Foreword
Thank you for choosing BYD e6AAUTO. For correct use and maintenance of your BYD e6A, please read this Manual carefully.
BYD e6A is the first electric vehicle in China to use ET-Power as its power source. It has a complicated high-voltage and
low-voltage wiring structure. Please do NOT disassemble any high-voltage cables and high-voltage electronic components or
add any electrical appliances, such as an anti-theft system, central locking system, electric window system, audio equipment,
etc. without permission; any failure incurred thereof will not be covered by the "Warranty" of BYD.
Please follow the instructions where "Warning", "Caution" and "Tips" are indicated in this Manual to avoid the possibility of
injury or damage.
The notice types and their purposes are as follows:
Safety Sign
The illustrations provided in this manual are for reference only.
BYDAuto Co., Ltd. reserves the right for revising technical characteristics and contents of this
manual without prior notice.
Thank you for choosing BYD e6AAUTO. Your comments and opinions are valuable and are warmly welcomed.
WARNING
Precautions to avoid severe personal injury or
vehicle damage
NOTE
May possibly cause general personal injury or
vehicle damage
Tips
Assist the owner use the vehicle more easily or skillfully
The safety sign indicated
above means "Do NOT do it"
or "Do NOT let it happen".

BYD e6AAUTO Owner's Manual
WARNING
In event of an accident
Pull off the emergency service switch
beneath the console, and tow the vehicle
away from the road.
To avoid personal injury, please do NOT
touch any high-voltage cables, their
connectors or any high-voltage
component.
Do NOT touch any exposed electric wires.
If the battery pack on the vehicle chassis
is damaged, and fluids leak or flow into
other parts and components of the
vehicle, please do not touch those fluids,
because they might contain electrolyte
from the battery pack. In event of battery
leakage onto your skin or into your eyes,
please flush immediately with plenty of
water and consult a doctor.
In event of a vehicle fire, please
extinguish it using a special fire
extinguisher for electric fires.
WARNING
Precautions in Use of Pure Electric
Vehicle (EV)
The high-voltage DC power generated by the
vehicle power battery is very dangerous, it
may cause electric shock or severe burns,
serious injury or even death.
To avoid personal injury, please do NOT
touch the high-voltage cable (orange) or its
connectors.
Please follow the instructions indicated on
warning labels attached to the high-voltage
components.
Please do NOT disassemble or replace any
high-voltage components; such as motor
controller located in the front motor
compartment and high-voltage power
distribution box in the trunk.
In emergency, you may pull off the
emergency service switch beneath the
console and keep the plug properly. Do
NOT touch the socket with your hand or an
uninsulated object.

BYD e6AAUTO Owner's Manual
Table of Contents
Vehicle Performance Parameters of BYD e6A.....................................................................................................................1
Chapter 1 Operation of Instruments and Controllers.......................................................................................................1-1
1.1 Combination instrument..........................................................................................................................................1-1
1.2 Doors and Keys ....................................................................................................................................................1-15
1.3 Seats, seat belts and airbags................................................................................................................................1-37
1.4 Steering Wheel and Rearview Mirror ....................................................................................................................1-53
1.5 Switch...................................................................................................................................................................1-59
1.6 Automobile Multimedia System.............................................................................................................................1-69
1.7 Air Conditioning System........................................................................................................................................1-79
1.8 Other Equipment...................................................................................................................................................1-91
Chapter 2 BYD e6A Operation and Driving.......................................................................................................................2-1
2.1 e6A Operation Tips .................................................................................................................................................2-1
2.2 Starting and Driving...............................................................................................................................................2-11
Chapter 3 Emergency Treatment .......................................................................................................................................3-1
Chapter 4 Vehicle Service & Maintenance ........................................................................................................................4-1
4.1 Anti-corrosion and Auto Exterior Maintenance........................................................................................................4-1
4.2 Maintenance Instructions........................................................................................................................................4-9

BYD e6AAUTO Owner's Manual
Chapter 5 Self-maintenance...............................................................................................................................................5-1
5.1 Foreword ..............................................................................................................................................................5-1
5.2 Motor and Chassis..................................................................................................................................................5-7
5.3 Electric Appliance.................................................................................................................................................5-17
5.4 Part Specifications................................................................................................................................................5-25

BYD e6AAUTO Owner's Manual
1
Vehicle Performance Parameters of BYD e6A
Product Model
e6A
e6B
Dimensions
Length mm
4560
Width mm
1822
Height mm
1630/1723 (with antenna)
Wheelbase mm
2830
Tread
Front mm
1556
Rear mm
1558
Curb Weight kg
2315
Gross Weight kg
2690
Tire Size
225/65R17 or T145/90R17 (spare tire)
Approach Angle (degree)
21 (e6A)
20 (e6B)
Departure Angle ° (degree)
25 (e6A)
32 (e6B)
Front Overhang mm
920

BYD e6AAUTO Owner's Manual
2
Rear Overhang mm
810
Seating Capacity
5
Maximum speed km/h
≥140
≥160
Motor Model
BYD-TYC120A
Type
Permanent magnetic synchronous motor
Maximum output power kw
120
Maximum torque Nm
450
Maximum Gradeability %
≥30
100 km energy consumption * kWh/100 km
≤15 (Constant speed metering method 60 km/h)
≤20.5 (Working condition method)
The actual power consumption depends on factors such as car and road conditions, driving patterns, etc.

BYD e6AAUTO Owner's Manual
3
Vehicle Identification of BYD e6A
The vehicle identification number (VIN) is marked on the beam of co-driver's seat. Aflexible label is available on the lower left of front windshield. The
VIN is also marked on the vehicle nameplate to facilitate the owner's registration.
VIN identification:
VIN plate
-- Lower left corner
of the front
windshield
Vehicle Identification Number (VIN)

BYD e6AAUTO Owner's Manual
4
Other signs and warnings:
Front nameplate
-- On the guard
plate of right shock
absorber inside the
motor
compartment
Warning sign of
cooling fan
-- In the middle of
front beam of front
motor
compartment
