BYD e2 User manual

BYD
Owner’s Manual

1
-
Superb skills & honest hearts
BYD
Superior and Sincere Services
BYD sincere service brand was established in 2006, adhering to the service concept
of “Superb Skills & Honest Hearts” from all BYD after-sales staff.
In the article “A Famous Doctor with Superbe Skills & Honest Hearts”, Sun Simiao, a
famous doctor in Tang Dynasty, discussed two issues concerning medical ethics:
the first is “Superb”, that is, a doctor should have superb medical skills and must
learn medical knowledge extraordinary and diligently. The second is “Sincere”, that
is, a doctor should have a noble moral, and a sincere heart to regard one`s distress
as his. BYD after-sales staff have introduced the concept of “Superb Skills & Honest
Hearts” from Sun Simiao into the automobile after-sales field and defined
“Professional & Sincere” as BYD sincere service brand with the brand features as
below:
■
Professional & High-quality ■Diligent & Focus
■
Passionate & Sincere ■Active & Care
BYD sincere service firmly believes that the exquisite service technologies come
from professional, diligent, and sincere service attitudes, responsibilities and
intentions. We are always committed to providing a high level of after-sales services
for BYD Auto users and their cars.

2
Foreword
Welcome to use BYD passenger car; please read the manual carefully to help you normally
use and maintain your car.
Special note: It is strongly recommended to choose genuine spare parts and use, maintain
and repair your car in accordance with the requirements in the manual. For any car that is
replaced and modified with non-original spare parts, its performance may be affected,
especially for safety and durability; and the resulted damage and performance problems will
be beyond the warranty. In addition, any modification for your car may not be consistent with
national laws and regulations and local government regulations.
Thank you for choosing BYD passenger car; welcome your comments and suggestions. In
order to ensure better services for you, please be sure to provide your accurate contact
information. If there is any change, please contact BYD Auto Authorized Service Station to
update it in the system. At the same time, please pay attention to relevant national laws and
regulations and local policies and regulations, and register your car as soon as possible;
otherwise, there may be a risk of register rejection.
In the manual, the positions marked with “Tips”, “Notes” and “Warnings” must be followed
carefully, to avoid any injury or damage. The representations and usages of various
reminding information types are as follows:
Tip
It refers to any item that must be followed for ease maintenance.
Note
Issues to be observed for prevention of vehicle damages
Warning
It refers to any item to prevent any injury.

3
The safety mark shown on the left indicates “Not Do It” or “Not Allow Its
Occurrence”.
The manual is used to help you use the product correctly and does not
represent any description of the configuration and software version of the
product. For product configurations and software versions, please consult
the contract associated with the product (if any) or consult your vendor.
To inquire for the power battery recycling network, please access the
official website of BYD Auto:
https://www.byd.com/cn/SocialResponsibility/BatteryRecycle.html
For detailed product usage instructions, please follow “BYD Fans Club”
on WeChat, or scan the following small program QR code.
201903 version
BYD Auto Industry Co., Ltd. All rights reserved
Any part or all of the manual cannot be reproduced or copied
without the written permission of BYD Auto Industry Co., Ltd.
All copyrights are reserved

4
Overview of BYD e2 passenger car
BYD e2 car is a new energy, new power and pure electric passenger
vehicle, and is an environmentally friendly product strived by BYD. The
body is a load-bearing type, the stringer is front-and-back through type,
and the power battery pack is integrated with the body to fully guarantee
the safety of the battery pack and the car.
Driven by motor under diversified working conditions, this vehicle
completely realizes zero emission in terms of environmental protection.
The car is completely driven under pure electric power conditions, so the
noise inside and outside the car is extremely small, which can provide
users with driving and riding experiences that the fuel-driven car cannot
achieve.
The safety of the high-voltage system is fully considered in the design
process of the car, and the safety of the passengers in the car can be
fully protected in case of any collision.
The battery management unit can be used to monitor the power battery at
all times, and adjust the power output from each battery unit based on
various performance indexes, such as voltage and current, to prevents a
series of faults affecting battery performance, such as overcharge,
overdischarge, and overtemperature, and so as to ensure the battery
operation under normal conditions.

5
Picture Index Search by illustration
1 Safety Make sure to read this section carefully
2Dashboard How to read various meters, warning lights, indicators, and etc.
3Controller
operation Opening and closing of doors and windows adjustment before driving, and etc.
4Use and drive Necessary driving operations and suggestions
5Interior devices Use of interior devices, etc.
6Maintenance Car maintenance steps
7In case of a fault Countermeasures in case of a fault or emergency
8Vehicle
specifications Vehicle specifications, customized functions, etc.
Index Alphabet index

6
Contents
Superior and Sincere Services.................1
Foreword.....................................................2
Overview of BYD e2 passenger car .........4
1Safety
1-1 Seatbelt..............................................19
Introduction to the seatbelt .................19
Use of seatbelt....................................20
1-2 Airbag ................................................23
Introduction to the airbag....................23
Driver and front passenger airbags ....24
Airbag triggering conditions and
notes...................................................26
1-3 Child restraint device........................31
Classification of child restraint system 31
Installation of child restraint device.....32
1-4 Anti-theft system ............................... 36
Anti-theft system.................................36
2Dashboard
2-1 Dashboard.........................................39
Dashboard view..................................39
Instrument indicator lamp ................... 40
3Controller Operations
3-1 Key and door..................................... 49
Key .....................................................49
Lock/unlock operation.........................52
Smart access and start system...........58
Child lock.............................................61
3-2 Seat.....................................................62
Seat notices ........................................62
Rear seat folding.................................64
Headrest..............................................64
3-3 Steering wheel...................................66
Steering wheel adjustment..................66
3-4 Switch.................................................67
Light switch .........................................67
Wiper switch........................................70
Front left door switch assembly ..........71
Passenger window control switch.......73
Emergency warning indicator switch...74
Mileage switchover switch...................74
Lighting adjustment switch group........74
Mode switch group..............................75
Steering wheel switch assembly.........76
Indoor light switch (If fitted).................80
4Use and drive
4-1 Charging and discharging
descriptions.......................................83
Charge instructions.............................83
Charge method ...................................88
Smart charge function.........................98
Charging coupler electric lock function
.....................................................98
4-2 Battery..............................................101
Power battery....................................101

Contents
7
Battery ..............................................104
4-3 Use essentials.................................106
Running-in period .............................106
Trailer towing....................................106
How to save the power and extend
the service life of your car.................107
Carrying luggage .............................. 108
Fire prevention..................................109
4-4 Start and drive ................................111
Charge instructions.错误！未定义书签。
Remote start function .......................114
Gearshift control mechanism (If fitted)115
Electronic parking brake (EPB) (If
fitted).................................................116
Parking brake pedal (If fitted) ...........120
Auto Hold (AVH) (If fitted).................120
Driving essentials..............................122
4-5 Use of driver assistance functions126
Cruise control (If fitted) .....................126
Low Speed Sound System ...............127
Parking assist system (If fitted).........129
Indirect tire pressure monitoring
system ..............................................132
Driving safety system........................136
4-6 Other main function descriptions. 142
Interior rearview mirror......................142
Electric exterior rearview mirror........143
Wiper ................................................144
Snow chains .....................................145
5Interior devices
5-1 Multimedia system..........................148
Multimedia control panel (If fitted).....148
Radio operation panel (If fitted).........150
5-2 Air conditioning system.................151
A/C panel ..........................................151
A/C operation panel (If fitted)............152
Function definition (If fitted)...............153
Air vent..............................................157
5-3 Storage device ................................158
Glovebox...........................................158
Central control storage box...............158
Front central armrest storage box.....159
Mobile phone tray..............................159
Storage box on interior trim panel.....159
File pocket.........................................160
Invoice box........................................160
Cup holder.........................................160
5-4 Other device ....................................161
Sunvisor............................................161
Makeup mirror...................................161
Safety handle....................................162
12V standby power supply................162
USB port/traveling data recorder card
slot (If fitted) ......................................163
6Maintenance
6-1 Maintenance ....................................166
Maintenance cycle and content ........166

8
Contents
6-2 Regular maintenance .....................172
Regular maintenance........................172
Car corrosion protection ...................172
Painted surface maintenance tips ....173
Clean the car ....................................174
Clean the inside of the car................175
6-3 Self-maintenance............................179
Self-maintenance..............................179
Car storage.......................................182
Front hatch........................................183
Cooling system.................................184
Braking system.................................185
Scrubber........................................... 185
Air conditioning system.....................186
Wiper blade.......................................186
Tires..................................................187
Fuse..................................................191
7In case of a fault
7-1 In case of a fault..............................200
If the smart key battery is exhausted 200
Emergency shutdown system...........201
Car fire rescue..................................201
Rescue in event of a vehicle impact.202
If the car needs to be towed .............203
In event of tire leakage .....................204
8Vehicle specifications
8-1 Data information............................. 208
Vehicle parameters...........................208
8-2 Tips...................................................210
Vehicle identification number............210
Warning label....................................212
Microwave window............................214

Contents
9

10
Picture Index
■Outside
AC charging coupler cap ..........................................................................................P90
Household portable AC charging..............................................................................P88
Charging pile single-phase/three-phase AC charging..............................................P93
Charging port emergency unlocking.......................................................................P100
Electric exterior rearview mirror..............................................................................P143
Wiper blade.............................................................................................................P186
Replace the wiper blade.........................................................................................P144
Wiper switch .............................................................................................................P69
Doors........................................................................................................................P51
Locking/unlocking operation.....................................................................................P51

Picture Index
11
Tires........................................................................................................................P187
In event of tire leakage ...........................................................................................P204
Lamps.....................................................................................................................P181
Light switch...............................................................................................................P66
DC charging coupler cap..........................................................................................P97
Charge post DC charge............................................................................................P96
Front hatch..............................................................................................................P183
Cooling system.......................................................................................................P184
Braking system.......................................................................................................P185
Scrubber.................................................................................................................P185
Front compartment distribution box........................................................................P191
Back door..................................................................................................................P54

12
Picture Index
■Dashboard
Multimedia touchscreen..........................................................................................P148
Side air vent............................................................................................................P157
Glovebox.................................................................................................................P158
Gearshift control mechanism..................................................................................P115
ESP button..............................................................................................................P138
Electronic parking...................................................................................................P116
12V standby power supply .....................................................................................P162
USB port/traveling data recorder card slot .............................................................P163
Automatic parking...................................................................................................P120

Picture Index
13
Switch assembly .....................................................................................................P74
Start/stop button .......................................................................................................P57
Volume knob/Audio OFF/Reboot multimedia button ..............................................P148
Emergency warning indicator switch ........................................................................P73
Economy mode button..............................................................................................P74
Sport mode button....................................................................................................P74
Snow mode button....................................................................................................P74
A/C panel................................................................................................................P151
Steering wheel..........................................................................................................P65
Steering wheel adjustment .......................................................................................P65
Steering wheel switch assembly...............................................................................P75
Central air outlet .....................................................................................................P157

14
Picture Index
■Inside
Light switch...............................................................................................................P66
Automatic lighting .....................................................................................................P66
Small light.................................................................................................................P66
Low beam.................................................................................................................P66
Rear fog lamp...........................................................................................................P67
Overtaking light.........................................................................................................P67
High beam ................................................................................................................P67
Turn signal................................................................................................................P67
Lighting adjustment switch group .............................................................................P73
Invoice box..............................................................................................................P160

Picture Index
15
Front hatch opening handle....................................................................................P183
Storage box on interior trim panel ..........................................................................P159
Front left door switch assembly................................................................................P70
Power window switch................................................................................................P70
Central door locker switch ........................................................................................P71
Exterior rearview mirror adjustment switch...............................................................P72
Door panel handle ....................................................................................................P52
Anti-theft indicator.....................................................................................................P36

16
Picture Index
Headrest...................................................................................................................P63
Front seats................................................................................................................P62
Front seat adjustment...............................................................................................P62
Passenger window control switch.............................................................................P72
Rear row middle seat belt.........................................................................................P20
Rear row seat ...........................................................................................................P63
Rear seat folding.......................................................................................................P63
Installation of child restraint device...........................................................................P31
File pocket ..............................................................................................................P160

Picture Index
17

18
Picture Index
1-1 Seatbelt ............................................. 19
Introduction to the seatbelt................. 19
Use of seatbelt.................................... 20
1-2 Airbag................................................ 23
Introduction to the airbag.................... 23
Driver and front passenger airbags.... 24
Airbag triggering conditions and notes26
1-3 Child restraint device........................ 31
Classification of child restraint system 31
Installation of child restraint device .... 32
1-4 Anti-theft system............................... 36
Anti-theft system................................. 36

1
Safety
1-1 Seatbelt
19
1-1 Seatbelt
Introduction to the seatbelt
The researches show that the correct use of seat belt can remarkably mitigate the
casualties of passenger within the vehicle in event of an emergency braking, sudden turn,
and collision accident. Therefore, to safeguard you and your family, please pay special
attention to and strictly abide by the “Warning” and “Notice” in this section.
Warning
● BYD strongly emphasizes the personal safety of driver and passengers within
vehicle. Please fasten the seat belt at all times. Otherwise, the injury possibility will
be increased in event of an accident.
● It's recommended to arrange child onto the rear row seat and use seat belt and
appropriate child restraint system.
● No matter for front or rear row seat, do not allow child to stand or kneel on the seat.
In event of an emergency braking or collision, the unprotected child will be seriously
injured or even killed. Similarily, do not allow child to sit on your legs, otherwise the
child can’t be adequately protected.
● During the traveling of vehicle, all passengers within the vehicle must sit in the seats
and correctly fasten the seat belts. Otherwise, in event of an emergency braking or
collision accident, the personnel within the vehicle will be easily injured or even
killed.
Note
● The seatbelts in the car is mainly designed on base of the size of the adult and are
not suitable for children; please choose the appropriate child restraint device based
on the ages and sizes of the children.
● If a seatbelt is damaged or abnormal, it is recommended to contact BYD Auto
Authorized Service Station for confirmation and disposal immediately, do not use
the corresponding seat before confirmation.
Seatbelt emergency locking (ELR) function:
■In event of a sudden cornering, emergency braking, or impact of vehicle or quick
forward tilting of passenger, the seat belt will lock automatically to realize the effective
restraint and protection for the passenger. However, during the stable traveling of
vehicle, the seat belt can be pulled out and retracted along with the slow and stable
movement of passenger and the passenger can move freely.
■In event of locking of seat belt due to fast retraction, pull tightly the seat belt and then
release to ensure the smooth retraction of seat belt.
