Bunn A10 Automatic Installation instructions

USE AND CARE OF YOUR
BUNN®POUR-OMATIC®
Model A-10 Coffee Brewer
Welcome to the world of fine coffee.
The Bunn®Pour-Omatic®Coffee Brewer will enhance
your enjoyment of each cup of coffee. Bunn®coffee
brewers are recognized in homes and restaurants
throughout the world as the very finest. Read this
booklet, and in no time you will know how to make
a great cup of coffee.
10070.0000F 11/07 ©1989 BUNN-O-MATIC CORPORATION
Keep this booklet for future reference.
The Bunn logo is a trademark of Bunn-O-Matic
Corporation.

2
Our
best
wishes
for
your
coffee
enjoyment.
Table of Contents
IMPORTANT SAFEGUARDS ............................................4
GENERAL INFORMATION................................................5
PREPARING THE BREWER FOR USE..............................6
BREWING DELICIOUS COFFEE .......................................7
HOT WATER....................................................................7
COFFEE FUNDAMENTALS ...............................................8
BREWING TIPS...............................................................8
ROUTINE CLEANING.......................................................9
HANDLE MAINTENANCE.................................................9
DELIMING.......................................................................9
SOFTENED WATER AND/OR
DECAFFEINATED COFFEE................................................9
WATER QUALITY ............................................................9
DRAINING THE BREWER..............................................10
HIGH ALTITUDE USE.....................................................10
AUTHORIZED SERVICE.................................................10
BUNN COMPANION PRODUCTS ...................................11
LIMITED WARRANTY......................................Back Cover
SPECIFICATIONS
Electrical - UL Listed. This brewer has an attached, polarized cord and
requires 2-wire service with ground, rated 120 volts ac, 10 amps, single
phase, 60 Hz.
Dimensions - 14 1/4 inches high; 6 3/4 inches wide; 13 1/2 inches deep.
Capacity - Two to eight 6-ounce cups (12-48 ounces) per batch.
Tank Size - 75 ounces.
Weight - 15 pounds; Includes decanter, water pitcher, filters, coffee funnel,
water funnel and deliming spring probe.
10070 111607
BUNN-O-MATIC CORPORATION
1400 STEVENSON DRIVE
SPRINGFIELD, ILLINOIS 62703
www.bunnomatic.com
If you need any assistance, please call us at:
1–800–352–2866
In order to receive full assistance, please have your Date Code ready
when calling for service.
(Located on the back of your brewer)

3
Bunn®Pour-Omatic®
MODEL A-10 COFFEE BREWER
LID
WARMER
SWITCH
BREW
FUNNEL
DECANTER
HOT WATER
TANK
(LOCATED INSIDE)
VACATION
SWITCH
P2076
Hazardous Voltage!
Can Cause Fire Or Electrical Shock!
Do Not Disassemble The Brewer!
There Are No User Serviceable Parts Inside!
Repair Should Be Done By Authorized Service Personnel!
(Refer to Page 10)
This symbol alerts you to the risk
of fire or electrical shock in the
accompanying message.
This symbol alerts you to
important operating and
service instructions.
P-229/P-230
10070 010704
RISK OF FIRE OR ELECTRICAL SHOCK
WARNING

4
IMPORTANT SAFEGUARDS
Follow these basic safety precautions when using electrical appliances to reduce
the risk of fire, electric shock, and/or personal injury:
• Read all instructions.
• Do not touch hot surfaces. Use
handles or knobs.
• Do not place cord, plugs, or brewer
in water or liquid.
• Close supervision is necessary when
the brewer is used by or near chil-
dren.
• Unplug from outlet when not in use
and before cleaning. Allow to cool
before putting on or taking off parts,
and before cleaning.
• Do not operate the brewer with a
damaged cord or plug or after the
brewer malfunctions, or has been
damaged in any manner. Return
the brewer to an Authorized Service
Facility for examination, adjustment,
or repair. (Refer to page 10.)
• The use of an accessory not evaluated
for use with this brewer may cause
injuries.
• For household use only. Do not use
outdoors.
• Do not let cord hang over edge of
table or counter, or touch hot sur-
faces.
• Do not place the brewer on or near
a hot gas or electric burner, or in a
heated oven.
• Do not use brewer for other than its
intended use.
• Do not place or remove funnel,
decanter, or decanter lid while brew-
ing.
• The decanter is designed for use with
this brewer. It must never be used on
a range top or in a microwave.
• Do not set a hot decanter on a cold
surface.
• Do not use a cracked decanter or a
decanter having a loose or weakened
handle.
• Do not clean decanter with cleansers,
steel wool pads, or other abrasive
materials.
SAVE THESE INSTRUCTIONS
• A short power supply cord is used to reduce the risks resulting from becoming
entangled in or tripping over a longer cord.
• If an extension cord is used, the marked electrical rating of the extension cord
should be at least as great as the electrical rating of the brewer and the cord
should be arranged so that it will not drape over the counter top or table top
where it can be pulled on by children or tripped over.
10070 030100

5
GENERAL INFORMATION
NOTE - THE BREWER IS NOT READY TO PLUG IN
Improper installation will result in permanent damage and void the limited
warranty. Read & follow the instructions on the next page.
• Be certain the tank is full of water before plugging in the brewer. (Requires at
least three quarts to fill).
• This brewer is designed to remain plugged in at all times (except during initial
installation or when cleaning.)
• A power switch is provided on the lower left side to completely shut off all elec-
trical components when your plans take you away from home for several days.
Safety features, designed into the Bunn®Pour-Omatic® coffee brewer, make the
daily use of this switch unnecessary.
• Whenever the brewer has been shut off or unplugged, allow the water in the tank
to heat to the proper temperature before using (about fifteen minutes or until the
heating sound stops).
• Your Bunn®Pour-Omatic®coffee brewer has a specially designed tank to keep
the water at the proper temperature. This constant supply of hot water assures
the correct method of brewing coffee, in less than three minutes.
• The brewed coffee flows into the decanter where it is kept at serving temperature
on the porcelain decanter warmer. The warmer is controlled by the lighted on/off
switch on the front of the brewer.
NOTE - The warmer switch only controls the decanter warmer.
• While coffee is being brewed, the newest water in the tank is heated to the proper
temperature and held until needed.
• The decanter lid reduces coffee evaporation and temperature loss.
• Hot water, approximately 50˚F hotter than that available from your hot water
faucet, is always available for other uses.
• This brewer has an attached, polarized cordset and requires 2-wire grounded
service rated 120 volts ac, 120 amps, single phase, 60 Hz. Do not attempt to
bypass the safety aspect of this polarized plug.
• The sprayhead will periodically become loose. Using extreme caution not to burn
yourself, retighten the sprayhead with your finger tips.
NOTE - A severe burn may result if the sprayhead becomes
loose and falls off while brewing.
10070 030100

6
PREPARING THE BREWER FOR USE
NOTE: THE BREWER IS NOT READY TO PLUG IN
Raise the hinged flip lid.
Place the decanter on the warmer. Pour two pitchers of water
(filled to the top line) into the screened area on top of the brewer.
Wait two minutes between pitchers to allow the water to fill the
tank. When the tank is full, some water will flow through the
funnel and into the decanter.
Close the lid and plug in the brewer.
Press the bottom of the vacation switch, located on
the lower left side of the brewer, to the “ON” position.
The vacation switch controls power to the tank heater.
Initially you will have to wait approximately ten minutes
in order for water to reach brew temperature.
P2078
P2079
P-214
P2080
10070 010704

7
BREWING DELICIOUS COFFEE
HOT WATER
The same basic steps can be used to obtain hot water by omitting the filter and
coffee and using the enclosed hot water funnel. The hot water from your Bunn®
coffee brewer is approximately 200˚F. This is hotter than the hot water from your
faucet and must be handled with care.
Insert a Bunn®coffee filter into the brew funnel. (Be sure
to use Bunn®coffee filters for proper brewing. There is a
difference.)
Measure coffee into the filter and gently shake to level the
bed of grounds.
Make sure that the sprayhead is tight. Slide the brew funnel
into the brewer under the warmer switch. Snap the decanter
cover in the decanter and place the decanter on the warmer
beneath the brew funnel. Place the lighted warmer switch
in the “ON” position.
Raise the hinged flip-lid and pour water into the top of the
brewer. The water pitcher, supplied, will yield approximately
eight 6 ounce cups of brewed coffee when filled to the top
line. Your Bunn®Pour-Omatic®will begin brewing coffee
immediately.
When brewing has stopped, remove the brew funnel and
discard the filter and grounds. Do not touch hot grounds.
P2081
P-206
P-205
P2079
P-215
10070 030100

8
COFFEE FUNDAMENTALS
Brewing delicious coffee is similar to cooking any favorite food. Both require a
good recipe. Proper coffee-making needs quality equipment to precisely control water
temperature, volume, and brew time. The Bunn®coffee brewer assures consistency
in your recipe by controlling all of these elements. The only variables remaining in
the recipe are the grind and amount of coffee used.
The amount of ground coffee is generally determined by the grind. For best
results, we recommend a drip (medium) grind.
Hot water extracts many elements from the ground coffee, some desirable,
some not. The taste and aroma are referred to as strength, the acidity as bitterness.
Increasing the amount of coffee results in a stronger beverage, and decreasing it
results in a weaker beverage.
As the amount of ground coffee decreases, you’ll note an increase in the bit-
terness of the beverage. This happens because the hot water begins to remove the
undesirable elements such as acidity after all of the desirable tastes and aroma have
been removed.
Fresh ground coffee gives the best results. Always store the ground coffee in
a coo, dry area away from other food items with strong odors. When stored in a
refrigerator, keep it in an airtight container.
BREWING TIPS
When properly brewed, the difference between the best quality ground coffee
and a poor quality ground coffee becomes very dramatic. Proper brewing requires
little effort with the Bunn®Pour-Omatic®coffee brewer.
You’ll always have a great coffee experience if you follow these tips:
1) Always start with clean equipment.
2) Always use fresh cold water.
3) Always use Bunn®paper coffee filters for proper extraction.
4) Using 2 ounces of fresh drip grind coffee for each full pot (4 oz) will give you a
consistently great pot of coffee with a full-bodied flavor and aroma. However,
the real criteria is personal taste. Adjust the recipe until it suits you. If you need
to make a smaller batch, experiment with less water and ground coffee.
5) Keep the beverage at the correct serving temperature by setting the decanter on
the porcelain warmer. For the freshest flavor, don’t keep brewed coffee for longer
than an hour.
10070 010704

9
ROUTINE CLEANING
Rinsing the brew funnel and decanter after each use
is the only routine cleaning required. Occasionally, wipe
the outside of the brewer including the area above the
funnel with a damp cloth. (The brew funnel, hot water
funnel and decanter are top rack dishwasher safe.)
HANDLE MAINTENANCE
Using a phillips screw driver, periodically tighten the screw in the handle.
DELIMING
Periodically, you should delime the brewer to clear any deposits that may have
accumulated due to impurities in the water source.
P2084
P2085
1) Unscrew the sprayhead with your fingertips and set
it aside.
2) Insert all but two inches of the flexible deliming spring
probe (supplied) through the sprayhead opening.
3) Slide the tool in and out five or six times to loosen
mineral deposits collected in the sprayhead tube.
Remove it and set it aside.
4) Check the holes in the sprayhead for mineral deposits.
These may be cleared by using a toothpick. Rinse the
sprayhead with water before reinstalling.
5) Plug in the brewer and allow the water in the tank
to reheat before using the brewer. The frequency
of deliming depends on the mineral content of your
water.
SOFTENED WATER and/or DECAFFEINATED COFFEE
Bunn®coffee brewers will brew a perfect decanter of coffee when used with
unsoftened tap water and regular coffee. If there’s a noticeable difference when us-
ing softened water and/or decaffeinated coffee, telephone or write us to request a
special sprayhead and use a coarser grind of coffee.
WATER QUALITY
Install a water conditioner if your water contains excessive amounts of sediment,
taste, or odors.
10070 030100
P2083

10
DRAINING THE BREWER
The water in your Bunn®Coffee Brewer should be emptied whenever it is taken
on a trip, shipped, or stored in an unheated location with a chance of freezing.
P2084
P2082
1) Unplug the brewer and cool the hot water in the tank.
Place the empty decanter on the warmer. Simply pour a
full water pitcher of cold water into the top of the brewer,
close the lid and wait for the water to stop flowing from
the funnel. Empty the decanter, repeat. This will cool the
water in the tank.
2) Remove sprayhead by turning counterclockwise with your
fingertips and set it aside.
3) Grasp the back of the brewer and quickly turn it upside
down over a sink as shown. Most of the water in the tank
will flow from the sprayhead opening but some water may
flow from the area around the top lid. Continue tipping
the brewer until the flow of water ceases.
4) Reinstall the sprayhead when all water has drained from
the brewer. Securely tighten it by turning clockwise.
HIGH ALTITUDE USE
Your Bunn®Pour-Omatic®Coffee Brewer is designed to operate in most areas
of the country. For high altitude use, over 5000 feet, the model A10-D should be
used.
AUTHORIZED SERVICE
For service (whether or not warranty is still in effect), drain the brewer, carefully
pack it so it is fully protected against breakage and send it to one of the authorized
Bunn-O-Matic facilities listed below:
Bunn-O-Matic Corporation
Retail Products Division
1400 Stevenson Drive
Springfield, Illinois 62703
[phone]
Bunn-O-Matic Corporation
Retail Products Division
16431 Carmenita Road
Cerritos, California 90701
[phone]
10070 010704
NOTE: Refer to “PREPARING THE BREWER FOR USE” before us-
ing the brewer.
