Bush BETC60S Assembly Instructions

I
Issue 1 - 23/05/14
These instructions contain important information which will help you get the best from
your appliance and ensure safe and correct installation, use and maintenance.
If you need help or have damaged or missing parts, call Argos Product Support 01759 487838
Important – Please read these instructions fully before installing or using
Installation & User Instructions - Please keep for future reference
Electric Cooker
Cat no Model
2599791 BUSH BETC60W WHITE
2677534 BUSH BETC60B BLACK
3328105 BUSH BETC60S SILVER
2556332 BUSH BETC50W WHITE
2445175 BUSH BETC50B BLACK
3555150 BUSH BETC50S SILVER
Cooker serial number place sticker here

Contents
Safety Information
Parts
Installation
Positioning
Fixing to the wall
Electrical connection
User Instructions
Using the hob
Cookware selection
Using the oven
Using the grill
Care and Maintenance
Cleaning
Removing the inner door glass
Troubleshooting
Technical Specications
Disposal information
A Guide to Wall Mounting & Fixings
Guarantee
2
3
4-5
4
4
5
6-8
6
6
7
8
9
9
9
10
11
11
12
Back
1

Important – Please read these instructions fully before installation
Safety Information
IMPORTANT: This product MUST be installed
by a qualied installer in accordance with local
regulations.
IMPORTANT: This appliance has been designed
for non-professional, domestic use only.
IMPORTANT: Carefully unpack and examine
the appliance for any damage. If you think there
is a defect, do not use the appliance and contact
Argos Product Support on 01759 487838.
IMPORTANT: The cooker is supplied setup
according to the conditions shown on the rating
label which is stuck to the rear of the appliance.
IMPORTANT: Keep the electrical cable (not
supplied) of your cooker away from the hot
areas; do not let it touch the appliance. Keep
the cable away from sharp edges and heated
surfaces.
IMPORTANT: In the event that the cable
connecting your cooker becomes damaged, it
must be replaced by a suitably qualied person.
This cable must not be replaced by an
unauthorised person.
IMPORTANT: When using the grill the oven door
must be kept closed to prevent damage to the
cooker knobs and to prevent the burn hazard
that very hot knobs would present.
IMPORTANT: Children and persons with
reduced physical, sensory or mental capabilities
or lack of experience and knowledge should not
be allowed to use the cooker unless supervised
and warned of the hazards involved
WARNING: The appliance and its accessible
parts become hot during use. Care should be
taken to avoid touching hot parts.
WARNING: Cooking on a hob with fat or oil can
be dangerous and should not be left unattended.
WARNING: NEVER try to extinguish a cooking
re with water. Instead switch off the appliance
and cover ame e.g. with a lid or a re blanket.
WARNING: Danger of re: do not store items on
the cooking surfaces or in the oven.
CAUTION: Cookers may topple forward if a child
climbs onto the cooker door. Children should be
supervised in the kitchen at all times and this
cooker must be secured to the wall using the
xing points provided to prevent accidents.
CAUTION: Do not allow children in the kitchen
when cooking or while cooker parts may still be
hot. Many parts of the cooker will become hot
and present a considerable hazard to children.
CAUTION: When the oven is hot never touch
the oven glass by hand or with tools.
CAUTION: Before starting to use your
appliance, ensure curtains, paper or ammable
items are kept away from your appliance.
Do not keep ammable materials inside of or
around your cooker.
CAUTION: Take care when closing the oven
door that there is nothing obstructing it from
closing as this may break the glass door.
2

3
If you have damaged or missing parts,
call Argos Product Support 01759 487838
1 - Control panel
2 - Oven and grill controls
3 - Ceramic hob
4 - Hob heat indicator
5 - Grill pan with removable handle
6 - Wire shelves X 2
7 - Oven door
8 - Grill compartment
9 - Oven
Accessories
Parts
Please familiarise yourself with the parts and accessories listed below
1
2
3
4
5
6
7
8
9

4
Argos Product Support 01759 487838
Installation
Positioning and xing to the wall
Positioning
1. Make sure that there are no
combustible or ammable materials,
such as curtains, in the vicinity of the
installation.
2. Furniture and cabinets surrounding
the cooker must be of material
resistant to temperatures
greater than 50°C.
3. Surrounding furniture, cabinets and
extractor fans should be positioned in
accordance with
the diagram shown in Figure 1.
4. There must be at least 2cm of
free space between the back wall and
the rear of the appliance to
allow for ventilation and air
circulation.
5. If tted, the extractor fan must be at
least 65cm above the hob. If no fan is
tted the minimum distance between
the hob and any cabinet
or other structure must be 75cm.
Fixing to the wall
Before using the appliance x it
securely to the wall using the chains
on the back of the cooker. This will
prevent the cooker from toppling
forward if excess weight is placed on
the oven door. Since the chains must
be attached to wall xings suitable for
your wall type, the wall xings are not
supplied with the cooker (Figure 2).
Please refer to the ‘Guide to Wall
Mounting and Fixings’ on page 12.
Levelling
Level the cooker before using it. To do
this, use the adjustable feet to achieve
the correct level and height
900mm
Figure 2
Figure 1

5
Argos Product Support 01759 487838
Installation
Electrical connection
IMPORTANT: Electrical connections
must be carried out by a suitably
qualied person and in accordance with
all relevant local building and installation
regulations.
1. See the rating label at the rear of the product for
the appliance’s rated load.
2. The cooker must be connected to a dedicated
circuit suitably rated for the load of the appliance
(see rating label at rear of appliance) as shown in
the wiring diagrams below. It must be connected
via a suitably rated cable to a double pole isolator
cooker switch also suitably rated for the appliance.
3. Electrical cable should not touch the hot
parts of the appliance.
The electrical cable should not be
routed through any area that may
be affected by heat from the oven,
especially the area directly behind the
oven.

6
Argos Product Support 01759 487838
User Instructions
Using the Hob
Each ceramic hob is regulated by a
selector knob (Fig. 3).
The control allows for the efcient transfer
of heat to the cooking pan.
The knob can be turned in both directions,
to numbers 1 to 6
These numbers correspond to the power
setting of the ceramic hob where 6 is the
highest setting and 1 is the lowest.
Turn the hob control knob to off (l) when
nished.
We recommend you turn off the ceramic
hob 5 to 10 minutes before the dish is
ready. This allows the heat accumulated in
the ceramic hob to be used economically.
The ceramic hob remains hot for a while
after use.
SAFETY ADVICE IN THE CASE OF A
COOKING PAN FIRE
In the event of a cooking pan re:
1. Turn off the cooker at the wall switch.
2. Cover the pan with a re blanket or
damp cloth. This will smother the ames
and extinguish the re.
3. Leave the pan to cool for at least an
hour before attempting to move it. Injuries
are often caused by picking up a hot pan
and rushing outside with it.
NEVER USE A FIRE EXTINGUISHER TO
PUT OUT A PAN FIRE
as the force of the extinguisher could
tip the pan over.
Never use water to extinguish oil or fat
pan res.
Figure 3
COOKWARE SELECTION
• Any cookware should have a thick, at and dry
base of the same diameter or slightly bigger than
the hob. If the cookware diameter is smaller than
the hob, heat will be wasted.
• Cookware with uneven bases is very inefcient,
making the cooking time longer and wasting
electricity.
• Cookware made of ameproof glass, suitable
for ceramic hob cooking, should match
the hob size. Pans projecting beyond the hob
may be broken due to temperature stresses.
The heated pan must never be lled up with cold
water or placed on cold metal or stone surfaces.
• Always use the pan with its lid on. This prevents
the accumulation of vapour in the kitchen.
Only use at bottomed pans
IMPORTANT!
1. Never turn the hob on before placing a pan on
it, except when rst used.
2. If the ceramic hob is not to be used for a long
time, apply a little grease to the
painted surface.
3. Do not allow spills to be burned onto the hob
as baked stains are harder to remove
Hob hot
indicater
Hob for this
knob
Front right

7
Argos Product Support 01759 487838
User Instructions
Using the oven
Using the Main Fan Oven
Turn the Main Oven knob clockwise and
align the marker on the control knob with
the required temperature (°C)
The indicator light on the control panel
will go out and the thermostat will turn
the element off when the selected
temperature has been reached inside the
oven. These will come back on once the
thermostat falls below the set value.
Fan only defrost
The fan can be used without heat to
defrost food (DEFROST)
IMPORTANT! Before using this method
of defrosting refer to the food packaging
defrosting information
Always turn the control knob to off (l)
when cooking has nished.
Please note: The appliance incorporates
a safety thermostat which cuts the electric
supply to the oven if the temperature
becomes excessive.
When using your oven for the rst time
your cooker may give off an unusual
odour from the heating elements. This is
normal for new cookers. To eliminate this
odour run the oven at 250 degrees for 40-
60 mins with the oven empty.
Oven indicator
Defrost only
Main oven
MINUTE MINDER AND CLOCK
SETTING THE CLOCK (24-HR)
To set the time of day press the + and - buttons
at the same time. The display will show 12:00.
Press the + or - button until the correct time is
shown in the display. Release the button.
SETTING THE MINUTE MINDER ALARM
Press the + button.
Press the + button again until the required
cooking period is shown in the display.
After 5 seconds countdown will start.
At the end of the cooking period the alarm will
sound.
Press the - button to stop the alarm.

8
Argos Product Support 01759 487838
User Instructions
Using the grill
Using the grill
Turn the control knob (GRILL) clockwise
to the required temperature.
The indicator light on the control panel will
go out when the selected
temperature has been reached inside the
grill compartment.
Always turn the control knob to off (l)
when cooking has nished.
The GRILL door must be closed during
use.
Always use the handle when handling
the grill pan
Grill control

9
Argos
Product Support 01759 487838
Cleaning and Maintenance
Cleaning
WARNING! Isolate the power supply to the cooker and make sure that the oven is cool.
Do not clean using caustic creams, abrasive cleaning powders, thick wire wool or hard tools.
Enamelled parts of the oven can be damaged if excess cleaning liquids are not immediately
removed.
After cleaning the interior parts of the oven with a soapy cloth, rinse it and then dry thoroughly
with a soft cloth.
Clean the glass surfaces with special glass cleaning agents.
Never use ammable agents like acid, thinner or petrol when cleaning your oven.
Do not clean your oven with a steam cleaner.
Do not wash any part of your oven in a dishwasher.
Removal of inner glass door for cleaning
Remove the inner glass by sliding the glass
out towards you.
Change of Oven Lamp
Turn the oven off from the electric supply
and make sure that the oven is cool.
Remove the bulb after removing the cover
in front of lamp. Replace the old bulb with
a new bulb resistant to 300°C (230 V, 25
Watt, Type E14).
Replace the lamp protective glass.
Your oven is now ready for use.
Care and use of the ceramic hob
For best results use pans with thick at
bases and match cooking pans to cooking
zones of equal size.
Always place the pan on the cooking zone
before switching on the cooking zone.
Always disconnect the power and check that
the hob is cool before cleaning.
Do not use harsh or abrasive cleaning
agents or abrasive cleaning products
such as wire wool to clean the hob. Use
only cleaning products designed to be
used on ceramic hobs.

Argos Product Support 01759 487838
Troubleshooting
If your cooker does not appear to function correctly
1. If no functions appear to work, check the
cooker isolation switch has not been turned
off also check the fuse in the switch and the
circuit breaker in you consumer unit
2. After replacing the fuse or resetting the
circuit breaker turn on individual parts of your
cooker one at a time to check function
3. DO NOT attempt to repair this cooker
yourself. Call Argos Product Support or
consult a qualied electrician
10
Problem Possible Cause Solution
Only parts of the cooker work
it may be that the hobs, the
ovens or the grill, do not work
Links may be missing in the
rear connector box
Refer to the Quick Start Guide
to check the correct placement
of the links
This must be done by a
qualied competent person
Nothing works (completely
dead)
Power is turned off at the
isolation switch or the
consumer unit
Poor electrical connection
Ensure isolation switch is on
Check consumer unit has not
tripped out
Have the connections checked
by a qualied electrician
Oven not heating up Oven temperature not set
correctly
Door is not properly closed
Ensure that the correct
temperature has been selected
and the door is properly closed

11
Argos Product Support 01759 487838
Technical Specications
Models BUSH BETC60
BLACK or WHITE or SILVER
BUSH BETC50
BLACK or WHITE or SILVER
Power supply 220-240V~50 Hz 220-240V~50 Hz
Maximum power 10000 W 9500 W
Size (H x W x D) 900 x 600 x 600 900 x 500 x 600
Net Weight 47.72Kg 42.89 Kg
Top oven volume 30 Lt. 25 Lt.
Main oven volume 61 Lt. 49 Lt.
Energy rating A A
We apologise for any inconvenience caused by minor inconstancies within these instructions that
may occur due to product improvements and development
All images and drawing are for illustration purposes only.
This appliance/tting is marked according to the European directive 2002/96/EC on Waste
Electrical and Electronic Equipment (WEEE). By ensuring this product is disposed of
correctly, you will help prevent potential negative consequences for the environment and
human health, which could otherwise be caused by inappropriate waste handling of
this product.
The symbol on the product, or on the documents accompanying the product, the
crossed out wheelie bin symbol, indicates that this appliance/tting may not be
treated as household waste. Instead it shall be handed over to the applicable
collection point for the recycling of electrical and electronic equipment. Disposal must
be carried out in accordance with local environmental regulations for waste disposal.
For more detailed information about treatment, recovery and recycling of this product, please
contact your local authority, your household waste disposal service or the retailer where you
purchased the product.

12
Argos Product Support 01759 487838
Wall Fixing Guide
Important note:
Types of walls
Care &
Maintenance
No.1 “General Purpose” wall plug
No.6 “Shield Anchor” wall plug
Heavy loads
No.3 “Cavity Fixing” wall plug
No.4 “Cavity Fixing-Heavy Duty”
wall plug
No.5 “Hammer Fixing” wall plug
No.2 “Plasterboard” wall plug
Generally aerated blocks should not
be used to support heavy loads, use
loads, general purpose wall plugs can
be used.
For use with heavier loads such as TV
& HiFi speakers and satelite dishes etc.
For use with plasterboard partitions or
hollow wooden doors.
heavy loads such as shelving, wall
cabinets and coat racks.
For use with walls stuck with
is secure to the retaining wall.
For use when attaching light loads on
to plasterboard partitions.
Safety:
and location to ensure your safety
in and around the home.
Fitting: From time to time check
or screws do not become loose.
You can use one of the following types of wall plug if your walls are made
of brick, breeze block, concrete, stone or wood.
Important: When drilling into walls always
check that there are no hidden wires or pipes etc.
Hints:
1: General rule: Always use a larger screw and wall plug
if you are not sure.
2: Ensure you use the recommended drill bit to match the wall
plug and hole size.
3: Ensure you drill the hole horizontally, do not force the drill or
enlarge the hole.
4: Take extra care when drilling high walls, ceilings and ceramic
tiles. Ensure wall plugs are inserted beyond the thickness of
the ceramic tiles to avoid the tiles splitting or cracking.
5:
drilled hole.
If plastic wall plugs
are supplied with your
product:
Make sure that the screws and wall plugs being used
tradesperson if you are unsure.
- these are only suitable for
use in masonry walls.
If you are in any doubt about
the correct wall plugs for
your wall, seek professional
advice.
Failure of the product due to
responsibility of the installer.

Argos Product Support 01759 487838
Guarantee
.
Product Guarantee
This product is guaranteed against manufacturing defects for a period of
Year
2
This product is guaranteed for 12 months from the date of original purchase.
Any defect that arises during this period due to faulty materials or workmanship will either
be repaired free of charge or replaced.
The guarantee is subject to the following provisions:
• The guarantee does not cover accidental damage, misuse, cabinet parts, knobs
or consumable items.
• The product must be correctly installed and operated in accordance with the
instructions contained in this manual.
• It must be used solely for domestic purpose.
• The guarantee will be rendered invalided if the product is re-sold or has been
damaged by inexpert repair.
• Specications are subject to change without notice.
• The manufacturer disclaims any liability for the incidental or consequential damages.
• The guarantee is in addition to, and does not diminish your statutory or legal rights.
• In the event of a problem with the product with in the guarantee period call :-
Argos Product Support 01759 487838.
Guarantor: Argos Ltd
489 - 499 Avebury Boulevard
Central Milton Keynes
MK9 2NW
