Bush BMS05DABIP User manual

DAB+ CD Mico System
with Universal Dock for iPod
The Gold Technical Support Line: 1902 215 259
Personal Product Support
(Charges will apply at $2.95 per minute)
BMS05DABIP

BMS05DABIP
Introduction
Thank you for buying this Bush product, which is designed to give you many years of trouble
free service.
You may already be familiar with using a similar unit, but please take time to read these
instructions. They are designed to familiarise you with the unit's many features and to ensure
you get the very best from your purchase.
Safety is important
Your safety and the safety of others is important.
Please therefore, ensure you read the “Safety Instructions” before you operate this unit.
Warranty
In the unlikely event that your product fails to work normally, please call the below free phone
number to discuss the problem with one of our qualified service engineers.
Australia.
Bush Warranty: 1800 509 394
New Zealand
Bush Warranty: 0800 450 259
2

BMS05DABIP
3
SAFETY PRECAUTIONS
To achieve the utmost in enjoyment, performance and in order to become familiar with its features, please
read this manual carefully before attempting to operate the unit.
The below safety and operating instructions should be retained for future reference.
* Do not place the unit in areas with direct sunlight or close to heat radiating appliances, such as; heaters
etc. This may cause the unit to overheat and damage the unit.
* Keep the unit in area that is well ventaliated and is not dusty.
* Place the unit on a clean flat surface that does not experience vibration or is exposed to humid or moist
conditions.
* Do not place any candles on or near the unit.
* Make sure you dispose of your old batteries in a safe and eco-friendly way.
* Do not allow anything to cover or obstruct the units ventilation openings. A minimum of 10cm should be
kept around the unit for ventilation.
* Please operate all features and functions as outlined in this manual. Any modifications or non-outlined
activities will make the warranty void.
* Make sure you connect the power cord correctly and turn the power on at the mains power before
operating the unit.
*
* Store your CDs in a cool area to avoid any damage.
* There are no serviceable parts in this unit. If you have any issues with the operation of this unit please
contact the Bush Service and Warranty number provided on the front page of this manual.
TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK), NO
USER SERVICEABLE PARTS INSIDE, REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
This unit is a conductor of dangerous voltage, do not open or modify this unit to avoid any risk
of electric shock to persons within this product's enclosure.
The owner's manual contains important operating and maintenance instructions, for your
safety, it is necessary to refer to the manual.
WARNING :TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO DRIPPING
OR SPLASHING WATER OR LIQUID .
This unit will become warm when used for a long periods of time. This is normal and does not indicate
a problem with the unit. This unit includes micro-processors which may malfunction as a result of external
electrical interference/noise or electrostatic discharge . If the unit is not working properly, disconnect the
power source and then reconnect it.
Important Notes
CAUTION:
DANGEROUS VOLTAGE
ATTENTION
Note:
* Do not exposed this Micro System to any types of liquid as they will cause serious damage to the unit. Do
not place any objects filled with water on or near the unit.
Make sure you use the iPod Dock connectors to connect your iPod to the unit. This will protect both the
unit and you iPod.

BMS05DABIP
4
Contents
FEATURES AND CONTROLS…….........……………………………………………….…………….... 5
REMOTE CONTROL…………..........……………………………………..…………….……………... 6
REMOTE BATTERY OPERATION...........................................……………......…………………… 6
……..…………………………….……………................…………. 7-8
……….........................................................…….… 9
…………………………………………………………...………..................…….. 9
…….……………...…………..........................…….. 9-11
……………………………………...……….............................…….. 11
……………………………………………...............…...…………….. 11
AUX INPUT…………………………………………………………...….........................………….. 11
………….……………………………………….....................…………….. 11
……………………………………………………...….....................………….. 12
…………………………………………...........…...…………….. 12
………………………...…….........................……….. 12
……………………...………...............................…….. 12
…………………...……...........................................................……….. 12
COMPACT DISC……………………...………..............................................................……... 13
…………………….................................................................…………….. 13
SUPPORTED iPod DEVICES………….............................................................…………...... 14
WARRANTY…………………………………………...………….……………...……………………… 15
LISTENING TO YOUR RADIO
STATION PRESETS (remote control only)
FACTORY RESET
LISTENING TO YOUR COMPACT DISCS
LISTENING TO YOUR iPod
CHARGING UP YOUR iPod
ON TIMER FUNCTION
SLEEP FUNCTION
PRESET EQ (remote control only)
X-BASS FUNCTION (remote control only)
MUTE FUNCTION (remote control only)
BACKLIGHT FUNCTION……………………...……………...................................................... 12
HEADPHONE INPUT
SPECIFICATION

1 2
3
4 5 6 7 8 9
10
11
12 13 14 15 16 17
18
19
20
21 22
23 24
BMS05DABIP
5
FEATURES AND CONTROLS
1. iPod/CD BUTTON:
2. STANDBY INDICATOR:
3. STANDBY BUTTON:
4. DAB+/FM BUTTON:
5. AUX BUTTON:
6. SCROLL BUTTON:
7. SCROLL BUTTON:
8. LCD DISPLAY:
9. VOL/SCROLL CONTROL & SELECT BUTTON:
10. BACKLIGHT BUTTON:
11. IR SENSOR:
12. DISPLAY/INFO BUTTON:
13. TIMER BUTTON:
14. SLEEP BUTTON:
15. STOP/MENU BUTTON:
16. PLAY/PAUSE BUTTON:
17. HEADPHONE JACK:
18. CD DOOR:
19. iPod DOCKING STATION DOOR:
20. OPEN BUTTON:
21. ANTENNA:
22. AUX IN JACK:
23. AC CORD:
24. SPEAKER TERMINALS:
Press to select iPod or CD function.
This will light up when the unit is in Standby mode.
Press to turn the unit on or off.
Press to switch between DAB+ and FM Radio mode.
Press to select Aux Input mode.
Press to scroll down through the menu settings or to
skip backwards through iPod/CD/AUX In modes.
Press to scroll up through the menu settings or to skip
forwards through iPod/CD/AUX In modes.
The LCD Display will show your Menu, Radio, Music etc
information.
Rotate the control to adjust the volume or to scroll through
the menu. Press this button to confirm any selections.
Press to turn the LCD Display backlight on or off.
This is where your remote control signal is received.
Press to scroll through DAB+ scrolling text information.
Press to set the on timer function.
Press to set unit sleep time function.
Press to stop play in iPod/CD/Aux In Mode or press to
access the Main Menu.
Press to play or pause in iPod/CD/Aux in mode.
This input allows you to connect your headphones for
personal listening.
CD Door will open when you press the open button then
load or remove disc.
Slide door to open and then connect your iPod.
Press to open the CD Door.
This is the Antenna Input. Ensure the Antenna wire is
straight to receive the best reception.
The Aux Input allows you to connect your other audios
sources i.e. MP3 Player.
The AC Cord input allows you to connect your unit to your
main power source.
I◀◀/▼
▶▶I / ▲
Extend the speaker wires and connect them to the
speaker terminals.

BMS05DABIP
6
REMOTE CONTROL
1. STANDBY BUTTON:
2. iPod/CD BUTTON:
3. SELECT/REPEAT BUTTON:
4. SCROLL BUTTON:
5.
6. PROGRAM BUTTON:
7. X-BASS BUTTON:
8. VOLUME - BUTTON:
9. MUTE BUTTON:
10. DAB+/FM BUTTON:
11. AUX BUTTON:
12. SCROLL BUTTON:
13. PLAY/PAUSE BUTTON:
14.
15. STOP/MENU BUTTON:
16. RANDOM BUTTON:
17. BACKLIGHT BUTTON:
18. DISPLAY/INFO BUTTON:
19. EQ BUTTON:
20. VOLUME + BUTTON:
Press to turn the unit on or off.
Press to select iPod or CD function.
Press to confirm selections in the main menu or press to repeat play
in CD/iPod/Aux In mode.
Press to scroll down through the menu settings or to skip backwards
through iPod/CD/AUX In modes.
NAVIGATE DOWN/FOLDER BUTTON: Press to recall stored station presets or to scroll
downwards in the MP3 folder.
Press to store station presets or to program song playlist.
Press to turn X-Bass function on or off.
Press to decrease the volume.
Press to turn the sound off completely.
Press to switch between DAB+ and FM Radio modes.
Press to select Aux Input mode.
Press to scroll up through the menu
settings or to skip forwards through iPod/CD/AUX In modes.
Press to stop play in iPod/CD/Aux In
Mode or press to access the Main Menu.
NAVIGATE UP /FOLDER BUTTON: Press to recall stored
station presets or to scroll upwards in the MP3 folder.
Press to stop play in iPod/CD/Aux In
Mode or press to access the Main Menu.
Press to select random play function.
Press to turn the LCD Display backlight
on or off.
Press to scroll through DAB+
scrolling text information.
Press ti scroll through the EQ Preset options.
Press to increase the volume.
I◀◀/▼
▶▶I / ▲
REMOTE BATTERY OPERATION
1.
2. Place the battery (CR2032) into the battery compartment according
to the polarity marking(place the “+” sign upwards).
3. Rep
Note: Remove the battery from the remote control if not in use for a long
period of time. Do not mix normal batteries with rechargeable batteries.
When the battery becomes weak, the remote control will not function to the
best of its ability. Be sure to replace with a new battery if that happened.
1. Please only use the battery type outlined in this manual.
2. Place the battery into the remote as outlined above only.
3.
Do not expose battery to heat.
Press downwards on the compartment cover of the remote control to
open battery compartment.
lace the cover by inserting the cover and pressing downwards.
Make sure it snaps in.
BATTERY PRECAUTIONS
Be sure to follow the correct polarity when installing the battery as indicated in the battery compartment.
** Battery Included **
1
2
3
4
5
6
7
8
9
10
12
11
13
14
15
17
18
20
16
19

F2 F3 F1
BMS05DABIP
7
F4
F6 F7
F5
LISTENING TO YOUR RADIO
Hints for better reception
This unit is fitted with a single lead wire DAB+/FM antenna, to obtain the best performance, you
should fully extend the wire antenna and adjust the position as well as the direction until you find the
best reception. For ideal DAB+ reception, always maintain the lead wire antenna in a vertical
position is highly recommended.
Getting started DAB+ mode
When the unit is powered up for the first time, it will be in standby mode. The display will show as
“00:00”. Press the STANDBY Button to turn the on and it will automatically enter into the DAB+ mode
and perform full station scan. During the scan the display will show “Scanning …” together with a
slide bar that indicates the progress of the scan and the amount of stations that have been found so
far. (F. 1) (F. 2) (F. 3)
Once the scan has finished, the radio will You can now with the
VOL/SCROLL Control or press the SCROLL ▲ or ▼ Buttons explore the new DAB+ stations. Press
the SELECT Button to select
Note: If there are no stations found after the full scan, the radio will enter into the Tune Select Menu
and you can press the SCROLL ▲ or ▼ Buttons and the SELECT Button to Manually Scan for the
DAB+ stations in your area. Visit www.digitalradioplus.com.au to check your postcodes receives
digital radio.
Clock
The clock if you can receive DAB+ signals in your
location. While the clock synchronises to the current local time please keep the unit in DAB+ mode.
DAB+ Full Scan
When you conduct a Full Scan the unit will search for all available DAB+ stations. Once the scan is
complete, the stations will be stored in alphanumerical order.
1. To conduct a DAB+ Full Scan, press the MENU Button and scroll to the Tune Select Menu. Then
press the SCROLL ▲ or ▼ Buttons to select “Full scan” and press the SELECT Button to
confirm. The display will show “Scanning...” and a progressing slide bar. (F.4) (F.5)
2. All the stations found will be stored automatically. To scroll through the
VOL/SCROLL Control or press the SCROLL ▲ or ▼ Buttons and press the SELECT Button
to confirm and play selected stations.
DAB+ Manual Scan
1. To conduct a Manual Station Scan, press the MENU Button and enter the Tune Select Menu.
Then press the SCROLL ▲ or ▼ Buttons to select “Manual tune”. Press the SELECT Button to
confirm. (F. 6)
2. Rotate the VOL/SCROLL Control or press the SCROLL ▲ or ▼ Buttons to move through the
DAB+ station frequencies. “5A to 13F” will display on the screen with their associated
frequencies (F. 7)
3. When your desired frequency appears on the display, press the SELECT Button to confirm.
The name of the station group (ensemble/multiplex) will also be displayed.
4. To listen to the station selected, press on the SELECT Button again.
select the first station found.
the station you wish to listen to.
stored stations rotate
the
will only be shown and automatically updated

Time/Date
Ensemble/Multiplex (Group name)
Frequency Audio Bit Rate
Signal strength
DLS
Programme Type
BMS05DABIP
8
DAB+ Display Modes
Every time you press the DISPLAY/INFO Button, the display will cycle through the following display
information:
Time and date
The time and date will be the time and date provided by the broadcaster. In the unlikely event that no
clock information is received, the display will show “[No Time]”.
Frequency
The frequency of the present station will be displayed.
Audio bit rate
The display will show the digital audio bit rate being received.
Signal strength
The display will show a slide bar to indicate the signal strength, the stronger the signal, the longer
the bar will be from left to right.
DLS
DLS stands for Dynamic Label Segment which is the scrolling text information provided by the
broadcaster. The information displayed may include song titles, album information etc.
Programme type
This describes the style of the programme that is being broadcast. If the information is not available,
the display will show “[No PTY]”.
Ensemble/Multiplex (Group name)
The Ensemble/Multiplex is the station broadcaster information.
Note: Press and hold the DISPLAY/INFO Button for longer than 2 seconds to view the software
information.
FM Radio
1. To switch to FM, press the DAB+/FM Button. (F. 8)
2. To search for the next available frequency, press and hold the I◀ ◀ or ▶ ▶I Buttons. The search
will stop automatically once a station has been found.
3. To manually search for the next available frequency, press the I◀ ◀ or ▶ ▶I Buttons or press the
SELECT Button then rotate the VOL/SCROLL Control until the desired frequency is displayed on
the screen.
4. To select audio mode, press the PLAY/PAUSE Button to toggle between the “Stereo” or “Mono”
selection.
Note: The radio will automatically switch between stereo and mono mode, but you can override this
and switch this function manually which is helpful for poor signal reception.
LISTENING TO YOUR RADIO
F8

You can store 10 DAB+ or 10 FM Stations Presets for easy access to your favourite stations.
1. To store a Station Preset, tune to the desired station and press and hold the PROGRAM Button on
the remote control until the display shows the preset number. (F. 9)
2. Press the SCROLL ▲ or ▼ Button to select the desired Station Preset number.
3. Press the PROGRAM Button again to confirm your selection, the display will show “Preset #
stored”. (F.10)
4. To recall a Station Preset that you have stored, press the Buttons on the
remote control, the display will show the preset number and the associated information. (F.11)
To conduct a Factory Reset, please follow the below instructions. Please note this will clear all settings.
1. Press and hold the MENU Button until the display shows “Press SELECT to confirm reset”.
2. Release the MENU Button and press the SELECT Button, the display will show “Restarting …”
and once reset is complete it will then perform full station scan.
3. After the scan has finished, the radio will select and display the first
Note: All of your stored DAB+ & FM presets will be lost once the reset has taken place.
NOTE : Although this CD/MP3 player can read CD-R and CD-RW discs in addition to normal CDs, the
playability of CD-R and CD-RW discs may be affected by the type of software that was used to create
the discs, as well as the quality and condition of the blank media you are using.
This is not an indication of a problem with the player.
Playing a CD
1. Press the iPod/CD Button to select CD function. The display will show “CD” and “NO DISC” if you
have not yet inserted your CD. (F.12) (F.13)
2. Press the OPEN Button on the top panel to open the CD door, load the disc with the printed label
side facing up and then close the CD door. The display will first show “READING” and then the
total track number and time. (F.14)
3. To start playback from the beginning, press the PLAY/PAUSE Button, the display will show the
current track number and the elapsed time. (F.15)
4. If a CD/MP3 disc is being played, the display will show “MP3” together with the current folder and
track number. To see the ID3 tag if available, press the DISPLAY/INFO Button.
5. Press the PLAY/PAUSE Button to play or pause the CD. The display will show “ II ” when the unit is
paused. (F.16)
6. To resume playback, press the PLAY/PAUSE Button again.
7. To stop playback, press the ■ Button.
STATION PRESETS (remote control only)
FACTORY RESET
LISTENING TO YOUR COMPACT DISCS
NAVIGATE/FOLDER
station found.
F11 F10 F9
BMS05DABIP
9
F12 F13 F14
F15 F16

BMS05DABIP
10
LISTENING TO YOUR COMPACT DISCS
Selecting a different track during play
1. To select a different track during play, press the I◀◀ or ▶▶I Buttons until your desired track
number is displayed. Release the button for playback.
2. To select other folders in the MP3 disc, press the Buttons on the remote
control.
3. To play the next track, press the ▶▶I Button.
4. To play the current track again from the beginning during play, press the I◀◀ Button.
5. To play the previous track, press the I◀◀ Button twice.
Repeat play (remote control only)
During normal playback, you can press the REPEAT Button on the remote control to select the
repeat play function:
1. To repeat the same track, press the REPEAT Button once, the display will show “ 1 ” (F. 17)
2. To repeat the entire disc, press the REPEAT Button again, the display will show “ ”. (F. 18)
3. If you are playing a MP3 disc, an additional “ ” option will appear. This will repeat the
current folder. (F. 19)
4. To cancel repeat play, repeatedly press the REPEAT Button until the repeat icon disappears
from the display.
Random play (remote control only)
1. During CD operation, press the RANDOM Button to start random play, the display will show
“RANDOM” and the tracks will be played randomly. (F.20)
2. To resume normal playback, press the RANDOM Button again and “RANDOM” will disappear
from the display.
3. To cancel random play, press the ■ Button.
Program play (remote control only)
You can use the program play feature to play up to 20 tracks on a disc in any desired order. You may
also program a particular track to play several times within a programmed sequence.
1. Load your disc as usual and wait until the display shows the total number of tracks on the disc.
2. Ensure it is in CD mode, press the PROGRAM Button on the remote control once, the display
will show “MEM” and “P-01”.(F.21)
3. Press the I◀ ◀ or ▶ ▶ I Buttons to select the first track number to be programmed. When the
desired track number appears in the display, press the PROGRAM Button to confirm and it is
programmed. The program memory number will advance to “P-02” and ready for the next entry.
4. If a MP3 disc is being loaded, press the Buttons to select the folder.
5. Repeat the above steps to program other tracks, a maximum number of 20 tracks can be
programmed. When you have completed programming, press the PLAY/PAUSE Button to begin
program play, playback will be started on the first track you programmed and will continue until
the last programmed track has played.
6. When the program play is completed, the player stops and “PROG” will be displayed. The
player remains in the program play mode. Press the PLAY/PAUSE Button will play the
programmed sequence again.
7. To erase the program, in CD stop mode, press the ■ Button once; in CD play mode, press the ■
Button twice. “PROG” will disappear in the display.
NAVIGATE/FOLDER
NAVIGATE/FOLDER
F19F18F17
F20 F21
