
N
F

5
F420
DE L
A
1
PL
1
2
3
4
MOD=9
Scenario 1/16
Scenario 2/16
Scenario 3/16
Scenario 4/16
346812
15/10/2013BT00653-a-
Conguration
Example 5 - MOD = 9
Control of the rst 4 scenarios (1-2-3-4) of the 16 saved in the F420 scenario module.
PIVOT 4 key
handset accessory
EN
Scenario modules
Example 6 - MOD = 3 (mixed mode)
Auto-switching on of the EP (P+1)
door lock of sec. EP (P+1)
intercom call to N=1
intercom call to N=2
Auto-switching on of the EP (P+1)
door lock of EP (P+1)
intercom call to N=1
intercom call to N=3
Auto-switching on of the EP (P+1)
door lock of EP (P+1)
intercom call to N=2
intercom call to N=3
NOTE: The operating mode of the intercom
function is the same as explained in example 2.
In this case however the intercommunication
is only established among 3 apartment, or 3
handsets for one-family installations.
- Key 1Auto-switching on of the EP (congured with P+1)
- Key 2Activation of the door lock of the EP (congured with P+1), directly, without call
- Key 3Intercom function
- Key 4Intercom function
230V a.c.
PS
BU S
TK
BU S
PI
1
2
3
4
1
2
3
4
2
2
22
2
1
2
3
4
346830
NP
3
NP
2
NP
1
2
1O
BUS 2 1
BUS
MOD=3
P=0 P=1
PE PE (P+1)
Power supply 346000
BUS
MOD=3 MOD=3
clack clack
IP30
PRI
PRI230 V~ 50 - 60 Hz 260 mA
346000
}
BUS
2- 1 27V 1,2A
CEBEC
N
N
F

6
346812
15/10/2013BT00653-a-
PIVOT 4 key
handset accessory
EN
230 Vac
PS
BU S
TK
BU S
PI
1
2
3
4
1
2
3
4
2
2
22
2
1
2
3
4
346830
NP
3
NP
2
NP
1
2
1
O
BUS 2 1
BUS
MOD=3
P=0
P=1
PE
PElocal
Power supply 346000
BUS
MOD=3 MOD=3
clack
clack
ON
346850
IN T
EXT
ON OF F
2 wire
riser
N = 8
M = 3
main
Local
door lock
IP30
PRI
PRI 230 V~ 50 - 60 Hz 260 mA
346000
}
BUS
2 - 1 27V 1,2A
CEBEC
N
N
F
Auto-switching on of the local EP
door lock of local EP
intercom call to N=1
intercom call to N=2
Auto-switching on of the local EP
door lock of local EP
intercom call to N=1
intercom call to N=3
Auto-switching on of the local EP
door lock of local EP
intercom call to N=2
intercom call to N=3
Apartment 8
Conguration
Example 7 - MOD = 3 (mixed mode) with 346850
For systems with apartment interface 346850
- Key 1Auto-switching on and cycling of local EPs
- Key 2Activation of the door lock of the local EP directly without call
- Key 3Intercom function among the apartment handsets
- Key 4Intercom function among the apartment handsets

7
346812
15/10/2013BT00653-a-
PIVOT 4 key
handset accessory
EN
Conguration
Example 8 - MOD = 7 Intercom in two-family systems
- Key 1Calls the handsets of the same apartment (the handsets congured with the same N as the one the call is made from)
- Key 2Calls the handsets of the other apartment (the handsets congured with a dierent N from the one the call is made from)
- Key 3Opens the door lock associated with the EP congured with P + 1
- Key 4Opens the door lock associated with the EP congured with P + 2
3
PS
BU S
TK
BU S
PI
230 Vac
1
2
3
4
1
2
3
4
2
2
22
346830
NP
2
NP
2
NP
1
BUS 2 1
BUS
MOD=7
P=0 P=1
PE
main
PE
main (P+1)
Power supply 346000
BUS
MOD=7
NP
1
2
NP
1
Apartment 2
NP
2
Apartment 1
2 2 2
PE
audio (P+2)
P=2
4
OOOO
P=2P=1P=0
IP30
PRI
PRI 230 V~ 50 - 60 Hz 260 mA
346000
}
BUS
2 - 1 27V 1,2A
CEBEC
N
N
F
NOTE: Maximum 3 devices per apartment.
Press repeatedly for entrance panel cycling.
It calls the handsets (general call)
congured with 2 (other devices
in apartment 2), same apartment
intercom
It calls the handsets (general
call) congured with 1 (devices in
apartment 1), intercom between
apartments
It calls the handsets (general call)
congured with 1 (other devices
in apartment 1), same apartment
intercom
It calls the handsets (general
call) congured with 2 (devices in
apartment 2), intercom between
apartments
1
2
3
4
1
2
3
4
1
2
3
4
1
2
3
4
NOTE: Maximum 3 PIVOT devices per apartment
with MASTER-SLAVE function.

8
346812
15/10/2013BT00653-a-




02'
PIVOT 4 key
handset accessory
EN
Conguration
Example 9 - MOD = 6
- Key 1Intercom
- Key 2Intercom
- Key 3Intercom
- Key 4Paging function using the loudspeakers of the 2WIRE sound system and melodic bells with M = 1
Press key 4to communicate with the outside using the loudspeakers of the 2 WIRE sound system and the Melodic bells M = 1.
The“paging”function can be used, for example, for communications inside supermarkets or oces: press key 4to switch the selected sound source o and activate the
audio on the loudspeakers. Once the handset has been replaced the sound source comes on again.
230 Vac
2
NP
3
MOD=7
P=0
PE
main
NP
2
2
BUS 2 1
F441
2
NP
1
2 2
2
SM2
1
M1
APF M1 M2 M3
103
2
2
IP30
PRI
PRI 230 V~ 50 - 60 Hz 260 mA
346000
}
BUS
2 - 1 27V 1,2A
CEBEC
N
N
F
Power supply 346000
Celing mounted loudspeakers L4566
DIN amplier
F502
Intercom call N = 2
Intercom call N = 3
Intercom call N = 4
Paging
Intercom call N = 1
Intercom call N = 3
Intercom call N = 4
Paging
Intercom call N = 1
Intercom call N = 2
Intercom call N = 4
Paging
RCA input L4560
3499
M = 1
4
3
2
1
4
3
2
1
4
3
2
1
Assembly, Installation

9




02'
346812
15/10/2013BT00653-a-
Assembly, Installation
PIVOT 4 key
handset accessory
EN
