BYD SEAL 2023 User manual

OWNER’S MANUAL

Foreword
Thank you for choosing BYD. To better use and maintain the vehicle, please read this
manual carefully and keep it for future reference.
Special instructions: BYD Auto Co., Ltd. recommends that you choose genuine spare parts
and use, maintain, and repair the vehicle in accordance with this manual. The use of
non-genuine spare parts to replace or modify the vehicle will a󽗈ect the performance of the
entire vehicle, especially its safety and durability. Vehicle damage and performance issues
caused thereby will not be covered by the warranty. In addition, vehicle modi󽗉cations may
also violate national laws and regulations and local government regulations.
Thank you for choosing BYD. Your valuable comments and suggestions are welcome. To
enjoy better services, please provide your accurate contact information. If there is any
change to the information, contact a BYD authorised dealer or service provider in a timely
manner to update the information in the system. You are also advised to pay attention to
the relevant national laws and regulations and local policies, and register the vehicle as
soon as possible; otherwise vehicle registration may fail.
Descriptions marked with an asterisk (*) in this manual are applicable to some models only
and attached pictures belong to one of the con󽗉gurations. If there is any di󽗈erence with the
vehicle you purchased, the con󽗉guration of the actual vehicle shall prevail.
Pay attention to the "REMINDER", "CAUTION" and "WARNING" symbols in this manual, and
follow the instructions carefully to avoid injury or damage. These symbols are de󽗉ned as
follows:
REMINDER
Items that must be observed to facilitate maintenance.
CAUTION
Items that must be observed to avoid damage to the vehicle.
WARNING
Items that must be observed to ensure personal safety.
is a safety mark to indicate an operation that should not be performed or an event that
should not happen.
1

This manual is expected to help you use the product correctly, and does not provide any
description of the con󽗉guration and software version of this product. For details about the
product con󽗉guration and software version, please refer to the contract (if any) related to
this product, or consult the dealer who sold the product to you.
Sustainability
As a pure electric passenger vehicle, BYD SEAL is an environmentally friendly product.
Please visit https://reach.bydeurope.com for environmental protection information about
the vehicle.
It is everyone's responsibility to protect the environment. Please use this vehicle properly
and dispose of any waste and cleaning materials according to the corresponding local laws
and regulations.
Contact Us
If you require assistance or clari󽗉cation on policies or procedures, please contact the
customer service centre.
E-mail: [e-mail]
Call 00800-10203000 for 24/7 roadside assistance or customer service centre (Monday-
Saturday 9:00-18:00).
Copyright © BYD Auto Co., Ltd. All rights reserved.
No part of this document may be reproduced or transmitted in any form or by any
means without prior written consent of BYD Auto Co., Ltd.
All rights reserved
2

Illustration Index
Exterior..............................................7
Dashboard......................................... 8
Interior.............................................. 9
Doors............................................... 10
Safety
Seat Belts.........................................12
Seat Belt Overview.................................. 12
Using Seat Belts.......................................12
Airbags............................................ 15
Airbags..................................................... 15
Driver and Front Passenger Airbags....... 16
Seat Side Airbags*................................... 17
Side Curtain Airbags*.............................. 18
Airbag Triggering Conditions and
Precautions..............................................18
Child Restraint Systems.................... 23
Child Restraint Systems.......................... 23
Anti-theft Alarm System....................30
Anti-theft Alarm System..........................30
Data Collection and Processing......... 31
Data Collection and Processing..............31
Instrument Cluster
Instrument Cluster........................... 36
Instrument Cluster.................................. 36
Instrument Cluster Indicators.................38
Controller Operation
Doors and Keys.................................48
Keys..........................................................48
Locking/Unlocking Doors....................... 50
Smart Access and Start System.............. 57
Child Protection Lock..............................59
Seats................................................60
Seats.........................................................60
Adjusting Front Seats.............................. 60
Folding Rear Seats...................................62
Rear Seat Head Supports........................62
Steering Wheel................................. 64
Steering Wheel.........................................64
Switches.......................................... 67
Light Switches......................................... 67
Wiper Switch............................................70
Driver's Door Switches............................ 71
Passenger Side Window Switch..............73
Odometer Switch.................................... 73
Mode Switches........................................ 73
Front Passenger Airbag Switch (PAB)..... 74
Hazard Warning Light Switch..................75
Emergency Call (E-Call)*......................... 75
Interior Light Switch................................76
Using and Driving
Charging/Discharging Instructions....78
Charging/Discharging Instructions........ 78
Charging...................................................82
Discharging Device..................................89
Charge Port Anti-theft Lock.................... 90
Driving Range Display............................. 91
Energy Regeneration Settings................ 92
Battery.............................................93
High-Voltage Battery............................... 93
Low-Voltage Battery................................95
Usage Precautions............................96
3

Break-in Period........................................96
Trailer Towing..........................................97
Driving Safety Precautions......................97
Suggestions for Vehicle Use....................98
Saving Energy and Extending
Vehicle Service Life..................................99
Carrying Luggage.................................... 99
Wading into Water................................. 100
Fire Prevention......................................101
Snow Chains.......................................... 103
Starting and Driving........................103
Starting the Vehicle............................... 103
Remote Start..........................................105
Gear Shift Controls................................105
Electric Parking Brake (EPB)................. 106
Automatic Vehicle Hold (AVH)...............108
Driving Precautions...............................109
Driver Assistance............................ 111
Adaptive Cruise Control (ACC).............. 111
Intelligent Cruise Control (ICC).............115
Predictive Collision Warning (PCW)
& Automatic Emergency Braking (AEB)117
Front Cross Tra󽗋c Alert (FCTA)/
Front Cross Tra󽗋c Braking (FCTB)........120
Tra󽗋c Sign Recognition (TSR) System. 121
Intelligent Speed Limit Control (ISLC)..122
High Beam Assist (HMA)........................123
Lane Departure Assist (LDA)................. 124
Emergency Lane Keeping Assist
(ELKA).....................................................126
Blind Spot Detection System (BSA)...... 127
Head-up Display (HUD)*....................... 130
Tyre Pressure Monitoring......................131
Acoustic Vehicle Alerting System
(AVAS).....................................................132
Panoramic View System........................133
Parking Assist System........................... 135
Driving Safety Systems..........................138
Intelligence Torque Adaption
Control (iTAC) System*..........................142
Driver Attention Warning (DAW)*..........142
Child Presence Detection (CPD)............143
0-62 mph (0-100 km/h): Full Throttle
Experience............................................. 144
Other Main Functions......................144
Interior Rearview Mirror........................144
Power Side Mirrors................................ 145
Wipers.................................................... 146
In-Vehicle Devices
Infotainment System...................... 148
Infotainment Touchscreen....................148
Navigation Bar.......................................149
Gestures and Responses.......................149
BYD Assistant......................................... 150
Bluetooth Call........................................150
File Management...................................150
A/C.................................................151
A/C Panel................................................151
A/C Operation Interface........................ 151
Function De󽗉nition............................... 153
Vents...................................................... 155
Air Puri󽗉cation System..........................156
A/C Settings........................................... 158
BYD App......................................... 158
About BYD App.......................................158
Account Registration.............................158
Vehicle Condition and Control..............159
Individual Centre and Vehicle
Management..........................................159
Storage.......................................... 159
Glove Box...............................................159
4

Cubby Box..............................................160
Cup Holder.............................................160
Storage Box on Interior Panel............... 161
Bill Box................................................... 161
Seatback Pockets.................................. 161
Engine Compartment Storage..............161
In-Vehicle Devices...........................162
Sun Visor................................................162
Grab Handles.........................................162
12V Auxiliary Power...............................162
USB Ports...............................................163
Wireless Phone Charger........................ 163
Maintenance
Maintenance Precautions................168
Maintenance Cycle and Items...............168
Regular Maintenance...................... 172
Regular Maintenance............................ 172
Vehicle Corrosion Prevention............... 172
Paint Maintenance Tips.........................173
Exterior Cleaning................................... 173
Interior Cleaning....................................175
Self-Maintenance............................176
Self-Maintenance.................................. 176
Vehicle Storage......................................178
Bonnet................................................... 179
Cooling System......................................179
Braking System......................................180
Washer................................................... 180
A/C System.............................................181
Wiper Blades..........................................181
Tyres.......................................................182
Fuses...................................................... 184
When Faults Occur
When Faults Occur.......................... 192
Re󽗊ective Vest....................................... 192
If Smart Key Battery Is Exhausted.........192
Emergency Shutdown System..............192
Vehicle Fire Rescue................................193
Battery Leakage Rescue........................193
If the Vehicle Needs Towing.................. 194
If a Tyre Goes Flat.................................. 195
If the Low-Voltage Battery Is
Exhausted.............................................. 198
If the Vehicle Needs Support................ 199
Speci󽗉cations
Data............................................... 202
Vehicle Parameter................................. 202
Tips................................................205
Vehicle Identi󽗉cation............................ 205
Warning Labels......................................206
Transponder Mounting......................... 207
Declarations of Conformity............. 208
Smart Key.............................................. 208
MmWave Radars....................................209
Radio Frequency....................................209
Abbreviation List
Abbreviations.................................215
5

6

Illustration Index
Exterior
1 Boot Lid
P53
Carrying Luggage P99
2 Tyre P182
Snow Chains P103
If a Tyre Goes Flat P195
3 Bonnet P179
Coolant P179
Washer System P180
Under-Bonnet PDB Nameplate P185
5 Doors P51
Locking/Unlocking P51
6 Check before Charging P82
Using Mode 2 Charging Cable* P82
Charging with AC Charging Piles* P85
Using DC Chargers* P86
7 Power Side Mirrors P145
Folding Side Mirrors P145
7

4 Combination Lights
P67
Dashboard
1 Instrument Cluster
P36
2 Adjusting the Steering Wheel P66
Steering Wheel Switches P64
3 Front A/C Panel P151
4 Hazard Warning Light Switch P75
5 START/STOP Button P104
6 Gear Shift Controls P105
7 Wireless Phone Charging P163
8 Glove Box P159
9 Infotainment Touchscreen P148
8

Interior
1 Odometer Switch
P73
2 12V Auxiliary Power P
USB Ports P
3 Front Seat Cup Holder P
4 Centre Console Cubby P
9

Doors
1 Opening with Interior Door Handle
P51
2 Driver's Door Switches P71
3 Bill Box P161
4 Interior Boot Switch P53
10

01 SAFETY
Seat Belts.......................................... 12
Airbags.............................................. 15
Child Restraint Systems................... 23
Anti-theft Alarm System................... 30
Data Collection and Processing.......31

Seat Belts
Seat Belt Overview
Studies have shown that proper use
of seat belts can signi󽗉cantly reduce
casualties in emergency braking, sudden
steering or collisions. Please read the
following information carefully and
observe it strictly.
WARNING
●Always have the seat belts
fastened while the vehicle is in
motion.
●Before driving, make sure all
occupants are properly buckled
up to prevent serious injury or
death in emergency braking or in
a collision.
●The seat belts are designed
primarily for adults and are not
intended for children. Make sure
to choose an appropriate child
restraint system according to your
child's age and size (see "Child
Restraint Systems").
●If a seat belt is damaged
or malfunctions, immediately
contact a BYD authorised
dealer or service provider
for con󽗉rmation and handling.
Until then, do not use the
corresponding seat.
●BYD has highly emphasised that all
occupants should always fasten their
seat belts while in the vehicle. Failure
to do so increases the risk of injury in
case of an accident.
●It is recommended that children be
seated in rear seats and always
use seat belts and suitable child
restraints. In emergency braking or
collision, unprotected children may be
seriously injured and their lives may
be endangered. Likewise, do not allow
children to ride on someone's lap. This
will render the children not adequately
protected.
Emergency Locking Retractor (ELR)
●When the driver turns sharply, brakes
suddenly, when there is a collision,
or when the occupant leans forward
too quickly, the seat belt automatically
locks to e󽗈ectively restrain and protect
the occupant.
●When the vehicle travels smoothly,
seat belts are pulled out and retracted
as the occupants move slowly and
smoothly, allowing the occupants to
move freely.
●If the seat belt locks due to sudden
retraction, pull on the seat belt
webbing to create retractable slack in
order to pull out the seat belt.
Pretensioner and Force Limiter
Function*
When a severe front collision occurs
and the triggering conditions of the
pretensioner are met, the pretensioner
quickly retracts part of the seat belt and
locks it to improve the protection of the
occupant. The force limiter limits the
seat-belt restraint force to the occupant's
body to a certain extent so as to avoid
injury to the occupant due to an excessive
restraint force.
Using Seat Belts
1. Adjust the seat position and seatback
angle (see Adjusting Front Seats).
2. Adjust the position of the three-point
seat belt.
12

●Keep the correct sitting posture and
pull out the shoulder belt diagonally
across the entire shoulder without
contacting the neck or falling from the
shoulder. Position the lap belt as low
as possible around the hip.
3. Insert the latch into the buckle until it
clicks, and then pull it back to make
sure it is 󽗉rmly locked. Do not fasten
the belt with any part of the strap
twisted.
4. Adjust the height of the (front)
seat belts for optimum comfort and
protection.
① Press the adjuster release button.
② Move the adjuster up or down to the
intended position. Release the button to
lock the adjuster.
5. Pull the belt 󽗉rmly to check that the
adjuster is locked.
WARNING
●The shoulder belt should cross
the centre of the shoulder. The
seat belt should be far from the
neck and not liable to slip from
the shoulder, otherwise it cannot
function well in the event of
emergency braking or accident,
and may even cause severe injury.
●The lap belt should be positioned
as low as possible around the hips
to avoid serious injury due to the
intense lap belt forces against the
abdomen in an accident.
●The seat belt should be 󽗉tted tight
to the body for better protection.
6. Unlock the seat belt.
●Press the red unlock button on the
buckle. The latch plate pops out, and
the seat belt automatically retracts. If
the seat belt does not retract smoothly
and automatically, pull it out and
check whether it is twisted.
13
01
SAFETY

REMINDER
●The method of wearing a rear
seat belt is the same as that
for a front seat belt. For normal
functioning of the rear seat belt,
please ensure that its latch is
inserted into the corresponding
buckle during use. The driver
should remind passengers to wear
seat belts properly.
●The driver should ensure that all
occupants are wearing seat belts
before driving the vehicle.
WARNING
●Each seat belt should be used by
one occupant only. Do not share
a seat belt with another occupant,
not even with a child.
●Avoid travelling with the seatback
leaning too far back. The seat belt
protection performs best when
the seatback is upright.
●Make sure that no seat belt
or itsspring bolt/buckle becomes
pressed by the door; otherwise
the seat belt may be damaged.
●Check the seat belts regularly
for cuts, wear, looseness, and
other abnormalities. If any
problem is found, contact a
BYD authorised dealer or service
provider for con󽗉rmation and
WARNING
handling. Until then, do not use
the corresponding seat.
●Do not remove, disassemble or
modify the seat belts without
permission.
●After an accident, have the seat
belts checked at a BYD authorised
dealer or service provider. If the
preloading function is activated,
the seat belt must be replaced.
●In the event of a serious
accident, even if there is no
apparent damage, the seat belt
should be replaced along with
the seat assembly. The airbag
system should also be thoroughly
inspected.
●Use an approved model whenever
you replace the seat belt.
●Pregnant women should also
fasten their seat belt properly.
Particularly, be sure to position
the lap belt as low across the
hip as possible to prevent serious
injury.
●Do not insert foreign objects such
as coins and clips into the buckle
as they prevent proper connection
between the latch and buckle.
Seat Belt Reminder
If the driver, front passenger or rear
passenger* has not buckled up after the
vehicle is started, the alarm system goes
o󽗈 and continues until the corresponding
seat belt is properly fastened.
●Unfastened seat belt indicator
●When any seat belt is not fastened,
the unfastened seat belt indicator
󽗊ashes.
14

●Display of unfastened belt's seat
●The indicator for the seat with
unfastened seat belt lights up.
●Seat belt reminder for the front
passenger
●If the driver or front passenger
does not wear the seat belt after
the vehicle is started, the seat
belt indicator and the indicator
associated with the corresponding
seat light up. If the seat belt remains
unfastened while driving, in addition
to the unfastened seat belt indicator,
an audible alarm is given to remind
the driver and occupants.
●Seat belt reminder for rear passengers*
●With the ignition switch on OK, if any
rear-row seat belt is not fastened,
the unfastened seat belt indicator
and the indicator associated with the
corresponding seat light up.
●When the drive speed is above 12
mph (20 km/h) and only rear seats
are loaded with occupant(s), who
have not buckled up, the seat belt
reminder indicator is on and an
audible alarm is given.
●When the driver, the front passenger,
and rear passengers* have buckled
up, the seat belt reminder indicator
and all indicators displayed for the
corresponding seats turn o󽗈.
WARNING
●In the event of abnormality
or function failure, contact
a BYD authorised dealer or
service provider. Do not use
the corresponding seat until the
functions return to normal.
●When driving, make sure all
occupants have their seat belts
properly fastened to prevent
serious injury or death in
WARNING
emergency braking or in a
collision.
Airbags
Airbags
●The airbag system is a part of
auxiliary restraint system and also
a supplement to seat belts. When
the vehicle is involved in a serious
collision and the airbag system meets
its deployment conditions, relevant
airbags will rapidly deploy and, along
with seat belts, provide additional
protection for heads and chests of
the driver and occupants, to reduce
likelihood of personal injury or even
death.
●Airbags are divided into front and
side types according to the type of
collision. The front airbags include
front passenger airbags, while the side
airbags include seat side airbags and
side curtain airbags.
●As an integral part of the vehicle's
passive safety protection system, the
airbag system does not replace seat
belts and must be used in combination
with seat belts to maximise protection.
Multi-collision Braking (MCB)
●In the event of an accident, the
automatic braking will be activated
when the driver airbag or the front
passenger airbag deploys.
●Speed reduction, along with the
intervention by additional driving
systems (ESC and ABS), assists the
vehicle to maintain stability and lane
position.
15
01
SAFETY

●Hazard warning light and brake light
would light up to warn oncoming
vehicles and aid to avoid secondary
collision.
●The brake is released after an accident
and brake lights are turned o󽗈 to
support emergency rescue or recovery
of the a󽗈ected vehicle.
●The driver can interrupt the multi-
collision braking at any time by
accelerating or braking.
WARNING
●Never seat a child in the front
passenger seat.
●Occupants must sit in a
proper position to maximise the
protection provided by seat belts
and the airbag system.
●Do not disassemble or assemble
airbag components without
authorisation.
●If the seatbacks get wet, the
side airbag system may not work
properly.
●Do not use seat covers, as they
restrict airbag deployment on the
corresponding side in an accident.
●Do not place anything between
the side airbag and the occupant.
●Do not apply excessive force to the
side of seats equipped with side
airbags.
●After a collision, even if the
airbag module did not deploy,
and the pretensioner did not
lock the seat belt, the airbag
computer may be encrypted in
order to protect occupants from
high-voltage danger. Contact a
BYD authorised dealer or service
provider for inspection.
Driver and Front
Passenger Airbags
This vehicle is equipped with driver
and front passenger airbags, when the
electronic control unit (ECU) of the airbag
system detects a moderate to severe front
impact during driving and the triggering
conditions are met, the airbags deploy.
Front airbag deployment
●In moderate to severe frontal crashes,
a sensor detects a sharp deceleration
and sends a signal to the ECU to trigger
the front airbags.
●When there is a frontal crash, the seat
belt secures the occupant's lower body
and torso in place. The airbag cushions
and protects the occupant's head and
chest.
●When the severity of the impact
does not reach the airbag deployment
threshold, seat belts provide the main
protection while airbags assist little to
the protection.
●The front airbag de󽗊ates immediately
after in󽗊ation, without a󽗈ecting the
driver's vision and ability to operate
the steering wheel or other controls.
●The airbag deploys quickly to protect
the occupants when reaching the
triggering condition.
●A loud noise will be heard when the
airbag deploys. It will not cause injury,
16

but it may cause temporary tinnitus or
deafness.
●A cloud of dust from the airbag surface
may come o󽗈 when the airbag deploys.
Although such powder is non-toxic,
individuals with respiratory problem
might experience some temporary
discomfort.
●The front passenger airbag is
controlled by the passenger airbag
(PAB) switch. See "PAB Switch*" for
details.
Seat Side Airbags*
If the vehicle is equipped with seat side
airbags (mounted on the outside of the
seatback, marked with "AIRBAG" at both
sides), when a moderate to severe side
impact is detected during vehicle travel
and the triggering conditions are met,
the side airbag deploys to protect the
occupant's chest to minimise the injury.
Front passenger side airbags
Rear passenger side airbags
Seat side airbags starting process
●Generally, only the airbag on the
impacted side deploys in the event of
a side impact.
●If the impact occurs on the passenger
side, the airbag on the passenger side
deploys even if there is no passenger in
the seat.
●For optimal side airbag protection,
occupants must have their seat belts
fastened and sit upright against the
seatback.
In a vehicle equipped with seat side
airbags:
●Prevent the seatbacks from getting
wet. If the seatbacks get wet from rain
or splashes, the side airbag system
may not work properly.
●Do not cover or replace seatback
covers on you own. Unsuitable
seatback covers may prevent airbag
deployment in a collision.
Front far side airbag:
●The vehicle you purchased is equipped
with a front far side airbag (installed in
the inner edge of the driver's seatback
and marked with "AIRBAG", as shown
in the illustration).
17
01
SAFETY

●When a moderate to severe front or
side impact is detected during vehicle
travel and the triggering conditions are
met, the far side airbag deploys to
protect the heads and shoulders of the
driver and the front passenger.
●If the impact occurs on the front
passenger side, the far side airbag
deploys even if there is no passenger
in the seat.
●For optimum protection from the far
side airbag, the driver must buckle up
and sit upright against the seatback.
Side Curtain Airbags*
If the vehicle is equipped with seat side
airbags (mounted on the outside of the
seatback, marked with "AIRBAG" at A, B
and C pillars), when a moderate to severe
side impact is detected during vehicle
travel and the triggering conditions are
met, the side airbag deploys to protect
the head of the occupant in a collision.
●Generally, only the airbag on the
impacted side deploys in the event of
a side impact.
●For optimum curtain airbag protection,
the occupant must have their seat belt
fastened and sit upright against the
seatback.
Airbag Triggering
Conditions and
Precautions
Airbag Triggering Conditions
●Airbag triggering conditions: In the
event of a vehicle collision, whether an
airbag will be triggered is decided by
factors such as the amount of collision
energy, accident type, collision angle,
obstacles, and vehicle speed. The
airbag system may be triggered in
special collisions.
●The airbag system does not always
work in any accident, and generally it
will not be triggered in the event of
a minor frontal collision, rear collision
or rollover. In this case, the driver
and passengers are protected by their
properly fastened seat belts.
●Determinants of airbag system
triggering: Decision is made by
comparing the deceleration curve,
generated in the collision and obtained
by the Electronic Control Unit(ECU )
and the set value. If signals, such as
the deceleration curve generated and
measured in the collision, are lower
than the respective reference values
preset in the ECU, the airbag system
will not be triggered even if the vehicle
may have been seriously deformed in
the accident.
●The ECU of the BYD airbag system
has been set up with considerations of
common misuse and road conditions.
18

However, due to the increasing
changes in causes and forms of vehicle
collisions, for your safety, please
strictly follow this user manual, use the
vehicle correctly, and avoid its misuse.
Otherwise, there is no guarantee that
the airbags will achieve their expected
e󽗈ect.
Cases Where Airbags May Be Deployed
The vehicle's nose hits the ground when
crossing a deep groove.
The vehicle hits a bump or curbstone.
The vehicle's nose hits the ground when
going down a steep slope.
One side of the vehicle is hit by another
vehicle.
Cases When Airbags May Not Be
Deployed
The vehicle hits a concrete column, tree,
or other slim objects.
The vehicle goes under a truck or another
large vehicle.
19
01
SAFETY
