Instruction Manual
MINK Oxygen
Claw Vacuum Pumps
MV 0602 B
0870168409/A0000_en / Original instructions / Modifications reserved 04/01/2018
Busch Produktions GmbH
Schauinslandstraße 1, 79689 Maulburg
Germany

Table of Contents
2 / 24 0870168409_MV0602B_O2_A0000_IM_en
Table of Contents
1 Safety........................................................................................................................... 3
2 Product Description ..................................................................................................... 4
2.1 Operating Principle............................................................................................... 4
2.2 Application ........................................................................................................... 5
2.3 Standard Features................................................................................................. 5
2.3.1 Vacuum Relief Valve..................................................................................5
2.3.2 Temperature Transmitter ...........................................................................5
2.3.3 Flow Control Device ..................................................................................5
2.4 Optional Accessories............................................................................................. 5
2.4.1 Inlet Filter ..................................................................................................5
3 Transport ..................................................................................................................... 6
4 Storage......................................................................................................................... 6
5 Installation................................................................................................................... 7
5.1 Installation Conditions ..........................................................................................7
5.2 Connecting Lines / Pipes ......................................................................................8
5.2.1 Suction Connection....................................................................................8
5.2.2 Discharge Connection................................................................................8
5.3 Filling Oil..............................................................................................................8
5.4 Electrical Connection ............................................................................................9
5.4.1 Wiring Diagram Three-Phase Motor ..........................................................9
5.5 Electrical Connection of the Monitoring Devices ................................................... 11
5.5.1 Wiring Diagram Temperature Transmitter..................................................11
5.5.2 Wiring Diagram Flow Control Device.........................................................11
6 Commissioning............................................................................................................ 11
7 Maintenance................................................................................................................ 12
7.1 Maintenance Schedule.......................................................................................... 13
7.2 Oil Level Inspection .............................................................................................. 13
7.3 Cleaning from Dust and Dirt................................................................................. 14
8 Overhaul...................................................................................................................... 15
9 Decommissioning ........................................................................................................ 15
9.1 Dismantling and Disposal...................................................................................... 15
10 Spare Parts................................................................................................................... 16
11 Troubleshooting........................................................................................................... 17
12 Technical Data ............................................................................................................. 19
13 Oil ............................................................................................................................... 19
14 EU Declaration of Conformity ...................................................................................... 20

Safety | 1
0870168409_MV0602B_O2_A0000_IM_en 3 / 24
1 Safety
Prior to handling the machine, this instruction manual should be read and understood. If
anything needs to be clarified, please contact your Busch representative.
Read this manual carefully before use and keep for future reference.
This instruction manual remains valid as long as the customer does not change anything
on the product.
The machine is intended for industrial use. It must be handled only by technically trained
personnel.
Always wear appropriate personal protective equipment in accordance with the local
regulations.
The machine has been designed and manufactured according to state-of-the-art meth-
ods. Nevertheless, residual risks may remain. This instruction manual highlights potential
hazards where appropriate. Safety notes and warning messages are tagged with one of
the keywords DANGER, WARNING, CAUTION, NOTICE and NOTE as follows:
DANGER
... indicates an imminent dangerous situation that will result in death or serious injuries if
not prevented.
WARNING
... indicates a potentially dangerous situation that could result in death or serious injuries.
CAUTION
... indicates a potentially dangerous situation that could result in minor injuries.
NOTICE
... indicates a potentially dangerous situation that could result in damage to property.
NOTE
... indicates helpful tips and recommendations, as well as information for efficient and
trouble-free operation.

2 | Product Description
4 / 24 0870168409_MV0602B_O2_A0000_IM_en
2 Product Description
CAI IN OFP
CAO ODP OSG OUT
FCD
TTB
IN Suction connection ODP Oil drain plug
OUT Discharge connection CAI Cooling air inlet
OFP Oil fill plug (=Venting valve) CAO Cooling air outlet
OSG Oil sight glass FCD Flow control device
TTB Terminal box with temperature transmitter
NOTE
Technical term.
In this instruction manual, we consider that the term ‘machine’ refers to the ‘vacuum
pump’.
2.1 Operating Principle

Product Description | 2
0870168409_MV0602B_O2_A0000_IM_en 5 / 24
The machine works on the claw principle.
2.2 Application
The machine is intended for the suction of air and other dry, non-aggressive, non-toxic
and non-explosive gases.
The oxygen version is especially designed for conveying gases with an increased oxygen
content (volume content greater than 21% and up to 100%).
Conveying of other media leads to an increased thermal and/or mechanical load on the
machine and is permissible only after a consultation with Busch.
The machine is intended for the placement in a non-potentially explosive environment.
The machine is not capable of maintaining ultimate pressure. The minimum allowed ulti-
mate pressure is to be read from the nameplate of the machine. By means of process
control and/or vacuum relief valves it must be made sure that the minimum allowed ulti-
mate pressure will not be underrun.
The machine is suitable for continuous operation.
Permitted environmental conditions, see Technical Data [►19].
2.3 Standard Features
2.3.1 Vacuum Relief Valve
The ultimate pressure is limited by a vacuum relief valve. The vacuum relief valve is ad-
justed ex-works to the minimum permitted ultimate pressure (see nameplate).
2.3.2 Temperature Transmitter
The temperature transmitter monitors the gas temperature of the machine.
The gas temperature must not exceed the permitted trip signal temperature, see Tech-
nical Data [►19].
A Trip signal must be set, see Wiring Diagram Temperature Transmitter [►11].
2.3.3 Flow Control Device
The flow control device monitors the cooling air volume flow of the machine.
The cooling air volume flow must neither exceed nor underrun the permitted monitoring
speed range, see Technical Data [►19].
A monitoring range is pre-installed, see Wiring Diagram Flow Control Device [►11].
2.4 Optional Accessories
2.4.1 Inlet Filter
The inlet filter protects the machine against dust and other solids in the process gas. The
inlet filter is available with a polyester cartridge.

3 | Transport
6 / 24 0870168409_MV0602B_O2_A0000_IM_en
3 Transport
WARNING
Suspended load.
Risk of severe injury!
• Do not walk, stand or work under suspended loads.
SCH
Mink
BU
Machine weight:
see the technical data or the nameplate
Use both eye bolts!
WARNING
Lifting the machine using the motor eye bolt.
Risk of severe injury!
• Do not lift the machine using the eye bolt fitted to the motor. Only lift the machine as
previously shown.
• Check the machine for transport damage.
If the machine is secured to a base plate:
• Remove the machine from the base plate.
4 Storage
• Seal all apertures with adhesive tape or reuse provided caps.
If the machine is to be stored for more than 3 months:
• Wrap the machine in a corrosion inhibiting film.
• Store the machine indoors, dry, dust free and if possible in original packaging
preferably at temperatures between 0 ... 40 °C.

Installation | 5
0870168409_MV0602B_O2_A0000_IM_en 7 / 24
5 Installation
WARNING
Lack of oxygen regulation knowledge.
Risk of fire!
• Installation, commissioning and maintenance must only be carried out by qualified
personnel who are informed about the applicable safety regulations and trained in the
handling of oxygen.
• Accident prevention regulations or methods must imperatively be complied with.
Seek further information:
- European Industrial Gases Association “EIGA” www.eiga.eu (EIGA SAG NL 79/04).
- Berufsgenossenschaft Rohstoffe und chemische Industrie "BG RCI” www.bgrci.de
(Merkblatt M 034 Sauerstoff).
5.1 Installation Conditions
WARNING
The machine is not absolutely gas tight.
Risk of fire!
• The installation area must be aired in such a way so as to prevent unacceptable levels
of oxygen.
SCH
Mink
BU
~1m
~1m ~1m
~1m
• Make sure that the ambient conditions comply with the Technical Data [►19].
• Make sure that the environmental conditions comply with the protection class of the
motor.
• Make sure that the installation space or location is vented such that sufficient cooling
of the machine is provided.
• Make sure that cooling air inlets and outlets are not covered or obstructed and that
the cooling air flow is not affected adversely in any other way.

5 | Installation
8 / 24 0870168409_MV0602B_O2_A0000_IM_en
• Make sure that the oil sight glass (OSG) remains easily visible.
• Make sure that enough space remains for maintenance work.
• Make sure that the machine is placed or mounted horizontally, a maximum of 1° in
any direction.
• Check the oil level, see Oil Level Inspection [►13].
• Make sure that all provided covers, guards, hoods, etc. are mounted.
5.2 Connecting Lines / Pipes
• Remove all protective caps before installation.
• Make sure that the connection lines cause no stress on the machine‘s connection; if
necessary use flexible joints.
• Make sure that the line size of the connection lines over the entire length is at least as
large as the connections of the machine.
In case of very long connection lines it is advisable to use larger line sizes in order to
avoid a loss of efficiency. Seek advice from your Busch representative.
5.2.1 Suction Connection
NOTICE
Intruding foreign objects or liquids.
Risk of damage to the machine!
If the inlet gas contains dust or other foreign solid particles:
• Install a suitable filter (5micron or less) upstream from the machine.
Connection size:
– G3
Depending on the specific order, other connection dimensions may apply.
5.2.2 Discharge Connection
Connection size:
– R2
Depending on the specific order, other connection dimensions may apply.
• Make sure that the discharged gas will flow without obstruction. Do not shut off or
throttle the discharge line or use it as a pressurised air source.
Unless the aspirated air is discharged to the environment right at the machine:
• Make sure that the discharge line either slopes away from the machine or provide a li-
quid separator or a siphon with a drain cock, so that no liquids can flow back into the
machine.
5.3 Filling Oil
WARNING
Fill the machine with wrong oil type.
Risk of fire!
• Only use oil approved by Busch and suitable for oxygen application, see Oil [►19].

Installation | 5
0870168409_MV0602B_O2_A0000_IM_en 9 / 24
At delivery, the machine is already filled with specific oil "Busch YLC 250 B" which is
suitable for oxygen application.
A lead seal is applied on the oil fill plug (OFP) and the oil drain plug (ODP) in order to
prevent wrong material from being filled in.
Lead seal must only be removed and applied by authorised and trained personnel, seek
advice from your Busch representative.
NOTICE
Remove lead seal without Busch approval.
Loss of Busch liability!
• Ask your Busch representative before filling or draining the oil.
5.4 Electrical Connection
DANGER
Live wires.
Risk of electrical shock.
• Electrical installation work must only be executed by qualified personnel.
• Make sure that the power supply for the motor is compatible with the data on the
nameplate of the motor.
• Provide overload protection according to EN 60204-1 for the motor.
• Make sure that the motor of the machine will not be affected by electric or electro-
magnetic disturbance from the mains; if necessary seek advice from Busch.
• Connect the protective earth conductor.
• Electrically connect the motor.
NOTICE
Incorrect connection.
Risk of damage to the motor!
• The wiring diagrams given below are typical. Check the inside of the terminal box for
motor connection instructions/diagrams.
5.4.1 Wiring Diagram Three-Phase Motor
Delta connection (low voltage): Star connection (high voltage):

5 | Installation
10 / 24 0870168409_MV0602B_O2_A0000_IM_en
Double star connection, multi-voltage
motor with 9 pins (low voltage):
Star connection, multi-voltage motor
with 9 pins (high voltage):
Double star connection, multi-voltage
motor with 12 pins (low voltage):
4
4
4
Star connection, multi-voltage motor
with 12 pins (high voltage):
4
4
4
Delta connection, multi-voltage motor
with 12 pins (middle voltage):
4
4
4
NOTICE
Incorrect direction of rotation.
Risk of damage to the machine!
• Operation in the wrong direction of rotation can destroy the machine in a short time!
Prior to start-up, ensure that the machine is operated in the right direction.
• Determine the intended direction of rotation with the arrow (stuck on or cast).
• Jog the motor briefly.
If the rotation of the motor must be changed:
• Switch any two of the motor phase wires.

Commissioning | 6
0870168409_MV0602B_O2_A0000_IM_en 11 / 24
5.5 Electrical Connection of the Monitoring Devices
5.5.1 Wiring Diagram Temperature Transmitter
Part no.: 0645139055
U = 10 ... 30 VDC
4 ... 20 mA ► -20 … +350°C
2
1
+
-
1
2
3
4
5
6
3
5
6
R
3 = White ; 5 = Red ; 6 = Red
Trip signal:
Ktrip = 250°C (15.676 mA / 194.074 Ω)
5.5.2 Wiring Diagram Flow Control Device
Part no.: 0549167327
Connector: M12x1; 5pin
U = 18 ... 36 VDC
2
L
L+
4
1
3
OUT1
OUT2
4:
2:
1 2
4 3
Minimum Trip signal:
Tripmin. = < 1200 min-1
Maximum Trip signal:
Tripmax. = > 3600 min-1
Pin 1 Ub +
Pin 2 Closer contact
• OUT2 (PNP): switch signal for flow monitoring
Pin 3 Ub -
Pin 4 Closer contact
• OUT1 (PNP): switch signal for flow monitoring
• IO-Link
6 Commissioning
WARNING
Lack of oxygen regulation knowledge.
Risk of fire!
• Installation, commissioning and maintenance must only be carried out by qualified
personnel who are informed about the applicable safety regulations and trained in the
handling of oxygen.
• Accident prevention regulations or methods must imperatively be complied with.
Seek further information:
- European Industrial Gases Association “EIGA” www.eiga.eu (EIGA SAG NL 79/04).
- Berufsgenossenschaft Rohstoffe und chemische Industrie "BG RCI” www.bgrci.de
(Merkblatt M 034 Sauerstoff).

7 | Maintenance
12 / 24 0870168409_MV0602B_O2_A0000_IM_en
NOTICE
Lubricating a dry running machine (process chamber).
Risk of damage to the machine!
• Do not lubricate the process chamber of the machine with oil or grease.
CAUTION
During operation the surface of the machine may reach temperatures of more than
70°C.
Risk of burns!
• Avoid contact with the machine during and directly after operation.
CAUTION
Noise of running machine.
Risk of damage to hearing!
If persons are present in the vicinity of a non noise insulated machine over extended
periods:
• Make sure that ear protection is being used.
• Make sure that the installation conditions (see Installation Conditions [►7]) are com-
plied with.
• Switch on the machine.
• Make sure that the maximum permissible number of starts does not exceed 12 starts
per hour.
• Make sure that the operating conditions are complied with, see Technical Data
[►19].
As soon as the machine is operated under normal operating conditions:
• Measure the motor current and record it as reference for future maintenance and
troubleshooting work.
7 Maintenance
WARNING
Lack of oxygen regulation knowledge.
Risk of fire!
• Installation, commissioning and maintenance must only be carried out by qualified
personnel who are informed about the applicable safety regulations and trained in the
handling of oxygen.
• Accident prevention regulations or methods must imperatively be complied with.
Seek further information:
- European Industrial Gases Association “EIGA” www.eiga.eu (EIGA SAG NL 79/04).
- Berufsgenossenschaft Rohstoffe und chemische Industrie "BG RCI” www.bgrci.de
(Merkblatt M 034 Sauerstoff).

Maintenance | 7
0870168409_MV0602B_O2_A0000_IM_en 13 / 24
WARNING
Use of non-Busch genuine spare parts.
Risk of fire!
• Only use Busch spare parts approved by Busch and suitable for oxygen application.
WARNING
Machines contaminated with hazardous material.
Risk of poisoning!
Risk of infection!
If the machine is contaminated with hazardous material:
• Wear appropriate personal protective equipment.
CAUTION
Hot surface.
Risk of burns!
• Prior to any action requiring touching the machine, let the machine cool down first.
• Shut down the machine and lock against inadvertent start up.
• Vent the connected lines to atmospheric pressure.
If necessary:
• Disconnect all connections.
• Make sure to have an authorisation from Busch to perform any maintenance tasks.
7.1 Maintenance Schedule
The maintenance intervals depend very much on the individual operating conditions. The
intervals given below are desired to be considered as starting values which should be
shortened or extended as appropriate. Particularly heavy duty operation, such as high
dust loads in the environment or in the process gas, other contamination or ingress of
process material, can make it necessary to shorten the maintenance intervals significant-
ly.
Every 3 months • Check the oil level, see Oil Level Inspection [►13].
Every 6 months • Clean the machine from dust and dirt.
Every 6 years • Have a major overhaul on the machine (contact
Busch).
7.2 Oil Level Inspection
• Shut down the machine.
• When the machine is stopped, wait 1 minute before checking the oil level.
MAX
MIN
MAX
MIN
MAX
MIN

7 | Maintenance
14 / 24 0870168409_MV0602B_O2_A0000_IM_en
The oil level should stay constant over the lifetime of the oil. If the level does fall, the
gear is leaky and the machine requires repair.
• Fill up if necessary, see Oil Filling [►8].
7.3 Cleaning from Dust and Dirt
SCH
Mink
BU
4 mm hex key Remove the front cover
and untie the rolled-up cable,
before removing side covers!
SCH
Mink
BU
Clean the ventilation grilles
and cooling fins
4 mm hex key

Overhaul | 8
0870168409_MV0602B_O2_A0000_IM_en 15 / 24
8 Overhaul
NOTICE
Improper assembly.
Risk of premature failure!
Loss of efficiency!
• It is highly recommended that any dismantling of the machine that goes beyond any-
thing that is described in this manual should be done through Busch.
WARNING
Machines contaminated with hazardous material.
Risk of poisoning!
Risk of infection!
If the machine is contaminated with hazardous material:
• Wear appropriate personal protective equipment.
In case of the machine having conveyed gas that was contaminated with foreign materi-
als which are dangerous to health:
• Decontaminate the machine as well as possible and state the contamination status
in a ‘Declaration of Contamination’.
Busch will only accept machines that come with a completely filled in and legally binding
signed ‘Declaration of Contamination’.
(Form downloadable from www.buschvacuum.com)
9 Decommissioning
• Shut down the machine and lock against inadvertent start up.
• Vent the connected lines to atmospheric pressure.
• Disconnect all connections.
If the machine is going to be stored:
• See Storage [►6].
9.1 Dismantling and Disposal
• Drain the oil.
• Separate special waste from the machine.
• Dispose of special waste in compliance with applicable regulations.
• Dispose of the machine as scrap metal.

10 | Spare Parts
16 / 24 0870168409_MV0602B_O2_A0000_IM_en
10 Spare Parts
NOTICE
Use of non-Busch genuine spare parts.
Risk of premature failure!
Loss of efficiency!
• The exclusive use of Busch genuine spare parts and consumables is recommended for
the proper function of the machine and for granting of warranty.
WARNING
Use of non-Busch genuine spare parts.
Risk of fire!
• Only use Busch spare parts approved by Busch and suitable for oxygen application.
If other parts are required:
• Contact your Busch representative for the detailed spare parts list.

Troubleshooting | 11
0870168409_MV0602B_O2_A0000_IM_en 17 / 24
11 Troubleshooting
DANGER
Live wires.
Risk of electrical shock.
• Electrical installation work must only be executed by qualified personnel.
CAUTION
Hot surface.
Risk of burns!
• Prior to any action requiring touching the machine, let the machine cool down first.
SCH
Mink
B
U
CPL IS VRE
Problem Possible Cause Remedy
The machine does not start. The motor is not supplied
with the correct voltage.
• Check the power supply.
The motor is defective. • Replace the motor.
The coupling (CPL) is de-
fective.
• Replace the coupling
(CPL).
The machine does not reach
the usual pressure on the
suction connection.
The inlet screen (IS) is par-
tially clogged.
• Clean the inlet screen (IS).
The vacuum relief valve
(VRE) is misadjusted or de-
fective.
• Replace the vacuum relief
valve (VRE)
The inlet filter cartridge (op-
tional) is partially clogged.
• Replace the inlet filter
cartridge.
Internal parts are worn or
damaged.
• Repair the machine (con-
tact Busch).

11 | Troubleshooting
18 / 24 0870168409_MV0602B_O2_A0000_IM_en
The machine runs very nois-
ily.
Worn coupling (CPL). • Replace the coupling
(CPL).
Oil level too low. • Top up oil.
Defective bearings. • Repair the machine (con-
tact Busch).
The machine runs too hot. Insufficient cooling. • Remove dust and dirt
from the machine.
Ambient temperature too
high.
• Observe the permitted
ambient temperature, see
Technical Data [►19].
Temperature of the process
gases at the inlet too high.
• Observe the permitted
gas inlet temperature, see
Technical Data [►19].
Oil level too low. • Top up oil.
For the solution of problems not mentioned in the troubleshooting chart contact your
Busch representative.

Technical Data | 12
0870168409_MV0602B_O2_A0000_IM_en 19 / 24
12 Technical Data
MV 0602 B
Nominal pumping speed (50Hz / 60Hz) m³/h 500 / 600
Ultimate pressure hPa (mbar) abs. see nameplate
Nominal motor rating (50Hz / 60Hz) kW 11.0 / 12.6
Permitted motor speed range min-1 600 - 3600
Noise level (ENISO2151) at 400 hPa (mbar) abs.
suction pressure (50Hz / 60Hz)
dB(A) 75 / 79
Ambient temperature range °C 0 … 40
Ambient pressure Atmospheric pressure
Oil capacity l 1.2
Temperature transmitter: Trip signal °C 250
Flow control device: Monitoring speed range
Trip signal (low)
Trip signal (high)
min-1
< 1200
> 3600
Weight approx. kg 472
13 Oil
YLC 250 B
Part number 0.5L packaging (~1 kg) 0831 131 400
Part number 1.0L packaging (~2 kg) 0831 108 878
Part number 5.0L packaging (~10 kg) 0831 108 879

14 | EU Declaration of Conformity
20 / 24 0870168409_MV0602B_O2_A0000_IM_en
14 EU Declaration of Conformity
This Declaration of Conformity and the CE-mark affixed to the nameplate are valid for the machine within the
Busch scope of delivery. This Declaration of Conformity is issued under the sole responsibility of the manufacturer.
When this machine is integrated into a superordinate machinery the manufacturer of the superordinate machinery
(this can be the operating company, too) must conduct the conformity assessment process for the superordinate
machine or plant, issue the Declaration of Conformity for it and affix the CE-mark.
The manufacturer Busch Produktions GmbH
Schauinslandstr. 1
DE-79689 Maulburg
declare that the machine(s): MINK ‘Oxygen’ MV 0602 B
has (have) been manufactured in accordance with the European Directives:
– ‘Machinery’ 2006/42/EC
– ‘Electromagnetic Compatibility’ 2014/30/EU
– ‘RoHS’ 2011/65/EU, restriction of the use of certain hazardous substances in electrical and electronic equip-
ment
and following the standards.
Standard Title of the Standard
EN ISO 12100:2010 Safety of machinery - Basic concepts, general principles of design
EN ISO 13857:2008 Safety of machinery - Safety distances to prevent hazard zones being reached
by the upper and lower limbs
EN 1012-1:2010
EN 1012-2:1996 + A1:2009
Compressors and vacuum pumps - Safety requirements - Part 1 and Part 2
EN ISO 2151:2008 Acoustics - Noise test code for compressors and vacuum pumps - Engineering
method (grade 2)
EN 60204-1:2006 Safety of machinery - Electrical equipment of machines - Part 1: General re-
quirements
EN 61000-6-2:2005 Electromagnetic compatibility (EMC) - Generic standards. Immunity for indus-
trial environments
EN 61000-6-4:2007 + A1:2011 Electromagnetic compatibility (EMC) - Generic standards. Emission standard
for industrial environments
EN ISO 13849-1:2015 (1) Safety of machinery - Safety-related parts of control systems - Part 1: General
principles for design
Person authorised to compile the technical file: Gerd Rohweder
Busch Dienste GmbH
Schauinslandstr. 1
DE-79689 Maulburg
Maulburg, 08.01.2017
Martin Gutmann, General director
(1) In case control systems are integrated.
