Cabletron Systems NB20E User manual

NB20E and NB25 E
TWO PORT ETHERNET BRIDGES
USER’S MANUAL
CABLETRON SYSTEMS, P.O. BOX 6257, ROCHESTER, NH 03867-6257

i
NOTICE
Cabletron Systems reserves the right to make changes in specifications
and other information contained in this document without prior notice.
The reader should in all cases consult Cabletron Systems to determine
whether any such changes have been made.
The hardware, firmware, or software described in this manual is subject to
change without notice.
IN NO EVENT SHALL CABLETRON SYSTEMS BE LIABLE FOR
ANY INCIDENTAL, INDIRECT, SPECIAL, OR CONSEQUENTIAL
DAMAGES WHATSOEVER (INCLUDING BUT NOT LIMITED TO
LOST PROFITS) ARISING OUT OF OR RELATED TO THIS
MANUAL OR THE INFORMATION CONTAINED IN IT, EVEN IF
CABLETRON SYSTEMS HAS BEEN ADVISED OF, KNOWN, OR
SHOULD HAVE KNOWN, THE POSSIBILITY OF SUCH DAMAGES.
© Copyright May 1990 by:
Cabletron Systems Inc.
P.O. Box 6257, E. Rochester, NH 03867-6257
All Rights Reserved
Printed in the United States of America
Order Number: 9030040-02 May 90
Remote LANVIEW , LANVIEW , NB25E , NB20E , and LAN-MD are
trademarks of Cabletron Systems Inc.

FCC NOTICE
ii
FCC NOTICE
This device complies with Part 15 of the FCC rules. Operation is subject
to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
WARNING: This equipment uses and generates and can radiate radio
frequency energy and if not installed properly and used in accordance
with the instruction manual, may cause interference to radio
communications. It has been tested and found to comply with the limits
for a Class A digital device pursuant to Subpart J, of Part 15, of the FCC
rules., which are designed to provide reasonable protection against such
interference in a commercial environment. Operation of this equipment in
a residential area is likely to cause interference in which case the user at
his own expense will be required to correct the interference.
If this equipment does cause interference to radio or television, which can
be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measure:
• Re-orient the receiving antenna.
• Relocate the antenna with respect to the bridge.
• Move the bridge away from the receiver.
• Plug the bridge into a different outlet so that the bridge and the
receiver are on different branch circuits.
If necessary, the user should consult the dealer or an experienced radio/
television technician for additional suggestions. The user may find the
following booklet prepared by the Federal Communication Commission
helpful:
“How to Identify and Resolve Radio TV Interference Problems”
This booklet is available from the U.S. Government Printing Office,
Washington, D.C. 20401- Stock No. 004-000-00345-4

iii
CONTENTS
CHAPTER 1 INTRODUCTION
1.1 USING THIS MANUAL................................................................1-1
1.2 GETTING HELP..........................................................................1-2
1.3 THE NB20E AND NB25E TWO PORT ETHERNET BRIDGE ....1-2
1.4 THE BRIDGE FILTERING METHOD..........................................1-3
1.5 MULTIPLE BRIDGE ENVIRONMENTS......................................1-5
1.5.1 The Root Bridge..............................................................1-5
1.5.2 Primary and Redundant Data Paths...............................1-6
1.6 REMOTE LANVIEW....................................................................1-7
1.7 RELATED MANUALS..................................................................1-8
CHAPTER 2 INSTALLATION REQUIREMENTS/
SPECIFICATIONS
2.1 LOCATION REQUIREMENTS....................................................2-1
2.2 NETWORK REQUIREMENTS....................................................2-1
2.3 OPERATING SPECIFICATIONS ................................................2-2
CHAPTER 3 INSTALLINGTHE NB20E OR NB25E BRIDGE
3.1 UNPACKING THE NB20E OR NB25E BRIDGE.........................3-1
3.2 INSTALLING THE BRIDGE.........................................................3-1
3.2.1 Installing the Rack Mount Brackets ................................3-2
3.2.2 Cable Support Installation...............................................3-3
3.2.3 Connecting The Bridge To The Network ........................3-3
3.2.4 Setting The Mode Switches............................................3-4
3.2.5 Connecting The NB20E or NB25E To
The Power Source.........................................................3-5
CHAPTER 4 TESTING AND LANVIEW
4.1 INSTALLATION CHECK-OUT.....................................................4-1
4.2 USING LANVIEW........................................................................4-2
4.3 USING THE FORWARD BROADCAST SWITCH.......................4-3
4.4 USING THE ROOT SWITCH ......................................................4-4

CONTENTS
iv

1-1
CHAPTER 1
INTRODUCTION
Welcome to the Cabletron Systems NB20E™ and NB25E™ Two Port
Ethernet Bridges User's Manual. We have designed this user’s manual to
serve as a simple installation and reference guide for the NB20E and
NB25E, and to explain the capabilities and special features of each
individual bridge. With the appropriate design, the Cabletron Systems
NB25E or NB20E can dramatically improve network performance and
bandwidth efficiency on heavily utilized network segments.
You should read through this manual to gain a full understanding of the
NB20E and NB25E Bridges and their capabilities.
1.1 USINGTHIS MANUAL
Chapter 1, Introduction , discusses the capabilities of Cabletron Systems'
NB20E or NB25E Two Port Ethernet Bridge. An explanation of the
bridge filtering process and a discussion of bridge functionality in
multi-bridge environments are also included. The chapter concludes with
a list of related manuals.
Chapter 2,
Installation Requirements/Specifications , contains a list of
hardware, software, location and environmental requirements that must be
met before you install either bridge.
Chapter 3,
Installing the NB20E or NB25E Bridge , contains
instructions for installing the NB20E or the NB25E Two Port Ethernet
Bridge.
Chapter 4,
Testing and Troubleshooting , provides procedures for testing
and troubleshooting the installation of the NB20E or the NB25E Bridge.
Instructions for using LANVIEW™, Cabletron Systems’built-in visual
diagnostic and status monitoring system, are also included.
We assume that you have a general working knowledge of Ethernet or
IEEE 802.3 type data communications networks and their physical layer
components.

INTRODUCTION
1-2
1.2 GETTING HELP
If you need additional support related to the Cabletron Systems NB20E or
NB25E Two Port Ethernet Bridge, or if you have any questions,
comments or suggestions related to this manual, feel free to contact
Cabletron Systems' Technical Support at:
Cabletron Systems Inc.
P.O. Box 6257
E. Rochester, NH 03867-6257
Phone: [phone]
1.3 THE NB20E AND NB25ETWO PORT ETHERNET
BRIDGE
With the Cabletron Systems NB20E or NB25E Two Port Ethernet Bridge,
you can dramatically increase the performance of two 10 Mbit per second
Ethernet networks efficiently and economically, regardless of the media
type. The bridges are designed to increase the efficiency of bandwidth use
across a LAN by building a list of local node addresses as it learns which
nodes are located on each side of the bridge. This list is called the Source
Address Table. The bridge uses the Source Address Table to determine
which data packets should be allowed to cross the bridge, keeping local
traffic local.
The NB20E Bridge uses a software filter database to check destination
addresses against its Source Address Table. The NB25E Bridge uses a
higher performance hardware filter database. Both bridges are equipped
with a feature called Aging Time, that continually makes space for new
entries into the Source Address Table by deleting addresses that are not
frequently used.
The NB20E and NB25E are designed to function in multiple-bridge
environment. As IEEE 802.1 compliant bridging units, the bridges
incorporate a Spanning Tree Algorithm to detect potential data loops in
the network. Spanning TreeAlgorithm is a hierarchy (or tree) of priorities
that is established between bridges.
The NB20E and NB25E can be controlled and managed by Cabletron
Systems' Remote LANVIEW™ - Network Control Management for the
Cabletron Systems' NB20E and NB25E. Remote LANVIEW provides the
most complete network management system for Ethernet networks in the
industry today. With Remote LANVIEW, a bridge can be managed

INTRODUCTION
1-3
according to the specific needs of a network manager. The network
manager's ability to set up parameters within Remote LANVIEW ensures
optimal performance for each bridge, and hence, each network. For
example, a network manager can manage and monitor: the flow of traffic
through a bridge, the status of a database, the bridge protocol and port
parameters, and the bridge setup.
Both bridges also incorporate Cabletron Systems' LANVIEW Status
Monitoring and Diagnostics Systems. Should a problem arise,
LANVIEW's LEDs will help you to diagnose problems, such as power
failures or cable faults. Individual or separate LEDs advise you that: the
bridge is on line and operational, the bridge is receiving or transmitting
data packets, or the bridge is detecting a collision signal from an
individual segment.
The NB20E or NB25E Bridge interconnects networks consisting of
Ethernet Version 1, Version 2, and/or IEEE 802.3 equipment. The bridge
has two AUI ports so it can be connected directly to any of Cabletron’s
many Ethernet transceivers for data transmission over various media
including twisted pair, fiber optic, and/or thick or thin Ethernet coaxial
cable.
1.4 THE BRIDGE FILTERING METHOD
The Cabletron Systems NB20E and NB25E prevent unnecessary network
traffic from passing through the bridge, by implementing a filtering
process. This process begins with the creation of a list of local node
addresses in a table referred to as the Source Address Table.
When the NB20E or NB25E first goes on line, the bridge initially
forwards all packets through the bridge.As the bridge receives a packet, it
learns the address of the sending node from the packet and stores that
address in its Source Address Table, indicating the segment on which the
address resides. In this manner, the bridge learns the address of each node
on each side of the bridge and is able to use the addresses stored in the
table to compare the destination address of each subsequent packet that
travels to the bridge. If the destination address of a packet is located on
the same segment (local segment) as the sending node, the packet is not
forwarded across the bridge.
Figure 1-1 provides an illustration of the filtering process.

INTRODUCTION
1-4
Figure 1-1 Bridging Method
In this example, when NodeA sends a packet to Node B, the bridge learns
Node A’s source address and adds the address to the Source Address
Table, indicating that the node is on LAN 1. If Node C subsequently sends
a packet to Node A, Node A’s address will be detected in the Source
Address Table for LAN 1 and the packet will not be forwarded across the
bridge to LAN 2. At the same time, the bridge will learn Node C’s source
address and add it to the SourceAddress Table, indicating that the node is
on LAN 1.
If the destination address of a packet is located on a different segment, the
bridge will forward the packet across the bridge. If Node B sends a packet
to Node A, the bridge will compare the destination address of the packet
against the addresses in the SourceAddress Table. It will then detect Node
A as being on the other side of the bridge and forward the packet through
the bridge to LAN 1. The bridge will store the address of Node B to
indicate that Node B is on LAN 2.
If no packets are sent from a source address in a five minute interval, that
address will be deleted from the bridge’s Source Address Table.
TT
TT
NODE A NODE C
LAN 1
LAN 2
NODE B

INTRODUCTION
1-5
This feature is referred to as Aging Time. Aging Time can be altered
through Cabletron Systems’Remote LANVIEW Network Control
Management for the Cabletron Systems' NB20E and NB25E.
1.5 MULTIPLE BRIDGE ENVIRONMENTS
Both the NB20E and NB25E Two Port Bridges are designed to promote
maximum network use in multiple bridge environments. A bridge learns
the bridge topology of its network from bridge protocol data that is
transmitted onto the network by each bridge. The bridges then apply a
Spanning TreeAlgorithm to select a root bridge and to determine primary
data paths within potential data loop configurations. A Spanning Tree
Algorithm, as defined earlier, is a hierarchy (or tree) of priorities that is
established between bridges. This hierarchy guarantees that primary and
redundant data paths will be clearly defined at all times, so that the
network is available to users at all times.
1.5.1 The Root Bridge
One bridge in the network is established as the root bridge. This bridge
has priority over all other bridges. Each bridge in a Spanning Tree must
learn which bridge is the root and then determine its own relative priority
within the network.
Determining the root bridge begins with the broadcast of Bridge Protocol
Data Units (BPDUs) across the network. When the bridges go on line,
each bridge sends out a BPDU which contains its priority field and its
unique identifier or Ethernet address. Through the broadcast of these
identifiers across the network, the bridges learn which bridge has the
highest priority, or lowest identifier. This bridge becomes the root bridge
for the network. Each bridge then determines its own priority in relation
to this bridge.
The network manager can, however, override this process for determining
the root. Using the root switch, the manager can manually select a
different bridge to be the root by applying a selectable switch at the
appropriate bridge. This bridge transmits BPDUs to inform the other
bridges that it is now the root. With this information, the bridges
immediately learn their new priority in relation to the new root, and the
system of priorities is maintained.

INTRODUCTION
1-6
1.5.2 Primary and Redundant Data Paths
To ensure the integrity of the network, primary data paths through
designated bridges, and redundant data paths through alternative bridges
are determined in each LAN or loop configuration in the network.A LAN
segment’s designated bridge is the bridge in a LAN or loop configuration
with the lowest cost path of transmission from that LAN segment to the
root bridge. The lowest cost path can be translated in a general way to
mean the data transmission path to the root that is most economical.
The bridges in the network send out BPDUs to the other bridges so that
they can all learn which is the bridge in the network, or in a potential loop
configuration, with the lowest cost path to the root. The bridges can then
determine their own priorities and roles as designated or redundant
bridges. Redundant bridges are “blocked” from forwarding packets, but
they continue to receive topology information.
Figure 1-2 provides a sample illustration of how a potential data loop is
prevented in a simple multibridge environment. A data loop exists
Figure 1-2 Multiple Bridging Environments
TT
TT
NODE A
BRIDGE 2
NODE B
TT
BRIDGE 1
BRIDGE 3
NB20E OR 25E
NB20E OR 25E
NB20E OR 25E

INTRODUCTION
1-7
if all three bridges are on line and Node A sends a packet to Node B. The
packet will be forwarded through Bridges 1 and 3, and through Bridge 2,
causing the packet to be circulated many times around the data loop. If
Bridge 1 has priority over Bridge 2, the Spanning Tree Algorithm will
place Bridge 2 in blocking, preventing the packet from being forwarded
through Bridge 2. If Bridge 1 should fail, the Spanning Tree Algorithm
will be modified automatically so that the packet will be forwarded
through Bridge 2.
1.6 REMOTE LANVIEW
Both the NB20E and the NB25E can be controlled and managed by
Cabletron Systems' optional Remote LANVIEW - Network Control
Management for the Cabletron Systems' Bridges. Remote LANVIEW
allows you to control and manage multiple NB20Es or NB25Es from a
single Ethernet Workstation through Cabletron System NCM-DOS™ or
Remote LANVIEW/Windows™ or an individual NB25E through an
RS232 port on the bridge.
Remote LANVIEW provides the necessary management tools so that a
bridge can operate at its full capacity. The network manager's ability to set
up parameters within Remote LANVIEW ensures optimal performance
for each bridge, and, hence, each network. For example, a network
manager can monitor: the flow of traffic through a bridge, the status of a
database, the bridge protocol and port parameters, and the bridge setup.
The number of frames received at the bridge is recorded as well as a
breakdown of the progress through the bridge, for example the frames
discarded inbound or the frames forwarded outbound. A breakdown of
errors is provided so the network manager can pinpoint potential problem
areas in a network.
Bridge protocol and port parameters such as Topology Change,
Designated Root, and Path Cost are provided, so that the network
manager can keep track of bridge activity and cost. Certain parameters
can be altered to accommodate a network's particular requirements.
Remote LANVIEW provides the network manager with the necessary
control to operate a bridge effectively. For instance, a network manager
can alter bridge setup, erase a database, disable or restart a bridge, reset
counters, or restore default settings.

INTRODUCTION
1-8
For further information for refer to the Remote LANVIEW - Network
Control Management for the Cabletron Systems' NB20E and NB25E
User's Manual.
1.7 RELATED MANUALS
The manuals listed below should be used to supplement the procedures
and other technical data provided in this manual. The procedures will be
referenced where appropriate, but will not be repeated.
Cabletron Systems'
Remote LANVIEW - Network Control
Management for the Cabletron Systems' NB20E and NB25E
User’s
Manual.
Cabletron Systems' LAN-MD User’s Manual.

2-1
CHAPTER 2
INSTALLATION REQUIREMENTS/
SPECIFICATIONS
Before you attempt to install Cabletron Systems' NB20E or NB25E Two
Port Ethernet Bridge, review the location and hardware requirements
outlined in this chapter. Also refer to the operating specifications and
environmental requirements that are listed.
All conditions, guidelines, specifications and requirements included in
this chapter must be met to ensure satisfactory performance of the NB20E
or NB25E. Failure to follow these guidelines will result in unsatisfactory
network performance.
2.1 LOCATION REQUIREMENTS
Before installing the NB20E or NB25E Two Port Ethernet Bridge, ensure
that the location for the bridge meets the following requirements:
• The location must have an unrestricted surface area 21 inches (53.34
cm) wide, and must be at least 18 inches (45.72 cm) deep and 6 inches
(15.24 cm) high.
• A standard 3 prong power receptacle must be located within 7 feet
(2.13 m) of the site.
• If a shelving unit is to be used, the unit must be able to support 30
pounds (13.6 kg) of static weight.
• The temperature of the location must be maintained between 5
° and
40
° C. Temperature changes of greater than 10 ° C per hour must not
occur.
2.2 NETWORK REQUIREMENTS
When bridging two segments using an NB20E or NB25E Two Port
Bridge, you must follow the network guidelines listed below:
• The transceivers to which the NB20E or NB25E will be connected
must meet Ethernet Version 1, Version 2, or IEEE 802.3 standards.
• The AUI cables connecting the NB20E or NB25E to the transceivers
on the network must be IEEE 802.3 type cables and must not exceed
50 meters in length.

INSTALLATION REQUIREMENTS/ SPECIFICATIONS
2-2
2.3 OPERATING SPECIFICATIONS
The operating specifications for Cabletron Systems' NB20E or NB25E
Two Port Bridge Series are included in this section. Cabletron Systems
reserves the right to change these specifications at any time without
notice.
GENERAL
Parameter NB20E NB25E
Packet Buffer Memory (RAM): 128K 128K
Internal Processor: 16MHz 16MHz
Intel 80186 Intel 80186
Ethernet Controller: two 8390 two 8390
Ethernet Ethernet
Controllers Controllers
Scratch Ram: 512K 512K
PERFORMANCE
Parameter NB20E NB25E
Packet Filter Rate
(max. viewed per second): 15,000 Packets 28,000 Packets
Packet Forward Rate
(max. viewed per second): 8,000 Packets 11,000 Packets
Forwarding Latency: 125 µ s Min. 91 µ s Min.
Source Address Table Size: 2048 Max. 8191 Max.
Age Time (User Definable): 5 Minutes 5 Minutes
(Default) (Default)

INSTALLATION REQUIREMENTS/ SPECIFICATIONS
2-3
FRONT PANEL INDICATORS
ON LINE When lit, this LED indicates the two port
bridge is on line and operational (green
indicator).
STAND BY When lit, this LED indicates the bridge is not
forwarding packets (yellow indicator).
NOTE: There is one TRANSMIT, RECEIVE, COLLISION, and POK
(Port OK) LED for each segment. The LEDs for RECEIVE, TRANSMIT
and COLLISION are pulsed-stretched for increased viewing effect.
XMT (transmit) When lit, this LED indicates the bridge is
transmitting packets to that segment (green
indictor).
RCV (receive) When lit, this LED indicates that the bridge
is receiving data packets from that segment
(yellow indicator).
CP (collision present) When lit, this LED indicates that a collision
is occurring on that segment (red indicator).
POK (port ok) When lit, this LED indicates transceiver
connected, port has passed Loop Back Test
and is ready for transmission (green
indicator).
FRONT PANEL SWITCHES
FORWARD BROADCAST | / O When this switch is on (|), it allows the
bridge to forward broadcast messages.

INSTALLATION REQUIREMENTS/ SPECIFICATIONS
2-4
FRONT PANEL SWITCHES (cont.)
ROOT | / O When the switch is on ( | ), it designates the
bridge as the root bridge in the network.
AUI PORT (NB20E/NB25E)
Interface Connector
Type: 15 position D type receptacle.
Pin 1 Logic Ref. Pin 9 Collision -
2 Collision + 10 Transmit -
3 Transmit + 11 Logic Ref.
4 Logic Ref. 12 Receive -
5 Receive + 13 Power (+12 Vdc)
6 Power return 14 Logic Ref.
7 No Connection 15 No Connection
8 Logic Ref
Connector Shell: Protective Ground
RS232 PORT
Type: Standard 9 pin RS232 Port
Pin 1 DCD Pin 6 NU
2 TX 7 TRS
3 RX 8 CTS
4 DTR 9 RX Clock
5 Signal Ground

INSTALLATION REQUIREMENTS/ SPECIFICATIONS
2-5
POWER SUPPLY REQUIREMENTS
Parameter Typical Worst
Value Case
120V Input Voltage: 120 V 90 to 130 V
Input Current
NB20E: 0.5 Amps 1.0 Amps
NB25E: 0.75 Amps 1.5 Amps
Frequency Range: 47 - 63 Hz
220V Input Voltage: 220 V 180 to 264 V
Input Current
NB20E: 0.25 Amps 0.5 Amps
NB25E: 0.375 Amps 0.75 Amps
Frequency Range: 47 - 63 Hz
Overload Protection
Input: (2) 3AG 3 amp fuses in series with both primary
inputs.
Output: (2) 3AG 1 amp fuse for each AUI port.
ENVIRONMENTAL REQUIREMENTS
Operating Temperature: +5 ° to +40 ° C
Non-operating Temperature: -30
° to +90 ° C
Operating Humidity: 5 to 95% (non-condensing)

INSTALLATION REQUIREMENTS/ SPECIFICATIONS
2-6
SAFETY
Designed in accordance with UL478, UL910, NEC 725-2(b), CSA, IEC,
TUV, VDE class A. Meets FCC part 15, Subparagraph J, Class A limits.
WARNING : It is the responsibility of the person who sells the system of
which the NB20E or NB25E will be a part to ensure that the total system
meets allowed limits of conducted and radiated emissions.
SERVICE
MTBF (MHBK - 20E):
NB20E: > 35,750 hrs. projected.
NB25E: > 26,533 hrs. projected.
MTTR: < 0.5 hrs.
PHYSICAL PROPERTIES
Dimensions: 3.2H x 17.0W x 12.4D inches
(8.13 x 38.1 x 31.5 cm)
Weight
Unit: 7 lbs. (3.17 kg.)
Shipping: 8 lbs. (3.63 kg.)
