BWI Eagle AIR-EAGLE SR PLUS 36-4500-DC Manual

PRODUCT INFORMATION
BULLETIN
238 Pillow Street
Butler, PA 16001
724-283-4681
724-283-5939 (fax)
www.bwieagle.com
AIR-EAGLE®SR PLUS
2.4 GHz RF Repeater
MODEL 36-4500-DC
DESCRIPTION
The AIR-EAGLE SR PLUS RF REPEATER IS designed to retransmit an
RF signal from any Air-Eagle SR or SR PLUS Transmitter. When
placed in an area where the signal is weak, this unit will then re-
transmit at full strength facilitating greater distances and allowing the
RF signal to reach around corners, through tunnels, over hills and
through valleys.
APPROVALS
United States (FCC) OUR-XBEEPRO
Canada (IC) 4214A-XBEEPRO
Europe (CE) ETSI
INSTALLATION
DISCONNECT DC Power from all equipment before installation.
1. Mount the AIR-EAGLE SR PLUS REPEATER in a convenient location.
2. Install antenna. The unit has an antenna connector located on the
rightside onthe enclosure. Attach the supplied portable antenna to
this connector.
3. Connect DC power and control to the proper terminals in your control
circuit.
TERMINAL STRIP WIRING
1 Not Used 7 Not Used 13 (-) 9-36VDC INPUT
2 Not Used 8 Not Used 14 (+) 9-36VDC INPUT
3 Not Used 9 Not Used
4 Not Used 10 Not Used
5 Not Used 11 Not Used
6 Not Used 12 Not Used
Dimensions (withmounting plate) 6.3” L x 4.8” W x 2.3” H
CONTROLS AND INDICATORS
TER1
D6
R11
D7
D3
R3
VR1
D2
MOV1
F1
BP1
BP2
MOV2
REL1
MOV3 MOV4
+
C3
FET3
+
+
INPUT OUT
--
PWR1
D1
R10
C1
C2
FET2
RF1
R9
D4
R8
R4
R5
R2
SEL1
D5
FET1
R6
FET4
LED1
R7
IC1
T1
R1
LED4LED3 REL4REL3 LED2
REL2
3.3V
N/O C N/C
- +
||
1 2
|
|| | | |
N/O C N/C 43
AC/DC INPUT
N/O C N/C N/O C N/C
.
RX LED Yellow LED illuminates as remote signals are
being received by the repeater
POWER LED Green LED is illuminated while power is applied
to the repeater
TX LED Red LEDilluminates as remotesignals are
being re-transmitted by the repeater
RF1 RFmodule that receives data from the remote
transmitter
SEL1 – 4 Not used on this model
SEL5 – 6 Used toset frequency

AIR-EAGLE®SR PLUS
2.4 GHz RF Repeater
MODEL 36-4500-DC
FREQUENCY SET-UP
The unitis shippedfrom the factory with SEL1 switches in theopen
positions (defaulting to Frequency #1). If you wish to change the default
frequency, follow the instructions onthe table below.
REMOVE POWER FROM REPEATER BEFORE CHANGING ANY OF
THE FOLLOWING DIP SWITCH SETTINGS!
FREQUENCY SET-UP
Frequency
Selection SEL1 –
SWITCH NUMBER
“5”
SEL1 –
SWITCH NUMBER
“6”
1 OPEN OPEN
2 CLOSED OPEN
3 OPEN CLOSED
4 CLOSED CLOSED
OTHER
SEL1
SWITCH
NUMBER
“7”
Reserved for future use
SPECIFICATIONS
DC Input 9 – 36 VDC @ 10 Watts
Fuse Protected 1 amp
Repeater Frequency 2.4 GHzSpread Spectrum
RF Output Power 60 mW
Repeater Range Approximately 1200 feet
Repeater Channels Four independent networks
Operating Temperature -40oF to +185oF
Enclosure ABS Plastic / NEMA 4, 4X, 12 + 13
REPLACEMENT PARTS & ACCESSORIES
PC Board (Main) 36-4502-DC
Standard Antenna (Included):
2.4GHz TNC Portable Antenna (For
distances up to 1200 feet*) 49-1201
Optional Antennas and Accessories –
Used to increase range in both non line of sight and line of sight
applications. - Contact BWI Eagle for recommendations
2.4GHz Thru-Hole Mount Mobile Antenna 49-2201
2.4GHz Magnetic Mount Mobile Antenna 49-2202
2.4GHz Omni Directional Antenna 49-3201
2.4GHz 13dB Yagi Antenna 49-3202
Flex Coax Cable w/Connectors – Connects
external antenna(s) to base unit(s). 49-4000-XX (XX = # of Feet)
Inline Lightening Arrestor 49-5002
* = Line of Sight
LIMITED WARRANTY STATEMENT
BWI Eagle Inc. warrants the Air-Eagle Remote Control System, if properly
used and installed, will be free from defects inmaterial and workmanship
for a period of 1 year after date of purchase. Said warrantyto include the
repair or replacement of defective equipment. This warranty does not
cover damage due to externalcauses, including accident, problems with
electrical power, usage not in accordance with product instructions,
misuse, neglect, alteration, repair, improper installation, or improper
testing. This limited warranty, and any implied warranties thatmayexist
under state law, applyonly to the original purchaser of the equipment, and
last only for as long as such purchaser continues to own the equipment.
This warrantyreplaces allother warranties, express or implied including,
but not limited to, the implied warranties ormerchantability andfitness for
a particular purpose. BWI Eagle makes no express warranties beyond
thosestated here. BWI disclaims without limitation, impliedwarranties of
merchantability and fitness for a particular purpose. Some jurisdictions do
not allow the exclusionof implied warranties so this limitation maynot
apply to you. To obtain warrantyservice, contact BWI Eagle for a return
material authorization. When returning equipment to BWI Eagle, the
customer assumes the risk of damage or loss during shipping and is
responsible for the shipping costs incurred.
DOCUMENT DATE: 18-Jul-07
