Burley LONGITUDE User guide

LONGITUDE
G4530 – G4539 MODELS
FLUELESS GAS HEATER
INSTALLATION, SERVICING
& USER INSTRUCTIONS
FOR USE IN THE COUNTRIES STATED ON THE DATA PLATE AND CARTON
WITH NATURAL GAS G20 & LPG G31
(REFER TO RATING LABEL)
For he following coun ries: GB, IE
EVEN IF YOU HAVE FITTED THESE FIRES BEFORE,
PLEASE FOLLOW THESE INSTRUCTIONS STEP BY STEP.
Legislation and regulations do change over time!
This produc is no sui able for primary hea ing purposes.
LEAVE THESE INSTRUCTIONS WITH THE USER
Burley Appliances L d,
Lands End Way, Oakha , Rutland, LE15 6RB
Telephone: [phone] Fax: [phone]
e- ail: [email protected] web: www.burley.co.uk
G4530-39Ins User
G20 / G31
March 2019
TO OBTAIN YOUR FIRST YEAR GUARANTEE, THE INSTALLER AND CUSTOMER
MUST FILL IN THE SEPARATE GUARANTEE AND RETURN IT TO
BURLEY WITHIN 7 DAYS OF FITTING.
A FREE SECOND YEAR GUARANTEE IS ALSO OFFERED BUT THIS IS SUBJECT TO THE FIRE BEING
SERVICED BY A GAS SAFE ™ REGISTERED INSTALLER (FORMERLY CORGI) DURING THE FIRST
YEAR OF OWNERSHIP. PROOF OF SERVICING MUST BE RETAINED
FAILURE TO HAVE THIS APPLIANCE FITTED BY GAS SAFE™ REGISTERED INSTALLER (FORMERLY
CORGI) FITTER INVALIDATES THE WARRANTY

Page 2 of 20
INTRODUCTION
Thank you for choosing this Burley product. All of our products carry a CE ark which is awarded
by an independent test house (notified body) and shows the fires have been type tested to eet
the essential require ents of the European Gas Appliance Regulations and the appropriate
British Standards.
Efficiency Declaration
This appliance has a ther al efficiency of 100% giving an Energy Efficiency Index of 91%. Which is
A rated on all variants & e its less than 130 g/kWh NOx.
Declaration of Confor ity
Burley Appliances declare that the appliance described in “Technical data” confor s to the
following standard(s) BS EN14829:2007
Please de onstrate the appliance ethod of operation to the custo er before leaving.
An oxygen depletion sensing pilot light is fitted and will sense any significant oxygen depletion in
the roo and shut the fire down safely.
1. TECHNICAL DATA
Refer to the appliance data badge affixed to the gas access cover (page 5).
ENSURE THAT THE LOCAL CONDITIONS OF USE CORRESPOND TO THE DATA ON THE BADGE
Na ural Gas G20 Propane G31
Ca egory I2H I3P
Supply Pressure 20 bar 37 Bar
Inle Pressure 20 bar* 37 Bar
Hea Inpu (ne ) (High) 4.2kW 4.2kW
(Low) 2.5kW 3.0kW
Inle Connec ion 8 Co pression
Injec or (manual valve) Elbow 82/340 Elbow 92/160
Pilo SIT 9116 Seagas P451
Average measured NO2 (room) 119ppb 115.1ppb
*The inlet pressure ust be wi hin +/- 1mBar of specification with all gas appliances in the house
switched on and also with just the Burley heater operating. If outside of this tolerance the fault is
ost likely to be in the installation pipe work or service governor at the eter. If the proble is
the eter governor, this is the property of the gas service provider (such as Transco / National
Grid 0800 111999 or Bord Gais) and they should be called to rectify this. The fire will not operate
correctly if the pressures are incorrect.
2. UNPACKING THE APPLIANCE
2.1 Carefully exa ine the carton for da age before unpacking. If it is obviously da aged,
consult the supplier as to whether to proceed with the installation.
2.2 Make sure the carton is stood upright and open the top.
2.3 Re ove the fittings boxes contained within and open the and check the condition of the
contents. Re ove the fire and exa ine its general condition, paying particular attention
to the fra e, the glass front and fire box flanges.
2.4 If satisfied by the general condition, place the decorative co ponents to one side and
proceed with the installation. If in any doubt, seek advice fro the supplier. Read hese
ins ruc ions fully before proceeding even if you have fi ed his model before.
THE APPLIANCE IS NOT TO BE RECESSED INTO THE WALL FOR SAFETY AND OPERATIONAL REASONS

Page 3 of 20
GENERAL REQUIREMENTS
3.1 Gas appliances ust be installed in accordance with the rules in force. In the UK it is the
law that all gas appliances ust be installed by a Gas Safe™ registered installer (for erly
CORGI), in accordance with the Gas Safety (Installation and Use) regulations (as
a ended). The installation ust also be in accordance with the relevant parts of local and
national building regulations and in accordance with BS5871 pt4 except where Burley
instruction state differently. For the Republic of Ireland, reference should be ade to
IS813 and ICP3 and any guidance notes fro Bord Gais. Failure to have the fire fitted by a
qualified person nullifies ALL guarantees.
3.2 The space to be heated ust have a wall vent of at least 100c ² of ventilation and an
openable window or patio door that co unicates directly to the outside. The vent ust
be positioned at least 1 etre away fro the appliance, in the Republic of Ireland two
vents of not less than 60c ² each, one not less than 1.6 above the other, ust be
installed in the roo . With the ini u size roo and with the ventilation specified, the
concentration of NO2 in the roo will be less than 150ppb.
3.3 When providing ventilator openings consideration ust be given to the avoidance of
locations where disco fort fro draughts ay cause the user to block the openings.
Si ilarly the possibility of curtains or furniture blocking ventilation openings ust be
considered. Floor ven s, ceiling ven s, closable window ven s or chimneys are no
sui able means of ven ila ion.
3.4 Working surfaces include the air outlet grille.
3.5 The heater ust not be used in a roo of less than 50 ³ in volu e. Adjoining spaces, not
separated by a door ay be included. To convert cubic feet (ft³) to cubic etre ( ³)
divide the roo volu e in cubic feet by 35.3.
3.6 The heater ust not be installed in high rise blocks of flats (unless a gas supply already
exists), bed sitting roo s, base ents which are not open on at least one side, bathroo s,
or bedroo s, in corridors stairways landing or hallways of ulti occupancy dwellings,
garages or roo s containing petroleu products.
3.7 Soft furnishings, decorations and wall coverings etc. ust not be placed within 1 etre of
the appliance and its convection outlets (see 5.0). Be aware of curtains etc which could be
blown towards the appliance.
3.8 The heater is intended as a secondary hea source. Check that a pri ary source of heat
(such as radiators) is present in the roo . If insufficient pri ary heat is being used there
ay be a build up of condensation, if this is the case, please warn the custo er of this.
3.9 The heater ust not be used in roo s where the at osphere is likely to contain water or
che ical vapours which ay adversely affect the appliance or its finish.
3.10 Do not use whilst painting & decorating, or in newly decorated roo s as the residues can
lead to unpleasant s ells fro the appliance. Always cover or have the appliance
re oved when decorating. (See points to note on page 14)
3.11 Candles too close to the fire ay elt. Scented candles ust be at least 1 etre away
fro the appliance.
3.12 Air freshener residues can enter the appliance and lead to residual odours, especially the
plug in type.
3.13 The catalyst is not an air cleaner and presence of odours is unlikely to be catalyst failure.
3.14 Houses with war air heating syste s, solid walls, or no da p proof course ay be
unsuitable for Flueless appliances.
3.15 This heater does not contain asbestos.
3.16 The oxy pilot can beco e blocked by fibres fro new carpets and pet hairs advise the
custo er to vacuu around the pilot on a regular basis to prevent blockage to pilot unit.

Page 4 of 20
4 INSTALLATION INSTRUCTIONS
Before working on pipe work, plug the ends to prevent the entry of debris. Decide upon the
route for the gas and lay pipes as required. Where pipes pass through walls they ust be
sleeved.
Before connecting any pipes to the appliance, fully purge pipes of debris or swarf etc. and
connect the gas supply to the 8 elbow on the fire. Leak test the supply using an approved
ethod. Fires can be connected to the supply using se i rigid pipe i.e. copper tube also
independently certified, hand bendable corrugated stainless steel connection pipe (such as
For a Pipe ™) ay be used with this appliance
Note: An isolating valve ust be situated near the appliance for servicing.
Tri securing screws
Outlet grille (do not obstruct)
Mounting key slots
Gas inlet hole
Inlet grilles (do not obstruct)
Control Opening

Page 5 of 20
THE APPLIANCE IS NOT TO BE RECESSED INTO THE WALL FOR SAFETY AND OPERATIONAL REASONS
4.1 The appliance is a flueless visual fla e heater designed to be installed on to a flat wall. It
MUST NOT BE INSET INTO THE WALL as this could block the inlet and outlet passageways
fro the fire leading to a hazard. The wall on which the appliance is to fix ust be upright
and flat. Failure to observe this could result in the appliance beco ing twisted or
da aged.
4.2 If the appliance is to be ounted on a dry lined or a ti ber fra ed construction wall then
the integrity and ability of the wall to carry the weight of the appliance ust be
confir ed. It is i portant in these circu stances that any vapour control barrier is not
da aged, and that any structural e bers of the house fra e are not da aged .
4.3 Care should be taken with wall coverings as heat ay discolour the over ti e.
4.4 Any co bustible aterials directly behind the ust be re oved and replaced with
suitable non co bustible aterial such as supalux board, calciu silicate, ce ent or
si ilar. Only the fra e supplied with the appliance ust be used. Any other type could
beco e da aged, effect co bustion or overheat the gas controls.
4.5 The appliance is designed to be wall ounted alone and not in conjunction with any type
of co bustible fire surround.
4.6 If an existing fireplace or flue is in the wall behind or adjacent to where the fire will be
fitted, it MUST be blocked off co pletely to prevent suction on the back of the appliance.
The top of the flue should also be capped off to prevent the entry of oisture etc, consult
building control if in any doubt.
5. CLEARANCES TO COMBUSTIBLE MATERIALS AND SHELVES
5.1 A non co bustible shelf with projection less than 100 ay be fitted to within 500
of the top edge of the fire fra e. Note that shelves will get hot and delicate orna ents,
wax candles etc should be kept away fro hot surfaces. No co bustible shelves should
be fitted for at least 1 etre above the appliance and a si ilar clearance should be
aintained to ceilings.
5.2 As with all heaters the possibility of convection staining on surfaces in the vicinity of the
heater shall be considered and the user advised. Particular attention should be taken to
ensure soft furnishings such as scatter rugs and curtains are kept at least 1 etre fro
the appliance.
5.3 On no accoun should glass mirrors or pic ure frames or any elec rical equipmen e.g.
plasma screen TV’s be fi ed or posi ioned on he wall above he appliance as he hea
rising could damage hem.
5.4 The user shall be advised when relevan ha ho convec ion air from he grille ou le
induces he possibili y of s aining on surfaces in he vicini y of he appliance. This can be
caused by he effec of hea on he finish and also burned dus & obacco par icles e c.
being carried in he convec ion curren s of he fire. Par icular a en ion should be aken
o ensure sof furnishings such as sof cushions and cur ains are kep a leas 1 me er
from he appliance. Blown vinyl and flock and embossed wallpapers can be scorch
damaged by being oo close o a hea source and may discolour over a period of ime.

Page 6 of 20
6. PREPARING THE APPLIANCE
6.1 Unpack the heater.
6.2 Ensure appliance is correctly arked for the gas it is to be used with. Take the appliance
co ponents and lay the out in an ordered anner. To prevent da age the decorative
fra e and fire bed co ponents can be placed safely to one side. Note how the fra e
attaches to the fire.
6.3 DO NOT ATTEMPT TO USE THE APPLIANCE WITH BROKEN/DAMAGED COMPONENTS.
Contact our service depart ent 01572 756956
6.4 Decide upon he rou e for he gas supply and if this is to be a concealed supply, select a
suitable hole in the fire box, re ove the knockout and lay in the supply as required. Note
the supply can be either concealed through the holes in the appliance back or surface
fitted but where pipes pass through walls they ust be sleeved. If the gas pipe passes
through a wall, cavity or un-vented void then there should be no joins in this area and the
pipes should be fully sleeved preferably in factory sleeved pipe. Before pushing gas pipes
through walls, seal the pipe ends to prevent debris entering the pipes.
6.5 The fire ust be ounted ini u 200 fro floor level
6.6 Hang he appliance on he wall and fix in o posi ion.
6.7 Fully purge pipes of air and any debris and connect the gas supply to the 8 isolation
elbow supplied with the fire. Leak test the supply using an approved ethod.
7. REMOVING AND REFITTING GLASS & DECORATIVE TRIM
7.1 To re ove the glass, re ove the decorative tri and then the 4 screws in the side fra es
and pivoting it out fro the botto then re ove glass fro its top channel. Refitting is
done in reverse order.
8. OPTIONAL FUEL LAYOUT
Op ional fuel layou
A bag of loose chippings is supplied for fitting in the appliance, if desired they can be
distributed in the chippings trays to the front and rear of the burner outlet. Chippings
should be evenly distributed and it is very i portant that on no account should the
chippings obstruct the burner outlet, fla e paths or pilot burner. Always replace the glass
after laying the chippings. Do no a emp o use he uni wi h broken / damaged glass
Do no use addi ional or non-s andard chippings, coals, logs e c.
Glass fixing
screws
Pivot glass out from
bottom

Page 7 of 20
8. Con rol Receiver Uni
Press the battery switch on the gas access cover to the O position.
Undo the securing screw for the receiver holder on the right hand side of the appliance as
shown below.
Pilot Burner
Burner Outlet
Battery Switch
Battery Switch
View fro underside of
appliance
Securing screw
or agnet.

Page 8 of 20
If required connect the cables fro the valve to the receiver as shown. Do not force the
valve cable plug when inserting into the receiver – it only fits one way.
HT
Lead
SW
)
yellow
TC
)
red
Valve
Cable
Ensure the battery switch on the gas access cover is in the O position & fit four AA (1.5V)
batteries into the receiver unit. Fit the PP3 (9V) battery into the trans itter (hand set).
Press the battery switch located on the underside of the gas access cover to the (I)
position. The handset should arrive already paired to the receiver, if the handset does
require pairing to the receiver turn to section 9.6.
Re-attach the holder to the appliance.
Re ove plastic
cover & fit 4 AA
batteries.

Page 9 of 20
9 Ligh ing he Appliance
Ensure that the battery ON/OFF switch located on the receiver holder is in the ON
position (I) & that the MAN/ON selection knob is also pointing upwards towards its ON
position (see below).
Si ultaneously press and hold the (red circle) and (large fla e) buttons until an
acoustic signal confir s the start sequence has begun, then release the buttons.
Press
these two
buttons
together to
light the
burner
Once lit
use this
button to
increase
gas rate
Once lit
use this
button to
decrease
gas rate
9.1 The acoustic signal should cease and be replaced with the ticking sound of the spark
igniter. When the pilot fla e is lit the igniter will stop & another acoustic signal will
confir the pilot has been established (if the pilot fails to establish repeat the process.
Due to the safe & efficient nature of the fire it is not unusual for this to take two or even
three atte pts). The acoustic signal will now cease & the gas rate adjusting knob will
auto atically turn to its high setting.
9.2 To adjust the gas rate to desired setting press the (large fla e) to increase the fla e
height or (s all fla e) to decrease the fla e height on the handset.
9.3 To leave the fire in s andby mode press the (s all fla e) until the ain burner goes out.
The pilot should re ain on in this ode & help to reduce condensation.
9.4 To urn he fire off co pletely (including the pilot) press the red OFF button on the
handset.
Gas rate adjusting knob
Re ote ON
select
or
Re ote Control Gas Valve

Page 10 of 20
9.5 Ba ery Replacemen
Handset
On the back of the handset re ove the battery cover by pressing down the top of the
cover & sliding it down. Re ove & unclip the old battery & replace with a new PP3 9 volt
battery.
Receiver Unit (located on your right hand side behind the trim)
Switch the battery isolator switch to the (O) position. Lift the unit fro its carrier carefully
noting the pathway of the associated wiring. Re ove the top cover, re ove old batteries
& replace with four new AA batteries ensuring the polarities are correct. Replace the
battery cover & return the receiver unit to its original position. Switch the battery isolator
switch back to the (I) position.
Press here and
slide down
CAUTION: With the exception of battery replacement the receiver must be
located in the carrier at all times.
9.6 Pairing Handse o Receiver
If for so e reason the re ote handset requires re-progra ing to operate the receiver
follow the procedure below:
1. Press and hold, using a pointed object, the receiver’s reset button until you hear two
acoustic signals.
2. After the second longer acoustic signal, release the reset button and within the
subsequent 20 seconds, press the (s all fla e) on the re ote handset until you hear
an additional long acoustic signal confir ing the new code is set.
RESET
DUE TO THE SENSITIVE NATURE OF THE PILOT, IT IS NOT UNUSUAL FOR THE PILOT TO
EXTINGUISH UP TO/AFTER 1 MINUTE WHEN FIRST LIT. RE-LIGHT AND THE PILOT WILL STAY
ALIGHT.

Page 11 of 20
10. COMMISSIONING
10.1 TEST THE GAS PRESSURE. Turn the fire on full, attach a ano eter to the inlet test point
and ensure there is a pressure of 20 bar (+/- 1 bar) for natural gas appliances or
37 bar for propane appliances. Now turn on every other gas appliance in the house and
re-check the pressure. The pressure ust still be within the tolerance of +/- 1 bar. Now
turn off all the other gas appliances and turn the fire down to pilot only, the pressure
ust still be within the tolerance of +/- 1 bar. If it is not TRANSCO, BORD GAIS or the gas
supplier ust be called to adjust the governor to the house before the fire can be
co issioned further. Call ou s o fires wi h incorrec pressures will be chargeable.
10.2 Brief the custo er on the operation of the appliance and give the all the instructions.
The custo er ust be told of the need for regular servicing of the appliance, this will be
at least once a year and be ade aware that no rubbish is to be thrown onto the fire bed.
The custo er ust also be ade aware that purpose provided ventilation should be
checked regularly and not be blocked.
10.3 If you have any ques ions or he fire is no opera ing correc ly, phone he Burley help-
line BEFORE you leave he ins alla ion.
If he appliance is no fi ed in s ric accordance wi h hese ins ruc ions, Burley canno
be held responsible for any damage caused and reserve he righ o charge for any
correc ive work. Double check s anding and working pressures and securely seal all
relevan open chimneys and flues.
10.4 Oxygen Deple ion Pilo Sys em There is a highly sensitive oxygen depletion sensor
designed into the pilot light and ay not light first ti e or ay extinguish after a few
inutes, please advise the custo er of this. If any part of the OXY Pilot is da aged the
entire unit ust be replaced. Do not atte pt to bend or alter the fla e head,
ther ocouple or aeration hole. Use only genuine spare parts as si ilar looking parts fro
other appliances ay well give different or inferior perfor ance and could lead to a
hazard.
10.5 Fireguards A fireguard is not supplied with this appliance and being wall ounted, the
need for one will have to be assessed depending on the position, height fro ground of
the fire; however it is reco ended that a fireguard to BS8423 is fitted if the fire is to be
used in the presence of young children, the elderly and the infir .
10.6 Comple ion of Warran y Card. The ins aller sec ion of he guaran ee card mus be filled
in fully o valida e he warran y. I.e. pressure, model, room size and Gas Safe™
regis ered ins aller (formerly CORGI) number

Page 12 of 20
11. SERVICING INSTRUCTIONS
As wi h all gas appliances he uni mus be serviced a leas once per year, preferably a
he beginning of he hea ing season. All servicing mus be carried ou by a qualified
service person.
Before co encing any servicing, ensure that the gas is turned off to the appliance and
that the appliance is cool.
Cleaning – If required the casing should be wiped with a cloth da pened in soapy water.
The glass ay be cleaned with any non-abrasive cleaner such as ‘hob brite‘.
Unscrew the decorative fra e to re ove. Unscrew the four screws holding the glass,
re ove and place thoughtfully to avoid da age or injury.
Carefully re ove the loose chippings and re ove any dirt with a soft brush (paint brush)
and clean the burner and associated parts using a vacuu cleaner. Take particular care to
re ove all debris around the pilot light.
We reco end the use of a HEPA filtered vacuu to re ove any dust and soot
accu ulated in the heater before and after working on it. Nor al hygiene rules of not
s oking, eating or drinking in the work area should be followed.
Disconnect the gas supply to the appliance.
Clean around all air inlet grills re oving all lint in the area of the injector and ensuring the
pilot light aeration hole and fla e head are clean. Injectors – Only original anufacturer’s
injectors ust be used, see section 1 for identification. Should the oxypilot syste need
to be replaced, the original anufacturer’s parts ust be used.
Controls – The GAS CONTROL IS FACTORY SET AND NORMALLY NEEDS NO ADJUSTMENT.
Check for s ooth operation of the gas valve. Re ove access cover & check the tightness
of the ther ocouple connection into the valve and test ignition leads.
Exa ine the fire casing, the firebox and catalytic converters for obvious signs of da age
or degradation. Clean out any dirt or dust accu ulated in the botto of the fire.
Reasse ble in reverse order.
Test all joints for leaks.
Following the instructions, re-lay the chippings (if used) and replace the glass.
Light the fire using the ethod in the instructions and ensure that the pilot lights
consistently and the pilot fla e envelopes the ther ocouple. The pilot should hold in
after approxi ately 10 seconds & turn the ain burner on, this should light s oothly
within 10 seconds. Ensure the valve turns down by double clicking the low fla e button.
The gas anifold pressures are factory preset using highly accurate equip ent and do not
nor ally need adjust ent.
Run appliance for 15 inutes, ensuring burner fla es settle evenly.
A co bustion analysis check should then be carried out. Using an analyser to BS7927, first
zero the equip ent and sa ple the entire width of the co bustion product outlet. Ratio
of CO/CO2 should be less than 0.002 within 30 inutes. (20pp CO per 1% CO2) A
reading of CO in the roo centre should give a rise of less than 9pp over a bient, peak
reading. The catalyst is unlikely to need replace ent during the life of the heater but if
the co bustion is suspect, disconnect the appliance and contact the anufacturer.

Page 13 of 20
12. PARTS LIST
Par Na ural Gas Par No. LPG Par No.
Re ote Control Handset REM1924 REM1924
Re ote Control Valve VAL1921 VAL1921
Re ote Control Receiver & Handset VAL1924 VAL1924
H.T. Lead CAB1921 CAB1921
Pilot Light Asse bly OXY4240NG OXY4240PR
Gas Injector NOZ4241NG NOZ4240PR
Magnetic Unit (valve) MAG-UNIT MAG-UNIT
Cable Interrupter Connector CAB1922 CAB1922
Chippings CHIP1000 900g CHIP1000 900g
Glass GLA4530 GLA4530
USE ONLY GENUINE REPLACEMENT PARTS.
Par s ordered from our fac ory will normally ake 5 – 7 working days o be delivered.
An ‘Express service’ is available upon reques .
Due to our policy of continual improvement and development the exact accuracy of
descriptions and illustrations can not be guaranteed.
urley Appliances are the only company to bench run and thoroughly test every single Flueless
gas fire it produces. urley is in the unique position of knowing that every appliance leaves the
factory in perfect working order.

Page 14 of 20
13. Flue Gas Analysers – Ins alla ion & Servicing Fac s
• Please read this sheet even if you have fitted our fires before.
• Please leave this sheet with the custo er as reference for future servicing of the
appliance.
• Please explain to the custo er how the fire works and the details and facts listed on this
sheet, particularly what the catalyst does and doesn’t do.
• If you have any doubts about the test procedure please visit our website or call our
technical help line
Tes ing – Poin s o no e…
• Before testing ensure that the ini u roo size is correct for the heat output of the
fire. 30 ³ for 2.5kw output, 40 ³ for 3.5kw and 50 ³ for 4.5kw.
• In all installations regardless of roo size there ust be an air vent positioned at least
one etre fro the fire at either high or low level through an outside wall providing
100c ² of free air. (For the Republic of Ireland 2 vents of not less than 60c ² ust be
provided at high and low level, with ini u vertical separation of 1.6 ).
• The analyser used ust be anufactured to BS7967 and the test ust be carried out in
accordance with BS5871 Pt 4
• The catalytic converter needs heat to work, therefore before you start testing; the fire
ust have been lit and burning on full for at least 15 ins.
There are two tests to carry out. A Co / CO² ratio test and a roo centre CO test.
1. The first test is the CO / CO² ratio test and should be carried out at the fire outlet grille, do
not stick the probe of the analyser in through the grill but ove the probe back and forth
1 inch on top of the outlet grill. You should record a ratio of no ore than 0.002 %
(20pp CO to 1% Co²). It is advisable to have a high sa ple of CO² as this will i prove the
test. If you have less than 1.0% CO2 the analyzer ay give false results due to the
accuracy of analysers reducing at low CO2 levels.
2. The second test is the roo centre CO test. You should stand in the roo centre with the
probe at waist height and read the level of CO; this should be no ore than 9pp over
a bient peak. Please record these readings on the custo ers guarantee card.
Our Flueless fires also contain the following safety devices an ODS (Oxygen Depletion Sensor) and
FSD (Fla e Supervision Device). Point out to the custo er that unfortunately these are not
found on all gas hobs; which are also flueless devices)

Page 15 of 20
14. Poin s o No e Regarding he Ca aly ic Conver or!
• If the custo er s okes tobacco products, lives on a busy road or is cooking with a gas
oven/hob at the ti e of testing you ust ensure that an a bient CO reading is taken
before lighting the fire and atte pting a reading.
• Does the catalytic convertor need replacing? The catalytic convertor does not need
replacing unless it has beco e physically broken or the co bustion test shows
deterioration in perfor ance over ti e. To constantly test the perfor ance of the
catalytic converter, our laboratory has been running appliances eight hours per day, five
days per week, for up to seven years. Periodically we send catalytic converters back to the
anufacturer for testing. After the equivalent of 30 years of use, the catalytic converter is
as efficient as it was when brand new. Burley anages to achieve this by designing the
fire to ensure that the catalytic converter is in exactly the right position for long life and
axi u efficiency. (For other akes of fire please consult the relevant anufacturer).
Only use replace ent catalyst supplied by Burley.
• If you or the custo er detects any odours fro the fire please re e ber that the
catalytic convertor is not an air filter and does not re ove s ells. The cera ics in the fire
can absorb household s ells and in turn these s ells get e itted when the fire is lit,
especially if the fire is used in an enclosed space for a period of ti e. If this is the case we
reco end that the fire is run on axi u for at least 5 hours with the doors and
windows open. This should be done at least twice a year, preferably in the spring and
autu n or at any ti e they notice a s ell.
• We do not advise the burning of wax candles within 1 etre of the fire. Wax particles can
beco e airborne and deposit and solidify in the fire causing potential co bustion
proble s.
• The catalyst can also be affected by airborne paint s ells and vapours fro so e plug in
air fresheners. The fire ust be re oved or sealed if you plan to decorate anywhere in
the house. If you can detect s ells fro the fire carry out the burning off procedure as
above.
Fur her informa ion regarding he ca aly ic conver or and Flueless fires in general can
be found on our websi e www.burley.co.uk

Page 16 of 20
15. Gas ra ing of Burley Flueless Appliances
Burley’s Flueless Gas Appliances are all gas input rated in the factory and undergo further line tests for
co bustion, sooting and visual perfor ance. For Installers who wish to gas input rate appliances we need
to establish tolerances for pass and fail.
Manufac urers Tolerances
The Heat Input on appliances can be expressed as either a Nett or a Gross figure. When the installer is gas
rating fro the eter they will be using gross heat input which is 10% higher than Nett. This conversion
has to be taken into account if the anufacturer has quoted a nett figure.
The anufacturer also has to account for production tolerances on pipes, injectors, valves etc and is
allowed a further +/-5% tolerance on the axi u rate.
Burn Down
Cold appliances generally allow a greater rate of gas to pass through the and once the appliance war s
the gas density alters and causes the rate to reduce to the figure stated. This is known as Burn Down.
Manufacturers carrying out their technical tests allow appliances to be fully war and burn down before
taking readings and this is typically after 1 hour. So e appliance anufacturers quote a ‘cold’ figure for
the gas rate so that installers can easure this i ediately.
Ins aller Tolerances
It is i portant to take a gas rate test over a reasonable period of ti e so that the capacity of the eter is
used. On low Input appliances such as our flueless this is even ore critical because uncertainties can
creep in. It is worth easuring over a 5 inute period to ake sure.
It is also i portant to get your inlet pressure to 20 Bar.
In a gas appliance factory co pensation is also ade for variations in
• % Saturation of Gas
• Variation in Calorific Value
• Variation in Gas Density
• Gas Te perature
• Gas Pressure
• At ospheric Pressure
• Meter Calibration
• Stopwatch Calibration.
In the ho e it is not possible to correct for these therefore an uncertainty factor needs to be built into all
easure ents.
Currently Gas Safe™ (for erly CORGI) does not quote a figure on this uncertainty but the easured gas
rate could vary by +/-5%.
Conclusion
In adding all the variables together,
• an appliance quoting Gross Heat Input could be anything fro +/-10% of the quoted heat input
• an appliance quoting Nett Heat Input could be anything fro 0% to +20% of the quoted figure
when easured as a Gross figure.
• If the appliance is cold anything up to a further 10% error could be expected and we don’t quote
these figures because they change rapidly. The figures shown below are hot figures.
Hea Inpu Minimum
(Gross)
Max (Gross) Cu F / Hr Cu M / Hr
Environ, Es eem,
La i ude
2.5kW Nett 2.5kW Gross 3.0kW Gross 8.49 0.2404
Ambience 4121 3.5kW Nett 3.5kW Gross 4.2kW Gross 11.67 0.3304
Acumen / Elan
4111
4.2kW Nett 4.2kW Gross 5.3kW Gross 14.85 0.4205
Longi ude 4.2kW Nett 4.29kW Gross 5.3kW Gross 14.85 0.4205

Page 17 of 20
Burley Appliances L d - Domes ic Guaran ee Condi ions?
We pride ourselves on the quality of service we deliver to our custo ers and all Burley Appliances’
products carry a fully inclusive 12- onth parts and labour guarantee. This guarantee is extended by
another 12 onths free of charge provided that your appliance is registered with us within two weeks of
installation and that it is serviced by a Gas Safe ™ registered installer (for erly CORGI) at the end of the
first year. What the guarantee cannot cover is proble s caused by incorrect installation or servicing, or
any work carried out by non- Gas Safe™ registered installer (for erly CORGI).
We undertake that if within 12 onths of the date of purchase, your fire or any part thereof is proved to
be defective by reason of faulty work anship or aterials, we will at our discretion repair or replace the
sa e free of any charge for labour, aterials or carriage subject to condition that:
• All gas appliances are installed to the latest Gas Installation regulations by a qualified Gas Safe™
registered installer (for erly CORGI) and connected to the correct gas type and pressure as stated
on the rating plate attached to the equip ent.
• The fire is fitted in a roo with the following ini u di ensions 2.5Kw = 30
3
/ 3.5Kw = 40
3
/
4.2Kw = 50
3
• A wall vent is installed not less than 1 eter away fro the fire allowing 100c
2
of free air.
• You have the fire serviced by a Gas Safe™ registered installer (for erly CORGI) within the first
year (as with all gas products, every gas appliances ust be serviced every year).
• The appliance has not been subject to isuse, accident, or repaired or fitted by anyone other than
a Gas Safe ™ registered installer (for erly CORGI) or our own engineer.
• The appliance has been used solely for do estic purposes and is on do estic pre ises i.e. not for
co ercial or trade use.
• The appliance has been used solely in accordance with the instruction book.
Any in guarantee work carried out by Burley Appliances will be charged for if the fault is caused by
incorrect pressure or gas, incorrect installation, operator error, neglect or abuse.
All guaran ee cover is ins an ly and permanen ly cancelled if a non- Gas Safe ™ regis ered ins aller
carries ou any ins alla ion or servicing.
Exclusions
This guarantee does no cover:
• Da age resulting fro external transportation, i proper use or neglect, the replace ent of any
light bulbs or re ovable parts of glass or plastic.
• Costs incurred for calls to put right an appliance, which is i properly installed.
• Appliances that are the subject of rental agree ents.
• EC Countries - the standard guarantee is applicable but is subject to the owner's responsibility and
cost, to ensure the appliance eets the standards set by the country to which the product is
taken.
Any appliance or defec ive par replaced shall become he Company's proper y
Service Calls are made be ween 09.30 am and 04.30 pm Monday - Friday.
This guaran ee is in addi ion o your s a u ory and o her legal righ s.
Proof of purchase will be required as will be a copy of he Gas Safe ™ regis ered ins aller no ice.
© Burley Appliances Ltd 2019

Page 18 of 20
Disposal
Recycling Informa ion:
The etallic & glass parts of the appliance & its packaging
should be sorted for environ ental-friendly recycling.
WEEE: Dispose of electrical equip ent in an environ entally
correct anner.
When disposing co ponents containing Refractory Cera ic
Fibres (RCF), we reco end that the ite s are not broken
up, but are sealed within heavy duty polythene bags, and
clearly labelled as RCF waste. RCF waste ay be disposed of
in suitably licensed landfill sites.

Page 19 of 20

Page 20 of 20
Burley Magiglo fires are protected by
UK patents 2193802, 2240620 and 2256920
Other Patents Pending
Burley Appliances Ltd, Lands’ End Way,
Oakham, Rutland, LE15 6RB
Tel: [phone] Fax: [phone]
www.burley.co.uk Email: [email protected]
