Cabletron Systems DELST-UI Programming manual

DIGITAL
WAN Modular Interface ST
DELST-UI
Local Management Guide

DIGITAL
WAN Modular Interface ST
DELST-UI
Local Management Guide
Part Number: 9032645
November 1998
This manual describes the DELST-UI module and provides information
concerning installation, troubleshooting, and the use of Local Management.
Revision/Update Information: This is a new document.

Cabletron Systems reserves the right to make changes in specifications and other information
contained in this document without prior notice. The reader should in all cases consult Cabletron
Systems to determine whether any such changes have been made.
The hardware, firmware, or software described in this manual is subject to change without notice.
IN NO EVENT SHALL CABLETRON SYSTEMS BE LIABLE FOR ANY INCIDENTAL,
INDIRECT, SPECIAL, OR CONSEQUENTIAL DAMAGES WHATSOEVER (INCLUDING BUT
NOT LIMITED TO LOST PROFITS) ARISING OUT OF OR RELATED TO THIS MANUAL OR
THE INFORMATION CONTAINED IN IT, EVEN IF CABLETRON SYSTEMS HAS BEEN
ADVISED OF, KNOWN, OR SHOULD HAVE KNOWN, THE POSSIBILITY OF SUCH
DAMAGES.
Copyright 1998 by Cabletron Systems, Inc., P.O. Box 5005, Rochester, NH 03866-5005
All Rights Reserved
Printed in the United States of America
QuickSET and Cabletron Systems are registered trademarks of Cabletron Systems, Inc.
DIGITAL and the DIGITAL logo are trademarks of Digital Equipment Corporation.
All other product names mentioned in this manual may be trademarks or registered trademarks of
their respective companies.
UNITED STATES GOVERNMENT RESTRICTED RIGHTS
The enclosed product (a) was developed solely at private expense; (b) contains “restricted computer
software” submitted with restricted rights in accordance with Section 52227-19 (a) through (d) of the
Commercial Computer Software - Restricted Rights Clause and its successors, and (c) in all respects
is proprietary data belonging to Cabletron and/or its suppliers.
For Department of Defense units, the product is licensed with “Restricted Rights” as defined in the
DoD Supplement to the Federal Acquisition Regulations, Section 52.227-7013 (c) (1) (ii) and its
successors, and use, duplication, disclosure by the Government is subject to restrictions as set forth in
subparagraph (c) (1) (ii) of the Rights in Technical Data and Computer Software clause at
252.227-7013. Cabletron Systems, Inc., 35 Industrial Way, Rochester, New Hampshire 03867-0505.

FCC Notice — Class A Computing Device:
This equipment generates, uses, and may emit radio frequency energy. The equipment has been type
tested and found to comply with the limits for a Class A digital device pursuant to Part 15 of FCC
rules, which are designed to provide reasonable protection against such radio frequency interference.
Operation of this equipment in a residential area may cause interference in which case the user at his
own expense will be required to take whatever measures may be required to correct the interference.
Any modifications to this device- unless expressly approved by the manufacturer - can void the user's
authority to operate this equipment under part 15 of the FCC rules.
DOC Notice — Class A Computing Device:
This digital apparatus does not exceed the Class A limits for radio noise emissions from digital
apparatus set out in the Radio Interference Regulations of the Canadian Department of
Communications.
Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites applicables
aux appareils numériques de la class A prescrites dans le Règlement sur le brouillage radioélectrique
édicté par le ministère des Communications du Canada.
VCCI Notice — Class A Computing Device:
Taiwanese Notice — Class A Computing Device:
CE Notice — Class A Computing Device:
Warning!
This is a Class A product. In a domestic environment, this product may cause radio interference, in
which case the user may be required to take adequate measures.
Achtung!
Dieses ist ein Gerät der Funkstörgrenzwertklasse A. In Wohnbereichen können bei Betrieb dieses
Gerätes Rundfunkstörungen auftreten, in welchen Fällen der Benutzer für entsprechende
Gegenmaßnahmen verantwortlich ist.
Avertissement!
Cet appareil est un appareil de Classe A. Dans un environnement résidentiel cet appareil peut
provoquer des brouillages radioélectriques. Dans ce cas, il peut être demandé à l'utilisateur de prendre
les mesures appropriées.

CABLETRON SYSTEMS, INC. PROGRAM LICENSE AGREEMENT
IMPORTANT: Before utilizing this product, carefully read this License Agreement.
This document is an agreement between you, the end user, and Cabletron Systems, Inc. (“Cabletron”)
that sets forth your rights and obligations with respect to the Cabletron software program (the
“Program”) contained in this package. The Program may be contained in firmware, chips or other
media. BY UTILIZING THE ENCLOSED PRODUCT, YOU ARE AGREEING TO BECOME
BOUND BY THE TERMS OF THIS AGREEMENT, WHICH INCLUDES THE LICENSE AND
THE LIMITATION OF WARRANTY AND DISCLAIMER OF LIABILITY. IF YOU DO NOT
AGREE TO THE TERMS OF THIS AGREEMENT, PROMPTLY RETURN THE UNUSED
PRODUCT TO THE PLACE OF PURCHASE FOR A FULL REFUND.
CABLETRON SOFTWARE PROGRAM LICENSE
1. LICENSE. You have the right to use only the one (1) copy of the Program provided in this
package subject to the terms and conditions of this License Agreement.
You may not copy, reproduce or transmit any part of the Program except as permitted by the
Copyright Act of the United States or as authorized in writing by Cabletron.
2. OTHER RESTRICTIONS. You may not reverse engineer, decompile, or disassemble the
Program.
3. APPLICABLE LAW. ThisLicense Agreement shall be interpreted and governed under the laws
and in the state and federal courts of New Hampshire. You accept the personal jurisdiction and
venue of the New Hampshire courts.
EXCLUSION OF WARRANTY AND DISCLAIMER OF LIABILITY
1. EXCLUSION OF WARRANTY. Except as may be specifically provided by Cabletron in
writing, Cabletronmakesno warranty,expressed or implied, concerning the Program (including
its documentation and media).
CABLETRON DISCLAIMS ALL WARRANTIES, OTHER THAN THOSE SUPPLIED TO
YOU BY CABLETRON IN WRITING, EITHER EXPRESSED OR IMPLIED, INCLUDING
BUT NOT LIMITED TO IMPLIED WARRANTIES OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE, WITH RESPECT TO THE PROGRAM, THE
ACCOMPANYING WRITTEN MATERIALS, AND ANY ACCOMPANYING HARDWARE.
2. NO LIABILITY FOR CONSEQUENTIAL DAMAGES. IN NO EVENT SHALL
CABLETRON OR ITS SUPPLIERS BE LIABLE FOR ANY DAMAGES WHATSOEVER
(INCLUDING, WITHOUT LIMITATION, DAMAGES FOR LOSS OF BUSINESS,
PROFITS, BUSINESS INTERRUPTION, LOSS OF BUSINESS INFORMATION, SPECIAL,
INCIDENTAL, CONSEQUENTIAL, OR RELIANCE DAMAGES, OR OTHER LOSS)
ARISING OUT OF THE USE OR INABILITY TO USE THIS CABLETRON PRODUCT,
EVEN IF CABLETRON HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH
DAMAGES. BECAUSE SOME STATES DO NOT ALLOW THE EXCLUSION OR
LIMITATION OF LIABILITY FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES, OR
ON THE DURATION OR LIMITATION OF IMPLIED WARRANTIES, IN SOME
INSTANCES THE ABOVE LIMITATIONS AND EXCLUSIONS MAY NOT APPLY TO
YOU.

DECLARATION OF CONFORMITY
Application of Council Directive(s): 89/336/EEC
73/23/EEC
Manufacturer’s Name: Cabletron Systems, Inc.
Manufacturer’s Address: 35 Industrial Way
PO Box 5005
Rochester, NH 03867
European Representative Name: Mr. J. Solari
European Representative Address: Cabletron Systems Limited
Nexus House, Newbury Business Park
London Road, Newbury
Berkshire RG13 2PZ, England
Conformance to Directive(s)/Product Standards: EC Directive 89/336/EEC
EC Directive 73/23/EEC
EN 55022
EN 50082-1
EN 60950
Equipment Type/Environment: Networking Equipment, for use in a
Commercial or Light Industrial
Environment.
We the undersigned, hereby declare, under our sole responsibility, that the equipment packaged
with this notice conforms to the above directives.
Manufacturer Legal Representative in Europe
Mr. Ronald Fotino Mr. J. Solari
___________________________________ ___________________________________
Full Name Full Name
Principal Compliance Engineer Managing Director - E.M.E.A.
___________________________________ ___________________________________
Title Title
Rochester, NH, USA Newbury, Berkshire, England
___________________________________ ___________________________________
Location Location

DELST-UI Local Management Guide vii
CONTENTS
PREFACE
Using This Manual................................................................................... ix
Structure of This Guide ............................................................................ x
Related Manuals ......................................................................................x
Document Conventions........................................................................... xi
Correspondence......................................................................................xii
Documentation Comments............................................................xii
World Wide Web............................................................................xii
Getting Help............................................................................................xii
SAFETY
Overview ................................................................................................xiii
Safety Requirements..............................................................................xiv
CHAPTER 1 INTRODUCTION
1.1 DELST-UI Features.....................................................................1-1
1.1.1 Performance ...................................................................1-2
1.2 ISDN............................................................................................1-2
1.3 ISDN Call Back-up.......................................................................1-2
1.3.1 Call Back-up Topology....................................................1-3
1.4 WAN Protocols............................................................................1-3
1.5 MIB Support.................................................................................1-4
CHAPTER 2 SETUP AND INSTALLATION
2.1 Installing the DELST-UI into a Host.............................................2-1
2.2 Jumper Settings...........................................................................2-1
2.3 Software Setup............................................................................2-3
2.4 ISDN Connection to the DELST-UI .............................................2-3
CHAPTER 3 LOCAL MANAGEMENT
3.1 Local Management Screen Overviews........................................3-2
3.1.1 The WAN Physical Configuration Screen.......................3-2
3.1.2 Remote Profiles Setup....................................................3-4
3.1.3 Bandwidth on Demand (MLP) Configuration ..................3-7
3.1.4 The WAN Interface Configuration Screen.....................3-10
3.2 Call Back-up Configuration........................................................3-13
3.2.1 Select the Protocol........................................................3-14

Contents
viii DELST-UI Local Management Guide
3.2.2 Enable Compression Control Protocol (CCP)...............3-16
3.2.3 Configure Backup..........................................................3-17
3.2.4 Set Idle Timeouts ..........................................................3-19
3.2.5 Configure the D Channel...............................................3-19
3.2.6 Set Phone Numbers and SPIDs for the Port.................3-19
3.2.7 Set Maximum Number of Neighbor/Remote Profiles ....3-21
3.2.8 Reset.............................................................................3-21
3.2.9 Configure the Profiles....................................................3-21
3.2.10 Verify Status..................................................................3-22
3.2.11 Configure Primary Lines and Routing ...........................3-22
APPENDIX A SPECIFICATIONS
Physical Properties .............................................................................. A-1
Environmental Requirements .............................................................. A-1
Regulatory Compliance ....................................................................... A-1
DELST-UI Interface Cable Pinouts...................................................... A-2
DELST-UI Wan Leds ........................................................................... A-2
APPENDIX B FCC PART 68 - USER’S INFORMATION
APPENDIX C WAN TERMS AND ACRONYMS

DELST-UI Local Management Guide ix
PREFACE
Welcome to the DELST-UI Local Management Guide. This manual
explains how to manage and set up the DELST-UI.
The DELST-UI resides in and provides connectivity and functionality to
Wide Area Network (WAN) devices such as the DELHW-UA. The
DELST-UI supports ISDN BRI in a back-up, or fail-over capacity. See
Chapter 1 for more detailed information on the DELST-UI capabilities.
USING THIS MANUAL
Reading through this manual completely will familiarize you with its
content and allow you to gain an understanding of the features and
capabilities of the DELST-UI. You should have a general working
knowledge of the following data communications networks and their
physical layer components before using the DELST-UI:
•WAN
•Ethernet and IEEE 802.3
In this document, the DELST-UI is also referred to as a WPIM
(WAN Physical Interface Module).
The device or module in which the DELST-UI is to be installed
may be referred to as the host platform in this document.

Preface
x DELST-UI Local Management Guide
STRUCTURE OF THIS GUIDE
The following list briefly explains each chapter of the DELST-UI manual:
Chapter 1, Introduction, describes DELST-UIfeatures, performance, and
the protocols that the DELST-UI supports.
Chapter 2, Setup and Installation, directs the user to appropriate
documentation in order to install the DELST-UI, and describes the jumper
settings and cable setup.
Chapter 3, Local Management, describes how to manage the DELST-UI.
Appendix A, Specifications, provides information on physical properties,
environmental requirements, regulatory compliance, pinouts and LED
definitions.
Appendix B, FCC Part 68 - User’s Information, explains the FCC
Rules for the DELST-UI.
Appendix C, WAN Terms and Acronyms, provides a brief glossary of
some of the terms used in this book, and others used in Wide Area
Networking.
RELATED MANUALS
The following manuals may help the user to set up and manage the
DELST-UI:
DIGITAL WAN Modular Interface DELHW-UA QuickSET Configuration
Guide
DIGITAL WAN Modular Interface DLEHW-UA Local Management
Guide
DIGITAL WAN Modular Interface DELHW-UA User’s Guide
The manuals referenced above can be obtained on the World Wide Web in
Adobe Acrobat Portable Document Format (PDF) at the following site:
http://www.networks.digital.com
The above WAN manuals may be found on the QuickSET CD included
with the devices.

Document Conventions
DELST-UI Local Management Guide xi
DOCUMENT CONVENTIONS
The following conventions are used throughout this document:
Note symbol. Calls the reader’s attention to any item of
information that may be of special importance.
!Caution symbol. Contains information essential to avoid
damage to the equipment.
Electrical Hazard Warning symbol. Warns against an action
that could result in personal injury or death due to an electrical
hazard.
bold type Denotes either a user input or a highlighted screen selection.
RETURN Indicates the RETURN or ENTER key, depends on the keyboard.
ESC Indicates the keyboard Escape key.
SPACE bar Indicates the keyboard space bar key.
BACKSPACE Indicates the keyboard backspace key.
arrow keys Refers to the four keyboard arrow keys.
[-] Indicates the keyboard – key.
DEL Indicates the keyboard delete key.
italic type Emphasizes important information, indicates variables, indicates
complete document titles, and indicates the first use of a term
described in the glossary.
n.nn Signals the decimal point indicator. (e.g., 1.75 equals one and
three fourths, or Decimal Dotted Notation (DDN) for an IP
address.
xIndicates the generic use of a letter. (e.g., xxx indicates any
combination of three alphabetic characters.)
nIndicates the generic use of a number. (e.g., 19nn indicates a
four-digit number in which the last two digits are unknown.)
[] Indicates (in the Local Management screens) that a value may be
entered or selected. In the format descriptions in the Network
Tools section, required arguments are enclosed in [].
<> In the format descriptions in the Network Tools section, denotes
that optional arguments are enclosed in <>.

Preface
xii DELST-UI Local Management Guide
CORRESPONDENCE
Documentation Comments
If you have comments or suggestions about this manual, send them to
DIGITAL Network Products:
World Wide Web
To locate product-specific information, refer to the DIGITAL Network
products Home Page on the World Wide Web at the following locations:
GETTING HELP
Contact your DIGITAL representative for technical support. Before
calling, have the following information ready:
•A description of the failure
•A description of any action(s) already taken to resolve the problem
(e.g., changing mode switches, rebooting the unit, etc.)
•A description of your network environment (layout, cable type, etc.)
•Network load and frame size at the time of trouble (if known)
•The device history (i.e., have you returned the device before, is this a
recurring problem, etc.)
Attn.: Documentation Project Manager
E-MAIL: [e-mail]
North America: http://www.networks.digital.com
Europe: http://www.networks.europe.digital.com
Asia Pacific: http://www.networks.digital.com.au

DELST-UI Local Management Guide xiii
SAFETY
OVERVIEW
Any warning or caution that appears in this manual is defined as follows:
WARNING Warns against an action that could result in
equipment damage, personal injury, or death.
VORSICHT Warnt den Benutzer vor Aktionen, die das
Gerät beschädigen, Personen verletzen oder
sogar zum Tot führen könnten.
DANGER Déconseille à l'utilisateur d'exécuter une action
pouvant entraîner des dommages matériels,
corporels voire même la mort.
AVISO Previene contra una acción que podría dañar
el equipo, provocar daños personales o la
muerte.
CAUTION Contains information essential to avoid
damage to the equipment.
ACHTUNG Liefert wichtige Informationen, um einen
Geräteschaden zu vermeiden.
ATTENTION Informations indispensables permettant
d'éviter les dommages matériels.
PRECAUCIÓN Contiene información esencial para evitar
daños al equipo.
!

Safety
xiv DELST-UI Local Management
SAFETY REQUIREMENTS
The warnings or cautions that must be observed for the hardware
described in this manual are listed below in English, German, French, and
Spanish.
WARNING Only qualified personnel should install or
service this unit.
VORSICHT Diese Einheit darf nur von qualifizierten
Fachleuten installiert oder gewartet werden.
DANGER L’installation et la maintenance de cet appareil
sont réservées à un personnel qualifié.
AVISO Sólo elpersonal cualificado debe instalar o dar
mantenimiento a esta unidad.
CAUTION These products are sensitive to static
discharges. Use an antistatic wrist strap and
observe all static precautions during this
procedure. Failure to do so could result in
damage to this equipment.
ACHTUNG Diese Produkte sind für statische Entladungen
empfindlich. Benutzen Sie deshalb ein
Antistatikarmband, und beachten Sie während
dieses Verfahrens alle Vorsichtsmaßnahmen.
Bei Nichtbeachtung könnte das Gerät
beschädigt werden.
ATTENTION Ces produits sont sensibles à l'électricité
statique. Portez un bracelet anti-statique et
observez les règles de sécurité pendant cette
procédure, sinon vous risqueriez
d'endommager l'appareil.
PRECAUCIÓN Estos productos son sensibles a las descargas
de electricidad estática. Utilice una muñequera
antiestática y observe las normas de
seguridad de manipulaciónde dispositivoscon
electricidad estática durante este
procedimiento. No hacerlo podría resultar en
daños para el módulo.
!

Safety Requirements
DELST-UI Local Management Guide xv
CAUTION If you have not configured the DELST-UI using
software, do not connect any cables. Refer to
the section titled Software Setup before
proceeding.
ACHTUNG Wenn Sie die DELST-UI-Einheit nicht unter
Verwendung von Software konfiguriert haben,
dürfen Sie keine Kabel anschließen. Lesen Sie
die Informationen im Abschnitt zum Einrichten
der Software (Software Setup), bevor Sie mit
diesem Schritt fortfahren.
ATTENTION Si vous n'avez pas configuré le DELST-UI à
l'aide d'un logiciel, ne connectez aucun câble.
Reportez-vous à la section intitulée Software
Setup (Configuration du logiciel) avant toute
opération.
PRECAUCIÓN Si no ha configurado el DELST-UI a través del
software, no conecte ningún cable. Consulte la
sección referente a la instalación y
configuración del software antes de continuar.
!

Safety
xvi DELST-UI Local Management
CAUTION DO NOT plug the ISDN cable into the ISDN
wall jack until after the software setup has
been completed by using either QuickSET or
the management procedure. If the ISDN cable
is plugged in prematurely, before the host unit
is configured, the telephone company may
disable the ISDN line for a period of time. Plug
in the cable as a final step, after you have
configured the DELST-UI.
ACHTUNG Stecken Sie das ISDN-Kabel erst dann in die
SteckdosefürdenISDN-Anschluß, NACHDEM
die Software vollständig entweder mit
QuickSET oder dem Verwaltungsverfahren
eingerichtet wurde. Wenn das ISDN-Kabel vor
der Konfiguration der Host-Einheit
angeschlossen wird, könnte es vorkommen,
daß die Telefongesellschaft die ISDN-Leitung
für einige Zeit sperrt. Das Kabel sollte deshalb
erst im letzten Schritt angeschlossen werden,
nachdem Sie die DELST-UI-Einheit
konfiguriert haben.
ATTENTION NE PAS connecter le câble RNIS (ISDN) à la
prise RNIS murale avant d'avoir terminé la
configuration du logiciel soit à l'aide de
QuickSET, soit par la procédure de gestion. Si
le câble ISDB est connecté trop tôt, avant
d'avoir configuré le système hôte, la
compagnie de téléphone risque de désactiver
la ligne RNIS pendant quelque temps. Ne
connectez le câble qu'après avoir configuré le
DELST-UI.
PRECAUCIÓN NO conecte el cable RDSI a la toma RDSI
mural hasta que se haya completado
totalmente la instalación del software mediante
el uso de QuickSET o el procedimiento de
gestión. Si se conecta prematuramente el
cable RDSI, antes de que se configure la
unidad central, la compañía telefónica puede
desactivar la línea RDSI durante cierto período
de tiempo. Conecte el cable durante el último
paso, tras haber configurado el DELST-UI.
!

DELST-UI Local Management Guide 1-1
CHAPTER 1
INTRODUCTION
This chapter provides information about the features and performance of
the DELST-UI. It also briefly explains Integrated Services Digital
Network (ISDN), call back-up, and the WAN protocols supported by the
DELST-UI.
Note the following requirements for successful operation of this device:
•Install the DELST-UI in a Wide Area Network host platform. Refer to
Chapter 2 for directions on installation procedures. Refer to the
appropriate host platform manual for other installation and
troubleshooting procedures.
•Use the Graphical User Interface QuickSET to fully configure the
DELST-UI. Due to the automation of setup features, QuickSET use is
strongly recommended. However, Chapter 3 contains additional
information on configuring the DELST-UI, which can be done
independently of QuickSET.
1.1 DELST-UI FEATURES
The DELST-UI provides ISDN 128 Kbps Basic Rate Interface (BRI) in a
backup or fail-over capacity for other devices in which the DELST-UI can
be installed. The DELST-UI provides an ISDN back-up link for a remote
site or branch office when the primary connection for a frame relay or
leased line is lost or becomes disabled.
The device or module in which the DELST-UI is to be installed
may be referred to in this document as the host platform.

Chapter 1: Introduction
1-2 DELST-UI Local Management Guide
1.1.1 Performance
The capability of the DELST-UI is 128 Kbps when both B Channels are
active.
There are several user-configurable timers that control the connect and
disconnect time-outs to provide optimum performance. These are detailed
in Chapter 3.
1.2 ISDN
ISDN provides inexpensive switched digital access to remote sites. The
ISDN BRI standard provides for two high-speed 64-Kbps bearer (B)
channels used for voice or data connections and one 16-Kbps signaling
data (D) channel used for call setup, signaling, and other information.
ISDN allows all types of information to be transmitted including voice,
data, fax, and video. Multiple devices can be linked to a single ISDN
connection, each having their own telephone number. Two or more
channels can be combined into a single larger transmission pipe offering
variable transmission speeds.
1.3 ISDN CALL BACK-UP
The ISDN call back-up feature provides a back-up link for a remote site
or branch office when one or more primary WAN interfaces for a frame
relay circuit or a nailed-up PPP connection fails. The DELST-UI serves
as the backup medium for this primary connection, using the ISDN
interfaces to back-up any primary interfaces that have been configured for
ISDN back-up.
The following are two reasons to use ISDN call back-up:
•Hardware failure of a nailed-up PPP connection
•PPP fails to connect (software problem)
Use call back-up if either of the following conditions exist when using
Frame Relay:
•DLCI circuit fails to connect in 12 minutes
•DLCI goes inactive
