Bush S273 Assembly Instructions

BUSH – Paper Shredder
Installation & User Instructions – Please keep for future reference 925
/
4493
These instructions contain important information which will help you get the best from your
appliance and ensure safe and correct installation, use and maintenance.
If you need help or have damaged or missing parts, call the Customer Helpline: 0845 640 0800
Important – Please read these instructions fully before installing or using

Contents
Safety Information 2
Parts 3
Installation 4-5
Location 4
Electrical Connection 5
User Instructions 6-7
Before first use 6
Using your appliance 6
Care and Maintenance 8
General 8
Trouble Shooting 8
Technical Specifications 9
Disposal information 9
Guarantee 10
Product codes
S273
1

Safet
y
Information
Im
p
ortant
–
Please read these instructions full
y
befo
r
e installation
Before use Durin
g
use
yDispose of all packaging carefully and
responsibly.
yThe appliance is designed for indoor use only.
Do not use outdoor.
yThis appliance is designed for household use.
yDo not use the appliance for industrial and
commercial use, or any other purpose.
yThe appliance MUST be positioned on a firm
level base.
yPlease use the shredder with a correct power
supply.
yDo not use appliance for other than intended use.
yKeep the power cord away from hot surface.
yDo not immerse the machine in water or any
other liquid to protect against electric shock.
yKeep children away from the machine. This
machine should be operated by adults only.
yPlease don't spay any flammable gas or oil on
this shredder, it may cause a fire.
yDo not allow this appliance to be exposed to rain
or moisture.
yPlease unplug the shredder when emptying the
waste bin or non-in use or moving the shredder.
yWARNING! Keep all loose articles of clothing,
ties, jewellery, long hair or other loose objects
away from opening, injury may result!
yNever insert fingers into opening. Serious injury
may result!
yPlease keep soft cloths and ties far away from the
paper entry.
yPlease keep your hair far away from the shredder.
yAlways operate on a flat horizontal surface.
yThis appliance is not intended for use by persons
(including children) with reduced physical,
sensory or mental capabilities, or lack of
experience and knowledge, unless they have
been given supervision or instruction concerning
use of the appliance by a person responsible for
their safety. Children should be supervised to
ensure that they do not play with the appliance.
yThis appliance is not intended for use by young
children or infirm persons unless they have been
adequately supervised by a responsible person to
ensure that they can use the appliance safely.
Young children should be supervised to ensure
that they do not play with the appliance.
yDo not operate the appliance with a damaged
cord or plug or after the appliance malfunctions,
or has been damaged in any manner.
yDo not attempt to repair the appliance yourself.
Contact the Customer Helpline: 0845 640 0800.
2

Part
Please familiarize yourself with the parts and accessories listed below
1. Power indicator 5. CD entry
2. Overheat indicator 6. Carry handle
3. Viewing window 7. Paper in throat
4. Function switch (Rev, OFF, Auto) 8. Waste bin
Instructions x 1 Waste bin for CD x 1
Accessories included
3

Installation
Location
Caution: Always operate this product on
a flat horizontal surface.
yCarefully remove all packaging materials and
dispose of correctly.
yEnsure the supply cable is not caught under
the appliance.
yDo not operate under or near curtains or other
combustible materials
yDo not place the appliance near a heat source
or in direct sunlight.
4

Installation
Electrical connection
Any electrical work that is required to
install this appliance MUST be carried out by
a qualified electrician.
Before making any electrical connections,
ensure that:
yDo not bend, stretch or pull the supply cable to
avoid electric shock.
yEnsure the power socket is suitable for the
maximum power of the machine.
yThe supply voltage should be the same as that
indicated in the technical specifications and
the appliance rating plate.
yIf the socket outlets in your home are not
suitable for the plug supplied with this unit
check with a qualified electrician for
replacement.
yThe use of adapters, multiple connectors or
extension cables are not recommended.
yThe appliance must be connected to a 220-
240 volt 50Hz AC supply by means of a three
pin socket, suitably earthed and protected by a
13 amp fuse.
yShould the fuse need to be replaced, a 13
amp fuse approved to BS1362 must be used.
yThe plug contains a removable fuse cover that
must be refitted when the fuse is replaced. If
the fuse cover is lost or damaged, the plug
must not be used until a replacement cover
has been fitted or the plug is replaced.
yA damaged plug should be cut off as close to
the plug body as possible, the fuse should be
removed and the plug disposed of safely.
Plug replacement (UK & Ireland only)
Should you need to replace the plug; the wires in
the power cable are coloured in the following
way:
Blue – Neutral ‘N’
Brown – Live ‘L’
As the colours of the wires in the power cable
may not correspond with the coloured markings
identifying the terminals in your plug, and
proceed as follows:
The blue wire must be connected to the terminal
that is marked with the letter N.
The brown wire must be connected to the
terminal that is marked with the letter L.
If power supply cord is damaged, it must
replaced by the manufacturer or its service
agent or a similar qualified person in order to
avoid a hazard.
5

Before first use
User Instructions
Setting up the shredder
1. Remove the shredder from the packaging
and unwind the cord to its full length.
2. Place the waste bin on a firm level surface in
a stable upright position.
3. This appliance is equipped with a safety
system. If the shredder head and waste bin
are not correctly in place, the appliance will
not function.
4. Take the main unit by holding on handle and
put it onto the waste bin. Ensure that the
alignment marks on the shredder head and
waste bin are in line.
5. Install the CD bin inside the waste bin.
Ensure to fix it in place.
6. Make sure the function switch is at “OFF”
position.
7. Connect the plug to the 220-240V AC mains.
Using your appliance
1. AUTO mode
yTo use this mode, turn the function switch to
“Auto”.
yFeed the paper into the paper in-throat, the
micro-switch in the throat will be pressed.
yThe shredder will operate to shred the paper.
yOnce all the papers have been shredded, it will
stop itself.
yWhen the motor is over heated, the machine
will be shut off automatically, after a cool down
time of 40 minutes around, the machine can
be started working again.
NOTE: The maximum paper can be fed
are 10 sheets. Should the shredder be
overfed, it will stop working due to paper jam.
OVERHEAT SAFETY DEVICE
Your shredder is fitted with a safety device that
switches off the unit in event of overload.
Should the unit stop working, turn the unit off
and unplug from the mains. Allow the motor to
cool down to room temperature (approx. 15mins)
before resuming operation.
If the unit fails to operate or the safety device
switches the unit off again, return the unit to your
nearest service center for examination or repair.
6

Usin
g
y
our a
pp
liance
User Instructions
2. OFF MODE
yTo switch off the shredder, turn the function
switch to “OFF” position.
3. REVERSE mode
yTurn the function switch to “REV” position.
yThe cutting blade in shredder will run in
reverse direction.
Paper jam
yTurn the function switch to “REV” position to
let the cutting blade running in reverse
direction. Then the paper will come out from
the throat.
yPull out the paper carefully to clear the throat.
yOnce the jammed paper is removed, turn the
function switch to “AUTO” position for normal
operation.
Empty the waste bin
ySwitch off the unit and disconnect from the AC
mains.
yRemove the main unit from the bin and put on
the floor.
yEmpty the bin.
yPlace the bin on the floor after empty and put
the main unit back. Make sure it is positioning
in good condition.
yConnect to the AC mains.
Note: Always empty the bin while it is
full to avoid hazard.
7

Care and Maintenance
General
Important: Always unplug the appliance from the power socket during cleaning and
maintenance.
yNever use any sharp instruments or abrasive substances, soap, household cleaner, detergent or wax
polish for cleaning.
yUse luke warm water to clean the cabinet of the appliance and wipe it dry.
yNever clean the appliance with flammable fluids. It could cause a damage and fire hazard.
yEnsure the unit is dry before connect to the mains.
Trouble Shooting
In the unlikely event of difficulties with your appliance please follow the trouble shooting guide below. If
the problem persists, contact the retailer if the machine is still under guarantee on 0845 640 0800.
Problem Possible cause Solution
Appliance does not
start yThe mains plug is not plugged in.
yFuses of the electrical system at
home open.
yOverheat protection device is
activated.
yInsert the mains plug.
yCheck the protection devices and
fuses.
yAllow the motor to cool down to
room temperature (approx. 15mins)
before resuming operation. Do not
overfed the shredder.
Motor is running but
cannot shred the
papers
yWaste bin is full. yEmpty the waste bin.
8

Technical Specifications
Disposal information
Model S273
Voltage 220-240 V 50Hz
Paper entry width 220 mm
CD entry width 122mm
Shred size 4 x 45 mm
Shred paper capacity 10 sheets (80 g/sm, A4)
Shred CD capacity 1 CD / credit card
Shred speed 2.5 m /min
Waste bin Volume 17 Liter (1.6 L for CD bin)
Noise level 72 dB
Duty cycle 2min ON 60min OFF
Net weight 4.3kg
Dimension 348 x 232 x 366 mm
We apologise for any inconvenience caused by any minor inconsistencies in these instructions, which may
occur as a result of product improvements and development.
This appliance complies with the following EEC directives:
2006/95/EEC Low voltage directive
2004/108/EEC EMC directive
The symbol on the product or its packaging indicates that this product may not be treated as
household waste. Instead it should be handed over to the applicable collection point for the
recycling of electrical and electronic equipment. By ensuring this product is disposed of
correctly, you will help prevent potential negative consequences for the environment and
human health, which could otherwise be caused by inappropriate waste handling of this
product. For more detailed information about recycling this product, please contact your local
council office, your household waste disposal service or the shop where the product was
purchased.
9

Guarantee
PRODUCT GUARANTEE
This product is guaranteed against manufacturing defects for a period of
Year
This product is guaranteed for twelve months from the date of original purchase.
Any defect that arises due to faulty materials or workmanship will either be replaced,
refunded or repaired free of charge where possible during this period by the dealer from
whom you purchased the unit.
The guarantee is subject to the following provisions:
yThe guarantee does not cover accidental damage, misuse, cabinet parts, knobs or
consumable items.
yThe product must be correctly installed and operated in accordance with the instructions
contained in this manual.
yIt must be used solely for domestic purpose.
yThe guarantee will be rendered invalided if the product is re-sold or has been damaged by
inexpert repair.
ySpecifications are subject to change without notice.
yThe manufacturer disclaims any liability for the incidental or consequential damages.
yThe guarantee is in addition to, and does not diminish your statutory or legal rights.
Guarantor: Home Retail Group
489 - 499 Avebury Boulevard
Central Milton Keynes
MK9 2NW
10
