CAD ZOE User manual

Operation:
2. If Zoe is not working after connecting ( LED is
constantly on ), click Control Panel > Sounds and Audio
Devices Properties > Audio. Choose C-Media USB Sound
Device for Default device under Sound recording.
Choose C-Media USB sound device under playback if you want
to use the headphone jack instead of your speakers.
Click on apply and OK.
Polar Pattern & Frequency ResponseAccessories:
USB cable:
Ø3.8x1.2M USB 2.0 USBA Type
to Mini B type plug
Tripod Stand
Thank you for purchasing the CAD Audio Zoe USB
microphone. Please read the manual carefully
before using and keep it for further reference.
Headphone volume UP
Power on/Microphone mute button
a.LED illuminates Blue to indicate power “on”
b.LED illuminates Red to indicate microphone “mute”
Headphone volume DOWN
Headphone output jack
USB PORT
1
2
3
4
5
1. Connect Zoe to your device with the supplied USB cable,
connection is completed whenthe Blue LED is lit.
Installation:
1
2
3
4
5
CAD Zoe
Zoe
Zoe
Zoe
Specs :
Operating Principle : Condenser USB with
TrakMix™ Headphone Output
Pattern : Unidirectional
Microphone Frequency Response : 50 – 16kHz
Sampling and bit rate : 48kHz 16 bit
Headphone Frequency Response : 20 – 20kHz
Headphone Output : 300mW
Compatibility : Windows and Mac
• Aggressive audio reproduction with finesse and flair
• TrakMix™ chip delivers precision headphone monitoring
• Supplied with Stand and USB cable
Features:
Assembly:
Simply screw Zoe onto the desk stand as shown,
Fold out the legs of the tripod stand and plug the
USB cable in.
Zoe uses a standard 5/8-27 thread so it can be used
on many other stands as well.
For Returns or Service visit CadAudio.com and click the Support tab.
CAD Audio
6573 Cochran Rd
Solon, Ohio 44139
CADAudio.com
Part # 62266-04-00 12-05-14 C.W.H.
Note, Sound is picked up from the front
of the mic only
FRONT
