Bush CBB1MP3 User manual

Instruction Manual
CBB1MP3

Page 1
Table of contents
Safety Warnings .............................2
Accessories included............................3
Overview of controls.............................3
General operation ...........................4
Battery installation..............................4
Mains operation.................................4
Standby mode ..................................4
Volume controls.................................4
Radio operation .............................5
Saving/recalling radio presets...................5
CD/MP3CD operation ........................5
Loading a disc...................................5
Playing a disc ...................................5
Skip & search for a specific point to play. . . . . . . . . 6
Repeat playback ................................6
Programmed playback ..........................6
Auxiliary in ..................................6
Auxiliary in (cont) ............................7
USB operation...............................7
Disc handling................................7
Care & maintenance .........................8
Troubleshooting .............................8
Technical specifications......................9
Fitting a plug ................................9
Product Codes
CBB1MP3

Page 2
Safety information
Important – Please read these instructions fully before installation
Safety Warnings
CAUTION:TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE ANY COVER. NO USER-
SERVICEABLE PARTS INSIDE, REFER ANY SERVICING
TO QUALIFIED SERVICE PERSONNEL.
• Please take the time to follow the instructions in
this owner’s guide carefully. It will help you set up
and operate your system properly and enjoy all of its
advanced features.
• Please save this owner’s guide for future reference.
• The product label is located on the back of the
product.
• This product must be used indoors. It is neither
designed nor tested for use outdoors, in recreation
vehicles,or on boats.
• Heed all warnings - on the product and in the
owner’s guide.
• Do not use this apparatus near water or moisture.
• Do not use this product near a bathtub, washbowl,
kitchen sink, and laundry tub, in a wet basement,
near a swimming pool, or anywhere else that water
or moisture is present.
• Only use attachments/accessories specified by the
manufacturer.
• Unplug this apparatus during lightning storms or
when unused for long periods of time - to prevent
damage to this product.
• Refer all servicing to qualified service personnel
• Servicing is required when the apparatus has
been damaged in any way:such as liquid has been
spilled or objects have fallen into the apparatus;the
apparatus has been exposed to rain or moisture,
does not operate normally, or has been dropped -
• Do not attempt to service this product yourself.
• Opening or removing covers may expose you to
dangerous voltages or other hazards.
• To prevent risk of fire or electric shock, avoid
overloading wall outlets, extension cords,or integral
convenience receptacles.
• Use proper power sources - Plug the product into a
proper power source, as described in the operating
instructions or as marked on the product.
• The mains plug is used as the disconnect device, the
disconnect device shall remain readily accessible
• Minimum distances around the apparatus for
sufficient ventilation
• The ventilation should not be impeded by covering
the ventilation openings with items such as
newspapers, table cloths, curtains etc.
• No naked flame sources, such as lighted candles
should be placed on the apparatus.
• Attention should be drawn to the environmental
aspects of battery disposal
• The use of apparatus in tropical and/or moderate
climates.
• Batteries shall not be exposed to excessive heat
such as
• sunshine,fire or the like.
This symbol means that this unit is double
insulated.An earth connection is not required.
CAUTION :CLASS 1 LASER PRODUCT
Use of contents or adjustments of performance of
procedures other than those specified Herein may
result in hazardous radiation exposure.
LASER SAFETY
This unit employs a laser, only qualified
service personnel should attempt repair.
DANGER:Invisible laser radiation when open and
interlock failed or defeated avoid direct exposure to
beam.
CAUTION:hazardous laser radiation when open and
intelock defeated.
CAUTION
RISK OF ELECTRIC SHOCK!
DO NOT OPEN!

Page 3
Functions & controls
Please familiarize yourself with the parts and accessories listed below
Accessories included
• 1 x CBB1MP3 • 1 x Mains cable • 1 x Instruction manual
Overview of controls
1: Speakers
2: STANDBY /SOURCE button
3: MODE/MEMORY/PROGRAM
button
4: VOLUME - button
5: VOLUME + button
6: USB input socket
7: SKIP< /TUNE - button
8: SKIP> /TUNE + button
9: M+/STOP button
10: PLAY/PAUSE/ FM STEREO/
MONO button
11: LCD display
12: CD door
13: Carry handle
14: Telescopic antenna
15: Battery compartment
16: AUX-IN socket
17: MAINS POWER socket
13
15
11
10
9
8
7
1
2
3
4
5
6
14
16
17
12

Page 4
General operation
Battery installation
1: Press and slide the battery compartment cover
carefully to remove.
2: Install 6x ‘C’ size batteries (UM-2 or equivalent) while
observing the correct polarities.
NOTE: There is an engraved diagram
showing battery installation inside the battery
compartment.
3: Replace the battery compartment cover.
NOTE: The mains cable must be detached
from the DC mains socket of the player for the
batteries to power the unit.
Leaking batteries may damage the battery
cabinet and the player as a whole,so they should
be removed from the cabinet when becoming flat
or when the player is not to be used with batteries
for some time.
*Batteries not included.
Mains operation
This unit is supplied with a mains cable.
1: To connect the power insert the figure 8shaped end
into the rear of the unit (17).
2: Insert the plug into a household power socket, and
switch the power ON.
Standby mode
Using the standby mode will save power when the unit
is not in use.
1: When the unit is switched ON for the first time the
display will remain blank to indicate the unit is in
STANDBY mode.
2: To wake the unit from the STANDBY mode, press the
STANDBY /SOURCE button (2).The unit will wake
and the display (11) will illuminate.
3: To enter the STANDBY mode press and hold the
STANDBY /SOURCE button (2) for at least 2
seconds.The display will dim.
NOTE: This unit is designed to enter STANDBY
mode automatically after 20 MINUTES of
inactivity. Press the STANDBY button (2) to wake
the unit.
Volume controls
1: To increase the volume level press the VOL+ button
(5) repeatedly, or press and hold for rapid advance.
2: To decrease the volume level press the VOL- button
(4) repeatedly, or press and hold for rapid advance.
User instructions

Page 5
User instructions
Radio operation
1: Wake the unit from STANDBY mode if required.
2: Press the STANDBY /SOURCE button (2) repeatedly
until you see ‘87.5’ or another radio frequency on the
display.
CD USB AUX FM RADIO
3: Extend the antenna fully, and angle for best reception
(you may need to adjust once tuned to a station).
4: Tune to the required station using the SKIP/TUN
buttons (7,8). Pressing either button once advances
the frequency in 0.1MHz increments. Press and hold
either button to search up or down the frequency
range, until a station is located.When a station is
found it will begin playback.You can stop the scan at
any time, by pressing either SKIP/TUN button again.
NOTE: When receiving an FM broadcast, fully
extend the telescopic antenna and angle it for the
best reception.
5: Adjust the volume to a comfortable listening level
using the volume controls.
7: To switch between STEREO & MONO radio modes
press the FM STEREO/MONO button (10) repeatedly.
Saving/recalling radio presets
After tuning to a radio station you may wish to store
the frequency to a preset location, so you can recall
easily at a later date. There are 20 preset locations.
1: When tuned to the station you wish to store,press
the MODE/MEMORY/PROGRAM button (3).You will
see ‘PXX’ on the display (XX indicates the preset
location).
2: Use the SKIP/TUN buttons (7,8) to cycle through the
preset locations 1-20.
3: Once a preset location number has been selected,
press the MODE/MEMORY/PROGRAM button (3)
to store the current station to the selected preset
location number.
4: To recall stations saved to a preset location,use
the M+/STOP button (9) to cycle through the preset
locations 1-20.When a preset number has been
selected the station will begin to play after a second.
CD/MP3CD operation
1: Wake the unit from STANDBY mode if required.
2: Press the STANDBY /SOURCE button (2) repeatedly
until you see ‘Cd’ appear on the display with a small
‘CD’ icon.
CD USB AUX FM RADIO
Loading a disc
1: Lift the CD door using the raised OPEN tab.You will
see ‘OP’ on the display to indicate the door is open.
2: Load a disc onto the disc tray with the label side
facing up.
3: Close the CD door.
4: When the disc is read the display will show the total
number of tracks found on the disc (and folders in
the case of MP3CD).If the disc is unrecognizable or
faulty ‘No’ will appear on the display. Either re-load
the disc or try another disc.
Playing a disc
1: Follow the previous steps to load a disc (if not already
loaded).
2: Press the PLAY/PAUSE button (10) once to begin
playback of the current disc.The ‘ ’icon appears on
the display to indicate PLAY mode is active.
3: Press the PLAY/PAUSE button (10) once more to
PAUSE the music playback.The track number & ‘ ’
icon flashes on the display to indicate the player is in
PAUSE mode.Pressing the PLAY/PAUSE button (10)
again resumes playback.
4: Press the M+/STOP button (9) to cease music
playback.The LCD shows the total number of tracks
again.
NOTE: MP3 tracks can be stored inside a
single folder or on the root of the disc. For example
FOLDER1 can store MP3’s but FOLDER2 inside
FOLDER1 wont be readable.See diagram below.
MP3
MP3
MP3
MP3
F2F1

Page 6
User instructions
Skip & search for a specific point to play
1: Press the SKIP/TUN> button (8) once during playback
to skip to the next track.To skip to a specific track
ahead,press this button several times until you reach
the track number required.
2: Press the <SKIP/TUN button (7) once during playback
to return to the beginning of the current track.Press
the <SKIP/TUN button (7) twice repeatedly to skip to
the previous track.To skip to a specific track,press
this button several times.
3: Hold the SKIP/TUN> button (8) during playback to
fast forward the current track.
4: Hold the <SKIP/TUN button (7) during playback to
fast rewind the current track.
Repeat playback
Should you wish to repeat a single track or entire disc,
follow the below steps.
1: During playback of a CD or PAUSE mode,press the
MODE/MEMORY/PROGRAM button (3). After one
press you will see the ‘ ’icon flash on the top of the
display, to indicate the current track will repeat.
2: MP3CD ONLY: Press the MODE/MEMORY/PROGRAM
button (3) again and the ‘ FOLDER’ icon will
appear to indicates the entire MP3CD folder will
repeat.
NOTE: All files in the root of the disc are
classified as Folder 1.
3: Press the MODE/MEMORY/PROGRAM button (3)
again and the ‘ ’ icon will appear again but remain
solid (no flash) to indicate the entire disc will repeat.
4: Pressing the MODE/MEMORY/PROGRAM button
(3) once more will see the ‘ ’ icon disappear,
this indicates that all REPEAT functions have been
cancelled.
Programmed playback
To program an alternative playback order of tracks
follow the below steps.
1: Make sure the unit is in STOP mode.
2: Press the MODE/MEMORY/PROGRAM button (3)
once.The ‘ ’ icon appears in the top left corner
of the display.You will also see ‘PXX’ appear on the
display.The XX indicates the track number to be
programmed.
3: Select the first track to be programmed using the
<SKIP/TUN> buttons (7,8).
4: Press the MODE/MEMORY/PROGRAM button (3)
again to store and advance to the next programmed
track.The playback order digit will increase each
time to indicate which playback track is being
programmed.
5: Repeat the steps above to program more tracks.
A maximum of 20 tracks (100 MP3CD/USB) can be
programmed.
6: Press the PLAY/PAUSE button (10) to begin the
programmed playback in the preferred order.
7: You may press the M+/STOP button (9) to terminate
programmed playback.In program STOP mode, press
the M+/STOP button again to clear the programmed
sequence or press the PLAY/PAUSE button to begin
the programmed playback again.
Auxiliary in
It is possible to connect an external audio source
like an MP3 player using a 3.5mm audio cable (not
supplied).
1: Connect one end of the cable to the MP3 players
headphone output and the other end to the AUX input
(16) on the rear of the unit.

Page 7
Auxiliary in (cont)
2: Wake the unit from STANDBY mode if required.
3: Press the STANDBY /SOURCE button (2) repeatedly
until you see ‘AUX’ on the display.
CD USB AUX FM RADIO
4: Press PLAY on the external audio source EG:-MP3
player.
NOTE: the volume output is effected by the
volume level on the source EG: MP3 player so
make sure that is set to about 70-80% ( not too
loud to avoid distortion ).
5: Adjust the VOLUME controls on the unit to the
required listening level.
USB operation
1: Insert a USB flash drive into the USB port (6) as
shown below.
2: Press the STANDBY /SOURCE button (2) repeatedly
until you see ‘USb’ on the display.
CD USB AUX FM RADIO
3: Audio tracks are detected and the total number of
folders and tracks on the device are displayed for 1-2
seconds before playback of track 1begins.
4: Once loaded the playback controls for USB operation
are identical to CD operation.Please see Playing
a disc,Skip & search for a specific point to play,
Repeat playback & Programmed playback on pages
5-6.
Disc handling
Do not touch the playback side of the disc.
Do not attach paper or tape to disc.
Fingerprints and dust on the disc cause picture and
sound deterioration. Wipe the disc from the centre
outwards with a soft cloth. Always keep the disc clean.
If you cannot wipe off the dust with a soft cloth,wipe
the disc lightly with a slightly moistened soft cloth and
finish with a dry cloth.
Do not use any type of solvent such as thinner, benzene,
commercially available cleaners or antistatic spray for
vinyl.It may damage the disc.
Do not store discs in a place subject to direct sunlight or
near heat source.
Do not store discs in a place subject to moisture and
dust such as a bathroom or near a humidifier.
Store discs vertically in a case, stacking or placing
object on discs outside or their case may cause warping.
User instructions

Page 8
User instructions
Care & maintenance
Important:Always unplug the appliance from the power socket during cleaning and maintenance.
Never use any sharp instruments or abrasive substances, soap, household cleaner, detergent or wax polish for
cleaning.
Clean the external surfaces with a damp soft cloth only. Never use abrasive products or solvents as it may
damage the appliance.
Troubleshooting
In the unlikely event of difficulties with your appliance please follow the trouble shooting guide below.
If the problem persists,contact the retailer if the machine is still under guarantee.
Customer helpline:0870 600 3030
Problem Reason(s) Solution(s)
No Power • Power cable not connected to
wall socket
• Power socket is not switched on
• Make sure the plug is connected
• Switch the power on
No Sound CD/AUX/RADIO/USB
No Sound from AUX input
• Volume is too low
• AUX source volume is too low
• Increase the volume
• Increase the output volume of the
AUX source.
Sound is distorted
Sound is distorted from AUX
input
• Volume is too high
• AUX source volume is too high
• Reduce the volume
• Reduce the output volume of the AUX
source.
Unable to Play • No disc in the tray
• Disc not loaded properly
• Disc is dirty
• Insert a compatible disc
• Check the disc loaded
• Clean the disc
Static Sound • Poor reception • Re-locate the antenna (FM)
Unit switches off after 20
minutes of inactivity
• Auto standby mode in operation • This unit is designed to enter
STANDBY mode automatically after
20 MINUTES of inactivity. Press the
STANDBY button to wake the unit.
We apologise for any inconvenience caused by any minor inconsistencies in these instructions,which may occur as
a result of product improvements and development.
This appliance complies with the following EEC directives:2006/95/EEC Low voltage directive /
2004/108/EEC EMC directive
Disposal information
The symbol on the product or its packaging indicates that this product may not be treated as household
waste. Instead it should be handed over to the applicable collection point for the recycling of electrical
and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent
potential negative consequences for the environment and human health,which could otherwise be
caused by inappropriate waste handling of this product.For more detailed information about recycling
this product,please contact your local council office,your household waste disposal service or the shop
where the product was purchased.

Page 9
Technical specifications
General
Power • AC:230-240V ~ 50Hz
• DC: 9V UM-2/”C” x 6pcs
Power Consumption • AC:10 Watts
Dimensions • Approx.250mm(L) x 220mm(W) x 135mm(H)
AUX In • 3.5mm stereo socket
Tuner
FM • 87.5 - 108 MHz
CD Player
Playback system • Compact Disc Digital Audio System
DAC • 1 Bit DA converter with 8 x over sampling.
Frequency response • 100Hz -7KHz
S/N ratio • ≥45dB
Dynamic range • 60dB
Audio
Output Power • 1.2W x 2 (RMS)
Speaker impedance • 8 ohms
Disc Compatibility
Disc Type • CD-DA/CD-R/CD-RW
Size • 12cm & 8cm
Fitting a plug
For your convenience a mains plug with a fuse (3 Amp) has been fitted to this appliance.
For your safety please observe the following information.
• The unit is designed to operate on AC mains supply 230 volts,50 Hz.
• The wires in the mains lead are coloured in
accordance with the following code:
BLUE - NEUTRAL
BROWN - LIVE
• Under no circumstances should Neutral or Live
wires be connected to the ‘E’ (Earth) terminal.
User instructions
E
L
N
BLUE TO
NEUTRAL
FUSE
BROWN TO
LIVE

Page 10
Guarantee
PRODUCT GUARANTEE
This productis guaranteed against manufacturing defects for a period of
Year
This product is guaranteed for twelve months from the date of original purchase.
Any defect that arises due tofaulty materials or workmanship will either be replaced,
refunded or repaired free of charge where possible during this period by the dealer from
whom you purchased the unit.
The guarantee is subjectto the following provisions:
The guarantee does not cover accidental damage, misuse, cabinet parts,knobs or
consumable items.
The productmust be correctly installed and operated in accordance with the instructions
contained in this manual.
It must be used solely for domestic purpose.
The guarantee will be rendered invalided if the product is re-sold or has been damaged by
inexpert repair.
Specifications are subject tochange without notice.
The manufacturer disclaims any liability for the incidental or consequential damages.
The guarantee is in addition to, and does not diminish your statutory or legal rights.
Guarantor: Argos Limited
489 - 499 Avebury Boulevard
Central Milton Keynes
MK9 2NW
