Vacuum Sealer VS02
220-240V~, 50Hz
165W
USER'S MANUAL
Important Points for your Safety
Read and fully understand all instructions and warnings prior to using this
machine. Your safety is most important !
1. Read the instructions carefully.
2. Do not allow the appliance to be used as a toy.
3. This appliance should not be operated by children.
4. Do not operate the appliance with a damaged power cord or plug.
5. Do not use the appliance on a wet or hot surface, or near a heat source.
6. Always use the appliance on a level surface.
7. Do not immerse any part of the appliance, power cord or plug into water
or other liquid.
8. To disconnect, unplug the power cord from the electrical outlet. Do not
disconnect by pulling on the cord. Always unplug the appliance before
cleaning and when not in use.
9. Do not operate the appliance if it malfunctions or is any way damaged. If
the cord or the machine is damaged, please return it to our after-sales
department for proper service, replacement or repair.
10. Close supervision is required when this product is used near children.
11. The appliance is not for commercial use. If sealing more than 20 bags
continuously, wait at least 25 minutes before resuming use of your
appliance.
12. Keep the upper lid of the appliance unlocked when not in use.
This appliance is for HOUSEHOLD USE ONLY.
Do not attempt to service this product. Service should be performed by an
authorized service representative.
A short power-supply cord is provided to reduce the risk resulting from
becoming entangled in or tripping over a longer cord. Extension cords are
not prohibited from being used when care is exercised in their use. When an
extension cord is used the marked electrical rating of the extension cord
shall be no less than the marked electrical rating of the appliance. The
longer cord shall be arranged so that it does not drape over the counter-top
or tabletop where it is capable of being tripped over, snagged, or pulled on
unintentionally, especially by children.
Start Enjoying the Benefits of your Vacuum Sealer System
Thank you for purchasing this vacuum sealer.
Your new vacuum sealer system includes the following :
⚫Vacuum Sealer
⚫English User Manual
⚫Starter Bags (optional)
Vacuum Sealing Guidelines
Food Storage & Safety
IMPORTANT : Vacuum packaging is NOT a substitute for refrigeration or
freezing. Any perishable foods that require refrigeration must still be
refrigerated or frozen after vacuum packaging.
For best result in extending the life of foods, it is important to vacuum
package foods that are fresh. Once food has begun to deteriorate, vacuum
packaging may only slow the deterioration process. Vacuum sealing cannot
prevent the growth of mold. Other disease causing microorganisms can still
grow in low oxygen environments and may require further meansures to be
eliminated.
Food Preparation Hints and Tips for Air-tight Vacuum Sealing
Cooking, Thawing and Reheating –Simmering in a vacuum bag helps food
retain its flavor and it helps with the clean up as well. No dirty saucepans...
When reheating foods in the microwave using your vacuum bags, always
puncture open the bag to allow hot air to escape. You can also reheat foods
in the vacuum bags by placing them in water at a low simmer below 170°F
(75°C).
IMPORTANT : Always thaw foods in either refrigerator or microwave –do
not thaw perishable foods at room temperature.
Preparation Hints for Meat and Fish :
Try pre-freezing meats and fish for 1-2 hours before vacuum pakaging. This
helps retain the juice and shape, and provides for a better seal.
If you can’t, place a folded paper towel between the food and top of the bag,
but below seal area. Leave paper towel in bag to absorb excess moisture
and juices during vacuum packaging process.
Preparation Hints for Cheeses :
Vacuum package cheese after each use. If you make your bag just a little
longer than needed, you can re-seal the bag after each use.
IMPORTANT : Due to the risk of anaerobic bacteria, soft cheeses should
never be vacuum packaged.
Preparation Guidlines for Vegetables :
Blanching is a process that should be done before vacuum packaging
vegetables. This process stops the enzyme action that could lead to loss of
flavor, color and texture. To blanch vegetables, place them in Simmering
water or in a microwave until they are cooked, but still crisp. Blanching times
can range from 1 to 2 minutes for leafy greens and peas ; 3 to 4 minutes for
snap peas, sliced zucchini or broccoli ; give your carrots about 5 minutes ;
and 7 to 11 minutes for corn on the cob. After blanching, immerse
vegetables in cold water to stop the cooking process.
NOTE : All vegetables (including broccoli, Brussels sprouts, cabbage,
cauliflower, kale, turnips) naturally emit gases, during storage. Therefore,
after blanching, it’s best if they’re stored in the freezer.
More on Vegetables :
Vegetables are a great candidate for portion control ; when storing
vegetables, try pre-freezing them for 1 to 2 hours, then separate them into
meal portions within your vacuum bags. After they have been vacuum
packaged, return them to the freezer.
IMPORTANT : Due to the risk of anaerobic bacteria, fresh mushrooms,
onions & garlic should never be vacuum packaged.
Preparation Hints for Powdery Foods :
When vacuum packaging powdery items like flour, it’s best to use their
original packaging inside of the vacuum bags. The fine powder could get
sucked into the machine and cause enough damage to shorten the life of the
sealer.
Preparation Hints for Liquids :
Before you vacuum package liquid such as soup stock, pre-freeze in a
casserole dish, loaf pan or ice cube tray until solid. Remove frozen liquid
from pan and vacuum package in the vacuum bags. You can then stack in
the freezer. When you’re ready to use, just cut corner of bag and place in
either a microwave dish or drop into water at a low simmer, below 170°F
(75°C).
Key Features of your New Vacuum Sealer
⚫Machine size: 390*200*100mm
⚫Sealing length: MAX 32cm
⚫Vacuum pressure: -0.65~-0.75bar / -0.75~-0.95bar
⚫Double sealing, each wide sealing line up to 3mm, prevents air leakage.
⚫"Pulse" button to control vacuum time and degree.
⚫Optional motor speed (high / low).
⚫Separate vacuum mode for dry and moist food.
⚫Canister function –to vacuum and seal with a canister.
⚫Seal only function.
⚫Cancel function –to cancel any working process.
⚫With roll storage compartment and integrated safety cutting facility.
⚫Removable tray, easy for cleaning.
Main Parts of your New Vacuum Sealer
A VACUUM&SEAL / CANCEL
Press this button to start vacuumizing, when the process is done, the
machine will seal the bag automatically.
If you press this button while the machine is working, it means to stop the
on-going process. (Cancel)
B SPEED (LOW / HIGH)
Press this button to choose the machine vacuumize in low or high speed.
C FOOD (DRY / MOIST)
Press this button to choose vacuumizing pattern for dry food or moist food.
D CANISTER
Press this button to make vacuum with canister.
E PULSE VAC
This button is used when extreme control of the vacuuming process is
needed for delicate foods. Press the button and the pump turns on, release
the button and it shuts off.
F SEAL ONLY
Press to create a seal when making bags from a roll.
Press to immediately stop the vacuum process and begin sealing the bag.
G ACCESSORY PORT
Allows vacuum packaging with Canisters, Wine Stoppers, etc.
HRELEASE BUTTON
Press right and left side buttons together to unlock the lid.
To lock the lid, press the lid down firmly to secure it, the system is properly
closed when you hear a "click" on each side. It is suggested to press right
and then left or press left and then right, which makes it easier to lock.
ISILICONE SEALING BAR
JSEALING GASKETS (UP & DOWN)
KHEATING BAR
There are two heating wires covered by teflon tape.
L VACUUM SLOT
M REMOVABLE TRAY
This part can be taken away for easy cleanning.
NROLL STORAGE CHAMBER
Place roll inside this area.
O&P EMBEDDED CUTTER
Use this cutter to cut bag materials from a roll.
Important Tips for Vacuum Sealing
1. Before each operation, ensure that the vacuum slot is completely empty.
Always ensure that the vacuum pump will not suck in any liquids.
Immediately cancel the running process by pressing the Cancel button,
if liquids are sucked in.
2. Only use bags, rolls and containers with the appliance that are suited for
vacuum sealing.
3. Keep in mind that the heating bar and sealing bar will get hot during
operation. Do not touch the heating bar and sealing bar with your hands
shortly after operation.
4. Do not lock the lid when not in use.
5. Make sure the silicone sealing bar and the sealing gaskets are located
in position and are smooth. Otherwise it will not vacuum and seal
properly.
6. Make sure you give the appliance time to cool down. Wait at least 20
seconds between seals. Under very heavy usage, appliance will shut off
automatically to prevent overheating. If it does, wait 25 minutes to allow
appliance to cool off.
How to Make Custom Sized Bags
This vacuum sealer is equipped with a roll holder compatible with various
vacuum sealing rolls, as well as an embedded cutter.
1. Put a roll into the roll storage chamber, pull enough bag material to hold
item to be vacuum packaged, plus 2 inches. Use the embedded cutter
on the sealer to cut desired bag length from the roll. Make sure to cut in
a straight line. Plug in the power cord.
2. Open the lid. Place one end of cut bag onto the sealing bar, don’t worry
if you accidently place any material onto the gasket area.
3. Close the lid by pressing down on both sides until two ’’click’’ sound
heard.
4. Now that the lid has been locked, press the ’’SEAL’’ button to create a
custom sized bag. The indicator light illuminates during the seal
process.
5. Once completed the indicator light of seal button will turn off; press the
release buttons on both sides of the machine, it is now safe to take out
the newly created bag.
6. The custom sized bag is now ready for vacuum sealing.
How to Vacuum Seal with the Vacuum Bags
1. Place the item(s) to be sealed into the pre-cut or custom sized bag.
Leave at least 2 inches between the contents and the top of the bag to
allow for bag contraction.
2. Open the lid and place the open end of the bag down into the vacuum
slot.
3. Close the lid by pressing down on both sides until two ’’click’’ sound
heard.
4. Choose low or high speed, dry or moist food.
NOTE : When vacuumizing moist food, please choose low speed
and moist food pattern.
5. To begin the vacuum process, press the ’’VACUUM&SEAL’’ button. The
unit will continue to vacuum and then seal once air has been removed.
6. Once the indicator light has turned off, press the release buttons on both
sides of the machine to release the bag.
How to Use the Pulse Vacuum Button (PULSE VAC)
Since the pressure under the normal vacuum function is set to be high,
sometimes it is easy to destroy some delicate items by high pressure in the
vacuum bags. In this case, you can use the ’’PULSE’’ vacuum function to
control the vacuum time and pressure, and prevent crushing delicate items.
When packing some juicy foods, you can also use this function and prevent
liquid being sucked out.
1. Place the item(s) to be sealed into the pre-cut or custom sized bag.
Leave at least 2 inches between the contents and the top of the bag to
