C-COM Satellite Systems iNetVu MP- 80 User manual

iNetVu®Motorized (3-Axis) Man Pack –80cm/100cm User Manual
The iNetVu®brand and logo are registered trademarks of C-COM Satellite Systems, Inc.
© Copyright 2020 C-COM Satellite Systems, Inc.
1-877-iNetVu6
www.c-comsat.com
Revision 3.0
January 22, 2020

C-COM Satellite Systems Inc. Page 2 of 68
iNetVu®MOT- 80cm/100cm User Manual
2
This page is intentionally left blank.

C-COM Satellite Systems Inc. Page 3 of 68
iNetVu®MOT- 80cm/100cm User Manual
3
Copyright © 2020. All rights reserved. C-COM Satellite Systems Inc.
This document contains information, which is protected by copyright. All rights reserved. Reproduction,
adaptation, or translation without prior written permission is prohibited, except as followed under the
copyright laws.
Both the iNetVu®and C-COM names and logos are registered trademarks of C-COM Satellite Systems Inc.
All other product names mentioned in this manual may be trademarks or registered trademarks of their
respective companies and are the sole property of their respective manufacturers.
Proprietary Notice: This document contains information that is proprietary and confidential to C-
COM Satellite Systems, Inc., and is intended for internal and or C-COM Satellite Systems Inc.
authorized partners use only. No part of this document may be copied or reproduced in any way,
without prior written permission of C-COM Satellite Systems, Inc.

C-COM Satellite Systems Inc. Page 4 of 68
iNetVu®MOT- 80cm/100cm User Manual
4
Table of Contents
1. INTRODUCTION......................................................................................................................5
1.1 ABOUT THIS MANUAL............................................................................................................ 5
1.2 SYSTEM OVERVIEW ............................................................................................................... 5
2. PHYSICAL OUTLINE...............................................................................................................6
3. SYSTEM WIRING DIAGRAM –NO MODEM (DVB RX ONLY).............................................8
4. SYSTEM WIRING DIAGRAM –MODEM................................................................................9
5. CLEARANCE REQUIREMENT (DWG OUTDATED) ...........................................................10
5.1 MP-80-MOT CLEARANCE ....................................................................................................10
5.2 MP-100-MOT CLEARANCE..................................................................................................11
6. ASSEMBLY/DISASSEMBLY ................................................................................................12
6.1 ASSEMBLY PROCEDURE.................................................................................................... 12
6.2 DISASSEMBLY PROCEDURE.............................................................................................31
7. POINTING ANTENNA WITH ONBOARD 8020 CONTROLLER.............................................43
7.1 MAIN SCREEN............................................................................................................................. 44
7.2 MENU FEATURES AND SYSTEM CALIBRATION...............................................................47
8. ANTENNA WEB INTERFACE..................................................................................................55
8.1 LOGIN............................................................................................................................................. 55
8.2 CONTROLS ................................................................................................................................... 56
8.2.1 AUTOMATIC........................................................................................................................... 57
8.2.2 MANUAL.................................................................................................................................57
8.2.3 MAINTENANCE..................................................................................................................... 58
8.2.4 DEMO.......................................................................................................................................58
8.3 CARRIERS..................................................................................................................................... 59
8.3.1 CARRIER CONFIGURATION.............................................................................................. 60
8.3.2 CARRIER BUTTONS............................................................................................................61
8.4 CONFIGURATION (CONFIG).....................................................................................................63
8.4.1 SEARCH OPTIONS............................................................................................................... 64
8.4.2 GPS.......................................................................................................................................... 64
8.4.3 NETWORK INTERFACE......................................................................................................65
8.5 ABOUT............................................................................................................................................ 67
9. CONFORMITY LETTER............................................................................................................68

C-COM Satellite Systems Inc. Page 5 of 68
iNetVu®MOT- 80cm/100cm User Manual
5
1. INTRODUCTION
1.1 ABOUT THIS MANUAL
The iNetVu®MP- 80/100 (ManPack) Motorized Pointing System, Installation and Operation are
described in this manual. An electronic version of this manual is included on the iNetVu®flash
drive that came with your system.
1.2 SYSTEM OVERVIEW
This motorized light weight multi-segment carbon fiber ManPack is easy to assemble and points
on satellite, within minutes. The Motorized Manpack systems are complimented by the
addition of the onboard 8020 ACU (Controller) for optimal pointing control. This motorized
three-axis ManPack allows for automatic fine-tuning operation on Azimuth and Elevation. This
robust antenna provides fast and accurate satellite acquisition with the push of one button.
Fig. 1: iNetVu®Motorized Manpack Antenna
Be sure use ballasts or anchors to weigh down the
antenna, failing to do so may result in equipment
damage.

C-COM Satellite Systems Inc. Page 6 of 68
iNetVu®MOT- 80cm/100cm User Manual
6
2. PHYSICAL OUTLINE
Fig. 2: iNetVu®MP-80-MOT/100-MOT Front View
Center Feed
Tripod Legs
Reflector
Tripod Leg
DVB
Module
Power Supply
8020 Controller
Modem (Bracket)
Modem
Tie Down Ring

C-COM Satellite Systems Inc. Page 7 of 68
iNetVu®MOT- 80cm/100cm User Manual
7
Fig. 3: iNetVu®Motorized MP-80-MOT/100-MOT Back View
Ensure to use ballasts or anchors to secure down the
antenna, failing to do so may result in equipment
damage.
Modem
BUC
8020 Controller
NAV Module
Eyebolt
Tie Down Ring

C-COM Satellite Systems Inc. Page 8 of 68
iNetVu®MOT- 80cm/100cm User Manual
8
3. SYSTEM WIRING DIAGRAM –NO MODEM (DVB RX ONLY)
Fig. 4: iNetVu®Motorized MP-80-MOT/100-MOT Wiring Diagram DVB Only
N/C –No Connection
INPUT 24VDC
iNetVu™ MP-80
!
RX IN
RX OUT
iNetVu™ DVB TUNER
N/C
8020 IP: 192.168.0.3
LAPTOP IP: 192.168.0.4
WIRELESS SSID
8020 + LAST 3 DIGITS
OF SN#
Ensure all cables, including RX are connected prior to
powering on 8020 Controller.
))))))))))))))
))))))))))))))))))))))))))))))))
RG6 Coaxial Cable
WIRELESS
Power Cable
Network Cable
)))))))))))
OR

C-COM Satellite Systems Inc. Page 9 of 68
iNetVu®MOT- 80cm/100cm User Manual
9
4. SYSTEM WIRING DIAGRAM –MODEM
Fig. 5: iNetVu®Motorized MP-80-MOT/100-MOT Wiring Diagram with Modem
INPUT 24VDC
iNetVu™ MP-80
!
RX IN
RX OUT
iNetVu™ DVB TUNER
BUC
8020 IP: 192.168.0.2
LAPTOP IP: 192.168.0.6
WIRELESS SSID
8020 + LAST 3 DIGITS
OF SN#
Be sure all cables, including RX and TX are connected prior
to powering on 8020 Controller.
))))))))))))))
))))))))))))))))))))))))))))))))
RG6 Coaxial Cable
WIRELESS
Power Cable
Network Cable
)))))))))))
RX IN
OR
8020 IP: 10.10.10.1
TX OUT
NEWTEC MDM3100
MODEM IP: 192.168.0.5
LNB

C-COM Satellite Systems Inc. Page 10 of 68
iNetVu®MOT- 80cm/100cm User Manual
10
5. CLEARANCE REQUIREMENT (DWG OUTDATED)
5.1 MP-80-MOT CLEARANCE

C-COM Satellite Systems Inc. Page 11 of 68
iNetVu®MOT- 80cm/100cm User Manual
11
5.2 MP-100-MOT CLEARANCE

C-COM Satellite Systems Inc. Page 12 of 68
iNetVu®MOT- 80cm/100cm User Manual
12
6. ASSEMBLY/DISASSEMBLY
The assembly and disassembly of the MP-80-MOT and MP-100-MOT are identical. The only
difference is the MP-100-MOT reflector consists of 7 Carbon Fiber segments instead of 5 on the
MP-80-MOT.
6.1 ASSEMBLY PROCEDURE
1) Set case upright and release lock clips.
Fig. 6: Motorized Manpack Antenna case
2) Open flap that houses the tripod. Remove tripod legs and expand out to maximum distance
until they are up against the stops (AZ base).

C-COM Satellite Systems Inc. Page 13 of 68
iNetVu®MOT- 80cm/100cm User Manual
13
3) Tighten the handles while pressing down securing the tripod legs. Ensure the handles are
pointing downwards as shown. Stabilize tripod using pegs, ballasts etc..
Note: Unit must be securely stabilized (via ballasts or pegs); failing to do so may compromise
satellite lock and damage the unit.
4) Put Orange Screw into the ground where the system will be set up. Plastic tube is used as a
handle to put screw into the ground.

C-COM Satellite Systems Inc. Page 14 of 68
iNetVu®MOT- 80cm/100cm User Manual
14
5) Remove tube.
6) Place Turnbuckle on Eyebolt.
Eyebolt
Turnbuckle

C-COM Satellite Systems Inc. Page 15 of 68
iNetVu®MOT- 80cm/100cm User Manual
15
7) Set Tripod over the Orange Screw and latch Turnbuckle.

C-COM Satellite Systems Inc. Page 16 of 68
iNetVu®MOT- 80cm/100cm User Manual
16
8) Use the pegs to secure down the Tripod Legs; ensure the pegs are oriented as shown.
9) Set the case on its side and open flap.

C-COM Satellite Systems Inc. Page 17 of 68
iNetVu®MOT- 80cm/100cm User Manual
17
10) Remove Elevation Center Section assembly from case; be careful handling, as the 8020
controller is attached. If Modem is attached in the bracket, be careful it does not slide out.
11) Loosen 2 Clamping Levers on the AZ base and make sure they are tilted forward. Line up the
Corner Bracket notches from Center Section onto the tripod.

C-COM Satellite Systems Inc. Page 18 of 68
iNetVu®MOT- 80cm/100cm User Manual
18
12) Make sure the Miniature Clamp Lever is loose to allow the Corner Bracket to slide under it.
13) Tighten the Miniature Clamp.
Miniature
Clamp

C-COM Satellite Systems Inc. Page 19 of 68
iNetVu®MOT- 80cm/100cm User Manual
19
14) Turn and lock the Clamping Lever by pushing down.
15) Connect AZ motor cable from 8020 controller to AZ motor connector; note the orientation
of the cable connector. The clip will snap out to lock connector in place.
Locking
Clip

C-COM Satellite Systems Inc. Page 20 of 68
iNetVu®MOT- 80cm/100cm User Manual
20
16) Connect the following coax cables before applying power to the system.
Note: All connectors to be tightened to 20 in-lbs ±5, if torque wrench available. Tighten the
connector onto the female port. Once hand tightened, if a torque wrench is not available, a
good rule of thumb is to wrench-tighten the connector an additional ¼ to ½ turn.
a. Connect coax cable coming from DVB Module labelled “LNB ” to the LNB.
b. Remove coax cable from side flap and connect coax cable to modem RF OUT.
