Bunkers SIDE LADDER BUNK Series User manual

SIDE LADDER BUNK ASSEMBLY
Single, King Single, Double & Queen
www.bunkers.com.au | 1300 66 17 64 1
COMPONENTS
Parts List
1 + 1
SAFETY RAIL
Single or Double
1920mm + 1495mm
King Single or Queen
1630mm + 2060mm
x1
HEAD FRAME
x1
FOOT FRAME
*foot frame features
dowel holes on
uprights
x2
SLATS
Single or King Single
x4
SLATS
Double or Queen
1 + 1
SAFETY SPACER
Single or Double
1920mm + 1495mm
King Single or Queen
1630mm + 2060mm
x4
SIDE RAIL
Single or Double
1920mm
King Single or Queen
2060mm
x2
LADDER RUNG
x1
LADDER
UPRIGHT
A B C D
x2
90mm
BOLT
x16
64mm
BOLT
x18
WASHER
x4
DOWEL
x1
ALLEN KEY
x32
Single & King Single
x20
Double & Queen
SCREW
x4
SCREW
x2
BRACKET
x16
Double & Queen
SCREW
E
*Not Included: 1 friend.
Like most things in life, assembling your bunk will be better with a friend!
Fixings

SIDE LADDER BUNK ASSEMBLY
Single, King Single, Double & Queen
www.bunkers.com.au | 1300 66 17 64 2
Position Side Rails inside Head Frame posts. Attach by placing bolt E through post
hole & aligning with t-nut thread inside Side Rail. Finger tighten bolts.
Attach the bottom Side Rails. Attach all
remaining fasteners.
Attach Side Rails to Foot Frame.
x2 Bolt
+ Washer
*Finger-tighten only
E
E
Then tighten all bolts with allen key.
1
2
3
x12 Bolt
+ Washer
E
x2 Bolt
+ Washer
E
*Finger-tighten only

SIDE LADDER BUNK ASSEMBLY
Single, King Single, Double & Queen
www.bunkers.com.au | 1300 66 17 64 3
Place Long Safety Rail inside Frame Post, align with top of post & fasten.
Centre Long Safety Spacer rail between Safety Rail & Side Rail then fasten
Insert dowels into frame. Tap in until fully inserted.
Position Ladder Rungs onto dowels.
x4 Dowel
Place Slats onto Side Rails. Align with one end of side cleat
& fasten through hole provided. Stretch to align other end
of side cleat & secure remaining screws.
x12 Screw
Align
SINGLE & KING SINGLE
DOUBLE & QUEEN
Align
x6 Screw A
Single or King Single
A
x16 Screw
Double or Queen
C
Place Slats onto Side Rails.
Align with one end of side cleat & fasten through hole provided.
Repeat opposite end with second slat.
Stretch both to create middle gap between 50-95mm & secure.
4
5
6

SIDE LADDER BUNK ASSEMBLY
Single, King Single, Double & Queen
www.bunkers.com.au | 1300 66 17 64 4
Attach the Brackets to
Ladder Upright using
guide holes.
Hook S-Bracket on Side Rails.
Fasten Bolts through Upright Post to
secure Ladder Rungs.
Secure Bracket to the side rails
x8 Screw A
x2 Bolt
+ Washer
D
x4 Screw B
7
8
9

SIDE LADDER BUNK ASSEMBLY
Single, King Single, Double & Queen
www.bunkers.com.au | 1300 66 17 64 5
Place Short Safety Rail inside Ladder Upright & Head Frame. Align with
top of posts & fasten. Centre Short Safety Spacer Rail between Safety
Rail & Side Rail then fasten.
The Important Stuff.
Tighten all bolts after one month of use.
All beds should be checked periodically to ensure fasteners are tight.
In rooms with ceiling fans care must be taken to ensure distance between
closest point is at least 2m.
Children should be discouraged from playing on bunks.
Upper bunk not suitable for children under the age of six.
ENJOY!
x6 Screw A
