Easy Clear High Performance
10,000 Gallon Water Quality Systems
• Consistent great-tasting brewed coffee and tea from water with reduced
sediment and chlorine taste and odor.
• Equipment protection from reduced sediment particles that can clog the
sprayhead.
• Reduced scale formation by the controlled release of proprietary scale
inhibitors with “L” model.
• System includes a head assembly, integral mounting bracket, and single
cartridge filter.
• Patented Quick Connect valve-in-head design simultaneously shuts off
and vents water with 1/4 turn, allowing for simple and trouble-free cartridge
change-outs.
• Filter cartridges incorporate carbon block media and require no pre-activation.
• Optional pressure gauge allows monitoring of downstream water pressure.
• NSF Standard 42 and/or FDA CFR-21 compliance provides assurance of
safety.
• 3/8”FNPT horizontal inlet and outlet ports allow direct or easily adaptable
connections to existing plumbing lines.
• System maximum operating pressure is 125 psi (862 kPa) and operating
temperature 100˚F (38˚C).
Model EQHP-10L or EQHP-10
Water Quality System
Medium/High Volume
Water Quality Systems
E9007.0006A
Replacement Cartridge
EQHP-10LCRTG
Product No.: 39000.1001
Replacement Cartridge
EQHP-10CRTG
Product No.: 39000.1004
Valve In-Head Assembly
EQHP-VHD
Product No.: 39000.1000
Gauge
Product No.: 39000.0100
Model Agency Listing
EQHP-10L
EQHP-10

   

BUNN® practices continuous product research and improvement. We reserve the right to change specifications and product design without notice. Such
revisions do not entitle the buyer to corresponding changes, improvements, additions or replacements for previously purchased equipment.
All dimensions shown in inches. Bunn Corporation owns all copyrights relating to materials in this publication. Please contact Bunn Corporation to request permission to reproduce any portion of this publication.
Dimensions & Specifications
BUNN Corporation - 1400 Stevenson Drive Springfield, Illinois 62703 • 800-637-8606 • 217-529-6601 • Fax [phone] • www.bunn.com
Note: Inlet and outlet plumbing connections are 3/8” FNPT.
Do not use with water that is microbiologically unsafe or of unknown quality
without adequate disinfection before or after the system. Systems certified for
cyst reduction may be used on disinfected water that may contain filterable
cysts. EPA Establishment Number 070595-CT-001.
BUNN recommends regularly scheduled maintenance and replacement of
the filter cartridge(s) in order for the product to perform as advertised/sold.
Change the filter cartridge at least every 6 months. BUNN shall not be liable
for system failures due to improper maintenance.
*16oz. drinks with location operating 365 days/year.
Assumption includes no ice in beverage.
EQHP-10L or EQHP-10
Model Product #
Service Flow
Rate & Capacity
Micron
Rating Bunn Applications Other Applications
Medium to High Volume
39000.0001 EQHP-10L 1.5 gpm/10,000
Gallons
1.0 CWT(F), CDBC(F), AXIOM Series, Infusion
Series, Liquid Coffee, TB3(Q), TU5Q, iMIX,
Dual, Dual TF, Dual SH, LCR-2, LCA-2, Urns,
3-Gallon Systems, HW2, H5E/X, H10X.
For Example (6 month period):
195 Cups of Coffee, 80 Glasses of
Ice Tea and 160 Cups of Cappucino per day*
Combinations totalling 10,000 gallon usage
per 6 months.
ICE MAKERS:
Cubers to 750lbs.
Flakers to 1200lbs.
Summary, for use in medium/high volume
applications where
scale inhibitor is needed.
39000.0004 EQHP-10 1.5 gpm/10,000
Gallons
1.0 TCD-1/2, LCA-2 IC, Granita Auto-Fill Systems.
In hard water situations combine with
Scale-PRO to reduce scale build up in hot
beverage and ice applications.
Single Low Flow Carbonater: 80,000 16oz
Soft Drinks before change out.
(437 Drinks per day)*.
Summary, for use in medium volume
applications where scale inhibitor is not
needed. Any beverage or application using
ambient water.
