Cablesson HDelity User manual
User manual
V1.0ep
Cablesson HDelity
1x2 HDMI splitter with 4K2K
(Adv EDID)
© All rights reserved - CABLESSON© All rights reserved - CABLESSON
Thank you for purchasing our product, we hope you will find
it to your complete satisfaction. We at Cablesson take pride in every
product we design and create, and will ensure you receive the very
best care for your merchandise.
The Cablesson brand’s greatest claim to fame is our consistent
ability to deliver premium quality products on par with the best known
international brands with unmatched speed and service. Cablesson is
a specialist technology distributor, supplying advanced High Definition
connectivity and distribution solutions exclusively to the custom
installer-integrator market and the end Consumers. All our products are
produced in IS09001 and IS014001 facilities and maintain the highest
standards for production and work environment. The Cablesson
products we sell are all RoHS compliant, reducing their environmental
impact.
If, for any reason, you find that this product does not meet
your requirements, please do get in touch with us and we will be
glad to be of assistance. Our dedicated customer support ocers
website: http://www.cablesson.com
“we hope you enjoy your purchase and
thank you for your custom”.
PAGE 02PAGE 01
TABLE OF CONTENTS I REVISIONS
Topic page
I Revisions ........................................................................................ 2
II Package contents........................................................................ 3
III Introduction ................................................................................ 3
IV Features ....................................................................................... 4
Tech specs ............................................................................. 5
Supported Input Video Formats ........................................ 6
V Operation Controls and Functions.......................................... 7
Front Panel............................................................................. 7
Rear Panel .............................................................................. 7
VI Connection Diagram................................................................ 8
VII EDID Management .................................................................... 9
VIII Safety Precautions................................................................. 10
IX Technical Support and Warranty......................................... 11
FAQ............................................................................................. 12
VERSION NO.
DATEDD/MM/YY
SUMMARY OF CHANGES
RDV1 15/02/2017 First Revision
PAGE 04PAGE 03
IV FEATURES
II PACKAGE
III INTRODUCTION
1. 1x2 HDelity UHD Splitter
2. Cablesson 5V power supply
3. Our perfection
1. Compliant with HDMI 2.0 /2.1, HDCP 2.2 and DVI 1.0;
2. Support video format up to 4k2k@60Hz with 24bit RGB/YcbCR 4:4:4/
YCBCR 4:2:2,and up to 4k/2k@120/60Hz with 12bit YCBCR 4:4:4;
3. Support 3D frame sequential video format up to 2160p@30;
1. Supports HDR, UHD, HDMI Deep Colour & 3D
2. HDMI 2.1 and HDCP 2.2 compliant
3. Video bandwidth: 18Gbps and beyond
4. Resolution up to 8K
5. Supports xvYCC, x.v.Colour & Deep Colour
6. Supports Dolby Digital, DTS-HD and Dolby True-HD audio
7. Easy “plug & play” installation
640x480@60/72/75/85 √ √
720x400@85 √ √
800x600@56/60/72/75/85 √ √
1024x768@60/70/75/85 √ √
1152x864@75 √ √
1280x720@60 √ √
1280x768@60/75/85 √ √
1280x800@60 √ √
1280x800@60 √ √
1280x960@60 √ √
1280x1024@60 √ √
1360x768@60 √ √
1366x768@60 √ √
1400x1050@60 √ √
1400x900@60 √ √
1600x900@60 √ √
1600x1200@60 √ √
1680x1050@60 √ √
1920x1080@60 √ √
1920x1200@60 √ √
1920x1440@60 √ √
2560x1600@60 √ √
1440x5761@60 √ √
1440x480p@59.94/60 √ √
720x480p@59.94/60 √ √
720x576@50 √ √
1280x720p@50/59.94/60 √ √
1920x1080i@50/59.94/60 √ √
[email protected]/24/25/29.97/30/50/59.94/60
v v
3840x2160@24/25/30/50/60 √ √
4096x2160@24/25/30/50/60 √ √
PAGE 06PAGE 05
TECHNICAL SPECIFICATIONS SUPPORTED INPUT VIDEO FORMATS
Video Bandwidth 600MHz/18Gbps
Input Ports 1 × HDMI (Female type)
Output Ports 2 × HDMI (Female type)
Output Resolution 480i ~1080p @120/60,
4Kx2K@24/30/60
ESD Protection
Human Body model:
±8 kV (air-gap discharge)
±4 kV (contact discharge)
Power Supply 5V/1A DC (US/EU standards, CE/
FCC/UL certified)
Dimensions 56 mm (W) × 100 mm (D) × 16 mm
(H)
Weight 165 g
Chassis Material Metal
Operating Temperature 0 °C~40 °C/ 32 °F~104 °F
Storage Temperature −20 °C ~ 60 °C/−4 °F ~140 °F
Relative Humidity 20~90 % RH (non-condensing)
Power Consumption (Max) 5W
Resolution Input Output
PAGE 08PAGE 07
VOPERATION CONTROLS AND FUNCTIONS VI CONNECTION DIAGRAM
Front Panel
Rear Panel
DC 5V
OUTPUT 1INPUT
OUTPUT 2
INPUTOUTPUT 1 OUTPUT 2
5
1 2 3 4
8
76 9
STD TV
|
EDID
DC 5V
OUTPUT 1INPUT
OUTPUT 2
INPUTOUTPUT 1 OUTPUT 2
5
1 2 3 4
8
76 9
STD TV
|
EDID
1) Power indicator
2) Output 1 connection indicator
3) Input signal indicator
4) Output 2 connection indicator
5) EDID interface
6) HDMI Output port 2
7) HDMI input port
8) HDMI Output port 1
9) Power Supply
PAGE 10PAGE 09
VII EDID MANAGEMENT VIII SAFETY PRECAUTIONS
You could switch between Standard (STD) and TV mode
STD mode - The unit will search for the common resolution supported by
all outputs (TVs / screens/ projectors).
TV mode - When this is switched on the unit will automatically detect and
replicate the sink EDID data of output 1 to the rest.
Before utilizing the product, the user should determine the suitability
of the product for its intended use. Cablesson expressly disclaim the
implied warranties and conditions of merchantability and fitness for a
particular purpose. In no case shall Cablesson be liable under any legal
theory, including but not limited to contract or strict liability, for any direct,
special, incidental or consequential damages resulting from product use.
PAGE 12PAGE 11
IX TECHNICAL SUPPORT AND WARRANTY X FAQ
For UK customers: If your product does not work properly because
of a defect in materials or workmanship, Cablesson (referred to as “the
warrantor’’) will, for the length of the period indicated as below, (One
Year) which starts with the dale of original purchase (“Limited Warranty
period”), at its option either (a) repair your product with new or refurbished
parts, or (b) replace it with a new or a refurbished product. The decision to
repair or replace will be made by the warrantor.
For customers within the EU but outside the UK, the length of the
warranty period would be taken as Two Years, starting from the dale of
original purchase.
This Limited Warranty is extended only to the original purchaser and
only covers product purchased as new. A purchase receipt or other proof
of original purchase date is required for Limited Warranty service.
This Limited Warranty only covers failures due to defects in materials
or workmanship, and does not cover normal wear and tear or cosmetic
damage. The Limited Warranty also does not cover damages or failures
which are caused by products not supplied by the warrantor, or failures
which result from accidents, misuse, abuse, neglect, mishandling,
misapplication, alteration, faulty installation, set-up adjustments,
maladjustment of consumer controls, improper maintenance, power line
surge, lightning damage, modification, or service by anyone other than
a Factory Service Centre or other Authorised Service, or damage that is
attributable to acts of God. No responsibility can be accepted for damage
caused to connected devices as a result of the use of the system.
There are no express warranties except as listed under “limited
warranty coverage”. The warrantor is not liable for incidental or
consequential damages resulting from the use of this product, or arising
out of any breach of this warranty. (As examples, this excludes damages
for lost time, cost of having someone remove or re-install an installed unit
if applicable, travel to and from the service location, loss of or damage to
media or images, data or other recorded content. The items listed are not
exclusive, but are for illustration only.
http://www.cablesson.co.uk/pages/faqs
