BURNiT Lambda series User manual

PyroBurn Wood-Gasifying Boiler
Lambda series
TECHNICAL PASSPORT
INSTALLATION and OPERATION MANUAL
Version i0.1.3
EN
model:
serial number:

TABLE OF CONTENTS
1. EXPLANATIONS OF SYMBOLS AND SAFETY INSTRUCTIONS ....................................4
1.1. Explanaonofsymbols ...........................................................................................4
1.2. Requirementstoboilerinstallaonroom............................................................... 4
1.2.1.Instruconstoboilerinstaller................................................................................. 4
1.2.2.Instruconstoinstallaonuser .............................................................................. 4
1.2.3.Minimumclearancesforinstallaonandcombusbilityofbuildingmaterials ......5
2. PRODUCT DESCRIPTION..........................................................................................6
3. FUEL TYPES.............................................................................................................. 7
4. TRANSPORTATION OF THE BOILER.......................................................................... 7
5. DELIVERY OF THE BOILER........................................................................................ 8
6. ASSEMBLY OF THE HEATING BOILER ....................................................................... 8
6.1. Requirements.......................................................................................................... 8
7. INSTALLATION OF THE HEATING BOILER ................................................................. 9
7.1. Connecngtheboilertoachimney........................................................................ 9
7.2. Connecngtheboilertothemainspowersupply................................................10
7.3. Connecngtheboilertotheheanginstallaon ................................................. 11
7.4. Connecngtheboilertothesafetyheatexchanger............................................. 12
7.5. ConnecondiagramsforPyroBurnLambdaboiler............................................... 12
8. FILLING THE HEATING INSTALLATION.................................................................... 16
9. BOILER OPERATION............................................................................................... 16
9.1. Loadingandignionofboiler ............................................................................... 16
9.2. Requirementsconcerningcleaningandmaintenanceoftheboiler .....................18
9.3. Importantrecommendaonforlong-lasngandcorrectoperaonoftheboiler .......20
10. CONTROLLER......................................................................................................... 23
11. WARRANTY TERMS ...............................................................................................27
12. TECHNICALFEATURESWOODGASIFYINGBOILERPyroBurnLambda...................27
12.1. ComponentsofthecombusonchamberofPyroBurnLambdaboiler ................29
12.2. Componentsoftheleaningsystem ...................................................................... 30
12.3 Technicalparameters ............................................................................................ 31
13. RECYCLING AND WASTE DISPOSAL ...................................................................... 33

TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL
TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL
4
1. EXPLANATION OF SYMBOLS AND
SAFETY INSTRUCTIONS
1.1. Explanaonofsymbols
CAUTION! - Important
recommendaon or warning
concerning safety condions
during installaon and operaon of the
heangboiler
DANGER! - fault or improper use
maycauseinjuryorbehazardous
tothelifeofhumansoranimals.
FIRE HAZARD! - fault or improper
installaon and operaon may
causere.
INFORMATION – Important
informaon on the proper
operaonoftheproduct.
1.2. Requirementstoboilerinstallaon
room
This manual contains important
informaon for the safe and correct
installaon, start-up and trouble-free
service and maintenance of the heang
boiler.
Theheangboilercanbeusedforheang
rooms only in the manner described in
thismanual.
Take note of the boiler type informaon
indicated on the factory scker and the
technical data provided in chapter 11 in
order to ensure proper operaon of the
product.
1.2.1. Instruconstoboilerinstaller
During installaon and operaon, the
country-specic requirements and
regulaonsmustbeobserved:
•local building regulaons on the
installaon, air supply and exhaust
gas extracon as well as chimney
connecon.
•regulaons and norms concerning the
ng of the heang installaon with
safetydevices.
iUse only original BURNiT parts

DANGERofintoxicaon,
suocaon.
Inadequate inow of fresh air
in the boiler room may result in
dangerous leak of exhaust gases
during boiler operaon.
- Make sure the air inlets and
exhaust gas outlets are not
clogged or closed.
- If faults are not remedied
immediately, the boiler must
not be operated, and the user
must be provided with wrien
instrucons on the fault and the
hazard it entails.
!
DANGER of re when burning
ammablematerialsorliquids.
-Flammable materials/liquids
must not be le in immediate
proximity of the heang boiler.
-Indicate to the installaon user
the allowed minimum clearances
from surrounding objects.
Customer must undergo boiler
operaon/maintenance training
by authorized installer/service
shop.
*It is mandatory to assure a backup
powergeneratorofcorresponding
ratedpower!(see12.3)
1.2.2. Instruconstoinstallaonuser
*Customer must undergo boiler
operaon/maintenance training
by authorized installer/service
shop.
*It is mandatory to assure a backup
powergeneratorofcorresponding
ratedpower!(see12.3)

5
TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL
TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL
$
DANGER of intoxicaon or
explosion
Toxic gases may be discharged
when burning waste, plascs,
liquids.
-Use only the fuels indicated in
this manual.
-In case of danger of explosion,
ignion or discharge of exhaust
gases in the room, stop the
heang boiler from operaon.
*
CAUTION! Danger of injury /
damage of installaon due to
incompetentoperaon.
-The heang boiler must be
serviced only by persons familiar
with the operaon manual.
-As a user, you are only allowed
to start the boiler up, adjust the
temperature of the boiler, shut
the boiler down and clean it.
-Unaended children must not be
allowed to access a room housing
a running boiler.
Safetyrulesforuseroperaon:
-Operatetheheangboileratamaximum
temperature of 85°C, and to that end
you must regularly inspect the boiler
room.
-Do not use ammable liquids to ignite
thereorincreaseboiler’soutput.
-Collecttheashinare-proofcontainer
withalid.
-Clean the heang boiler surface using
non-ammableagentsonly.
-Donotplaceammableobjectsontothe
heang boiler or in its proximity. (see
diagram1fortheminimumclearances)
-Donotstoreammablematerialsinthe
boilerroom.
1.2.3. Minimum clearances for
installaon and combusbility of
building materials
The applicable minimum clearances in
your country may dier from the ones
specied bellow. Please, consult your
installer.
The minimum distance from the heang
boiler or exhaust gas pipe to objects or
wallsmustbeatleast200mm.
Diagram 1
Recommended clearances between the
boiler and walls.
For general safety consideraons, we
recommendthattheboilerbeplacedon
afoundaonwithheightof100mmmade
ofclassAmaterial,seetable1.
Table 1
Combusbility of building materials
Class
А– non-
combusble
Stone, bricks, ceramic les,
baked clay, soluons, plaster
freeoforganicaddives.
Class
B– hard
combusble
Gypsum board panels, basalt
ber needled felt, berglass
board, AKUMIN, Izomin,
Rajolit,Lignos,Velox,Heraklit.
Class С1/С2
Medium
combusble
Woodbeech,oak
Woodsowood,layeredwood
Class
C3– easy
combusble
Asphalt, cardboard, cellulose,
tar, berboard, cork,
polyurethane,polyethylene.

TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL
TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL
6
2. PRODUCT DESCRIPTION
PyroBurnLambdaboilersaredesignedto
burnsolidfuel–woodorwoodbriquees
class B on the principle of wood gas
generaon using a fan. The body of
the boiler is manufactured as welded
sheet-steel structure. It comprises a
loading chamber which in its lower part
is equipped with ceramic nozzle with
longitudinal slot through which passes
the wood gas produced. Below it is the
combuson chamber where the wood
gas burns, lined with ceramic refractory
pieces.Onthefront,intheupperpartof
the boiler is located the upper door for
loading the upper chamber with wood,
and in the lower part is the combuson
chamberdoor.Opendoorsensordetects
when boiler door is open and acvates
fumeextractorfanonfullspeed(100%).
Fume extractor fan draws smoke from
the chamber to the chimney via back-
sideupperchamberopening.Opendoor
sensorfunconistopreventboilerroom
from fume polluon when reloading.
The boiler body is heat-insulated on the
outsidewithmineralwoolinsertedunder
the housing. Smart MCU controller is
build-upinboilerupperpart.
• Design. Boiler body is made of high-
qualityboilersteelsheetswiththickness
of 6 mm for the combuson chamber
and4mmforthewaterjacket.Thebuilt-
in refractory ceramic pieces help ensure
theuniformtransferoftheheatproduced
tothewaterjacketandprotectthesteel
walls from the high temperatures (up to
1200°С).
• Pyrolyc combuson. Wood in the
loading chamber burns (above 580°С)
and releases wood gas rich in carbon
compounds. When combined with the
primary air it forms a burnable mixture
and is then routed to the nozzle in the
combuson chamber. In the nozzle the
mixture is enriched with secondary air
and is self-ignited in order to reach the
combuson chamber at 1200°С. Before
leaving the boiler body, ue gases pass
throughuepipeswheretheylosetheir
heat and cool down to 150°С. Pyrolyc
combusonhelpsachieveecientwood
burningwithminimumproduconofash.
• Eecve. Thanks to the pyrolyc
principle of wood burning, the boiler
achieves eciency of more than 92%.
The water jacket envelops the enrety
of the combuson chamber in order to
ulize maximum amount of the heat
produced.Ontheoutside,theboilerbody
isinsulatedbymeans of50mmlayerof
mineralwoolthermalinsulaon.
• Intelligent microprocessor control unit
ThePyroBurnLambdaboilerisequipped
with a hi-tech reliable controller
capable of managing complex heang
installaons. The controller manages
the combuson process via permanent
monitoring of oxygen levels in exhaust
gases, their temperature as well as
the boiler temperature. Depending on
those values the controller adjusts air
intake into the primary and secondary
combuson chamber. The control unit
is capable of managing various heang
circuitswhereasithas3typesofheang
installaonsembeddedinitslogic.Thanks
to the integrated lambda sensor the
combusonprocessisopmizedtosuch
an extent that boiler eciency exceeds
92%,andexhaustgasemissionsconform
tostrictestEUstandards.
The microprocessor control is able to
controloneheangcircuitandoneDHW
circuit through the built-in terminals for
connecng circulaon pumps and DHW
sensor.
• Lambda sensor for accurate

7
TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL
TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL
combusonprocessmanagement
• Fuel loading door
• Cleaningdoor(combusonchamber)
• Actuator-drivenairapsforairintake
management
• STB–emergencythermostat
• Flue gas sensor
• Safetyheatexchanger.
• Open door sensor and fume
extraconopening
• Safetydevicesoftheboiler
Theboilerisequippedwith4independent
overheangprotecons.
1.Uponreaching95°Сthecontrollerturns
thefanoandacvatesthepumpsfor
domeschotwaterandheangsystem.
2.An independent STB thermostat shuts
downthefanuponreaching99°С.
3.Emergencycoolingcoilintegratedinthe
top secon of the water jacket allows
theconneconofthermostacvalve.
4.Safetyvalve3bar
3.FUELS
Theheangboilercanulizeonlynatural
and untreated wood. Log length should
be up to 500 mm. Pressed fuels and
briqueescontainingonlywoodmayalso
beused.Fuelmoisturecontentmustnot
exceed15-20%.
For maximum ulizaon of the wood
heang value we recommend to use
wood which has dried over a period of
1.5-2years.Highmoisturecontentofthe
wooddecreasesitsheangvaluewhichin
turnreducesboileroutput.
Diagram 2
Relaon between wood heang value and
water content.
Table 2
Heang value of the most common wood
species
Wood
species
Energy contained in 1 kg
kcal kJoule kWh
Spruce 3900 16250 4,5
Pine 3800 15800 4,4
Birch 3750 15500 4,3
Oak 3600 15100 4,2
Beech 3450 14400 4,0
4. TRANSPORTATION OF THE BOILER
Werecommendtotransporttheheang
boiler to the installaon site in its
packaging placed on the pallet. During
transport and installaon, depending on
theweight,suitablesafetydevicesshould
be used in accordance with Direcve
2006/42/EC.
When transporng items weighing more
than 30 kg, the use of pallet jack, fork
truckorotherhoisngdevicesisamust.
The boiler is safely secured by means of
anchorngstoawoodenpalletofsizes
А,B,C.Ithasthenbeenstretch-wrapped
to protect the housing from scratching
anddustbuildup.Thelastelementofthe
packingisaheightDcardboardbox.The
cardboard box protects the boiler from
ambientcondionsduringtransport.

TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL
TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL
8
*
Important: When installing the
boiler, the wooden pallet onto
whichtheboilerisplacedmust
be removed by unscrewing the
bolted connecons using at
ringwrenchS13.
Diagram 3
Model A B C D kg
20 kW 850 1200 120 1360 490
30kW 850 1260 120 1470 572
5. DELIVERY OF THE BOILER
•Inspect the integrity of the packaging
upondelivery.
•Check whether all components have
been delivered to you. Boiler scope of
deliveryincludes:
1)Boilerbodywithboilerdoors
2)Safetyvalve3bar.
3)Ashpan
4)Cleaningbrushforuepipes
5)CockG½”
6)Installaonandoperaonmanual
7)ServicebookletandWarrantycard
If any of the above items are missing,
contactyoursupplier.
•Youmustremovethepolystyreneblocks
placedinthecombusonchamberprior
topungtheboilerintooperaon.
6. ASSEMBLY OF THE HEATING BOILER
*
The assembly, installaon and
set-up of the boiler must be
performed by a technician
authorizedforsuchoperaons.
Installermustindicatetotheuser
of the installaon the minimum
clearances from ammable
materials and liquids.
6.1. Requirements:
-Boilerroommustbefrost-proof;
-Boiler room must allow for connuous
access of air necessary to maintain
combuson;
-Boilersmustnotbeplacedininhabitable
rooms;
-All boiler rooms must have correctly
calculatedventdependingontheboiler
output.Theventmustbeprotectedby
meansofanetorgrate.
Thesizeoftheventiscalculatedaccording
totheformula:
А=6,02Q-where:
 А–areaoftheventincm,
Q–boileroutputinkW
-Removethepackagingwithoutpollung
theenvironment;
-Observe building supervision
instrucons, in parcular the exisng
Ordinance on combuson devices and
storage of combuson materials, on
building requirements applicable to
installaonsitesandonvenlaon;
-The boiler must be placed on a
foundaonwhosesurfaceareaislarger
than the base of the heang boiler
accordingtodiagram1;
-Theboilermustbeplacedinaposion

9
TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL
TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL
which allows for the easiest possible
cleaningandservicing;
-Installaon must be carried out
according to installaon diagram 1
whichshowstheboilerhousing;
-Noobjectsmadeofammablematerials
or liquids may be placed on/near the
boiler;
7. INSTALLATION OF THE HEATING
BOILER
7.1.Connecngtheboilertoachimney
Diagram 4
Boiler-to-chimney connecon must
alwayscomplywiththeexisngstandards
and rules. The chimney must provide
sucient draught for evacuaon of the
smokeunderanycondions.
The proper funconing of the chimney
requires adequate sizing of the chimney
itselfsincethedraughtitproducesaects
combuson,boiler’soutputandlifespan.
The draught created by the chimney
is in funconal relaon to its cross-
secon, height and the roughness of its
interior walls. No other appliance may
beconnectedtothechimneyservingthe
boiler. Chimney diameter must not be
smallerthantheueoutletoftheboiler.
Flue outlet must be connected to the
chimneyopening.Intermsofmechanical
properes,theueoutletmustbesturdy
and properly sealed (to avoid gas leak)
and allow for easy access for cleaning
on the inside. The inner secon of the
ueoutletmustnotbegreaterthanthe
eecveseconofthechimneyandmust
notnarrow.Avoidusingelbowjoints.
Table 3
Recommended minimum chimney heights
Boiler output Chimney
diameter
Recommended
height
20-30kW
Ø 160 mm
Ø 180 mm
Ø 200 mm
Ø 220 mm
At least 9 m
At least 9 m
At least 8 m
At least 8 m
i
Datainthetablesareforindica-
vepurposes.
Draught depends on the diam-
eter, height, uneven secons
along the chimney surface and
dierences in temperature of
combuson products and out-
side air. We recommend that
you use chimney ed with
ueterminal. Heangspecialist
mustcalculatetheprecisesizing
ofthechimney.

TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL
TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL
10
7.2. Connecngtheboilertothemains
powersupply.
*Such connecon must be
performed by a technician /
serviceshopauthorizedforsuch
operaons.
+
Cauon! ELECTRIC SHOCK
HAZARD!
- Before opening the unit: switch
o the voltage and secure the
unit against accidental restart.
- Observe installaon instrucons.
Diagram 5.
Connecon of the controller with power supply and peripheral equipment.
Socket X61-usedtoconnectthedisplay
tothecontroller.
Next photo shows how to connect the
mains power supply to the controller.
SocketislabeledX1.
yellow-green
blue
brown
Socket X59isforthepowersupplycable
oftheprimaryairintakeactuator.Socket
X60is forthepowersupplycableofthe
secondaryairintakeactuator.
yellow-green
blue
brown
Socket X44 serves to connect the open
doorsensor.

11
TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL
TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL
blue
brown
Socket X28 serves to connect the
temperature sensor inside the boiler
waterjacket.
SocketX31servesforthesensorreading
thetemperatureofexhaustgases.
brown
white
red
SocketX38servestoconnectthewiresof
thelambdasensor.
grey
white
red
Theboiler mustbe connectedtoa220V
/ 50Hz mains using a cable and a plug.
The boiler must be placed in a posion
which allows for unobstructed access
to the power supply plug. Dismount the
inspecon cover on the back side of
housing.
Usinga screwdriver,connectthepower
supply and the external components
(pumpfortheheangcircuitanddomesc
hot water pump). Make sure you have
connected the external components
properlyaccordingtotheenclosedwiring
diagram.
Createsolidconneconwiththeelectrical
mains which complies with the local
regulaons.
*It is mandatory to assure a backup
powergeneratorofcorresponding
ratedpower!(see12)
Table 4
Problem Prevenon
Firehazard!
Hotpartsof
theboiler
maydamage
electrical
conductors
Makesureallconductors
areplacedinthe
requiredcableguides
andpassoverthe
thermalinsulaonofthe
boiler.
7.3. Connecng the boiler to the
heanginstallaon.
*Such connecon must be
performed by a technician /
service shop authorized for such
operaons.
Whentheboilerisconnectedtoaheang
system,itismandatorytoinstalla3bar
reliefvalveandexpansionvessel.
No shut-o ngs may be installed
betweenthereliefvalve,expansionvessel
andboiler.
*
Itismandatorytoinstallathree-
way valve (Laddomat or similar)
orafour-waymixingvalvewhich
to ensure that the temperature
of the heang medium fed into
the boiler from the heang
installaonisatleast65°С.

TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL
TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL
12
7.4. Connecng the safety heat
exchanger
*Such connecon must be
performed by a technician /
service shop authorized for such
operaons.
The heang boiler is equipped with
safetyheatexchanger(coolingcircuit).It
connects to the water system through a
thermostacvalve.Incaseofoverheang,
thethermostacvalvefeedsincoldwater
from the water mains which passes
throughtheheatexchangerandabsorbs
theheatintheboiler.
1. Water supply network (pressure 6-10 bar)
2. Drainage (sewerage)
3. Boiler WBS Acve
4. Safety heat exchanger inlet
5. BVTS valve sensor
6. Safety heat exchanger outlet
Diagram 6
The water is then discharged into the
sewage system. This arrangement
ensures safe evacuaon of the excess
heat without the need for addional
energy.Thisguaranteesthatthewaterin
the boiler will not exceed the maximum
safelevelof95°C.
The minimum operang pressure of the
coolingwaterinthesafetyheatexchanger
mustbewithintherange2-10bar.
Aowrateofatleast12l/minisrequired.
Connect the safety heat exchanger
accordingtothehydraulicdiagramusing
thermostac valve. Install a lter on the
inletbeforethethermostacvalve.
7.5. Connecondiagrams
*Such connecons must be
performed by a technician /
serviceshopauthorizedforsuch
operaons.

13
TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL
TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL
≥65 С
о
T1
T2
TB
TEG
PBB
Diagram 7.
Connecon of PyroBurn Lambda boiler to P type buer tank and three-way valve
/* An extra thermostat reads the temperature inside the buer tank and upon reaching the set
temperature switches on or o the central heang circuit pump./

TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL
TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL
14
≥65 С
о
T3
TB
TEG T1
T2
PBB
PDHW
T
Diagram 8.
Connecon of PyroBurn Lambda boiler to solar tank SN, buer tank P and three-way valve
/* An extra thermostat reads the temperature inside the buer tank and upon reaching the set
temperature switches on or o the central heang circuit pump./

15
TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL
TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL
≥65 С
о
T1
T2
TB
TEG
PBB
T
Diagram 9.
Connecon of PyroBurn Lambda boiler to combi tank KSC2 and three-way valve
/* An extra thermostat reads the temperature inside the buer tank and upon reaching the set
temperature switches on or o the central heang circuit pump./

TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL
TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL
16
8. FILLING THE HEATING INSTALLATION
Table 5
Problem Prevenon
Possible installaon damage due
tostrainsinthematerialcausedby
temperaturedierences.
Fill the heang installaon only in cold condions (inlet
temperaturemustnotexceed40°C).
Dangerofinstallaondamagedue
toaccumulaonofdeposits
Condensate formaon and tar
deposits may shorten boiler’s
operaonallife.
-Donotoperatetheheangboilerforalongperiodofme
inparalloadmode
-Thetemperatureattheboilerinletmustnotbelessthan
65°C,boilerwatertemperaturemustbebetween80and
85 °C.
-Usetheboilerforashortperiodtoheatwarmwaterinthe
summer.
9. BOILER OPERATION
9.1. Loadingtheboiler
Whenlighngtheboilerfortherstme,
a condensate is formed which is later
drained(thisisnotafaultintheboiler).
When burning moist wood, the boiler
stops working eecvely and fuel
consumpon increases signicantly,
desired output is not achieved and the
operaonallifeoftheboilerbodyandthe
chimneyisshortened.
Fuel is loaded in the upper combuson
chamberanditisrecommendedistoload
logs of length equal to the combuson
chamber length and stack them ght
insidewithleastpossibleairgaps.
Recommendations for fuel loading:
1. Keep air openings (upper chamber)
cleanfromash/Diagram10/.
Cloggingofairopeningsmayaffectboiler
operation.
2.Stackingfirewoodinboilerchamber.
Wood in the chamber must be neatly
arrangedandnotthrown,asisillustrated.
This is a top plan view of the boiler
chamber/Diagram11/
Diagram 10
Diagram 11
An important condition for the smooth
runningofthepyrolysiscombustionisthe
upperchambertobewelltightwithfuel,
i.e. with minimal air gaps between the
woodpieces.

17
TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL
TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL
When stacking the wood in the firebox
keep clear the opening between upper
andlowerchambers.
Theentryofalargeloginthisopeningcan
affectthepyrolyticcombustion
Recommendedapproximatedimensionsoffirewood:
Type of
firewood
А,cm 8 - 10 7 - 9 5
B,cm 12 - 15 13-16 20
3.Combustionofdisproportionatefirewood:
3.1.Loadingofbiganddisproportionatefirewood
Place disproportionate firewood upon an already stacked
standardsizefirewoodatupperpartofboilerchamber
3.2.Loadingofsmallbrushwood,piecesofwoodandjoiner
waste.
Werecommendfirsttoarrangestandardsizedfirewood/at
least3lines/andthenstackallthelittlepiecesofwoodand
disproportionatelyonthem.Stackthefirewoodtightinside
withleastpossibleairgaps.
Remember the rule: Smallest and fine pieces of wood
shouldbeplacedlast!
3.3.Neverloadsmallbrushwood,piecesofwoodandjoiner
wasteinthelowerpartofchamber!Prohibitedtheburning
of plastics and other paper packaging. This can affect to
blockageofboiler.
Prohibited the burning of flammable substances or
mixtures: diesel, gasoline, gunpowder, turpentine, paint
andthelike.Dangerofexplosion.

TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL
TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL
18
9.2 Combusonadjustment
Boom chamber door as well as all
inspecon openings must be closed and
sealed. Inside the boiler there should
notbeanyreorsmoke.Press F4keyto
start calibraon of lambda sensor. Over
a period of 2-3 min. the lambda sensor
is calibrated and can shi on to ignion
of the boiler. This calibraon is only
necessarybeforeigningtheboiler.Once
the boiler has entered work mode no
calibraonisrequiredbetweenreloads.
TostartignionoftheboilerpressF1 key
and load the boiler with the inial dose
of twigs and small wood, then kindle
them.Itisnecessarytomakeagoodglow
bedinorderthatrewoodloadedinthe
combusonchambersubsequentlymakes
a good re. During the glow-making
period it is necessary to hold the upper
doorslightlyopentoallowexhaustgases
be suconed through the slit in its top
part.Onceyouhavetheglowbedready,
top up with rewood to ll the enre
volumeofthecombusonchamber.
Thesuconfanintherearprovidesforthe
maintenanceofcombusonprocessinthe
boiler.Theinowoffreshairtotheboiler
is made possible by 2 aps operated by
motoractuators.Animportantcondion
isthatapsbewellcentered beforethe
actuatorisfastenedtotherespecveap.
Sustainablecombusonprocessdepends
ontheproperadjustmentoftheapsand
thecorrectsengsofthecontroller.
9.3. Requirementsconcerningcleaning
andmaintenanceoftheboiler.
*Cauon! Hot surfaces.
Before cleaning the boiler, make
sure the re in it has died out and
the boiler has cooled down.
9.3.1.Cleaning and maintenance by
customer.
-Exploitaon of the boiler and the type
ofusedfueldeterminehowoenhave
to clean the boiler residues from the
combusonprocess.
-Werecommendcleaningtheashesfrom
the upper chamber of the boiler to be
doneevery 3-4 days.Inthecasewhere
ashes has reached faster the level of
primary air openings, then ashes must
be cleaned immediately (see diagram
10). Do not let the ashes clog these
holes.
-The ash accumulatesin lowerchamber
aswell.Cleanashwhenitslevelreaches
1/3oflowerchambervolume(Diagram
13). Uncleaned ash a ects boiler
operaon.
Diagram 12
9.3.2. Cleaning and maintenance by
authorizedinstaller/service
Boilercleaningandmaintenancemustbe
performedbyatechnician/serviceshop
authorized for such operaons. Before
the beginning of heang season must
be done inspecon and maintenance of
followingboilerparts:
1. Adjustment of boiler doors again.
Make sure the doors seal well. If
necessary, replace insulaon rope at
the door with a new one. Make sure
that the new insulang rope is placed
correctly,followingexactlythegeometry
ofchannel.Pulltheropewelltothedoor
cornersbyusingascrewdriver.

19
TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL
TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL
Tightlyclosing thedoorsiscontrolled by
hexagonal plate (A) located under each
hingenut(B).
Diagram 13
2.Cleaningofthefaninbackboilerpart.
Use a switch S13 to remove the nuts (4
pieces)thatsecurefanplate.Disassemble
thefanwithplate.Itispossiblethatthe
plate is stuck to the gasket. Thoroughly
clean the fan turbine by using a brush.
Remove the ash and soot accumulaon
intheplacewherethefanwasmounted.
Replace the plate gasket with new one.
Assemblethefanbacktotheboiler.
3.Cleaningofboilerupperchamber.
Disassemble protecve steel plates from
the upper chamber and clean the area
behindthem.
Thoroughlycleantheashusing apaddle
brush and a vacuum cleaner (hoover).
Assemble protecve steel plates back to
the upper chamber. Make sure they are
properlyseated.
Dismantlingoftheprotecveplates
1.Theplateisrivet-mounted.
2.Slide the plate upwards so as to catch
therivetinthewideporonoftheslot.
3.Pullthereleasedplateaway.
Diagram 14
4. Cleaning of boiler lower chamber /
Diagram16/.
Disassemble ceramic elements from
lower chamber. Follow the sequence of
diagram.
Diagram 15
•Disassembletheboomceramicpartof
combusonchamber(1and2).
•Disassemble both ceramic sides by
smoothrotaonofthedetail(3and4).
•Disassemble back ceramic part: step
one-pulltheboompartforward;step
two-twistthedetailandtakeitout(5).

TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL
TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL
20
•Thoroughlycleanthelowerchamber.
•Assemble the ceramic elements back
intothelowerchamberinreverseorder
– back (5), both sides (3 and 4) and
boom(2and1).
5. Cleaning of fume exhaust tubes of
boiler.
Diagram 16
•Uppercleaningopeningislocatedontop
ofboiler.Itisprotectedbytwocovers.
Unscrewthetwowingnuts.Disassemble
the decorave lid of upper cleaning
openingonboilercasing(1)
•Unscrewthetwowingnuts.Disassemble
the lid of upper cleaning opening on
boilerbody(2)
Diagram 17
•Remove the cleaning system (diagram
17) using a wrench S13 and S7.
Thoroughly clean fume exhaust tubes
(3)ofsootdeposits.Usethebrushfrom
equipmentdelivery.
•Lowercleaningopeningislocatedbehind
theboiler,lowdown.Itisprotected by
twocovers.Unscrewthetwowingnuts.
Disassemblethedecoravelidoflower
cleaningopeningonboilercasing(4)
•Lower cleaning opening. Unscrew
the two wing nuts. Disassemble the
decoravelidoflowercleaningopening
onboilercasing(5).
•Remove soot accumulaon aer the
cleaningoffumeexhausttubes
•Assemble the lid of upper cleaning
opening on boiler body (2). Make sure
thelidisplacedcorrectlyandght.
•Assemble the decorave lid of upper
cleaningopeningonboilercasing(1).
•Assemble the lid of lower cleaning
opening on boiler body (5). Make sure
thelidisplacedcorrectlyandght.
•Assemble the decorave lid of lower
cleaningopeningonboilercasing(4).
9.4. Important recommendaons for
long-lasngandcorrectoperaonofthe
boiler
•Pleaseperformperiodicmaintenanceof
the boiler as described in instrucons,
secon9.2.
•Theallowedmoisturecontentofthefuel
usedmustnotexceed15%÷20%.
•Gas emission in the combuson
chambermayresultintheformaonof
tar and condensate (acids). Therefore,
a mixing valve must be installed and it
mustbeadjustedsothattheminimum
temperature of the water returning in
the boiler is 65°С. This extends the life
spanoftheboileranditswarranty.The
operang temperature of the water in
