C. Crane CC LANTERN DYNAMO User manual

INSTRUCTION MANUAL
PLEASE READ ALL THE INSTRUCTIONS COMPLETELY
BEFORE USE AND SAVE THIS MANUAL
FOR FUTURE REFERENCE.
All manuals and user guides at all-guides.com
all-guides.com

S fety Instructions
Unp cking
READ BEFORE
OPERATING EQUIPMENT
SAVE THESE INSTRUCTIONS
Ꮨ 
To prevent damage to your lantern or possible injury to
you or others, read these safety precautions and in-
structions entirely before applying power to your lantern.
Keep these precautions and instructions where all who
use this lantern will read them.
1. To protect against electrical hazards, do not immerse
adapter or unit in water or other liquid. 
2. Use only supplied adapter for 12 Volt Charging. 
3. Keep magnet in unit away from sensitive products. 
4. Do not store unit near extreme heat. 
P ge 2 CC L ntern
The box should contain the CC Lantern, USB
Charger Cable, 12 Volt Charger Adapter, USB Cell
Phone Adapter for cell phones with voltage less than
4.8V. If anything is missing or damaged, please con-
tact your dealer immediately. We recommend you
keep the box in the unlikely event your lantern needs
to be serviced.
All manuals and user guides at all-guides.com

Loc tion of Controls
CC L ntern P ge 3
Q
WW
E
R
T
Y
UI
QHand Crank
WRelease Buttons
EPower Knob
RPower Indicator
Light
TUSB Input/-
Output Switch
YUSB Port
URed and Green
Charge Indicator
Lights
IEmergency Siren
All manuals and user guides at all-guides.com

Using Your L ntern
P ge 4 CC L ntern
B sic Oper tion
1. Press and hold the Release Buttons on the sides
of the lantern and pull the top up until it locks into
position.
2. To turn the light on, turn the Power Knob right to
the “High” setting. All 15 LEDs will illuminate for
maximum brightness.
3. For lower light, turn the Power Knob left to the
“Low” setting. ine LEDs will illuminate. This set-
ting conserves battery life.
4. Return the Power Knob to “Off” to turn the lantern
off.
5. Press and hold the Release Buttons and push the
top down until it locks in its closed position.
Ch rging the L ntern
We recommend charging the lantern, using the 12
Volt Charger or the USB Charger Cable, for 6 hours
before first use.
The Red Charge Indicator Light will illuminate while
charging.
The Green Charge Indicator Light will illuminate
when charging is complete.
If storing for long periods of time, we recommend
charging the lantern, using the 12 Volt Charger or
the USB Charger Cable, for at least 6 hours every
All manuals and user guides at all-guides.com

Using Your L ntern
CC L ntern P ge 5
Charging with the 12 Volt Charger Adapter:
1. Slide the USB Input/Output
Switch to “Input” setting.
2. Connect one end of
the USB Charger
Cable to the 12 Volt
Charger Adapter and
the other end into the
lanternʼs USB Port.
3. Plug the 12 Volt Charger Adapter into your vehi-
cleʼs accessory socket.
Charging with the USB Charger Cable:
1. Slide the USB Input/Output Switch to “Input” set-
ting.
USB Charger
Cable
12 Volt
Charger Adapter
Charging with the
Hand Cran :
Pull the Hand Crank up
and rotate in either direc-
tion until appropriately
charged. ormally, the
unit will not fully charge
using only the Hand
Crank.
two months.
All manuals and user guides at all-guides.com

Using Your L ntern
P ge 6 CC L ntern
Approximate Lantern Charging Times
CHARGE
TIME
USABLE TIME
High Setting Low Setting
Hand Cran
1 Min. 5 Minutes 8 Minutes
12V Adapter
3 Hours 5 Hours 7 Hours
3 Min. 10 Minutes 15 Minutes
5 Min. 15 Minutes 20 Minutes
Ch rging Cell Phone
This unit can charge cell
phones with voltage less
than 4.8V.
1. On the lantern, slide the
USB Input/Output Switch
to “Output” setting.
2. Using the USB Cell Phone Adapter, insert the USB
connector into the lantern and plug your cell phone
car charger (not included) into the other end.
USB Cell
Phone
Adapter
2. Connect one end of the USB Charger Cable to the
lanternʼs USB Port and the other end to any USB
output device.
All manuals and user guides at all-guides.com
all-guides.com

Using Your L ntern
CC L ntern P ge 7
Approximate Cell Phone Charging Times
CHARGE
TIME TALK TIME STAND BY
1 Min. 20 Minutes
3 Min. 3 Minutes 35 Minutes
5 Min. 5 Minutes 150 Minutes
Using the Emergency Siren
A loud alert will sound when the
Emergency Siren Button is de-
pressed. To turn the siren off,
press the button again.
Siren Button
All manuals and user guides at all-guides.com

Copyright © 2011 by
C. Crane Company, Inc.
1001 Main St, Fortuna, CA 95540
Phone: [phone] Web: ccrane.com
All rights reserved. o part of this booklet may
be reproduced, in any form or means whatsoever, without permission
in writing from C. Crane Company, Inc.
Specific tions
1. umber of Bulbs: 15 LEDs
2. LED Luminance: 12,000 mcd
3. LED Life: 50,000 Hours
4. Battery: 4 Built-in Rechargeable
iMH, 1.2V, 1,200mAh
5. Built-in Alternator: 400mA 9V AC Output
6. Consumer Power: 3W
7. Unit Weight: 17.5 oz.
8. Unit Size: 4.2" W x 9" H X 4.5" D Open
4.2" W x 6.1" H X 4.5" D Closed
