CABAC HNS050MD User manual

Customer Care Australia P: 133 122 F: 1300 303 310 E: [email protected] W: cabac.com.au
A: 8 Distribution Pl, Seven Hills NSW 2147
Customer Care New Zealand P: 8 0077 6969 F: 8 0088 6969 E: [email protected].nz W: cabac.co.nz
1
CP14117 Rev 1, 24TH APRIL 2015
HNS050MD MOTION DETECTOR 3-WIRE
Note: This manual was correct at the time of manufacture. For the latest version of the manual and any technical or
safety updates refer to the website:- cabac.com.au, cabac.co.nz or scan the QR code with a mobile phone.
HNS050MD
OWNER’S MANUAL
Scan our QR code
with your phone to go
directly to our website
for technical information
1. FEATURES
• SwitchthelightONtouchfree
• Iftheroomisdark(<20lux)andtheHNS050MDisconnectedtoaCabacS-Clicktimer,movementwilltrigger
ittoturnthelightONforaprogrammedamountoftime
• Idealforspaceswithnaturallightsuchasmeetingrooms,hallways,ofces,laundriesandgarages
• Detectsmotionupto2mfromthesensor
• MustbeusedwithCabacS-Clickrangeof2-Wireor3-WireTimerSwitches
• TurnslightsONonlyinlowlightconditions-savingpower
• Timerswitchremainsusableasnormal
• Usestimerswitchtocontroltime
• Extremelylow<100mWstandbypowerconsumption
• CompatiblewithHPMandClipsalwallplates–lensesincluded
• 3-Wirerequiresneutral
2. OPERATING CONDITIONS
• OperatingVoltage: 220–240Va.c.50Hz
• OperatingTemperature: 0to+50°C
• CertiedStandards: CISPR15,AS/NZS3100
• MaximumLoad: AsperconnectedCabacTimerSwitches
Note:Operationattemperature,voltageorloadoutsideofthespecicationsmaycausepermanentdamagetotheunit.
3. COMPATIBLE SWITCHES
TheHNS050MDmustbeusedwithoneofthetimerswitcheslistedbelow.Itcannotbeusedonitsown.
• HNS410TMMinuteTimer2-Wire
• HNS420TMHourlyTimer2-Wire
• HNS440TMMinuteTimer3-Wire
• HNS450TMHourlyTimer3-Wire
4. OPERATION
 TheHNS050MDisacombinationofpassiveinfra-redmotionandlightleveldetectorthatdetectsmotionupto
2mfromthesensor.TheHNS050MDisasensorandiftheroomisdark(<20lux)willtriggertheCabacS-Click
timertoturnthelightONattherstinstanceofmovementforaxedamountoftime-offeringbothhands
freeswitchingandpowersavings.SeeSection3forcompatibleproducts.
 WhentheHNS050MDdetectsmotioninadarkenedroomorhallwayitwilltriggertheconnectedtimerswitch.
TheroomorhallwayneedstobefairlydarkbeforethesensorwilltriggerthetimerandturnthelightON.The
lightcanalwaysbeturnedondirectlyatthetimerswitch.Thelengthoftimethelightstaysonissetonthe
timerswitch.
 WhenusedwiththeHNS410TMorHNS420TMtimers,thelightswillashbrieyabout1secondaftermotionis
detected,beforeturningonforthesettimingperiod.
REQUIRES
CABAC TIMER
SWITCH

Customer Care Australia P: 133 122 F: 1300 303 310 E: [email protected] W: cabac.com.au
A: 8 Distribution Pl, Seven Hills NSW 2147
Customer Care New Zealand P: 8 0077 6969 F: 8 0088 6969 E: [email protected].nz W: cabac.co.nz
2
CP14117 Rev 1, 24TH APRIL 2015
HNS050MD MOTION DETECTOR 3-WIRE
5. INSTALLATION INSTRUCTIONS
 TheHNS050MDistobeinstalledaspartofaxedwireelectricalinstallation.Bylawsuchinstallationsmust
bemadebyanelectricalcontractororsimilarlyqualiedperson.Avoidexcessiveforceonterminalblock
duringinstallation.
5.1 WIRING
• Disconnectpoweratthecircuitbreakerbeforeanyelectricalwork.
• InsertCabacS-ClickTimerSwitchintofaceplateasperinstructionsinitsmanual.
• InsertHNS050MDintofaceplaceandttheappropriatelens,asshowninFigure1.
• ConnecttheHNS050MDandCabacS-ClickTimerSwitchasperthewiringdiagraminFigure2for2-wire
timer(HNS410TM/HNS420TM)installationorFigure3for3-wiretimer(HNS440TM/HNS450TM)installation.
• FitfaceplacewiththeHNS050MDandCabacS-ClickTimerontowall.
• Reconnectpoweratthecircuitbreakeronceinstallationiscomplete.
• Afterinstallationwaitapproximately30to40secondsfortheHNS050MDtocompletestart-upsequence.
LEDwillashduringthisstart-upsequence.
• Triggerthemotiondetectorandensurethedetectorandtimeroperatecorrectly.TheHNS050MDwillonly
detectmotioniftheroomisdark.
NOTE:TheHNS050MDisdesignedforindooruse.Itisnotratedforoutdoorinstallation.
Figure1:InstallationofHNS050MD
Figure2
Figure3
WIRING DIAGRAM FOR THE HNS050MD USING THE
HNS410TM / HNS420TM 2-WIRE TIMER SWITCHES
HNS410TM / HNS420TM
Load Neutral
HNS050MD
Trigger
Active
Neutral
Loop
Active
WIRING DIAGRAM FOR THE HNS050MD USING THE
HNS440TM / HNS450TM 3-WIRE TIMER SWITCHES
HNS440TM / HNS450TM
Load Neutral
HNS050MD
Trigger
Active
Neutral
Remote
Active
Neutral

Customer Care Australia P: 133 122 F: 1300 303 310 E: [email protected] W: cabac.com.au
A: 8 Distribution Pl, Seven Hills NSW 2147
Customer Care New Zealand P: 8 0077 6969 F: 8 0088 6969 E: [email protected].nz W: cabac.co.nz
3
CP14117 Rev 1, 24TH APRIL 2015
HNS050MD MOTION DETECTOR 3-WIRE


23 March 2015
Hallway1-Issue 06A


25 Feb 2015
Motion-01C








6. SUITABLE PLACEMENT FOR HNS050MD
6.1 SUGGESTED HALLYWAY LOCATIONS
6.2 SUGGESTED ROOM LOCATIONS
WIRING DIAGRAM FOR THE HNS410TM / HNS420TM
CONTROLLED BY MULTIPLE HNS050MD MOTION DETECTORS
HNS410TM / HNS420TM
HNS050MD
Trigger
Active
Neutral
Neutral
HNS050MD
Trigger
Active
Neutral
Load
Active
Loop
WIRING DIAGRAM FOR THE HNS440TM / HNS450TM
CONTROLLED BY MULTIPLE HNS050MD MOTION DETECTORS
HNS440TM / HNS450TM
Load
HNS050MD
Trigger
Active
Neutral
Neutral
HNS050MD
Trigger
Active
Neutral
Remote
Active
Neutral
5.2 MULTIPLE HNS050MD WIRING
• MultipleHNS050MDcanbeusedtostartasingleCabacS-Click2-WireorCabacS-Click3-WireTimer.
• RefertoFigure4and5forthedifferentmethodsofconnectingatimerwithmultipleHNS050MD.
• ThereiseffectivelynolimittothenumberofHNS050MDthatcanbeconnectedtoasinglecircuitprovidedthe
totaltriggerwirelengthdoesnotexceed50m.
Figure4
Figure5

Customer Care Australia P: 133 122 F: 1300 303 310 E: [email protected] W: cabac.com.au
A: 8 Distribution Pl, Seven Hills NSW 2147
Customer Care New Zealand P: 8 0077 6969 F: 8 0088 6969 E: [email protected].nz W: cabac.co.nz
4
CP14117 Rev 1, 24TH APRIL 2015
HNS050MD MOTION DETECTOR 3-WIRE
7. IMPORTANT SAFETY WARNINGS
7.1 LOAD REPLACEMENT
• ItshouldbeassumedthatevenwhenOFF,mainsvoltagewillstillbepresentatthelamptting.Mains
powershouldbedisconnectedatthecircuitbreakerbeforereplacingfaultylamps.
7.2 HNS050MD INSTALLATION
• TheHNS050MDistobeinstalledaspartofaxedwireelectricalinstallation.Bylawsuchinstallations
mustbemadebyanelectricalcontractororsimilarlyqualiedperson.Avoidexcessiveforceduring
installation.
7.3 LOW READING DURING INSULATION BREAKDOWN TEST
• TheHNS050MDisasolidstatedevice.Thereforealowreadingmaybeobservedwhenconducting
Insulationbreakdowntestingonthecircuit.
7.4 CLEANING
• Cleanonlywithadampcloth.Donotuseabrasivesorchemicals.
8. TROUBLESHOOTING
8.1 LIGHTS DO NOT TURN ON
• Ensurethatthecircuithaspowerbycheckingthecircuitbreaker.
• Ensurethelamp(s)isnotdamagedorbroken.
• Theroommaybetoobright-theHNS050MDwillnotactivateiftheroomislight.CheckifHNS050MD
indicatorLEDlightswitchesonwhenmotionisdetected.
• EnsuretheHNS050MDiscorrectlyconnectedtothetheCabacS-ClickTimerSwitch.
• TheHNS050MDmayhavebeendamagedandneedstobereplaced.
8.2 TIMER HAS POWER BUT MOTION DETECTOR DOESN’T WORK
• Theroommaybetoobright-theHNS050MDwillnotactivateiftheroomislight.
• TheHNS050MDmightnotbeconnectedtothetimerswitchcorrectly.
• TheHNS050MDisobstructedorbeinginterferedwithbydirt,furnitureoranobject.
• Ashadowmaybecastoversensorbypersonorobject.
8.3 LIGHTS TURN ON, THEN OFF
• TheHNS050MDisretriggering.Checkthattheroomlightisnotobstructedfromtheviewofthe
HNS050MD.
• Thelightintheroommaynotbebrightenough,whichmayhappenifaperson’sshadowcastacrossthe
sensorandtheroomlightisnotbrightenough.
9. WARRANTY AND DISCLAIMER
CABACwarranttheproductagainstmanufacturingandmaterialdefectfromthedateofinvoicetotheinitial
purchaserforaperiodof12months.DuringthewarrantyperiodCABACwillreplaceproductsthatprove
tobedefectivewheretheproducthasbeencorrectlyinstalledandmaintainedandoperatedwithinthe
specicationsdenedintheproductdatasheetandwheretheproductisnotsubjecttomechanicaldamage
orchemicalattack.Thewarrantyisalsoconditionalontheunitbeinginstalledbyalicensedelectrical
contractor.Nootherwarrantyisexpressedorimplied.
CABACshallnotbeliableforanydirect,indirect,incidentalorconsequentialdamages.
Note: This manual was correct at the time of manufacture. For the latest version of the manual and any technical or
safety updates refer to the website:- cabac.com.au, cabac.co.nz or scan the QR code with a mobile phone.
