Cabela's 551306 User manual

Please read this manual in its entirety prior to using this product.
Visit www.cabelas.com or call for assistance 1-800-237-4444.
Cabela’s Item Number: 551306
Ultimate Turkey Fryer

WARNING
CARBON MONOXIDE HAZARD
Burning charcoal inside can
kill you. It gives off carbon
monoxide, which has no odor.
NEVER burn charcoal inside
homes, vehicles or tents.
IMPORTANT: Read your cooker Instruction Manual before using
this thermometer. The Red Zone is Danger. Never allow tem-
perature of oil to exceed 350ûF. NEVER LEAVE COOKER
UNATTENDED. Failure to follow these instruc-
tions could cause a grease fire / explosion result-

ing in personal injury, death, or property damage.
DEEP FRY THERMOMETER


WARNING
®
ASSEMBLY INSTRUCTIONS
AND
USE AND CARE MANUAL
THE INSTRUCTION MANUAL CONTAINS IMPORTANT INFORMATION NECESSARY
FOR THE PROPER ASSEMBLY AND SAFE USE OF THE APPLIANCE.
READ AND FOLLOW ALL WARNINGS AND INSTRUCTIONS BEFORE ASSEMBLING
AND USING THE APPLIANCE. FOLLOW ALL WARNINGS AND INSTRUCTIONS WHEN
USING THE APPLIANCE.
KEEP THIS MANUAL FOR FUTURE REFERENCE.
METAL FUSION, INC.
712 St. George Avenue.
Jefferson, LA 70121
If you have any problems or questions
Call Us Toll Free at
1-800-783-3885
7:30 A.M. to 3:30 P.M. CST • Monday through Friday
[phone]
www.kingkooker.com
OUTDOOR COOKERS
WITH
GAS SHUT-OFF TECHNOLOGY
MODEL/SERIAL # __________
English
FAILURE TO FOLLOW THESE INSTRUCTIONS
AND WARNINGS COULD RESULT IN FIRE, EXPLOSION, BURN HAZARD OR CARBON
MONOXIDE POISONING WHICH COULD CAUSE PROPERTY DAMAGE,
PERSONAL INJURY OR DEATH.

FOR YOUR SAFETY
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. If odor continues, keep away from the appliance and immediately
call your Fire Department.
FAILURE TO FOLLOW THESE INSTRUCTIONS COULD RESULT IN FIRE OR EXPLOSION
WHICH COULD CAUSE PROPERTY DAMAGE, PERSONAL INJURY OR DEATH.
1. Never operate this appliance unattended.
2. Never operate this appliance within 10 feet (3.05m) of any structure,
combustible material or other gas cylinder. Do not locate this
appliance under ANY overhead construction.
3. Only use propane burning units outdoors. Risks include fire and
carbon monoxide fumes. Lack of ventilation can cause injury or
death.
4. Never operate this appliance within 25 feet (7.5m) of any flammable
liquids or vapors.
5. Do not fill cooking vessel beyond maximum fill line (if
applicable).
6. When cooking with oil/grease, always use the thermometer
provided and never allow the oil/grease to get hotter than 350°F
(177°C). If the temperature exceeds 350°F (177°C) or if oil begins
to smoke, immediately turn the burner or gas supply OFF.
7. Heated liquids and equipment remain at scalding temperatures
long after the cooking process. Never touch cooking appliance
until liquids have cooled to 100°F (38°C) or less.
8. If a fire should occur, keep away from the appliance and immediately
call your Fire Department. Do not attempt to extinguish an oil/
grease fire with water. When cooking, have a Type BC or ABC fire
extinguisher readily available. A Type BC or ABC fire extinguisher
may, in some circumstances, contain the fire.
2
FAILURE TO FOLLOW THESE INSTRUCTIONS AND WARNINGS COULD RESULT IN
FIRE, EXPLOSION, BURN HAZARD OR CARBON MONOXIDE POISONING WHICH COULD
CAUSE PROPERTY DAMAGE, PERSONAL INJURY OR DEATH.
DANGER
DANGER

3
1) This is an ATTENDED appliance. The gas shut-off system is NOT a
replacement for proper monitoring. Do NOT leave this appliance unattended
while the burner is lit or while heating oil, grease, water or cooking food.
Monitor the appliance when hot after use [oil, grease or water above 100
° F
(38
° C)]. Heated liquid and equipment can remain at scalding temperatures
long after cooking has ended.
2) Keep children, pets and unauthorized persons away from the appliance at
all times.
3) The use of alcohol, prescription or non-prescription drugs may impair
your ability to properly assemble or safely operate this appliance. Do NOT
assemble or operate this appliance if using alcohol, prescription or non-
prescription drugs.
4) This appliance is for OUTDOOR use only. Do NOT use in a building, garage,
tent or any other enclosed area. Do NOT use in or on a recreational vehicle
or boat. NEVER use this appliance as a heater.
5) Do not locate this appliance under ANY overhead construction. Keep a
minimum clearance of 10ft. (3.05m) from the sides, front and back of the
appliance to ANY construction. Keep the area clear of ANY combustible
material. Do not use on or under ANY apartment or condo balcony or deck.
6) When cooking, the fryer/boiler must be on a level, stable, noncombustible
surface such as brick, concrete or dirt. Not suitable are surfaces such as
wood, asphalt or plastic which may burn, blister or melt.
7) Check all cooker fittings for leaks before each use. Do not use a flame
to check for gas leaks. Keep the fuel supply hose away from any heated
surfaces. Only the LP hose/regulator assembly specified by Metal Fusion,
Inc. should be used with this appliance.
8) When cooking with oil or grease, the thermometer provided MUST be
used. Follow instructions in this manual for proper installation and use of
thermometer. If the thermometer supplied with the fryer/boiler has been
lost or damaged, a replacement thermometer specified by Metal Fusion,
Inc. shall be obtained before using the appliance.
9) If the temperature of cooking oil exceeds 350
° F (177 ° C) or if oil begins to
smoke, immediately turn the burner or gas supply OFF and wait for the
temperature to decrease to less than 350
° F (177 ° C) before relighting burner
according to the instructions in this manual.
10) When cooking with oil/grease, have a Type BC or ABC fire extinguisher
readily available. In the event of an oil/grease fire, do not attempt to
extinguish with water. Immediately call the Fire Department. A Type BC or
ABC fire extinguisher may, in some circumstances, contain the fire.
11) NEVER overfill the cooking pot with oil, grease or water. Follow instructions
in this manual for establishing proper oil, grease or water levels.
WARNING
CARBON MONOXIDE HAZARD
Burning charcoal inside can
kill you. It gives off carbon
monoxide, which has no odor.
NEVER burn charcoal inside
homes, vehicles or tents.
IMPORTANT: Read your cooker Instruction Manual before using
this thermometer. The Red Zone is Danger. Never allow tem-
perature of oil to exceed 350ûF. NEVER LEAVE COOKER
UNATTENDED. Failure to follow these instruc-
tions could cause a grease fire / explosion result-

ing in personal injury, death, or property damage.
DEEP FRY THERMOMETER


WARNING
READ AND UNDERSTAND BEFORE USING THIS PRODUCT
Throughout this manual the words appliance, cooker, fryer/boiler, burner and stove
will be used interchangeably to refer to the King Kooker®Outdoor Cooker.

4
12) Introduction of water or ice from any source into the oil/grease may cause
overflow and severe burns from hot oil and water splatter. When frying with oil/
grease, all food products MUST be completely thawed and towel dried before
being immersed in the fryer.
13) Never drop food or accessories into hot cooking liquid. Lower food and
accessories slowly into the cooking liquid in order to prevent splashing or
overflow. When removing food from the appliance, care shall be taken to avoid
burns from hot cooking liquids.
14) This appliance and pot, including handles and lids, gets dangerously hot in use.
Use well-insulated pot holders or oven mitts for protection from hot surfaces or
splatter from cooking liquids. Safety goggles are also recommended to protect
you from oil splatter. The oil remains dangerously hot hours after use.
15) Do NOT place an empty cooking vessel on the appliance while in operation.
Use caution when placing anything in the cooking vessel while the appliance is
in operation. Never use a cooking vessel larger than the capacity and diameter
specified in this manual.
16) In the event of rain, snow, hail, sleet or other forms of precipitation while
cooking with oil/grease, cover the cooking vessel immediately and turn off the
appliance burners and gas supply. Do not attempt to move the appliance or
cooking vessel.
17) Do NOT move the appliance when in use. Allow the cooking vessel to cool to
100
° F (38 ° C) before moving or storing.
18) Avoid bumping of or impact with the appliance to prevent contact with hot
appliance, spillage or splashing of hot cooking liquid.
19) See Use and Care section for LP Gas Cylinder Information. A 20 pound (9 kg)
cylinder should be used with this cooker. The LP-gas supply cylinder used must
have a protective collar and must be constructed and marked in accordance with
the specifications for LP-gas cylinders of the U. S. Department of Transportation
(DOT) or the National Standard of Canada, CAN/CSA-B339, Cylinders, Spheres
and Tubes for the Transportation of Dangerous Goods. Do not store a spare
LP-gas cylinder under or near this appliance. Never fill the cylinder beyond 80%
full. For proper vapor withdrawal, the 20 lb. (9 kg) cylinder should be used in the
proper upright position. Cylinder must be turned off while not in use. Failure to
follow these instructions and warnings could result in fire or explosion which
could cause property damage, personal injury or death.
20) This appliance is not intended for commercial use.
21) Use King Kooker
®
appliances only in accordance with state and local ordinances,
or in the absence of local codes, with the National Fuel Gas Code, ANSIZ223.1/
NFPA 54, Storage and Handling of Liquefied Petroleum Gases, ANSI/NFPA 58 or
CSA B149.1, Natural Gas and Propane Installation Code.
WARNING
CARBON MONOXIDE HAZARD
Burning charcoal inside can
kill you. It gives off carbon
monoxide, which has no odor.
NEVER burn charcoal inside
homes, vehicles or tents.
IMPORTANT: Read your cooker Instruction Manual before using
this thermometer. The Red Zone is Danger. Never allow tem-
perature of oil to exceed 350ûF. NEVER LEAVE COOKER
UNATTENDED. Failure to follow these instruc-
tions could cause a grease fire / explosion result-

ing in personal injury, death, or property damage.
DEEP FRY THERMOMETER


WARNING
FAILURE TO FOLLOW THESE INSTRUCTIONS AND WARNINGS COULD RESULT IN
FIRE, EXPLOSION, BURN HAZARD OR CARBON MONOXIDE POISONING WHICH
COULD CAUSE PROPERTY DAMAGE, PERSONAL INJURY OR DEATH.

READ AND UNDERSTAND ALL INSTRUCTIONS BEFORE
USING YOUR KING KOOKER®PRODUCT
TABLE OF CONTENTS
Warnings .......................................................................................2-4
Table of Contents ..................................................................................5
Warranty..........................................................................................6
Owners Registration ..............................................................................7-8
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Section I - King Kooker®Outdoor Cooker Assembly....................................................10
Components .................................................................................10
Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-12
Work Table Assembly Instructions (Model 6612 Only). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Section II - Use and Care of King Kooker®Outdoor Cookers and Accessories..............................14
Thermometer Instructions and Safety Precautions for Deep Frying with Outdoor Cookers ...................14
Determining Proper Fill Levels for Cooking Vessels ..................................................14
LP Gas Cylinder Information ....................................................................15
Connection Instructions ........................................................................15
Leak Test Instructions..........................................................................15
Placement Instructions .........................................................................16
Lighting and Operating Instructions............................................................16-17
Overheat Protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Flame Out Protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Turning Off and Storing the Cooker after Use ...................................................... 18
Maintenance Of Outdoor Cookers And Accessories..................................................19
Tips for Caring for Pots.........................................................................20
Information Regarding Cooking Oil ...............................................................20
Section III - Cooking Specialties.....................................................................21
Deep Fried Turkey Instructions ..................................................................22
Injecting Techniques...........................................................................23
Operation of Spigot Pot (Model 6611BSP and CAB6610SSP Only). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Section IV - Recipes ...............................................................................25
Boiled Seafood ...............................................................................25
King Kooker®Beans ..........................................................................25
King Kooker®Jambalaya. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Fried Seafood ................................................................................26
Deep Fried Turkey ............................................................................26
Deep Fried Chickens ..........................................................................26
Deep Fried Turkey Breast.......................................................................27
Southern Fried Chicken ........................................................................27
Fried Onion Rings.............................................................................27
Fried Mushrooms .............................................................................27
Deep Fried Boston Butt ........................................................................28
King Kooker®Wings ..........................................................................28
Section V -Troubleshooting .........................................................................29
5

6
METAL FUSION, INC.
LIMITED ONE-YEAR WARRANTY
WHAT THIS WARRANTY COVERS
This warranty covers all components of this outdoor cooker to be free from defects in materials and
workmanship, with the exceptions stated below.
HOW LONG COVERAGE LASTS
This warranty runs for one year from the date of purchase. Please keep your receipt with this manual
for future reference.
WHAT IS NOT COVERED
This warranty does not cover the following:
Incidental and Consequential Damages. This warranty does not cover incidental and
consequential damages arising in any way out of the use of this outdoor cooker. The liability of
Metal Fusion, Inc. is, in any event, limited to the amount of the original purchase price of this
outdoor cooker, and remains in force only as long as the product remains in its original, as-built
configuration. Some states do not allow the exclusion or limitation of incidental or consequential
damages, so the above limitation or exclusion may not apply to you.
Neglectful Operation. This warranty does not cover any loss or damage arising in any way
due to the negligent operation of this outdoor cooker.
Altered, Repaired or Misused Equipment. This warranty does not cover any loss or
damage arising in any way out of the use of this outdoor cooker when it has been altered, repaired
by persons other than Metal Fusion, Inc., or when it has been abused or misused, or when it has
been used other than in accordance with the manufacturer’s operating instructions, including,
without limitation, any damage to the consumer’s pots because they were placed on a lit cooker
while the pot is empty. Damage to the cooker unit or pot caused by failure to follow maintenance
instructions is not covered by the warranty.
Other Assumed Responsibilities. Unless otherwise provided by law, this warranty does
not cover any responsibility or liability arising in any way out of the use of this product where that
responsibility or liability was purportedly assumed by any other person or agent.
Paint, Discoloration and Rust. This warranty does not cover the paint on the outdoor cooker,
as in a normal use of the outdoor cooker, the paint will be burned off. Nor does this warranty cover
discoloration or rust as these occurrences are part of the cooker’s normal wear and tear.
WHAT METAL FUSION, INC. WILL DO
Metal Fusion, Inc. will repair or replace any outdoor cooker that proves to be defective in materials
or workmanship. In the event repair is not possible or economically feasible, Metal Fusion, Inc. will
replace your outdoor cooker with an identical or substantially equivalent outdoor cooker. Metal
Fusion, Inc. will perform this service at no charge to you, except for the actual cost of shipping and
handling the outdoor cooker or replacement parts.
HOW TO GET SERVICE
In the event you have a problem or malfunction with your outdoor cooker, simply call Metal Fusion,
Inc. at [phone].
HOW STATE LAW APPLIES
This warranty gives you specific rights, and you may have other rights which vary from state to
state.

7
OWNER’S REGISTRATION
Dear Customer,
Thank you for purchasing a King Kooker®! Please take a moment to fill
out your registration form and return it to us. We are always happy to hear
suggestions and comments from our customers about our products. Completion
of this registration allows us to contact you if the need arises. Please keep your
receipt with your instruction manual. It will be necessary as a proof of purchase
for us to help you if there is a problem with your cooker.
Name:__________________________________________________________________
E-Mail: _________________________________________________________________
Address:________________________________________________________________
________________________________________________________________________
________________________________________________________________________
Telephone: _____________________________________________________________
Model# ________________________________________________________________
Date of Purchase ________________________________________________________
Place of Purchase _______________________________________________________
Price Paid ______________________________________________________________
Was this a gift _____ or did you _____ purchase it yourself?
________________________________________________________________________
________________________________________________________________________
Comments:
________________________________________________________________________
________________________________________________________________________
A SATISFIED CUSTOMER IS OUR MAIN GOAL. If you have any questions or
problems, please call us at 1-800-783-3885 before returning the product to the
point of purchase. Please have your receipt available when calling.
THANK YOU,
ENJOY YOUR COOKING EXPERIENCE.
®
#

8
________________________
________________________
________________________
METAL FUSION, INC.
712 St. George Avenue
Jefferson, LA 70121
Place
Stamp
Here
FOLD
FOLD
TAPE HERE

9
INTRODUCTION
Your new King Kooker ® Outdoor Cooker is equipped with a gas
shut-off system. This system helps prevent the overheating of cooking oil and
fires which could result, by stopping the gas flow to the appliance. The pot
contains a high temperature probe that senses when the oil temperature is too
high. The system then stops gas flow to the appliance.
To operate your new cooker, the pot must be properly placed and plugged into
the burner system as per the assembly instructions in this manual.
The system will also stop gas flow in the event the flame blows out, preventing a
dangerous build up of gas that could ignite.
Follow all warnings and instructions contained in this manual for proper
assembly and use of this product.
IMPORTANT: The gas shut-off system is NOT a replacement for proper
monitoring and will not control the temperature of the cooking liquid within
the pot. Your cooker must always be attended while in use and monitored
after use while still hot [100 ° F (38 ° C)]. The oil in the pot can overheat
quickly if left unattended. The thermometer supplied with this appliance
must always be used to monitor the temperature of the cooking liquid.
WARNING
CARBON MONOXIDE HAZARD
Burning charcoal inside can
kill you. It gives off carbon
monoxide, which has no odor.
NEVER burn charcoal inside
homes, vehicles or tents.
IMPORTANT: Read your cooker Instruction Manual before using
this thermometer. The Red Zone is Danger. Never allow tem-
perature of oil to exceed 350ûF. NEVER LEAVE COOKER
UNATTENDED. Failure to follow these instruc-
tions could cause a grease fire / explosion result-

ing in personal injury, death, or property damage.
DEEP FRY THERMOMETER


WARNING
FAILURE TO FOLLOW THESE INSTRUCTIONS AND WARNINGS COULD
RESULT IN FIRE, EXPLOSION, BURN HAZARD OR CARBON MONOXIDE
POISONING WHICH COULD CAUSE PROPERTY DAMAGE,
PERSONAL INJURY OR DEATH.
READ AND UNDERSTAND ALL INSTRUCTIONS BEFORE
USING YOUR KING KOOKER®PRODUCT

SECTION I
OUTDOOR COOKER ASSEMBLY
THE USE AND CARE MANUAL MUST BE READ AND UNDERSTOOD
BEFORE USING THE APPLIANCE
Throughout this manual the words appliance, cooker, fryer/boiler, burner and stove will be
used interchangeably to refer to the King Kooker®Outdoor Cooker.
COMPONENTS
Before assembling, check that all cooker components are included in the shipping carton.
Accessories such as pots may vary according to model. Check the list of accessories on your
cooker box. The following parts are considered essential and should be included in your package
regardless of model number.
Required Parts List:
1 - Cooker stand
1 - Burner/Gas Train Assembly (Burner, Hose and Regulator,
Thermoelectric Valve, Thermocouple, Copper Tubing)
1 - Thermometer
1 - Pot with High Temperature Probe and Wire Harness Assembly
Remove burner assembly from packaging and inspect to ensure all components of the burner/gas
train assembly are present and without damage. Use care during assembly not to damage any
components. See Figure 1 for detailed view of the burner/gas train assembly.
10
FIGURE 1
WARNING
CARBON MONOXIDE HAZARD
Burning charcoal inside can
kill you. It gives off carbon
monoxide, which has no odor.
NEVER burn charcoal inside
homes, vehicles or tents.
IMPORTANT: Read your cooker Instruction Manual before using
this thermometer. The Red Zone is Danger. Never allow tem-
perature of oil to exceed 350ûF. NEVER LEAVE COOKER
UNATTENDED. Failure to follow these instruc-
tions could cause a grease fire / explosion result-

ing in personal injury, death, or property damage.
DEEP FRY THERMOMETER


WARNING
Burner (Casting)
Thermocouple Tip
Venturi
Igniter Button
Thermoelectric Valve
Connector
Copper
Tubing
Place Wrench Here Only
(Burner Side of Valve) LP Hose
Type 1
Connection
Adjustable Regulator
FIGURE 1
* Model May Vary From Picture

11
Tools Required:
Torque Wrench or Adjustable Wrench, Leak Testing Solution and Screwdriver
ASSEMBLY
1. Read assembly instructions, and understand sequence of assembly, before commencing to assemble
your cooker.
2. The casting for your cooker must be installed into the unit as instructed below before use.
Casting Installation:
A) Remove top nut from casting bolt. Leave bottom nut attached and tightened (if applicable.)
B) Place the casting bolt through the hole on the flat bar casting support bracket as pictured below. The
venturi tube of the burner should be located underneath the windshroud. The venturi tube of the burner
should also be positioned under the horizontal plating on the cooker frame to protect the wire harness
assembly of the gas shutoff system. For cookers supplied with a heat plate, place the heat plate onto the
casting bolt beneath the flat bar casting support bracket. The copper tubing located underneath the casting
must be routed through the cutout provided on the heat plate.
C) Reinstall nut to casting bolt. Tighten. Check to see if casting is pointing straight up and is sturdy.
* Above Figure Does Not Show Hose/Valve Assembly
Which Will Be Pre-Assembled to the Casting
3. Refer to Figure 2 below for picture of a properly installed burner/gas train assembly.
Bottom Nut
(If Applicable)
Top Nut
Casting Bolt
Venturi Tube
Windshroud
Flat Bar Casting
Suppport Bracket
Copper Tubing
Horizontal
Plating
Venturi Tube
Positioned Under
Horizontal Plating
Heat Plate
(If Applicable)
FIGURE 2
* Model May Vary From Picture
* Model May Vary From Picture

12
4. Place pot on cooker with wire harness assembly in line with the venturi tube as shown in Figure 3.
Attach pot connector to thermocouple connector as shown in Figure 4. These must be attached for
the outdoor cooker to operate.
FIGURE 3
FIGURE 4
* Model May Vary From Picture
* Model May Vary From Picture
Pot Connector
Thermocouple
Connector
Venturi
Wire Assembly
Pot

13
WORK TABLE ASSEMBLY INSTRUCTIONS
(MODEL 6612 ONLY)
CONTENTS
(1) Work Table
(1) Legs
(4) Bolts, Lockwashers and Nuts
1. Assemble the legs to the outside of the work table with two bolts, lockwashers and nuts.
Wrench tighten. See below Figure 1.
2. Assemble the work table to the cooker with two bolts, lockwashers and nuts. Wrench tighten.
See below Figure 2.
FIGURE 1
LEGS
WORK TABLE
ASSEMBLED VIEW
BOLT
CONNECTION
BOLT
CONNECTION
FIGURE 2

READ AND UNDERSTAND BEFORE USING THIS APPLIANCE
FAILURE TO FOLLOW THESE INSTRUCTIONS AND WARNINGS COULD RESULT IN FIRE,
EXPLOSION, BURN HAZARD OR CARBON MONOXIDE POISONING WHICH COULD CAUSE
PROPERTY DAMAGE, PERSONAL INJURY OR DEATH.
THERMOMETER INSTRUCTIONS AND SAFETY PRECAUTIONS FOR
DEEP FRYING WITH OUTDOOR COOKERS
1. The gas shut-off system should stop the gas flow if the oil in the pot overheats. However, it is important to always attend the appliance
and monitor the cooking liquid temperature with the deep fry thermometer provided with the appliance for successful and safe
cooking.
2. Always use a deep fry thermometer when using this appliance as a fryer/boiler.
a. Before each use of the appliance make sure that the thermometer is properly calibrated by placing the tip in
a pot of boiling water. The thermometer should register within +/-20°of 212°F or +/-10°of 100°C. If
the thermometer is miscalibrated, contact Metal Fusion, Inc. to obtain a replacement before using
the appliance.
b. Hang the thermometer on the inside of the pot with the probe immersed in the cooking
liquid. Never place a lid over a pot when monitoring the temperature of oil.
c. Once the fire has been lit monitor the temperature on the thermometer at all times. Water boils at
212°F(100°C). The temperature of hot oil should never be allowed to exceed 350°F(177°C).
IMPORTANT: Oil can ignite at high temperatures. Most King Kooker®thermometers have a Red Zone above
350°F(177°C) to signify Danger. Never allow the temperature to exceed 350°F(177°C). If the temperature goes above
350°F(177°C) immediately turn the burner and gas supply OFF and wait for the temperature to decrease to below
350°F(177°C) before relighting according to instructions in the manual. If at any point during the cooking process the
oil begins to smoke, immediately turn the burner and gas supply OFF regardless of the reading on the thermometer.
Allow time for the oil to cool, then contact Metal Fusion, Inc. for further instructions.
d. When the cooking is complete and the cooker has been turned off, allow the temperature of the oil to fall
below 100°F(38°C) before moving the pot, cooking oil, or cooker.
e. Please call Metal Fusion, Inc. at [phone] with any questions concerning the use or operation of
the thermometer.
3. Never cover the pot when cooking with oil.
4. Always thaw and dry food completely before placing it into hot oil. Frozen or wet food may cause oil or grease to
overflow.
5. Never put an empty pot over an open flame.
6. In the event of rain, snow, hail, sleet or other forms of precipitation while cooking with oil/grease, cover the cooking
vessel immediately and turn off the appliance burners and gas supply. Do not attempt to move the appliance or
cooking vessel.
7. When cooking with oil or grease, fire extinguishing materials shall be readily accessible. In the event of an oil or
grease fire do NOT attempt to extinguish with water. Immediately call your Fire Department. A Type BC or Type ABC
fire extinguisher may, in some circumstances, contain the fire.
DETERMINING PROPER FILL LEVELS FOR COOKING VESSELS
Never overfill the cooking vessel with oil, grease or water. Always fill to at least the minimum fill line. Never fill a pot
beyond the maximum fill line. Some models include fry pans that are stamped with only one fill line. This indicates
the exact level to which the oil should be filled before it is heated and food is added.
Follow these instructions to determine the amount of cooking liquid to be used on turkey pots (up to a 20 lb. turkey):
a. Place the food product in or on the holder.
b. Place the food product and holder into the empty vessel.
c. Fill the vessel with water until the food product is completely submerged. There must be a
minimum of 3 inches (7.5cm) between the water level and top of the vessel.
d. Remove the food product from the vessel and either mark the water level on the side of
the vessel or measure the amount of water in the vessel.
e. Remove the water and completely dry the vessel and the food product.
f. This is the amount of cooking liquid the vessel is to be filled with to cook the food product. Make sure this
level is located between the minimum fill line and maximum fill line.
14
SECTION II
USE AND CARE
Throughout this manual the words appliance, cooker, fryer/boiler, burner and stove will be used
interchangeably to refer to the King Kooker®Outdoor Cooker.

LP GAS CYLINDER INFORMATION
King Kooker® Outdoor Cookers are manufactured for use with 20lb. (9 kg) LP Gas Cylinders. Important
information to remember about LP Gas cylinders include:
1. Always read and follow the cylinder manufacturer’s instructions.
2. Make sure that the gas cylinder is not overfilled. The maximum weight of a properly filled 20 lb. (9 kg) LP
gas cylinder is approximately 38 lbs (17 kg). Never fill the cylinder beyond 80% full.
3. Make sure that the cylinder valve has the proper connection for a Type 1 appliance fitting.
4. Do not store a spare LP gas cylinder under or near this appliance.
5. Disconnect the cylinder from the cooker for storage.
6. Store the cylinder out of the reach of children.
7. Do not use or store the cylinder in a building, garage or enclosed area.
8. Always use a 20 lb. (9 kg) cylinder in the proper upright position for the proper vapor withdrawal. It should
also be stored and transported in the upright position.
9. The cylinder must have a protective collar to protect the cylinder valve.
10. Place dust cap on cylinder valve outlet whenever the cylinder is not in use. Only install the type of dust cap
on the cylinder valve outlet that is provided with the cylinder valve. Other types of caps or plugs may result
in leakage of propane.
11. Cylinder must be turned OFF while not in use.
ALWAYS READ AND FOLLOW THESE AND THE CYLINDER MANUFACTURER’S INSTRUCTIONS. FAILURE TO
FOLLOW THESE INSTRUCTIONS AND WARNINGS COULD RESULT IN FIRE, EXPLOSION, BURN
HAZARD OR CARBON MONOXIDE POISONING WHICH COULD CAUSE PROPERTY DAMAGE,
PERSONAL INJURY OR DEATH.
15
CONNECTION INSTRUCTIONS
1. Check that your hose assembly is set to not allow gas flow. Turn the regulator control counterclockwise
until it stops. This is the OFF position.
2. Attach the regulator to the cylinder valve by turning the Type 1 fitting clockwise. Hand tighten with the
regulator positioned upright. Refer to the assembly diagram for the appliance below.
3. Perform the Leak Test:
4. Before lighting the cooker, check that the venturi tube is free of obstruction and that the orifice is properly
threaded into the venturi tube as per instructions on pages 10-11. Both situations must be corrected if
necessary before lighting to prevent flashback.
LEAK TEST
Before lighting the appliance, a thorough leak test must be satisfactorily completed using
a non-ammonia soapy water solution (50% non-ammonia soap and 50% water). This is to be
applied with a small brush to all gas joints after the cylinder valve is opened (no more than
1/2 turn). If bubbles are seen, indicating a leak, turn off the cylinder and tighten the leaking
connection until a further leak test shows no leaks.
If tightening the connection does not stop the leak, call Metal Fusion, Inc. [phone],
for assistance.
NEVER USE HOSE/REGULATOR ASSEMBLY IF LEAKING.
TYPE 1
CONNECTION
* Model May Vary From Picture
20 lb. LP
Gas Cylinder

16
LIGHTING AND OPERATING INSTRUCTIONS
THE COOKER MUST NOT BE LIT UNTIL THE PRECEDING
PLACEMENT INSTRUCTIONS HAVE BEEN COMPLETELY FOLLOWED.
(ILLUSTRATIONS PAGE 17)
1. Check the appliance to make sure it is set up as per the illustration (Figure 1).
2. Make certain that the regulator control is turned to OFF by turning it counterclockwise until it
reaches the stop.
3. Open cylinder control valve by turning it counterclockwise as per the diagram (Figure 2).
4. Turn the regulator control toward the “ON” position. Press and hold down the valve igniter button
to start the flow of gas as per Figure 3. Insert a multi-purpose lighter through the hole in the
shroud as per Figure 4, or use a paperbook match as per Figure 5. Turning the regulator control
clockwise increases the gas pressure to the burner and hence the flame size. See Figure 2.
Continue to press down on the igniter button upon ignition for approximately 10 to 20 seconds
and then release the igniter button. The burner should remain lit. If ignition does not continue
(flame goes out) or fails to ignite, wait 5 minutes then repeat lighting procedure. If burner still
does not remain lit, check connectors and try again. If burner can not be successfully lit call Metal
Fusion, Inc. at [phone] (7:30AM to 3:30PM CST, Mon.-Fri.) for assistance.
5. Check that the flame is blue and that the flames are emitted from every port in the casting. If not,
rotate the air shutter position until there is a blue flame. Opening the shutter too much will cause
the flame to “Lift” off the burner (Figure 6).
If there is a yellow flame, or if some ports have no flame, this indicates there may be an obstruction
in the venturi tube or ports. Check the maintenance instructions on page 19 for more information
regarding a yellow flame.
Lighting and Operation Instructons continued on pg. 17
WARNING
CARBON MONOXIDE HAZARD
Burning charcoal inside can
kill you. It gives off carbon
monoxide, which has no odor.
NEVER burn charcoal inside
homes, vehicles or tents.
IMPORTANT: Read your cooker Instruction Manual before using
this thermometer. The Red Zone is Danger. Never allow tem-
perature of oil to exceed 350ûF. NEVER LEAVE COOKER
UNATTENDED. Failure to follow these instruc-
tions could cause a grease fire / explosion result-

ing in personal injury, death, or property damage.
DEEP FRY THERMOMETER


WARNING
NEVER PUT HANDS OR FACE DIRECTLY OVER BURNER WHILE LIGHTING OR
WHILE THE APPLIANCE IS LIT.
1. Never operate this appliance within 10 feet (3.05m) of any structure, combustible material or
other gas cylinder. Never operate this appliance within 25 feet (7.5m) of any flammable liquids or
vapors.
2. There must be no combustibles or roof overhead.
3. Keep 24” (.61m) of space between the LP gas cylinder and the appliance.
4. The LP gas cylinder and appliance must be located so that any wind is blowing the heat of the appliance away
from the propane cylinder. This also helps fire prevention by blowing the flames of a grease fire away from the
propane cylinder.
5. Center the pot over the burner on the cooker. Only use the pot supplied with your appliance.
PLACEMENT INSTRUCTIONS
* Model may vary from
picture.
20 lb. LP
Gas Cylinder
(3.05m) (3.05m)
(.61m)
WIND DIRECTION
CLEAR
OVERHEAD
10 FEET
GROUND LEVEL
24 INCHES
10 FEET
to
NEAREST
COMBUSTIBLE
(All Directions)
Keep twenty-four inches between the
cylinder and the appliance. Placing the
cylinder too close to the appliance could
result in fire or explosion which could
cause property damage, personal injury
or death.
The hose connecting the appliance to the
tank poses a trip hazard. Do not step over
the hose or walk between the cylinder and
appliance. Tripping could cause the appli-
ance or cylinder to tip over, leading to fire
or explosion which could cause
property damage, personal injury or
death.

17
WARNING
CARBON MONOXIDE HAZARD
Burning charcoal inside can
kill you. It gives off carbon
monoxide, which has no odor.
NEVER burn charcoal inside
homes, vehicles or tents.
IMPORTANT: Read your cooker Instruction Manual before using
this thermometer. The Red Zone is Danger. Never allow tem-
perature of oil to exceed 350ûF. NEVER LEAVE COOKER
UNATTENDED. Failure to follow these instruc-
tions could cause a grease fire / explosion result-

ing in personal injury, death, or property damage.
DEEP FRY THERMOMETER


WARNING
NEVER PUT HANDS OR FACE DIRECTLY OVER BURNER WHILE LIGHTING OR
WHILE THE APPLIANCE IS LIT.
6. The gas shut-off system is NOT a replacement for proper monitoring and will not control the temperature of
the cooking liquid within the pot.. Your cooker must always be attended while in use and monitored after
use while still hot [100 ° F (38 ° C)]. The oil in the pot can overheat quickly if left unattended. The
thermometer supplied with this appliance must always be used to monitor the temperature of the
cooking liquid.
7. When lowering and raising the food product, always wear protective mitts and use extreme caution
not to splash hot oil. Make sure the burner is off before lifting the rack or basket to drain.
(Figure 1) Turn Cylinder Handle
toward ON
(Counterclockwise)
Next
Turn Regulator Control
toward ON
(Clockwise)
Figure 2
ADJUSTABLE REGULATOR
20LB. LP
GAS
CYLINDER
(Figure 3) IGNITER BUTTON
MULTIPURPOSE LIGHTER PAPER BOOK MATCH
(Figure 4) (Figure 5)
(Figure 6)
Casting
PROPER FLAME EMISSION
* Model may vary from
picture.

OVERHEAT PROTECTION
In the event the oil in your pot is overheated, the gas shut-off system will stop the flow of gas to the
burner and will extinguish the flame.
CAUTION: THE APPLIANCE, POT (INCLUDING HANDLES),COOKING LIQUID AND GAS SHUT-OFF
COMPONENTS WILL BECOME HOT DURING THE COOKING PROCESS AND MUST BE ALLOWED
TO COOL BEFORE ATTEMPTING TO RE-LIGHT.
Allow the temperature to drop to at least 350°
F (177 ° C) before re-lighting. If you re-light the burner
immediately after the system shuts down, the burner will not stay lit when the igniter button is released.
If you were monitoring the temperature of the cooking liquid with your deep fry thermometer and your
thermometer reading was below
350° F (177 ° C) and the gas shut-off system extinguished the flame, please
review “THERMOMETER INSTRUCTIONS AND SAFETY PRECAUTIONS FOR DEEP FRYING WITH
OUTDOOR COOKERS” on page 14 and check that the thermometer is operating properly.
FLAME OUT PROTECTION
In the event that wind or low pressure were to cause the flame to blow out, the gas shut-off system
will stop gas flow. If this occurs, re-light the outdoor cooker per normal lighting instructions.
TURNING OFF AND STORING THE COOKER AFTER USE
1. After each use turn OFF the King Kooker®at the regulator first, then at the gas cylinder valve. Depress
igniter button on thermoelectric valve to relieve pressure in the gas train assembly. Check to make sure
there is no flame and all valves are off. Do not leave the cooker until it has cooled completely. When
removing food from the cooker wear protective mitts.
2. Prior to removing the pot from the stand, unplug connectors attaching the wire assembly of the pot
to the burner assembly. No other components of the gas shut-off system should be disconnected or
removed for storage or transport.
WHEN REMOVING THE POT FROM THE COOKER STAND, IF CONNECTORS ARE
NOT DISCONNECTED, THE POT OR STAND COULD TIP RESULTING IN FIRE,
EXPLOSION OR BURN HAZARD WHICH COULD CAUSE PROPERTY DAMAGE,
PERSONAL INJURY OR DEATH.
3. Disconnect the regulator from the cylinder by turning the Type 1 fitting counterclockwise until the
regulator is separated from the tank.
4. Storage of this cooker indoors is permissable only if the cylinder is disconnected and removed from the
cooker. Do not use or store cylinder in a building, garage or enclosed area. Read and follow all cylinder
manufacturer’s instructions. The cylinder must be stored out of the reach of children at all times. Keep
entire unit in area to avoid insects and contamination that can clog the venturi tube.
5. Use caution when handling cooker. Avoid abuse to thermoelectric valve and thermocouple (copper
wire). When in storage use care not to place anything on top of or against thermoelectric valve and
thermocouple.
18
WARNING
CARBON MONOXIDE HAZARD
Burning charcoal inside can
kill you. It gives off carbon
monoxide, which has no odor.
NEVER burn charcoal inside
homes, vehicles or tents.
IMPORTANT: Read your cooker Instruction Manual before using
this thermometer. The Red Zone is Danger. Never allow tem-
perature of oil to exceed 350ûF. NEVER LEAVE COOKER
UNATTENDED. Failure to follow these instruc-
tions could cause a grease fire / explosion result-

ing in personal injury, death, or property damage.
DEEP FRY THERMOMETER


WARNING
WARNING
CARBON MONOXIDE HAZARD
Burning charcoal inside can
kill you. It gives off carbon
monoxide, which has no odor.
NEVER burn charcoal inside
homes, vehicles or tents.
IMPORTANT: Read your cooker Instruction Manual before using
this thermometer. The Red Zone is Danger. Never allow tem-
perature of oil to exceed 350ûF. NEVER LEAVE COOKER
UNATTENDED. Failure to follow these instruc-
tions could cause a grease fire / explosion result-

ing in personal injury, death, or property damage.
DEEP FRY THERMOMETER


WARNING
NEVER MOVE THE COOKER OR POT WHILE IN USE OR STILL HOT [ABOVE 100°F (38°C)].
FAILURE TO FOLLOW THESE INSTRUCTIONS AND WARNINGS COULD
RESULT IN FIRE, EXPLOSION, BURN HAZARD OR CARBON MONOXIDE
POISONING WHICH COULD CAUSE PROPERTY DAMAGE,
PERSONAL INJURY OR DEATH.

MAINTENANCE OF OUTDOOR COOKERS AND ACCESSORIES
1. The area where the cooker will be used must be kept clear and free from combustible materials,
gasoline and other flammable vapors and liquids. Before each use of the cooker inspect and remove any
combustible items.
2. The flow of combustion and ventilation of air must not be obstructed. The cooker must be set in an open
area with 10 ft. (3.05m) of space on all sides and no roof or overhang overhead. Check the location and
placement of the cooker before each use.
3. Before each use of the appliance check the burner/venturi tube for insects, insect nests, and other
obstructions. A clogged tube can lead to a fire beneath the appliance.
4. Follow all Lighting Instructions in the Use and Care Manual each time the cooker is used. Check the flame
for proper color and appearance. The flame should burn with a primarily blue color. If a strong yellow
flame is present, this could indicate an obstruction in the burner/venturi tube.
If there is any obstruction or a yellow flame, and the air shutter adjustment has not solved the problem,
turn off the cooker and allow time for it to cool. Detach thermocouple nut from the bottom of the
thermoelectric valve. Detach thermoelectric valve from the venturi tube of the burner using an adjustable
wrench. Remove the air shutter using a phillips head screwdriver. Check the venturi tube with a flashlight
to see if there is a blockage. If a blockage is present use a wire such as a coat hanger to slide into the
venturi tube to remove the blockage. Reattach the air shutter to the venturi tube using the phillips head
screwdriver. Reattach thermoelectric valve to casting using an adjustable wrench. Reattach thermocouple
nut to the bottom of the thermoelectric valve. Light the cooker per the instructions in this manual. If this
does not resolve the problem, please call Metal Fusion, Inc. at [phone].
5. Always use the gas shut-off system supplied with the appliance. Before each use of the appliance
check the LP hose for evidence of abrasion, wear, cuts or leaks. If there is any damage to the hose,
the hose/regulator assembly must be replaced prior to using the appliance. Contact Metal Fusion, Inc.
at [phone] for information regarding a replacement hose assembly. Only the LP hose/regulator
assembly specified by Metal Fusion, Inc. as part of the burner/gas train assembly should be used with
the appliance. Visually inspect all components of the burner/gas train assembly (see Figure 1, page 10)
and the pot’s wire assembly for any visible damage. Check the connectors for debris or contamination
prior to reattachment.
6. For purchase of any replacement parts which may have become damaged or lost, please contact Metal
Fusion, Inc. at [phone] between the hours of 7:30am-3:30pm (CST) Monday through Friday.
7. Avoid abuse to the product in transport and storage. Do not pull on wires or handle pot with wires. Do
not hit or pull on valve or thermocouple. Do not sit anything on valve or thermocouple. Avoid dropping
stand or pot. Do not pull unit using regulator/hose. Secure regulator to stand using wire hook when not
in use.
8. Cleaning of the appliance:
Cooker Stand and Burner/Gas Train Assembly: If neccessary, remove any oil or liquid which has
spilled onto the unit during cooking with mild soapy water on a rag and towel dry. Do not
immerse the burner/gas train assembly components into water as this will cause rust. Do not clean
stand or components with chemical cleaner. Do not attempt to remove or disassemble gas shut-off
components from unit.
Thermometer: Clean after each use with mild soapy water and towel dry. Do not submerge in liquid or
put in dishwasher.
Pots: Clean after each use according to the directions on page 20.
19
