SCT-H Series Industrial Telephones –716-207-4-S
SCT-H telephones are designed to provide safe, reliable communication in hazardous areas that are
prone to high humidity, chemical vapors, dust and physical abuse. Several variations and options
are available to suit the end user’s requirements.
Standard Features on All Models
Enclosure
•16 Gauge steel, zinc dichromate plated and powder coated
Encapsulated Circuitry
•circuit boards are resistant to corrosive agents (e.g. H2S, SO2 and
NH3), and environments with high humidity
Surge Arrestor
•protects the user in the event of a high voltage spike on the telephone
line
Fuse
•prevents damage to the electronic circuits in the event of a high
voltage spike on the telephone line
Magnetic Reed Hook Switch
•no moving parts
Tone (DTMF) Operation
•factory set to tone (DTMF) dialing
•pulse dialing can be ordered or configured in the field
6’ Heavy Duty Handset Cord (SCT-10/20/30-H)
•withstands severe use
Armored Handset Cord (SCT-40-H)
•vandal resistant
Hearing-Aid Compatible (HAC)
•compatible with inductively coupled hearing-aid devices
Receiver Volume Control
•Switches in handsets, (on keypad of SCT-20-H), provide 13.5dB of
range.

C.J. ANDERSON & CO | Item: 716-207-4-S | SCT-20 Phone Installation Guide
IMPORTANT WARNING
Elevator Equipment MUST BE maintained and installed by qualifiedelevator servicetechnicians and elevator contractors. Most states require that bothmechanic and elevator
company be licensed inorderto perform repair andreplacement. If you are not a licensed elevator company or mechanic, you are puttingyour life and those that ride elevators at risk.
Failure to have a qualifiedtechnicianrepair orinstall elevator equipment will nullify any warranty and may causedeathor injury.
PAGE 3
For a complete copy of our termsand conditions pleasecall 708-867-4002, 800-252-1910 or visit http://www.cjanderson.com/termsconditions.aspx Rev.A 3/20
Features (Specific Models)
SCT-20-H
•Membrane Keypad ith Features
1. weather tight
2. 10 number memory
3. Redial - last number (31 digits)
4. Recall - obtains dial tone without hanging up handset
5. Flash - 600ms timed loop break
6. Pause - 3 second pause in programming
7. Mute - disables handset microphone
8. Softer/Louder –2.7dB steps (+8.1dB/-5.4dB 3 steps up, 2
steps down)
Figure 1 - Features

C.J. ANDERSON & CO | Item: 716-207-4-S | SCT-20 Phone Installation Guide
IMPORTANT WARNING
Elevator Equipment MUST BE maintained and installed by qualifiedelevator servicetechnicians and elevator contractors. Most states require that bothmechanic and elevator
company be licensed inorderto perform repair andreplacement. If you are not a licensed elevator company or mechanic, you are puttingyour life and those that ride elevators at risk.
Failure to have a qualifiedtechnicianrepair orinstall elevator equipment will nullify any warranty and may causedeathor injury.
PAGE 4
For a complete copy of our termsand conditions pleasecall 708-867-4002, 800-252-1910 or visit http://www.cjanderson.com/termsconditions.aspx Rev.A 3/20
Figure 2 - Dimensions Above –Figure 3. - Below

C.J. ANDERSON & CO | Item: 716-207-4-S | SCT-20 Phone Installation Guide
IMPORTANT WARNING
Elevator Equipment MUST BE maintained and installed by qualifiedelevator servicetechnicians and elevator contractors. Most states require that bothmechanic and elevator
company be licensed inorderto perform repair andreplacement. If you are not a licensed elevator company or mechanic, you are puttingyour life and those that ride elevators at risk.
Failure to have a qualifiedtechnicianrepair orinstall elevator equipment will nullify any warranty and may causedeathor injury.
PAGE 5
For a complete copy of our termsand conditions pleasecall 708-867-4002, 800-252-1910 or visit http://www.cjanderson.com/termsconditions.aspx Rev.A 3/20
Figure 3 & 4 - Installation SCT-20-H
Installing the SCT-H
•Follow all appropriate electrical codes and use only approved electrical
fittings for the installation.
•Choose a wall location that is free of obstructions and permits space for
cable or conduit runs.
See: Figure 2 -
Dimensions
•Ensure mounting can support 4lbs (1.8kg) and any additional foreseeable
load.
•To avoid the possibility of creating sparks in a hazardous atmosphere
disconnect the wiring at the demarcation block or ensure that the area is
non-hazardous before proceeding.
•To avoid shock hazard ensure that none of the electrical connection circuits
are live by disconnecting the Tip and Ring conductors at the demarcation
block.
•Remove the eight (8) cover screws from the front of the unit and carefully
remove the front cover assembly. NOTE that the handset and all
electronics are attached to the front plate. The front cover may be
separated from the back box by disconnecting the harness plugs.
To change the Tone/Pulse setting to pulse, if required:
Tip: The SCT-H is
factory preset for DTMF
tone.
See: Figure 3 -
Installation SCT-20-H
o Move the jumper from pins 1 & 2 of the Tone/Pulse connector to
pins 2 & 3.
o To change the setting back to tone move the jumper back to pins 1 & 2.
•Use the template provided to locate and drill holes for #8 or M4 mounting
screws.
•Attach the back box to the wall. If weather resistance is important in your
application select washers that will assist in sealing the mounting holes.
Tip: Use #8 or M4
screws to secure the unit
to the wall.
Wiring the SCT-H to the Telephone System
•Use the conduit hub provided or fit an appropriate cable gland, grommet or
conduit connector to the 7/8” opening in the bottom of the enclosure.
•Bring cable into the enclosure through the opening and attach individual
wires from the exchange (Tip/Ring/Ground) to the connector (Tip & Ring are
not polarity sensitive). If a conduit hub is used, ensure it is grounded to the
ground stud.
See: Figure 3 - Figure
4 - Installation SCT-20-
H
•Ensure all connections are tight, then replace and secure the cover.
•Connect the telephone into the system.
•Test the unit by calling to and from another unit on the exchange.

C.J. ANDERSON & CO | Item: 716-207-4-S | SCT-20 Phone Installation Guide
IMPORTANT WARNING
Elevator Equipment MUST BE maintained and installed by qualifiedelevator servicetechnicians and elevator contractors. Most states require that bothmechanic and elevator
company be licensed inorderto perform repair andreplacement. If you are not a licensed elevator company or mechanic, you are puttingyour life and those that ride elevators at risk.
Failure to have a qualifiedtechnicianrepair orinstall elevator equipment will nullify any warranty and may causedeathor injury.
PAGE 6
For a complete copy of our termsand conditions pleasecall 708-867-4002, 800-252-1910 or visit http://www.cjanderson.com/termsconditions.aspx Rev.A 3/20
Field Repairs
Field repairs may only be carried out by qualified technicians using OEM parts.
Substitution of parts voids warranty and may pose a hazard to users of the
equipment.
See: Replacement Parts
•Disconnect the telephone from Tip and Ring power supplied by the PABX
or central office before attempting to make repairs.
•Carefully remove the front cover assembly and separate from the housing
by disconnecting the harness plugs. NOTE that the handset and all
electronics are attached to the front plate.
See: Figure 3 -
Installation SCT-10-H &
SCT-30-H & Figure 4 -
Installation SCT-20-H
•Perform the necessary repairs or adjustments.
•Carefully replace the front plate and install all eight screws. Do not over
tighten the cover screws; there is a flexible gasket between the cover and
the body. Excessive tightening of the screws deforms the gasket and
reduces the weather resistance of the set.
Fuse Replacement
•Remove the old fuse by pushing in the end cap of the fuse holder and
turning counterclockwise to open. Insert a new 0.25 amp, 250Volt, 3AG
fast blow fuse and close the fuse holder.
WARNING!
•Replace only with a 0.25 amp 250V 3AG fast blow fuse. Failure to do so
will void the warranty.
•If, on reconnecting power, the fuse fails, check the telephone system
wiring. The fuse protects the Tip and Ring line from the telephone system.
It is usually powered at 48 volts DC and must not be connected to 120 volts
AC.
Changing the Tone/Pulse Setting
•Set the Tone/Pulse jumper for the desired operation. For pulse, set the
jumper between the center pin and the “P”, for tone set it between the
center pin and “T”.
See: Figure 3 -
Installation SCT-10-H &
SCT-30-H & Figure 4 -
Installation SCT-20-H

C.J. ANDERSON & CO | Item: 716-207-4-S | SCT-20 Phone Installation Guide
IMPORTANT WARNING
Elevator Equipment MUST BE maintained and installed by qualifiedelevator servicetechnicians and elevator contractors. Most states require that bothmechanic and elevator
company be licensed inorderto perform repair andreplacement. If you are not a licensed elevator company or mechanic, you are puttingyour life and those that ride elevators at risk.
Failure to have a qualifiedtechnicianrepair orinstall elevator equipment will nullify any warranty and may causedeathor injury.
PAGE 7
For a complete copy of our termsand conditions pleasecall 708-867-4002, 800-252-1910 or visit http://www.cjanderson.com/termsconditions.aspx Rev.A 3/20
Operation –Models with Standard Keypad
•Once the standard Model SCT-H Telephone has been properly installed
and energized operation is identical to most other single line telephones.
Programming the SCT-20-H with Multi-Function Keypad
A direct memory access register can be assigned to each of the 10 number
keys.
Each direct memory access register can contain up to 20 characters.
Tip: Valid characters are
0-9, *, # and Pause.
•Lift the telephone handset off the hook.
•Press Program to put the phone into programming mode.
•Press Memory.
•Press a number key 0-9.
Tip: The number
selected is assigned to
the access register.
•Enter the telephone number you want to store (e.g., 1-800-363-8010).
•N.B. valid entries are 0-9, *, #, and Pause
Tip: You can store up to
10 numbers in memory.
•If your phone requires you to dial 9 (or other digit) to access an outside line,
press the 9 key, then the Pause key, then enter the telephone number you
want to store (e.g., 1-800-363-8010).
•Press Program again to leave programming mode and return to normal
telephone operation.
Operating the SCT-H
Manual Operation:
Tip: Valid keys for
manual dialing are 0-9, *
and #.
•Lift the handset and dial manually.
•Hang up the handset at the end of conversation.
Automatic Memory Dialing: For Model SCT-20-H with Optional Multi-
function Keypad
Tip: Program the SCT-H
to use this quick dialing
method.
•Lift the handset.
•Press Memory.
•Press a number key 0-9.
•The number stored in the register will automatically dial.

C.J. ANDERSON & CO | Item: 716-207-4-S | SCT-20 Phone Installation Guide
IMPORTANT WARNING
Elevator Equipment MUST BE maintained and installed by qualifiedelevator servicetechnicians and elevator contractors. Most states require that bothmechanic and elevator
company be licensed inorderto perform repair andreplacement. If you are not a licensed elevator company or mechanic, you are puttingyour life and those that ride elevators at risk.
Failure to have a qualifiedtechnicianrepair orinstall elevator equipment will nullify any warranty and may causedeathor injury.
PAGE 8
For a complete copy of our termsand conditions pleasecall 708-867-4002, 800-252-1910 or visit http://www.cjanderson.com/termsconditions.aspx Rev.A 3/20
Specifications
Electrical Performance
AUDIBLE RANGE FREQUENCY RESPONSE
300 –3400 HZ
DIALING METHOD
DTMF OR 40/60 PULSE AT 10 PPS
TRANSMIT OBJECTIVE LOUDNESS RATING (TOLR)
-38 +/- 3 dB
RECEIVER VOLUME ADJUSTMENT
+8.1 / -5.4 dBIN 5 STEPS OF 2.7 dB
RECEIVE OBJECTIVE LOUDNESS RATING (ROLR)
-AT NOMINAL VOLUME LEVEL
50 +/- 3 dB
-AT MAXIMUM VOLUME LEVEL
41.9 +/- 3 dB
-AT MINIMUM VOLUME LEVEL
55.4 +/- 3 dB
SIDE TONE OBJECTIVE LOUDNESS RATING (SOLR)
-AT NOMINAL VOLUME LEVEL
11 +/- 4 dB
-AT MAXIMUM VOLUME LEVEL
7 +/- 4 dB
-AT MINIMUM VOLUME LEVEL
14 +/- 4 dB
MEMORY DIAL (SCT-20-H ONLY)
10 REGISTERS OF 20 DIGITS EACH
FLASH
( "
)
600MSEC TIMED DISCONNECT
MUTE
( "
)
PRESS KEY TO MUTE TRANSMITTER
REDIAL
( "
)
31 DIGITS MAXIMUM
RINGER OUTPUT
>85 dB
FCC RINGER EQUIVALENCE
0.8B
SET IMPEDANCE
600 OHMS NOMINAL
MAXIMUM LOOP
15,000 FT (4,600 M) OF 22 AWG COPPER
Electrical
RINGER SENSITIVITY
40 –100 V, 16 –25 HZ
LINE VOLTAGE
24 –56 VDC
LOOP CURRENT
20 - 120 mA
CONNECTION METHOD
SURGE ARRESTOR /TERMINAL BLOCK
FUSE
¼AMP 250 VOLT 3AG FAST BLOW
Environmental
WEATHERPROOF
ENCLOSURE NEMA 3R
TEMPERATURE
-40O TO +60O C(-40O TO +140O F)
HUMIDITY
0 TO 95% RH
DUSTPROOF
FULLY GASKETED ENCLOSURE

C.J. ANDERSON & CO | Item: 716-207-4-S | SCT-20 Phone Installation Guide
IMPORTANT WARNING
Elevator Equipment MUST BE maintained and installed by qualifiedelevator servicetechnicians and elevator contractors. Most states require that bothmechanic and elevator
company be licensed inorderto perform repair andreplacement. If you are not a licensed elevator company or mechanic you are putting your life and those that rideelevators at risk.
Failure to have a qualifiedtechnicianrepair orinstall elevator equipment will nullify any warranty and may causedeathor injury. PAGE 9
For a complete copy of our termsand conditions pleasecall 708-867-4002, 800-252-1910 or visit http://www.cjanderson.com/termsconditions.aspx Rev. A
3/18
Mechanical
HOOK SWITCH (CRADLE SWITCH) LIFE
>1000 000 OPERATIONS
BODY CONSTRUCTION
16 GA STEEL, ZINC DICHROMATE PLATED & POWDER COATED
OVERALL DIMENSIONS (HX W X D)
9.0 X 5.0 X 5.0 INCHES (229 X 127 X 127 MM)
NET WEIGHT
4 LBS (1.8 KG)
SHIPPING DIMENSIONS
12.0” X 7.0” X 12.0” (305 X 178 X 305 MM)
SHIPPING WEIGHT
6.0 LBS (2.72 KG)
HANDSET MATERIAL
HIGH IMPACT ABS
MICROPHONE
NOISE REDUCING ELECTRET
OPTIONAL MICROPHONE
NOISE CANCELING DYNAMIC
RECEIVER
HEARING AID COMPATIBLE
STANDARD MOUNTING
VERTICAL WALL
WIRING ACCESS
SHIPPED WITH 1/2” CONDUIT HUB
(7/8” DIAMETER OPENING FOR OWNER SUPPLIED FITTING)
HARDWARE MATERIAL
STAINLESS STEEL
Compliance
INDUSTRY CANADA
1012 6721 A
FCC
HQHCAN-22517-TE-E
CSAC/US
CLASS I, DIV. 2, GROUPS A, B, C, D

C.J. ANDERSON & CO | Item: 716-207-4-S | SCT-20 Phone Installation Guide
IMPORTANT WARNING
Elevator Equipment MUST BE maintained and installed by qualifiedelevator servicetechnicians and elevator contractors. Most states require that bothmechanic and elevator company be
licensed in orderto perform repairandreplacement. If you are not a licensedelevator company or mechanic you are putting your life and those that ride elevators at risk. Failure to have a
qualifiedtechnician repair or install elevator equipment will nullify any warranty andmay cause death or injury. PAGE 10
For a complete copy of our termsand conditions pleasecall 708-867-4002, 800-252-1910 or visit http://www.cjanderson.com/termsconditions.aspx Rev. A 3/18
Cleaning Tips for the SCT-20-H Telephone
These Telephones may occasionally need to be cleaned to maintain appearance. Generally, wiping
the surface with a clean, water-dampened cloth will remove most films or residues. If the soiling is
too stubborn for plain water, a mild detergent solution may be used. Be sure to wipe away any
detergent residue with a plain water dampened cloth. The Telephone may be cleanedwith any
general-purpose household glass and surface type cleaner. Do not spray the telephonedirectly!
Spray the cleaner on a soft cloth then wipe the surface. Pre-treated cloths such as those used for
eyeglasses or cameras may be used to clean the Telephone. Premoistened towelettes may also be
used, however, avoid those containing lanolin or aloe, as they will leave a slippery residue. The
handset and surface of the telephone may be cleaned with disinfectants used for general cleaning
in a medical environment. Isopropyl alcohol may be used applied with a cloth. Avoid using alcohol
on silicon-based keypads, since doing so may significantly degrade legibility.
•Do not use furniture polishes, waxes or plasticizer-based cleaner (Armor All etc.)
•Do not use lanolin, aloe, glycerin or other skin care type products.
•Do not apply any solvent such as acetone, mineral spirits etc.
•Do not directly spray or immerse the handset.
Storage
General Storage (All situations):
•Note any stacking limits or warnings on packaging (if any).
•Do not store in temperatures over +80C.
•Store in original packaging if possible until needed.
Long Term Storage (> 6 Months):
•If area is air-conditioned and not subject to high changes in humidity, continue to store in
original packaging.
•If wide humidity shifts are expected, then use these steps:
oRemove product from packaging (including plastic bags) and store on shelf in open air.
oIf area is subject to a high degree of dust, to help maintain cosmetic appearance you can
cover with cloth (Do not cover with plastic or materials that will trap moisture) or clean
periodically.
oDo not store out of packaging long term where they are exposed to sunlight. Long-term
exposure to UV may cause fading on plastic parts.
