Bunn BCM2 User manual

Features ITEM#
PROJECT
DATE
For available variations to some BUNN products,
please contact your BUNN sales representative.
Corporate Offices
1400 Stevenson Drive
Springfield, Illinois 62703
Phone
800-637-8606
217-529-6601
Fax
217-529-6644
Technical Services
800-286-6070
Internet
http://www.bunnomatic.com
Western Regional Office
16431 Carmenita Road,
Cerritos, California 90701
Phone
562-926-0764
Fax
562-926-0858
Canadian Office
280 Industrial Parkway South
Aurora, Ontario, L4G 3T9
Phone
905-841-2866
Fax
905-841-2775
Patents
Apply
1/2000
BUNN recommends the use of our EasyClear®water
filters to assure perfect taste.They remove sediment,bad
taste and odor, while reducing lime.
EasyClear®CP-120 Water Filter
with Bracket & Shutoff valves
Product No. : 30045.1000
Dimensions: 24
3
⁄
4
H" x 8 " W x 5
1
⁄
4
D
EasyPour®black decanter
Product No. : 06100.0101
Quantity: 1 (also packaged in quantities of 2, 3, 6, 12, & 24)
A5.1
Coffee Brewers/Coffee Management System/BCM 9/98
Coffee Management System
Model
BCM2
Coffee Management System
• Computer controlled automatic
coffee management system
records all brewing activity
• Consistently brews perfect
coffee; adjusts to individual
taste profile.
• Auto refill connects to 2GPR
Safety-Fresh®portable server
keeping server full of fresh
coffee all day.
• Self cleaning for easy disposal
of grounds. Remote grounds
separator makes removal efficent.
• Push-button operation makes it
fast and easy to use.
• Batch sizes from 1⁄4 decanter up
to 2 gallons.
• International electrical
configurations available.
BCM2 with Auto Refill Conversion
BCM2 connecting to a 2GPR Safety-Fresh®
portable server & RWS2 warming stand for fresh
coffee all day.
Auto Refill Conversion
Product No. : 26192.0000
2GPR
Product No. : 12830.0001
Dimensions:
10
5
⁄
8
" H x 9
5
⁄
8
" W x 13
3
⁄
4
" D
RWS2 Product No.:
12202.0001
Dimensions:
8
3
⁄
4
" H x 10" W x 10" D
Remote Grounds Separator
Product No. : 26099.0000
Related Products
BUNN®practicescontinuousproductresearchandimprovement.Wereservetherighttochangespecificationsandproductdesignwithoutnotice.Suchrevisions
do not entitle the buyer to corresponding changes, improvements, additions or replacements for previously purchased equipment.
Model BCM2
(decanters not included)

Dimensions & Specifications
The Mark of Quality in Beverage Equipment Worldwide
All dimensions shown in inches.
Model Product # Volts Amps Tank Heater Total Brewing Cu. Ft. Shipping
Watts Watts Capacity Weight
BCM2 23350.0000 120/240V 30 6700 7200 8.0 gal./hr. 42.6 257 lbs. (116.6 kg)
BCM2 23350.0001 120/208V 30 5700 7200 8.0 gal./hr. 42.6 257 lbs. (116.6 kg)
BCM2* 23350.0002 120/240V 30 6700 7200 8.0 gal./hr. 42.6 257 lbs. (116.6 kg)
BCM2* 23350.0003 120/208V 30 5700 6240 8.0 gal./hr. 42.6 257 lbs. (116.6 kg)
*Auto refill on both sides
Electrical: All are 3-wire, single phase, 60Hz.
Plumbing:
Brewers are supplied with a BUNN EasyClear
®
water filter model 120-CP (product no. 30045.0000).The filter and brewer must be
connected to a cold water system with operating pressure between 20 and 90 psi (138-621 kPa) from a
1
⁄
2
" (13 mm) or larger water supply line.
Install a regulator in the line when pressure is greater than 90 psi (621 kPa) to reduce it to 50 psi (345 kPa).The water inlet fitting is
3
⁄
8
" (10
mm) OD male flare.
Drain: The brewer has a
1
⁄
2
" (13 mm) hose barb fitting
which must be connected to an unrestricted drain.
Physical: This brewer is for use on a sturdy counter at
least 26" (66 cm) deep, 23" (58 cm) wide, with at
least 50" (127 cm) above the counter to allow
adequate space for filling the hoppers.The brewer
weighs approximately 220 lbs (99 kg) with both
ground coffee hoppers,water tank, and waste
bin full.
