Bush BC100DFB Assembly Instructions

I
These instructions contain important information which will help you get the best from
your appliance and ensure safe and correct installation, use and maintenance.
If you need help or have damaged or missing parts, call Argos Product Support 01759 487838
Important – Please read these instructions fully before installing or using
Installation & User Instructions - Please keep for future reference
Dual Fuel Range Cooker
Cat no Model
Cooker serial number place sticker here
BC100DFB BLACK
7176229
BC100DFB BLACK
7157499
BC100DFB BLACK
7195303

1
Contents
Safety Information
Parts
Installation
Positioning
Fixing to the wall
Electrical connection
User Instructions
Using the hob
Cookware selection
Using the fan oven
Minute minder and clock
Using the grill
Using the conventional oven
Care and Maintenance
Troubleshooting
Technical Specications
Disposal information
A Guide to Wall Mounting & Fixings
Guarantee
2-3
4
5-8
6
7
9
9-12
9
10
11
11
12
13
15
16
17
17
18
19

4
If you have damaged or missing parts,
call Argos Product Support 01759 487838
Accessories
Parts
Please familiarise yourself with the parts and accessories listed below
wire shelves

3
Important – Please read these instructions fully before installation
Safety Information Argos Product Support 01759 487838
IMPORTANT: Make sure the cooker control
knobs are all in the off position when not in use.
IMPORTANT: If you do not intend to use your
cooker for a long period of time turn off the gas
and electric supply to the cooker.
CAUTION: Using gas cooking appliances
results in the production of heat, moisture and
the products of combustion. Ensure that the
room where your cooker is installed is well
ventilated particularly while the cooker is in use.
Keep natural ventilation holes open or install a
mechanical ventilation device (extractor hood)
Prolonged intensive use of your cooker may
call for additional ventilation (by opening a
window) or by increasing the level of mechanical
ventilation where present.
GENERAL SAFETY WARNINGS
IMPORTANT: This appliance has been designed
for non-professional, domestic use only. Do not
use this cooker for commercial use or any other
application e.g. room heating.
WARNING: Danger of re: do not store
ammable items on or near the cooking surfaces
or inside the oven.
IMPORTANT: Do not try to lift or move this
cooker by pulling on the door handle.
WARNING: Ensure that the appliance is
switched off before replacing the lamp to avoid
the possibility of electric shock.
IMPORTANT: Your appliance is produced in
accordance with all applicable local and
international standards and regulations.
IMPORTANT: Maintenance and repair work
must only be performed by authorised service
technicians.
Installation and repair work that is carried out
by unauthorised technicians is dangerous
and could invalidate your guarantee.
IMPORTANT: When the door of the oven is
open, do not hang or lean anything on it. You
may unbalance your appliance or damage the
door or door hinges.
IMPORTANT: Do not hang towels, dishcloths or
clothes from the cooker or its handles.
CLEANING AND MAINTENANCE
IMPORTANT: Always turn the appliance off
before operations such as cleaning or
maintenance. You can do this by switching the
cooker off using cooker isolation switch.
IMPORTANT: Do not remove the control knobs
to clean the control panel.
TO MAINTAIN THE EFFICIENCY AND SAFETY
OF YOUR APPLIANCE,
WE RECOMMEND YOU ALWAYS USE
OUR AUTHORISED SERVICE AGENTS AND
ORIGINAL SPARE PARTS.
FOR ASSISTANCE CALL
ARGOS PRODUCT SUPPORT
01759 487838.

4
If you have damaged or missing parts,
call Argos Product Support 01759 487838
Accessories
Parts
Please familiarise yourself with the parts and accessories listed below

5
Argos Product Support 01759 487838
Installation
Installation gas
THIS COOKER MUST BE INSTALLED
ACCORDING TO BS 6172: 2010 BY
A SUITABLY QUALIFIED GAS SAFE
REGISTERED INSTALLER
This modern cooker was manufactured with
parts and materials of the highest quality and
was designed to meet your cooking needs.
You should read this manual so that you are
able to use the cooker correctly and to avoid
any potential problems with using the cooker.
The following information outlines the required
rules for correct installation and service of your
cooker. This is particularly important for the
technician who will install the appliance.
CONTACT AN AUTHORISED SERVICE
AGENT FOR INSTALLATION OF YOUR OVEN!
VENTILATION REQUIREMENTS
For rooms with a volume of less than 5 m³ -
permanent ventilation of 100 cm² is required see
gure 1 and 2 for an example.
For rooms with a volume of between 5 m³ and
10m³ a permanent ventilation of 50 cm² will be
required unless the room has a door which
opens directly to the outside, in which case no
permanent ventilation is required.
For rooms with a volume greater than 10 m³ - no
permanent ventilation is required.
Attention: Regardless of room size, all rooms
containing the appliance must have
direct access to the outside air via an
openable window or equivalent. The room
containing the cooker should have an air
supply in accordance with BS 5440: Part 2.
Environment where your appliance will be
installed
Your cooker must be set up and used in a place
where it will always have ventilation.
While operating, this appliance needs 2m3/h air
per kw input.
There must be enough natural ventilation to
provide the gas to be used in the environment.
The average air ow must directly come in
through ventilation from the outside.
Emptying of the Burned Gases from
Environment
For cooking appliances that operate with gas,
burned gas wastes are exhausted directly to the
outside or through cooker hoods that are
connected to a chimney that opens directly to
the outside. If it is not possible to install a cooker
hood, it is required to set an electric fan on the
window or wall that has access to fresh air. This
electric fan must have the capacity to change
the volume of air in the kitchen environment 4-5
times per hour.

6
Argos Product Support 01759 487838
Installation
Installation gas
Installation of cooker
IMPORTANT - All Gas installations must be
carried out by a suitably qualied person. For
information on choosing a gas installer contact
the ‘Gas Safe Register’.
www.gassaferegister.co.uk
The appliance can be placed close to other
furniture on condition that the furniture’s height
does not exceed the height of the cooker panel
Make sure that there are no combustible or
ammable materials, such as curtains, in the
vicinity of the installation.
There must be at least 2cm of free space
between the back wall and the rear of the
appliance to allow for ventilation and
air circulation.
Positioning
The furniture close to the cooker must be
manufactured resistant to temperatures up to
100°C.
If the kitchen furniture are higher than the hob
plate of the cooker, it must be at least 10cm
away from the cooker’s side.
Surrounding furniture, cabinets and extractor
fans should be positioned in accordance with the
diagram shown in gure 3. If tted, the extractor
fan must be at least 65cm above the hob.
If no fan is tted the minimum distance between
the hob and any cabinet or other structure must
be 70cm.
Adjustment of feet
The height and level of the appliance can be
adjusted by rotating the feet located underneath
the appliance at each corner. Rotate in a
clockwise direction to decrease the height and
anti clockwise to increase the height.
Figure 3
Min 100cm

7
Argos Product Support 01759 487838
Installation
Installation gas
Gas Connection
THIS COOKER MUST BE INSTALLED
ACCORDING TO BS 6172: 2010 BY
A SUITABLY QUALIFIED GAS SAFE
REGISTERED INSTALLER
! Failure to do this will void your warranty
Fixing to the wall
Before using the appliance x it securely to the wall
using the chain kit provided. Fix to the wall and the
back of the cooker. This will prevent the cooker
from toppling forward if excess weight is placed on
the oven door. Since the chains must be attached
to wall using xings suitable for your wall type, the
wall xings are not supplied with the cooker (Figure
4).
Please refer to the ‘Guide to Wall Mounting and
Fixings’ on page 18.
Fixing to the cooker
Fix the chain to the cooker bracket with the screw
provided in the xing kit.
Figure 4
Bracket
Screw
Chain

8
Argos Product Support 01759 487838
Installation
Electrical connection
IMPORTANT: Electrical connections
must be carried out by a suitably
qualied person and in accordance with
all relevant local building and installation
regulations.
1. See the rating label at the rear of the product for
the appliance’s load rating.
2. The cooker must be connected to a dedicated
circuit suitably rated for the load of the appliance
(see rating label at rear of appliance) as shown in
the wiring diagrams below. It must be connected
via a suitably rated cable to a double pole isolator
cooker switch also suitably rated for the appliance.
3. The electrical cable should not touch the
hot parts of the appliance.
The electrical cable (not supplied)
should not be routed through any
area that may be affected by heat from
the oven, especially the area directly
behind the oven.
3x6mm2
3x6mm2

9
Argos Product Support 01759 487838
User Instructions
Using the Hob
Ignition Button
Press and turn the control knob towards
the large ame position.
Pressing the control knob down will
engage the electronic ignition and allow
the gas to ow.
Manual Ignition of the Gas Burners
In the case of electricity failure resulting
in loss of electronic ignition follow this
procedure.
To ignite one of the burners, press and turn
its knob clockwise so that the knob
is in max. position, ignite with a match,
taper or another manual aid to its upper
circumference. Move the ignition source
away as soon as you see a stable ame.
Flame failure device:
This cooker is equipped with a ame failure
device.
In order for these to work correctly and to
prevent the ame going out when you rst
ignite your burners, keep the knob pressed
and hold for 10 seconds after the burner has
ignited.
Control of the hob burners
The knob has 3 positions: Off (l), max (big
ame symbol) and min (small ame symbol).
After you ignite the burner in max. position you
can adjust the ame length between max. and
min. positions.
Do not operate the burners when the knob
position is between max. and off positions.
After the ignition, check the ames visually. If
you see yellow tips, lifted or unstable ames;
turn the gas ow off, and check the assembly
of burner caps and crowns. Also, make sure
that no liquid has spilled into the burner caps.
If the burner ames go out accidentally, turn
the burners off, ventilate the kitchen with fresh
air, and do not attempt re-ignition for 90 sec.
Left front burner Left rear burner
Large ame Small ame
Hob Burner Control

10
Argos Product Support 01759 487838
User Instructions
Using the Hob
When turning the hob off, turn the knob in the
clockwise direction so that the knob shows “l”
position or the marker on the knob points
upwards.
Your hob has burners of different diameters.
The most economic way of using gas is to
choose the correct size gas burners for your
cooking pan size and to bring the ame to
the minimum position once the boiling point is
reached. It is recommended to always cover
your cooking pan.
Cookware Selection
In order to obtain maximum performance from
the main burners, use pots with the following
at bottom diameters. Using smaller pots than
the minimum dimensions stated below will
cause energy loss.
Rapid Burner: 22-26cm
Medium Burner: 14-22cm
Auxiliary Burner: 12-18cm
Make sure that the tips of the ames do
not spread out of the outer circumference
of the pan, as this may also harm the
accessories around the pan (handles etc.)
When the burners are not in use for
prolonged periods, always turn the main
gas control valve off.
WARNING:
Use only at bottomed pans and with a
sufciently thick base.
Ensure that the base of the pan is dry
before placing it on the burners.
The temperature of accessible parts may
be high when the appliance is operating.
So it is important to keep children and
animals out of the reach of the burners
during and after cooking (until the cooker
has cooled down).
After use the hob remains very hot for a
prolonged period of time, do not touch it
and do not place any object on top of the
hob.
Never place cutlery or lids on the hob as
they will get hot and could cause serious
burns.
SAFETY ADVICE IN THE CASE OF A
COOKING PAN FIRE
1. Turn off the burner.
2. Cover the pan with a re blanket or
damp cloth. This will smother the ames
and extinguish the re.
3. Leave the pan to cool for at least an
hour before attempting to move it. Injuries
are often caused by picking up a hot pan
and rushing outside with it.
NEVER USE A FIRE EXTINGUISHER TO
PUT OUT A PAN FIRE
as the force of the extinguisher could
tip the pan over.
Never use water to extinguish oil or fat
pan res.

11
Argos Product Support 01759 487838
User Instructions
Using the fan oven (top right)
Using the Fan Oven
Turn the Main Oven knob clockwise and
align the marker on the control knob with
the required temperature (°C).
The indicator light on the control panel
will go out and the thermostat will turn
the element off when the selected
temperature has been reached inside the
oven. These will come back on once the
thermostat falls below the set value.
Fan only defrost
The fan can be used without heat to
defrost food (DEFROST).
IMPORTANT! Before using this method
of defrosting refer to the food packaging
defrosting information.
Always turn the control knob to off (l)
when cooking has nished.
Please note: The appliance incorporates
a safety thermostat which cuts the electric
supply to the oven if the temperature
becomes excessive.
When using your oven for the rst time
your cooker may give off an unusual
odour from the heating elements. This is
normal for new cookers. To eliminate this
odour run the oven at 250 degrees for 40-
60 mins with the oven empty.
DEFROST
MAIN OVEN
MINUTE MINDER AND CLOCK
SETTING THE CLOCK (24-HR)
To set the time of day press the + and - buttons
at the same time. The display will show 12:00.
Press the + or - button until the correct time is
shown in the display. Release the button.
SETTING THE MINUTE MINDER ALARM
Press the + button.
Press the + button again until the required
cooking period is shown in the display.
After 5 seconds countdown will start.
At the end of the cooking period the alarm will
sound.
Press the - button to stop the alarm.
FAN COOKING

12
Argos Product Support 01759 487838
User Instructions
Using the grill
Using the grill
Turn the control knob (GRILL) clockwise
to the required temperature.
The indicator light on the control panel will
go out when the selected
temperature has been reached inside the
grill compartment.
Always turn the control knob to off (l)
when cooking has nished.
The GRILL DOOR
MUST BE CLOSED during use.
Always use the handle when handling
the grill pan.
Grill control

13
Argos Product Support 01759 487838
User Instructions
Using the conventional oven (lower left)
Using the conventional oven
Select which element you wish to use:
- Top element
- Bottom element
- Both elements
Turn the temperature control knob
clockwise and align the marker on the
knob with the required temperature.
The indicator light on the control panel will
go out when the selected temperature has
been reached inside the oven.
Always turn the control knob to off (l)
when cooking has nished.
Please note: The appliance incorporates
a safety thermostat which cuts the electric
supply to the oven if the temperature
becomes excessive.
Oven control (variable temp)
Top element onlyBoth elements
Bottom element only

14
Argos Product Support 01759 487838
User Instructions
Storage compartment (lower right)
Storage compartment
This range cooker incorporates a storage
compartment.
This compartment is for pans, oven
trays and other non ammable cooking
equipment.
Do not store anything ammable in this
compartment.
Please note this compartment may get
hot.
Storage Compartment
Top element only

15
Argos
Product Support 01759 487838
Cleaning and Maintenance
Cleaning
WARNING! Isolate the power supply to the cooker and make sure that the oven is cool.
Do not clean using caustic creams, abrasive cleaning powders, thick wire wool or hard tools.
Enamelled parts of the oven can be damaged if excess cleaning liquids are not immediately
removed.
After cleaning the interior parts of the oven with a soapy cloth, rinse it and then dry thoroughly
with a soft cloth.
Clean the glass surfaces with special glass cleaning agents.
Never use ammable agents like acid, thinner or petrol when cleaning your oven.
Do not clean your oven with a steam cleaner.
Do not wash any part of your oven in a dishwasher.
Removal of inner glass door for cleaning
Remove the inner glass by sliding the glass
out towards you.
Change of Oven Lamp
Turn the oven off from the electric supply
and make sure that the oven is cool.
Remove the bulb after removing the cover in
front of the lamp. Replace the old bulb with
a new bulb resistant to 300°C (230 V, 15
Watt, Type E14/SES).
Replace the lamp’s protective glass.
Your oven is now ready for use.
Burner Caps:
Periodically, the enamelled pan support,
enamelled covers and burner heads must be
washed with warm soapy water, rinsed and
dried. After drying them thoroughly, place
them back in their original positions on the
burners.
Enamelled Parts:
In order to keep them as new, it is necessary
to clean them frequently with mild warm
soapy water and then dry with a cloth. Do
not wash them while hot and never use
abrasive powders or abrasive cleaning
materials. Do not leave anything spilled onto
enamelled parts for long periods of time.
Stainless Steel:
Stainless steel parts must be cleaned
frequently with mildly warm soapy water
and a soft sponge and then dried with a
soft cloth. Do not use abrasive powders or
abrasive cleaning materials. Do not leave
anything spilled onto stainless steel parts for
long periods of time.

16
Argos Product Support 01759 487838
Troubleshooting
If your cooker does not appear to function correctly
1. If no electrical functions appear to work,
check the cooker isolation switch has not
been turned off also check the fuse in
the switch and the circuit breaker in you
consumer unit.
2. After replacing the fuse or resetting the
circuit breaker turn on individual parts of your
cooker one at a time to check function.
3. DO NOT attempt to repair this cooker
yourself. Call Argos Product Support on the
number above or consult a qualied person.
Problem Possible Cause Solution
Only parts of the cooker work
it may be that the ovens or the
grill, do not work
Links may be missing in the
rear connector box
Refer to the Quick Start
Installation Guide to check the
correct placement of the links
This must be done by a
qualied competent person
Nothing works (completely
dead)
Power is turned off at the
isolation switch or the
consumer unit
Poor electrical connection
Ensure isolation switch is on
Check consumer unit has not
tripped out
Have the connections checked
by a qualied electrician
The hob burners do not
operate correctly
Check if the burner parts
are correctly assembled
(especially after cleaning).
The gas supply pressure may
be too low/high.
For appliances working with
bottled LPG, the LPG cylinder
may be depleted.
Oven not heating up Oven temperature not set
correctly
Door is not properly closed
Ensure that the correct
temperature has been selected
and the door is properly closed

17
Argos Product Support 01759 487838
Technical Specications
Models
Power supply 220-240V~50 Hz
Maximum power 5550W
Size (H x W x D) 900 x 1003 x 600
Net Weight  kg
Grill compartment volume 25 lt
Fan oven volume (upper right) 49 lt
Lower left oven 54lt
Energy rating A
We apologise for any inconvenience caused by minor inconstancies within these instructions that
may occur due to product improvements and development.
All images and drawing are for illustration purposes only.
This appliance/tting is marked according to the European directive 2002/96/EC on Waste
Electrical and Electronic Equipment (WEEE). By ensuring this product is disposed of
correctly, you will help prevent potential negative consequences for the environment and
human health, which could otherwise be caused by inappropriate waste handling of
this product.
The symbol on the product, or on the documents accompanying the product, the
crossed out wheelie bin symbol, indicates that this appliance/tting may not be
treated as household waste. Instead it shall be handed over to the applicable
collection point for the recycling of electrical and electronic equipment. Disposal must
be carried out in accordance with local environmental regulations for waste disposal.
For more detailed information about treatment, recovery and recycling of this product, please
contact your local authority, your household waste disposal service or the retailer where you
purchased the product.

18
Argos Product Support 01759 487838
Wall Fixing Guide
Important note:
Types of walls
Care &
Maintenance
No.1 “General Purpose” wall plug
No.6 “Shield Anchor” wall plug
Heavy loads
No.3 “Cavity Fixing” wall plug
No.4 “Cavity Fixing-Heavy Duty”
wall plug
No.5 “Hammer Fixing” wall plug
No.2 “Plasterboard” wall plug
Generally aerated blocks should not
be used to support heavy loads, use
loads, general purpose wall plugs can
be used.
For use with heavier loads such as TV
& HiFi speakers and satelite dishes etc.
For use with plasterboard partitions or
hollow wooden doors.
heavy loads such as shelving, wall
cabinets and coat racks.
For use with walls stuck with
is secure to the retaining wall.
For use when attaching light loads on
to plasterboard partitions.
Safety:
and location to ensure your safety
in and around the home.
Fitting: From time to time check
or screws do not become loose.
You can use one of the following types of wall plug if your walls are made
of brick, breeze block, concrete, stone or wood.
Important: When drilling into walls always
check that there are no hidden wires or pipes etc.
Hints:
1: General rule: Always use a larger screw and wall plug
if you are not sure.
2: Ensure you use the recommended drill bit to match the wall
plug and hole size.
3: Ensure you drill the hole horizontally, do not force the drill or
enlarge the hole.
4: Take extra care when drilling high walls, ceilings and ceramic
tiles. Ensure wall plugs are inserted beyond the thickness of
the ceramic tiles to avoid the tiles splitting or cracking.
5:
drilled hole.
If plastic wall plugs
are supplied with your
product:
Make sure that the screws and wall plugs being used
tradesperson if you are unsure.
- these are only suitable for
use in masonry walls.
If you are in any doubt about
the correct wall plugs for
your wall, seek professional
advice.
Failure of the product due to
responsibility of the installer.

19
Argos Product Support 01759 487838
Guarantee
.
Product Guarantee
This product is guaranteed against manufacturing defects for a period of
Year
2
This product is guaranteed for 12 months from the date of original purchase.
Any defect that arises during this period due to faulty materials or workmanship will either
be repaired free of charge or replaced.
The guarantee is subject to the following provisions:
• The guarantee does not cover accidental damage, misuse, cabinet parts, knobs
or consumable items.
• The product must be correctly installed and operated in accordance with the
instructions contained in this manual.
• It must be used solely for domestic purpose.
• The guarantee will be rendered invalided if the product is re-sold or has been
damaged by inexpert repair.
• Specications are subject to change without notice.
• The manufacturer disclaims any liability for the incidental or consequential damages.
• The guarantee is in addition to, and does not diminish your statutory or legal rights.
• In the event of a problem with the product with in the guarantee period call :-
Argos Product Support 01759 487838.
Guarantor: Argos Ltd
489 - 499 Avebury Boulevard
Central Milton Keynes
MK9 2NW
