Buffalo TeraStation Essentials User manual

Network Attached Storage
TeraStation 3010/3020, TeraStation Essentials
User Manual
TeraStation 3010 TS3210DN TS3410DN
TS3410RN
TeraStation 3020 TS3220DN TS3420DN
TS3420RN
TeraStation Essentials TS3420DS TS3420RS
Please make sure to read this manual before using and follow the procedures. If you have any inquiries about
the product, contact the number on the warranty statement or the packing box. Do not discard the included
documents, the warranty statement, or the packing box.
Americas: www.buffaloamericas.com
Europe: www.buffalo-technology.com
Asia Pacific: www.buffalo-asia.com
35021138-33
April 2023

Table of Contents
Chapter 1 Notice .......................................................... 10
Regulatory Compliance Information........................................... 10
Warning Symbols and Graphical Icons on the Product.............. 11
Safety Precautions ........................................................................ 11
Chapter 2 Getting Started .......................................... 12
Diagrams........................................................................................ 12
TS3010 Series TeraStations .....................................................................12
TS3020 Series TeraStations, TeraStation Essentials ..............................15
Turning the TeraStation On and Off............................................. 18
Creating a USB Initialization Drive .............................................. 19
Accessing Settings ........................................................................ 19
Opening Settings .....................................................................................19
Configuring Settings via Setup Wizard ..................................................22
Checking the Device Information from Dashboard ..............................23
Shutting Down or Restarting the TeraStation from Settings ...............23
Chapter 3 File Sharing................................................. 25
Configuring Shared Folders ......................................................... 25
Adding a Shared Folder...........................................................................25
Recycle Bin................................................................................................27
Read-Only Shares.....................................................................................27
Hidden Shares ..........................................................................................28
Configuring Users ......................................................................... 28
Adding a User...........................................................................................28
1

Importing User Information....................................................................31
Adding a Group ............................................................................. 31
Configuring Access Restrictions .................................................. 34
Restricting Local User Access to Shared Folders ...................................34
Restricting AD Domain User Access to Shared Folders.........................36
Restricting Access to Subfolders ............................................................39
NFS ................................................................................................. 41
Enabling NFS ............................................................................................42
NFS Mount Commands............................................................................47
Offline Files for Windows.............................................................. 47
Chapter 4 RAID Modes and Drive Management ....... 50
Available RAID Modes .................................................................. 50
Working with RAID Arrays............................................................ 51
Using JBOD...............................................................................................51
Creating a RAID Array..............................................................................52
Shutting Down the TeraStation Automatically If an Error Occurs........53
Configuring Actions for If a Drive Used for the RAID Array Has Not Been
Detected ...................................................................................................55
Configuring a Hot Spare..........................................................................57
Managing a RAID Array Without Deleting Data ....................................59
RAID Scanning..........................................................................................63
Configuring Low Drive Space Alerts............................................ 64
Adding an External Drive ............................................................. 66
Dismounting Drives ...................................................................... 67
Using the Function Button ......................................................................67
Using Settings ..........................................................................................67
Checking Drives ............................................................................ 68
2

S.M.A.R.T. ....................................................................................... 69
Displaying S.M.A.R.T. Information .........................................................70
Checking the Drive Condition.................................................................71
Formatting Drives ......................................................................... 71
Encrypting Drives.......................................................................... 72
Erasing Data on the TeraStation Completely.............................. 73
Performing a Full Format ........................................................................73
Performing the Secure Erase Command ................................................74
Quotas............................................................................................ 76
Limits for Users ........................................................................................76
Limits for Groups .....................................................................................77
Limits for LVM Volumes ...........................................................................79
Using the TeraStation as an iSCSI Device .................................... 81
Introduction .............................................................................................82
Creating an iSCSI Volume........................................................................82
Connecting Volumes................................................................................84
Formatting Volumes ................................................................................85
Disconnecting Volumes...........................................................................86
Configuring Access Restrictions .............................................................86
Connecting Access-Restricted Volumes .................................................89
Expanding Volume Capacity...................................................................90
Deleting Volumes.....................................................................................92
Enabling the iSNS Protocol .....................................................................93
Advanced iSCSI Volume Settings............................................................94
Chapter 5 Backup ........................................................ 95
Backing Up Data on the TeraStation............................................ 95
Backup Modes..........................................................................................95
3

Preparing a Backup Destination.............................................................97
Configuring a Backup Job .......................................................................99
If Backing Up from rsync-Compatible Devices to the TeraStation.....102
Restoring Backup Data..........................................................................103
Backup Logs for If Backup Fails ............................................................104
Replication................................................................................... 106
Preparing a Replication Destination ....................................................107
Configuring a Replication Job ..............................................................109
Synchronizing Between Source and Destination TeraStations
Periodically.............................................................................................112
Failover ........................................................................................ 113
Before Configuring Failover..................................................................114
Usage Restrictions .................................................................................114
Configuring Failover..............................................................................115
Changing Settings While Failover Is Configured.................................117
Maintenance Mode ................................................................................118
Synchronizing Between Main and Backup TeraStations Periodically120
Switching to the Backup TeraStation Manually...................................122
Reconfiguring After Failover Occurs ....................................................122
Stopping Failover...................................................................................124
Backing Up Your Mac with Time Machine ................................. 126
Chapter 6 Cloud Services and Remote Access......... 133
Synchronizing with Amazon S3 ................................................. 133
Creating an Amazon S3 Job ..................................................................133
Uploading Files to Amazon S3..............................................................136
Synchronizing with Dropbox ..................................................... 140
Creating a Dropbox Sync Job................................................................140
Changing Job Settings ..........................................................................143
4

Creating a Shared Link (Windows Only)...............................................146
Using Microsoft Azure for Data Preservation ........................... 146
Creating an Azure Storage Sync Backup Job.......................................146
Creating an Azure Storage Sync Restore Job.......................................154
Changing Job Settings ..........................................................................159
Synchronizing with Microsoft OneDrive................................... 162
Creating a OneDrive Sync Job...............................................................162
Changing Job Settings ..........................................................................173
Corrective Actions for in Case of Error .................................................175
WebAccess ................................................................................... 178
Configuring WebAccess.........................................................................178
Accessing via WebAccess.......................................................................181
Unable to Create a BuffaloNAS.com Name..........................................181
FTP................................................................................................ 182
Enabling FTP ..........................................................................................182
Accessing the TeraStation with an FTP Client......................................184
Chapter 7 Security Enhancement............................. 185
Two-Factor Authentication ........................................................ 185
Enabling Two-Factor Authentication ...................................................185
Restricting Logins for Non-Admin Users..............................................190
Disabling Two-Factor Authentication ..................................................192
Antivirus Software ...................................................................... 194
Activating Virus Scanning .....................................................................194
Configuring Security Settings ..............................................................196
Licenses ..................................................................................................197
Connecting Through a Proxy Server ....................................................198
Updating Antivirus Pattern Files ..........................................................199
5

Configuring Folders as Virus Scanning Targets...................................200
Configuring Virus Scanning ..................................................................201
Checking the Log ...................................................................................202
Opening the Online Help ......................................................................203
Encrypting Data Transmission ................................................... 204
Encrypting Settings Data ......................................................................204
Encrypting FTP Transfer Data ...............................................................204
SSL...........................................................................................................204
Boot Authentication ................................................................... 205
Notes Before Use....................................................................................206
Important Notice ...................................................................................206
Setting Up the Authentication Server on a Windows PC ....................206
Configuring Boot Authentication on the TeraStation.........................207
If the TeraStation Cannot Be Accessed .................................................208
Chapter 8 Settings Backup/Restoration .................. 211
Saving and Applying Settings.................................................... 211
Saving Settings ......................................................................................211
Applying Settings ..................................................................................212
Transferring Another Buffalo NAS Device’s Settings ............... 213
Creating a Config File (.nas_config)......................................................214
Transferring Settings.............................................................................214
Restoring Factory Defaults......................................................... 215
Initializing from Settings ......................................................................215
Initializing Using the USB Initialization Drive .....................................216
Resetting the Administrator Password ..................................... 217
6

Chapter 9 Network Settings ..................................... 219
Wake-on-LAN .............................................................................. 219
Port Trunking............................................................................... 219
SNMP............................................................................................ 223
Proxy Server ................................................................................ 225
Jumbo Frames ............................................................................. 225
Changing the IP Address ............................................................ 227
Mapping IP Address and Hostname .......................................... 228
Chapter 10 Advanced Features ................................ 231
Email Notification ....................................................................... 231
Enabling Email Notification ..................................................................231
Changing Events for Email Reports......................................................232
Sleep Mode .................................................................................. 233
UPS (Uninterruptible Power Supply)......................................... 235
Logs .............................................................................................. 237
Displaying TeraStation’s Logs ...............................................................237
Transferring Logs to the Syslog Server ................................................238
Creating a Shortcut to the Logs in the Shared Folder.........................238
Changing Archive Rules for File Access Logs.......................................239
Updating the Firmware............................................................... 240
Updating Manually Using Settings ......................................................240
Enabling Automatic Update..................................................................241
Configuring Update Notification..........................................................242
Name, Date, Time, and Language .............................................. 243
Beep Alerts .................................................................................. 245
7

LEDs.............................................................................................. 246
Chapter 11 Drive Replacement and Troubleshooting ...
..................................................................................... 248
Replacing a Defective Drive ....................................................... 248
Drive Replacement for a Redundant RAID Array (TeraStation Is On) 249
Drive Replacement for a Redundant RAID Array (TeraStation Is Off)251
Drive Replacement for a RAID 0 Array .................................................252
Drive Replacement for a JBOD..............................................................253
Drive Replacement for a Hot Spare ......................................................253
Replacing a Non-Malfunctioning Drive..................................... 254
Re-Inserting Drives ..................................................................... 254
“Recovery needed” Appears under the “Status” Field on the RAID
Array List...................................................................................... 256
TeraStation Does Not Work Properly......................................... 257
Power LED Keeps Blinking ....................................................................257
Booting the TeraStation in Emergency Mode......................................259
Unable to Access Shared Folders ............................................... 259
Opening the Network Credentials Window .........................................259
Restoring Owner and Permission Settings ..........................................260
Cleaning the Dustproof Filter .................................................... 262
Chapter 12 Utilities.................................................... 264
NAS Navigator2........................................................................... 264
Windows .................................................................................................264
macOS.....................................................................................................264
NovaBACKUP ............................................................................... 264
8

Chapter 13 Appendix ................................................ 265
Info and Error LEDs ..................................................................... 265
Errors.......................................................................................................265
Notices ....................................................................................................266
Information Events ................................................................................267
Default Settings .......................................................................... 269
Specifications .............................................................................. 270
9

Chapter 1 Notice
Regulatory Compliance Information
For Customers in the United States
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his own expense.
For Customers in Europe
Warning: This is a class A product. In a domestic environment this product may be cause radio interference in which
case the user may be required to take adequate measures.
This product may cause interference if used in residential areas. Such use must be avoided unless the user takes
special measures to reduce electromagnetic emissions to prevent interference to the reception of radio and
television broadcasts.
Environmental Information
• The equipment that you have purchased has required the extraction and use of natural resources for its
production.
• The equipment may contain hazardous substances that could impact health and the environment.
• In order to prevent the dissemination of those substances into the environment, and to relieve pressure on
natural resources, we encourage you to seek out an appropriate take-back program. Take-back programs will
reuse or recycle materials of any end-of-life equipment in a responsible way.
• Products with the crossed-out wheeled-bin symbol above should not be recycled. Instead, seek out a take-back
program as mentioned.
• If you need more information on the collection, reuse, and recycling of our end-of-life products, please contact
your local or regional waste administration.
For Customers in Taiwan
BSMI
警告使用者 :
此為甲類資訊技術設備，於居住環境中使用時，可能會造成射頻擾動，在此種情況下，使用者會被要求採取某
些適當的對策。
10
Chapter 1 Notice

Warning Symbols and Graphical Icons on the Product
Warning symbols are used on the product for safety operation and prevention of injury to you and damage to the
unit. The following explains the meanings of symbols used on the product.
This symbol indicates important warnings or cautions for operation and maintenance.
Additional information will follow this symbol.
This symbol indicates the presence of an alternating current.
This symbol indicates that the rack-mounted equipment should not be used for a shelf or a work
space.
This symbol indicates danger of hazardous high voltage.
Safety Precautions
Before using your device, basic safety instructions should always be followed.
(1) Read these instructions.
(2) Keep these instructions.
(3) Heed all warnings and follow all instructions.
(4) The socket-outlet shall be installed near the equipment and shall be easily accessible.
(5) Only use the cables and accessories that are included in the package. Don’t use other accessories or cables
unless specifically instructed to in the documentation. Also, do not use USB cables that are 3 meters or longer to
connect USB devices.
(6) The device can only be used in a fixed location, such as a telecommunication center or a dedicated computer
room. When you install the device, ensure that the protective earthing connection of the socket-outlet is verified
by a technician.
Translation to Norwegian:
Utstyr som er koplet til beskyttelsesjord via nettplugg og/eller via annet jordtilkoplet utstyr – og er tilkoplet et
kabel-TV nett, kan forårsake brannfare. For å unngå dette skal det ved tilkopling av utstyret til kabel-TV nettet
installeres en galvanisk isolator mellom utstyret og kabel- TV nettet.
Translation to Swedish:
Utrustning som är kopplad till skyddsjord via jordat vägguttag och/eller via annan utrustning och samtidigt
är kopplad till kabel-TV nät kan i vissa fall medföra risk för brand. För att undvika detta skall vid anslutning av
utrustningen till kabel-TV nät galvanisk isolator finnas mellan utrusningen och kabel-TV nätet.
11
Chapter 1 Notice

Chapter 2 Getting Started
The procedures in this manual correspond to firmware version 5.64 and later. To read the manual for older firmware
versions installed on your TeraStation, click View Manual from Settings.
Diagrams
Depending on the number or type of drives in the unit, the model name will be different. Check the sticker on the
packing box for your unit’s model name.
TS3010 Series TeraStations
TS3210DN
8
19
9
12 13 14
15
16
11
10
7
23 4 5 61
12
Chapter 2 Getting Started

TS3410DN
8
12
13
14
15
16
11
10
9
19
7
23 4 5 61
TS3410RN
10 17 10 18 3456 10 1710 9122
1611 18 12 13 14 15 11
19
1 Power Button ( )
To power on the TeraStation, connect the power cable and wait for 10 seconds, then press the power button.
To power off the TeraStation, press and hold down the power button for three seconds.
If the TeraStation beeps, pressing and holding this button for a short period will stop the beeping.
2 Power LED
For the TS3210DN and TS3410DN TeraStation models, the LED glows green when the TeraStation is on. For the
TS3410RN TeraStation model, the LED glows white when the TeraStation is on.
Note: If the LED continues to blink for longer than 15 minutes instead of turning into a solid glow, refer to the
“Power LED Keeps Blinking” section in chapter 11 for more details.
3 Info LED
If there is a status message, the info LED will light up amber. Check the Settings interface or NAS Navigator2 to
see the status message.
13
Chapter 2 Getting Started

4 Error LED
If there is an error, the error LED will light up red. Check the Settings interface or NAS Navigator2 to see the
error message.
5 LAN1 LED
When LAN port 1 is connected, this LED glows green and blinks when the connection is experiencing activity.
6 LAN2 LED
When LAN port 2 is connected, this LED glows green and blinks when the connection is experiencing activity.
7 Function Button
Use this button for dismounting USB devices, rebuilding RAID arrays, configuring failover, stopping the
TeraStation’s beeping, and initializing settings using a USB drive.
8 Drive Lock ( )
Open the front panel with the key to replace drives or access the init button.
9 Init Button
Press and hold down this button to initialize the TeraStation’s admin username and password, two-factor
authentication settings, IP settings, SSL, and service port restriction settings to their factory default values. The
effects of this button can be changed in Settings.
During initialization, the TeraStation will beep and the I23 message will appear as a notification. When
initialization finishes, the I23 message will disappear.
10 Status LEDs
Normally, these LEDs blink green when drives are accessed. If a drive fails, its LED will turn red.
11 Fan
Spins to prevent overheating inside. Do not block the fan.
12 USB Port ( )
Compatible USB drives, USB memory devices, and USB UPS devices can be connected. USB hubs are not
supported.
13 LAN Port 1 (1GbE, )
Connect an Ethernet cable to use this port for your network. It is available for communicating at max. 1000
Mbps.
14 LAN Port 2 (1GbE, )
Connect an Ethernet cable to use this port for your network. It is available for communicating at max. 1000
Mbps.
15 Power Connector
Use the included power cable to connect to a UPS, surge protector, or outlet.
16 Anti-Theft Security Slot ( )
Use this slot to secure your TeraStation with a cable lock (not included).
17 Serial Number
This sticker shows the TeraStation’s serial number.
18 UID Button
Press this button to cycle the blue LED on and off.
14
Chapter 2 Getting Started

19 Link LED
Glows green when the TeraStation is connected to a network.
TS3020 Series TeraStations, TeraStation Essentials
TS3220DN
8
9
12 13 14
15
16
11
10
19
20 21
7
23 4 5 61
TS3420DN
8
12
13
20
21
19
14
15
16
11
10
9
7
23 4 5 61
15
Chapter 2 Getting Started

TS3420DS
12
13
20
21
19
14
15
16
11
8
10
9
7
23 4 5 61
TS3420RN
10 17 10 18 3456 10 1710 9122
1611 18 12 13 14 15 11
19
20 21
16
Chapter 2 Getting Started

TS3420RS
10 17 10 18 3456 10 1710 9122
1611 18 12 13 14 15 11
19
20 21
1 Power Button
To power on the TeraStation, connect the power cable and wait for 10 seconds, then press the power button.
To power off the TeraStation, press and hold down the power button for three seconds.
If the TeraStation beeps, pressing and holding this button for a short period will stop the beeping.
2 Power LED
For the TS3220DN, TS3420DN, and TS3420DS TeraStation models, the LED glows green when the TeraStation is
on. For the TS3420RN and TS3420RS TeraStation models, the LED glows white when the TeraStation is on.
Note: If the LED continues to blink for longer than 15 minutes instead of turning into a solid glow, refer to the
“Power LED Keeps Blinking” section in chapter 11 for more details.
3 Info LED
If there is a status message, the info LED will light up amber. Check the Settings interface or NAS Navigator2 to
see the status message.
4 Error LED
If there is an error, the error LED will light up red. Check the Settings interface or NAS Navigator2 to see the
error message.
5 LAN1 LED
When LAN port 1 is connected, this LED glows green and blinks when the connection is experiencing activity.
6 LAN2 LED
When LAN port 2 is connected, this LED glows green and blinks when the connection is experiencing activity.
7 Function Button
Use this button for dismounting USB devices, rebuilding RAID arrays, configuring failover, stopping the
TeraStation’s beeping, and initializing settings using a USB drive.
8 Drive Lock
Open the front panel with the key to replace drives or access the init button.
17
Chapter 2 Getting Started

9 Init Button
Press and hold down this button with something pointed to initialize the TeraStation’s admin username and
password, two-factor authentication settings, IP settings, SSL, and service port restriction settings to their
factory default values. The effects of this button can be changed in Settings.
During initialization, the TeraStation will beep and the I23 message will appear as a notification. When
initialization finishes, the I23 message will disappear.
10 Status LEDs
Normally, these LEDs blink green when drives are accessed. If a drive fails, its LED will turn red.
11 Fan
Spins to prevent overheating inside. Do not block the fan.
12 USB Port
Compatible USB drives, USB memory devices, and USB UPS devices can be connected. USB hubs are not
supported.
13 LAN Port 1 (1GbE)
Connect an Ethernet cable to use this port for your network. It is available for communicating at max. 1000
Mbps.
14 LAN Port 2 (2.5GbE)
Connect an Ethernet cable to use this port for your network. It is available for communicating at max. 2.5 Gbps
if using the included Ethernet or category 6A cable.
Note: To communicate at up to 2.5 Gbps, all network devices must be compatible with 2.5GbE.
15 Power Connector
Use the included power cable to connect to a UPS, surge protector, or outlet.
16 Anti-Theft Security Slot
Use this slot to secure your TeraStation with a cable lock (not included).
17 Serial Number
This sticker shows the TeraStation’s serial number.
18 UID Button
Press this button to cycle the blue LED on and off.
19 Link/Act LED
Glows green when the TeraStation is connected to a network. It blinks when the connection is experiencing
activity.
20 Link/Act LED
Glows amber when the TeraStation is connected to a network at 100 Mbps or 2.5 Gbps. It blinks when the
connection is experiencing activity.
21 Link/Act LED
Glows green when the TeraStation is connected to a network at 1000 Mbps. It blinks when the connection is
experiencing activity.
Turning the TeraStation On and Off
Press the power button on the TeraStation to turn it on.
18
Chapter 2 Getting Started

To turn off the TeraStation, press and hold down the power button for three seconds. When the power LED turns off,
the shutdown process is finished.
Don’t unplug the power cable without powering the TeraStation off first.
Note: Do not disconnect or reconnect the internal drives while turning the TeraStation on or off.
You can also shut down or restart the TeraStation remotely from Settings. For the detailed procedure, refer to the
“Shutting Down or Restarting the TeraStation from Settings”section below.
Creating a USB Initialization Drive
We recommend creating a USB initialization drive as soon as possible. This USB drive can be used to initialize the
TeraStation’s settings to its factory default values or recover the system if your TeraStation encounters an error
that prevents the unit from booting. For the detailed procedure, refer to the“Creating a USB Initialization Drive”
subsection in chapter 8.
Accessing Settings
Configure and manage your TeraStation using the Settings interface, accessible from a browser window. Open
the interface using the appropriate procedure below or type the TeraStation’s IP address into the URL field of your
browser.
Note: Microsoft Edge, Firefox, Google Chrome, Internet Explorer 9 or later, and Safari 9 or later are supported. If you
have difficulty viewing Settings, check the following:
• If there are a large number of registered users, groups, or shared folders, use another browser instead of Internet
Explorer.
• If you have a proxy server enabled in the browser settings, configure the exception settings for Settings or disable
the proxy server.
• With Internet Explorer, set security to Local intranet. On Windows Server operating systems, higher-level security
is configured by default. Set the security to a lower level temporarily.
Opening Settings
1 Double-click the NAS Navigator2 icon ( ) to start NAS Navigator2.
19
Chapter 2 Getting Started
