OWNER’S OPERATING MANUAL
MM3156A DRUM SANDER
Please keep this operating manual for future reference.
0101

MM3156A DRUM SANDER
１
THANK YOU FOR BUYING A WIDE DRUM SANDER
Your new 16”-32” Wide Drum Sander has been engineered and manufactured to high standard for
dependability, ease of operation, and operator safety. Properly cared for, it will give you years of
rugged, trouble-free performance.
Caution: Carefully read through this entire owner’s manual before using your new drum
sander. Pay close attention to the Rules for Safe Operation, Warnings, and Cautions. If
you use your sander properly and only for what it is intended, you will enjoy years of safe,
reliable service.
The purpose of safety symbols is to attract your attention to possible dangers. The safety symbols,
and the explanations with them, deserve your careful attention and understanding. The safety
warnings do not by themselves eliminate any danger. The instructions or warnings they give do not
substitute for proper accident prevention measures.
SAFETY ALERT SYMBOL
Indicates caution, warning, or danger. May be used in conjunction with other symbols
photographs.
DANGER: Failure to obey a safety warning will result in serious injury to yourself or
others. Always follow the safety precautions to reduce the risk of fire, electric shock, and
personal injury.
WARNING: Failure to obey safety warning can result in serious injury to yourself or to
others. Always follow the safety precautions to reduce the risk of fire, electric shock, and
personal injury.
CAUTION: Failure to obey safety warning may result in serious injury to yourself or to
others. Always follow the safety precautions to reduce the risk of fire, electric shock, and
personal injury.
NOTE: Advise you of information or instructions vital to the operation or maintenance of the
equipment.
RULES FOR SAFE OPERATION
KNOW YUR POWER TOOL
Safe operation of this power tool requires that you read and understand this owner’s manual and all
labels affixed to the tool. Learn its applications and limitations as well as the potential hazards
peculiar to a drum sander. Keep this manual readily available for future reference.

MM3156A DRUM SANDER
２
IMPORTANT
Servicing of a tool requires extreme care and knowledge of the system and should be performed only
by a qualified service technician.
WARNING: Do not attempt to operate this tool until you have read thoroughly and
understand completely all instructions, safety rules, etc, contained in this manual. Failure
to comply can result in accidents involving fire, electric shock, or serious personal injury.
Save the Owner’s Manual and review frequently for continuing safe operation and
instructing others who may use this tool.
WARNING: When using power tools, basic safety precautions should always
be followed to reduce the risk of fire, electric shock, and personal injury,
including the precautions beginning on the following page.
READ ALL INSTRUCTIONS
SAFETY PRECAUTIONS
1. KEEP GUARDS IN PLACE and in good working order.
2. REMOVE ADJUSTING KEYS AND WRENCHES. Get in the habit of checking to see that hex
keys and adjusting wrenches are removed from the tool before turning it on.
3. KEEP THE WORK AREA CLEAN. Cluttered work areas and work benches invite accidents.
4. DO NOT USE IN DANGEROUS ENVIRONMENTS. Do not use power tools near gasoline or
other flammable liquids, in damp or wet locations, or expose them to rain. Keep the work area
well lighted.
5. KEEP CHILDREN AWAY FROM POWER TOOLS. All visitors should be kept at a safe
distance from the work area.
6. MAKE THE WORKSHOP CHILDREN-PROOF with padlocks and master switches or by
removing starter keys.
7. DO NOT FORCE THE TOOL. It will do the job better and safer at the rate for which it was
designed.
8. USE THE RIGHT TOOL. Do not force the tool or attachment to do a job for which it was not
designed.
9. USE THE PROPER EXTENSION CORD. Make sure your extension cord is in good condition.
When using an extension cord, be sure to use one heavy enough to carry the current your
product will draw. An undersized cord will cause a drop in line voltage resulting in loss of power
and overheating.
10. WEAR PROPER APPAREL. Do not wear loose clotning, glove, neckties, rings bracelets, or
other jewelry that could get in moving parts. Non-slip footwear is recommended. Wear protective
covering over long hair.
11. ALWAYS WEAR SAFETY GLASSES. Everyday eye glasses have only impact-resistant lenses;
they are NOT safety glasses.
12. SECURE THE WORK. Use clamps or a vise to hold work when practical. It is safer than using
your hands to operate the tool.

MM3156A DRUM SANDER
３
13. DO NOT OVERREACH. Keep proper footing and balance at all times.
14. MAINTAIN THE TOOL WITH CARE. Keep saw toos sharp and clean for the best and safest
performance.
15. DISCONNECT POWER TOOLS BEFORE SERVICING or before changing accessories such as
the blade.
16. REDUCE THE RISK OF UNINTENTIONAL STARTING. Make sure the switch is in the OFF
position before plugging in the tool.
17. USE ONLY THE MANUFACTURER’S RECOMMENDED ACCESSORIES. Consult this
owner’s Manual for recommended accessories. Using improper accessories may increase the
risk of injury.
18. NEVER STAND ON THE TOOL. Serious injury could occur if the tool is tipped or if the blade is
unintentionally contacted.
19. CHECK DAMAGED PARTS. Before further use of the tool, a guard or other part that is damaged
should be carefully checked to determine if it will operate properly and perform its intended
function. Check for alignment of moving parts, binding of moving parts, mounting, and any other
conditions that may affect its operation. A guard or other part that is damaged should be properly
repaired or replaced.
20. DIRECTION OF FEED. Feed work into a blade or cutter against the direction of rotation of the
blade or cutter only.
21. NEVER LEAVE THE TOOL RUNNING UNATTENDED. Turn off the power. Do not leave the tool
until it comes to a complete stop and is disconnected from power source.
22. STAY ALERT. Never operate a power tool when tired or while under the influence of drugs,
alcohol, or medication.
23. MAKE SURE A TOOL IS CONNECTED only to the voltage marked on the nameplate.
24. NEVER USE A TOOL if its cover or any bolts are missing. If the cover or bolts have been
removed, replace them prior to use. Maintain all parts in good working order.
25. NEVER START A TOOL when its rotating component is in contact with the work piece.
26. SAVE THESE INSTRUCTIONS. Refer to them frequently and use to instruct other users. If you
loan someone this tool, also loan them these instructions.
WARNING: The operation of any power tool can result in foreign objects being thrown
into your eyes, which can result in severe eye damage. Before commencing power tool
operation, always wear safety goggles or safety glasses with side shields and a full face
shield when needed. We recommend Wide Vision Safety Mask for use over eyeglasses
or standard safety glasses with side shields.
ADDITIONAL SAFETY RULES FOR WIDE DRUM SANDERS
1. DURING NORMAL OPERATIONS, there is a tendency for the tool to tip over, side, or walk on
the supporting surface.Always secure tool to workbench or workstand.
2. NEVER MAKE A SANDING OPERATION with the sanding drum dust cover or drive guard
removed.
3. NEVER MAKE A SANDING PASS deeper than 1/32” (.03125).

MM3156A DRUM SANDER
４
4. DO NOT SAND MATERIAL shorter than 3” or narrower than 3/4”.
5. MAINTAIN THE PROPER RELATIONSHIP between the infeed and outfeed surfaces and the
sander drum path.
6. SUPPORT THE WORK PIECE ADEQUATELY at all times during operation; maintain control of
the work at all times.
7. DO NOT BACK THE WORK toward the infeed table.
8. DO NOT ATTEMPT TO PERFORM an abnormal or little used operation without the use of sturdy
and adequate jigs, fixtures, stops, and a thorough understanding of the operation being
performed.
9. BEFORE STARTING, re-check to make certain adjustments are correct and all locks and screws
are tight.
10. ALWAYS STOP THE MOTOR and disconnect the power source before making any adjustments
or changing abrasve strips.
11. STOP THE MACHINE and re-check the motor/drum mounting bolts and feed rollers for tightness
after about 50 hours of operstion. (See Figure8.)
12. DO NOT FORCE-FEED THE WORK PIECE through the machine. Let the sander apply the
proper feed rate.
13. CHECK THE FEED BELT occasionally to be sure there is no debris or sawdust between any
components.
14. SAND ONLY SOUND LUMBER; there should be no loose knots and as few tight knots as
possible. Make sure the work piece is free from nails, screws, stones, or other foreign objects
that could damage the sanding drum or feed belt.
15. NEVER STAND DIRECTLY IN LINE with either the infeed or outfeed sides. Stand to one side.
16. MAKE SURE THE ABRASIVE STRIP IS ATTACHED as described in the operation instructions.
An improperly attached abrasive could come loose during operation and damage the work piece
or intenal components.
17. NEVER PUT YOUR FINGERS into the dust port or under the drum dust cover. (See Figure2.)
18. ALLOW THE SANDING DRUM to reach full speed before using the Wide Drum Sander.
GROUNDING INSTRUCTIONS
1. In the event of an electrical malfunction or breakdown, grounding provides a path of least
resistance for electric current to reduce the risk of electric shock. This tool is equipped with an electric
cord having an equipment grounding conductor and a grounding plug. The plug must be plugged into
a grounding outlet. The plug must be plugged into a matching outlet that is properly installed and
grouded in accordance with all local coodes and ordinances.
2. Do not modify the plug provided.If it will not fit the outlet, have the proper outet installed by a
qualified electrician.
3. Improper connection of the equipment-grounding conductor can result in a risk of electric shock.
The conductor with insulation having an outer surface that is green with or without yellow stripes is
the equipment-grounding conductr. If repair or replacement of the electric cord or plug is
necessary,do not connect the equipment-grounding conductor to a live terminal.
4. Check with a qualified electrician or service personnel if the grounding instructions are not

MM3156A DRUM SANDER
５
completely understood or if in doubt as to whether the tool or outlet is properly grounded.
5. Use only 3-wire extension cords that have grouding plugs, and the receptacles must accept the
tool’s plug.
6. Have a damaged or worn cord repaired or replaced immediately by a qulified technician.
EXTENSION CORDS
When using a power tool at a considerable distace distance from a power source,use an extension
cord heavy enough to carry the curremt that the tool will draw. An undersized extension cord will
cause a drop in line coltage,resulting in a loss of power and ocerheating.
When working with the tool outdoors, use an extension cord that is designed for outdoors.
Before using an extension cord,inspect it for loose or exposed wires and cut or worn insulation
Also, do not use an extension cord on a take up reel. The electric current passing through the
extension cord will generate heat, and if the cord is wrapped around a reel, a heat buildup will result
that could melt the insulation, causing a fire and/or electric shock.
CAUTION: Keep the cord away from the sanding area and position the cord so that it
will not be caught on lumber, tools, or other objects during sanding.
INTRODUCTION TO DRUM SANDING
FUNCTION
Drum sanding, sometimes referred to as ”abrasive planting” is a repetitive process of
sanding both sides of wooden stock to a desired thickness and/or smoothness. When
this performed correctly, both face surfaces will be parallel to one another.
Do not confuse drum sanding with thickness planning! Drum sanding gradually
removes material in increments of 1/32” or less depending on sanding grit, stock
hardness, stock hardness, stock width, etc. Thickness planning,on the other hand, is for
quick, bulk material removal at rates up to 1/8” per pass with portable machines. If you
have used a thickness planer to smooth and dimension stock you will quickly learn to
work with your new drum sander and not against the machine.Be patient, let the drum
sander do the work,1/32”or less per pass for best results.
The most common mistake made with a drum sander is forcing it to remove too much
material too fast. Variables such as sandpaper grit, stock width, wood type, feed rate,
and moisture content all influence how much material can be removed in a single pass.

MM3156A DRUM SANDER
６
DRUM SANDING ADVANTAGES
One advantage of the wide drum sander is that you can work with material up to 32”
wide with this unit because of its open side design. Although you still abrasive sand with
the grain, you do not have to read the grain to prevent tear-out. This is especially
important with thin stock and material with convoluted or mixed grain directions, like bulr,
crotch, and tiger patterns.
Drum sanders exert much less pressure on stock than a thickness planer, giving you the
capability of working with very thin material. You have the ability to sand to veneer
thickness if desired, expanding your woodworking horizons. You can also sand smaller
lengh wood, odd-shaped pieces, and end-grain.
REMOVING LUMBER CUP
The ideal machine for removing cup from luber is a jointer. However, because of the
minimal pressure exerted by the drum sander, it is possible to remove cup, since the
lumber is not compressed flat on feed belt and table. Be patient, this process can take
quite a while deoending on cup depth. Feed the stock into the machine cup crown up
(edges resting on feed belt) and use a coarse grit abrasive. Repeat until the crown is flat.
With one face now flat, flip the board over and sand it flat. Do not be shocked by how
thin the board may become after all cup has been removed.
Board warp and twist will not be remedied by a drum sander, or a planer, for that matter.
Always inspect your lumber for warp and twist before drum sanding since it is prone tp
hanging-up in the machine, shorter length lumber in this condition is especially
troublesome.
PLAN YOUR WORK IN ADVANCE
Planning your drum sanding operations in advance will minimize setups, work time, and
frustration level. Group material to be sanded by thickness and grit requirements and
work through each required sanding grit starting with the thickest material through the
thinnest, then change over to next finer grit and begin the process again.
We suggest that you experiment with the varions sanding grits and wood species to
determine the results you can expect before ruining project material. With new set-ups,
always test with scrap lumber before sanding your project material.
WOOD SPECIES TO BE CAUTIOUS WITH
Highly resinous species will tend to quickly clog (load-up) abrasives and in many cases
abrasive loading cannot be removed with belt cleaning sticks.The most notorious
abrasive loaders are some common pine species. It is nearly impossible to clear the
abrasive of the pitch, sap sawdust combination.
Be aware of species that have toxic properties, such as members of the rosewoodfamily

MM3156A DRUM SANDER
７
(i.e.cocobola). Despite dust control, you may inhale small airborne particulate or suffer
allergic reactions through handing of stock. Wear a mask and gloves for extra protection.
UNPACKING
1. Carefully remove all parts from the shipping carton.
2. Do not discard the packing materials until you have identified all the parts using the
Loose Parts List.
3. If you are missing a part, contact your dealer to obtain it.
4. Examine all parts to make sure that no breakage has occurred during shipping. Any
damaged parts should be replaced before attempting to use the tool.
LOOSE PARTS LIST
The following items are included with the Wide Drum Sander.
1 - Owner’s Operating Manual
1 - Height adjustment handle
1 - Height adjustment crank (See Figure 3.)
2 –Extension table
1 –Set of machine support
1 –Dust collection port elbow
Familiarize yourself with the follwing components and features of the Wide Drum Sander
using Figures 2, and 3 before connecting the power cord or using the tool.
Height Adjustment Handle Assembly
Dust Collection Port
Elbow
Sanding Drum Dust
Cover
Conveyor Belt
Tracking Adjuster
Stand Mounting
Hole
Sanding Drum
Drive Motor
Conveyor Feed
Motor
Variable Speed
Control Box
Extension Table
Support cabinet

MM3156A DRUM SANDER
８
Figure 1
Figure 2
ASSEMBLY
After unpacking your WDS Wide Drum Sander and checking the Loose Parts List for
missing components, you are ready to assemble and install the Height Adjustment
Handle Assembly.
1. Screw the Height Adjustment Handle into the threaded nut in the Height Adjustment
Crank using a slotted screwdriver until snug. (See Figure 4.)
Figure 3
Conveyor
Feed Motor
Extension
Table
Elevation
Tension
Adjustment
Screws
Evevation Tension
Adjustment Screws
Feeding Conveyor
Sanding Drum
Nip Guard
Sanding Drum
Motor
On/Off Switch and
Variable Speed Control
Box
Height Adjustment
Handle
Height Adjustment
Crank
Threaded Nut

MM3156A DRUM SANDER
９
2. Locate the 4 mm set screw thresded into the side of the Height Adjustment
Crank. Position the Height Adjustment Crank over the Height Adjustment
Shaft with the set screw aligned with the machined flat area on the Height
Adjustment Shaft.
Height Adjustment Shaft (with machined flat)
Figure 4
3. Lower the Height Adjustment Handle Assembly onto the Height Adjustment Shaft and
tighten the set screw with the Wrench Key. (See Figure 5.)

MM3156A DRUM SANDER
１０
Height Adjustment Handle Assembly
Figure 5
4. Secure the assembled Wide drum Sander to the accessory workstand or to
an adequately stable workbench or stand before operating the machine.
WARNING: To prevent possible serious personal injury, always disconnect the
Wide Drum Sander from the power source before servicing the unit or
changing the abrasive strips.
WARNING: For your own safety, never connect the plug to a source outlet
until you have read and understand the safety and operating instructions for
your Wide Drum Sander.
WARNING: Make certain that the switch is in the OFF position before inserting
the plug into a power source. Do not connect the power until you are ready to
operate the machine. Be sure that the bolts are firmly tightened before
connecting to power source.
CAUTION: The surface to which the Wide Drum Sander is mounted must not
be warped or uneven. Mounting the base to a warped suface will cause
distortion and poor operation.
ADJUSTMENTS
Your Wide Drum Sander was aligned and completely adjusted during assembly.

MM3156A DRUM SANDER
１１
However, due to stresses imposed on the unit during shipment, you may need to adjust
or align your unit or return it to perfect alignment. It is very important that the following
adjustments be performed as described.
WARNING: Never make any adjustments with the unit connected to the power source.
Failure to heed this warning can result in serious personal injury.
WARNING: Always secure tool to workbench or workstand to avoid tendency for tool
to tip over, slide, or walk on the supporting surface. Failure to secure tool can result in
serious personal injury.
SANDING DRUM DEFLECTION
Before beginning the sanding drum alignment procedures outlined in the following
section, ensure that minimal upward deflection of the sanding drum occurs when
sanding. The three primary causes of excessive sanding deflection are:
1. Excessive depth of cut. Decrease the depth of cut to minimize pressure on the
sanding drum assembly. Refer to the Introduction to Drum Sanding
section for hints regarding depth of cuts.
2. Loose Elevation Tension Screws. Refer to Step 1 in the Drum Alignment section
for hints regarding depth of cuts.
3. Loose Motor/Sanding Drum Assembly Mounting Bolts. (See Figure 6.) Check the
tightness of the four (4) bolts, 2 upper and 2 lower, and tighten as needed.
Figure 6
DRUM ALIGNMENT
WARNING: To prevent possible serious personal injury, always disconnect the wide
Drum Sander from the power source before serving the unit, aligning, or making any
adjustments.
1. Check the tightness of the Elevation Tension Adjustment Screws (Figure 7).
The tightness of these screws must be adjusted to allow smooth height
Motor/Sanding Drum Assembly
Mounting Bolt (2 lower bolts
hidden from view)
Drum Roller and Abrasive Strip
Front Nip Guard

MM3156A DRUM SANDER
１２
adjustments, while ensuring a tight enough fit to limit drum deflection. (If the
screws are too loose, the drum will deflect during use, causing an uneven
sanding surface. If the screws are too tight, sanding drum height adjustments
will be difficult.)
Figure 7
2. To adjust the Elevation Tension Adjustment Screws, loosen the lock nuts, securing
each screw in place. Loosen or tighten each screw, as required, in 1/4 turn increments to
attain the desired fit and smoothness. Retighten the lock nuts to secure the tension
screws in position.
3. Check the sanding drum to conveyor table alignment by first removing the abrasive
strip from the abrasive strip from the drum. The purpose of this adjustment is to achieve
equal distances at point A and point B which will ensure that the drum is parallel to the
feed table and provide uniform sanding. (See Figures 8.)
Elevatation Tension
Adjustment screws

MM3156A DRUM SANDER
１３
Note: Drum frame not depicted for clarity.
Figure 8
If the measurement at A is greater than the same point at B by .020 or less, proceed as
follows:
1. Loosen the 2 outboard conveyor table mounting bolts as shown in Figure 9.
Conveyor Table
Drum

MM3156A DRUM SANDER
１４
Conveyor Tabel Mounting Bolts
Figure 9
2. Slide one or both of the shims (not supplied) as needed under the edge of the
conveyor tabie as shown.
3. Tighten conveyor table mounting bolts. Re-check the measurement at A and at B.
4. Test sand a piece of wood and check for uniform thickness.
If the measurement at A exceeds B by more than .020”, or if distance B is greater than A,
proceed as follows:
1. Loosen the two front and two rear adjistment bolts as shown in Figure 10, thus
allowing the entire drum assembly to pivot.

MM3156A DRUM SANDER
１５
Figure 10
NOTE: If the unit is bolted to a stand or bench, loosen the mounting bolts at the
motor end.
2. Using the Height Adjstment Handle Assembly, lower the drum until the distances at A
and B are equal. Tighten the alignment bolts and the mounting bolts.
3. Test sand a piece of wood and check for uniform thickness. Repeat the above
procedure if necessary.
CONVEYOR FEED BELT TRACKING ADJUSTMENT
Occasioal adjustment of the conveyor feed belt tracking may be required due to belt
stretching. ldeally, the conveyor feed belt should track in the center area of the conveyor
feed belt table.
1. Conveyor feed belt tracking adjustment screws are located on both the inboard and
outboard sides on the rear of the wode drum sander. (See Figures 11 and 12.)
Inboard
Conveyor
Table
Alignment
Bolts.
Front
Inborard
Conveyor
Table
Alignment
Bolts.
Rear

MM3156A DRUM SANDER
１６
Figure 11
Figure 12
2. To tighten the tracking tension, the tracking screw is rotated clockwise while holding
its nut in place with a 7/16” open end wrench (not supplied).To loosen the tracking
tension, the tracking screw is rotated counterclockwise while the nut is held with the
wrench.
3. If the converyor feed belt is tracking towards the inboard (motor side) of the machine,
tighten (add tension) to the tracking adjustment screw on that side of the machine.
NOTE: Due to the width of the conveyor feed belt, tracking adjustments may not
become apparent immediately! Increase the speed of the conveyor feed belt to
hasten the effects of your adjustments. Make small measured corrections of

MM3156A DRUM SANDER
１７
approximately 1/4 turn increments and evaluate the results. RE-adjust as
necessary until the proper tracking solution is found.
HELPFUL HINT
Tighten the side opposite the desired tracking direction. For example, tighten the
right side tracking adjustment to make the conveyor feed belt track left.
OPERATING INSTRUCTIONS
WARNING: Never put your fingers into port or under drum cover.
CAUTION: To avoid damage to your Durm Sander, adequate dust collection must be
must be used during sanding operations. A 2-1/2” port is included in the sanding drum
dust cover for connecting dust collection unit/hose to your Wide Drum Sander.
DRUM HEIGHT CONTROL
The height of the drum is raised by turning the height control knob (refer to Figure 2) in a
clockwise direction. To lower the drum, turn the height control knob in the
counter-clockise direction. The depth of the movement is approximately 1/64” per 1/4
turn in either direction. One complete turn is 1/16”. Depth settings can be measured
using the depth indicator scale located on the right side of the drum support frame.
NOTE: Depth settings used during surface sanding of stock are adjusted by
considering several variables.The hardness of the material, the width of the
material being surfaced, and the feed rate selected are all considered when
determing the amount of material to be removed on each pass. Never remove
more than 1/32”of material in one pass. The variable feed rate is set to prevent
burning and provide a smooth sanded surface on different types and widths of
materials. As a general rule,1/4 turn or 1/64” or less is recommended stock
removal for coarser grits and softer woods, while 1/8 of a turn or 1/128” may be
more desirable with harder woods and/or finer grits if abrasives. When selecting
the rate of feed for the material being surfaced, the wider the material, the slower
the feed rate to be set. Similary, the harder the wood, the slower the feed rate.
Some experimenting and practice will be required to become familiar with the sanding
performance of your Wide Drum Sander. While performing a surfacing operation with
your Wide Drum Sander closely parallels the wide surface preparation of a planer, a
planer is much more capable of making deeper passes due to its characteristic knives,

MM3156A DRUM SANDER
１８
while a Wide Drum Sander is limited to its abrasive material for stock removal.
SANDING
1. With power off, rest stock on the feed table and advance the stock to a point so that
you can adjust height of sanding drum to equal thickness of stock at its greatest
point.
2. Connect and turn on dust collection equipment.
3. Adjust feed rate to match sanding requirements and width of stock.
4. Turn on unit and rest stock on the feed conceyor table allowing the fee bekt to carry
the stock into and engage the sanding action of the drum. Support long stock as
necessary during the feed operation. Once the sanding operation feed allows,
reposition yourself to the outfeed side of the machine to accept, support, and control
the board as it exits the Wide Drum Sander.
NOTE: Do not apply upward or downward pressure when supporting and guiding stock
through the sander. To do so may induce snipe (sander drum dig-in) into the sanded
stock.
5. Reverse the feed direction of the stock on successive passes, while adjusting the
depth of cut using the height adjustment handle assembly (refer to Figure2). Several
variables affect the proper depth of cut selected. They are: abrasive grit choice, width
of stock, hardness of stock, feed rate and moisture content of stock.
INSTALLING NEW REPLACEMENT ABRASIVE STRIPS
WARNING: To prevent possible serious personal injury, always disconnect the Wide
Drum Sander from the power source before serving the unit or changing the abrasive
strips.
Abrasive strips are available from local dealer in precut strips which require no special
measuing or trimming before installation. The abrasive strips are tapered at the ends to
be wrapped radially around the drum to provide a continuous sanding surface. You may
cut your own strips from bulk stock using the included abrasive strip as a pattern for
cutting your new replacenent strip.
1. Make sure the power swotch is off and disconnect the power cord from the outlet.
2. Using either a precut strip or one which you have cut for use, you begin the abrasive
installation by inserting the tip of the tapered strip into the slot in the left side of the
drum while depressing the clip (Figure13). Approximately one inch of material should
be inserted into the slot to make the connection in the abrasive clip. Release clip
pressure once the inserted tapered end is securely loaded in the clip jaws.

MM3156A DRUM SANDER
１９
Abrasive Cutting Specification
Figure 13
3. Once the abrasive strip is secured in the left clip, stand in front of the unit and radially
wrap the abrasive material. Roll the drum away from you with your left hand while
holding tension on the abrasive strip with your right hand and guiding the material
onto the drum. Use this technique to warp the abrasive strip edge to edge radilly
around the drum. Make sure you do not overlap the material as you wrap the
abrasive (Figure 14).The material should be flush to slightly gapped, but not
overlapped, during the wrap.
Figure 14
4. When you have completely wrapped the drum, keep tension on the strip and insert
the remaining tapered end of the strip into the slot in the drum. Using your right hand,
raise the tensioner clip completely to open the jaws. Insert the tapered end of the
abrasive strip (Figure 15). The tensioner clip will secure and will secure and tension
the abrasive strip during use and will shold tension in the event the strip stretches
during use. If the abrasive strip is not tightly captured, the tensioner clip was not
raised sufficiently to open the jaws properly before inserting the abrasive strip.
