Standard Features
Model Color Electrical
Volts Watts Amps
Unit
Dimensions
Ship
Wt./lbs.
Carton
Dimensions
UPC#
CAPO-403 Brushed
Stainless
208-240 10,000 50 w:37, h:30, l:34-3 4 165* w:40-1 4, h:26, l:37 654796-51475-5
For more information, please contact Cadco, Ltd, 145 Colebrook River Road, Winsted, CT 06098
Tel. [phone] u Fax [phone] u E-mail: [email protected] u Web site: www.cadco-ltd.com
Due to continual product improvement, specifications and design are subject to change without notice.
l Steam convection: roast, bake, cook hold
or any combination
l 4.6 cubic feet cooking chamber (14-1/2 H x
27-1/2 W x 20 D)
l Handles 4 full size steam pans** or 4 full size
size sheet pans (pans not included)
Pan spacing 3 (** based on 2-1 2 deep
steam pans).
l Four shelves included
l Compact design maximizes available space
l Digital controls provide easy operation
l Programmable (Memory for 70 programs)
l Variable steam l Venturi drying system
l Heat settings from 175o - 500o F
l Even heat system l Two fans l Probe
l 10 hour timer or continuous on
l Cool-touch, easy-clean safety door
l Insulated double wall construction
l All stainless exterior; easy to clean
l Water feed, drain lines, filter and pressure regulator
not included with product
l Water filter required - Call Cadco for current filter model
l Full one year on-site warranty covering parts and
labor plus two-year warranty on heating element;
90 day warranty on light bulbs & gasket
l Complete internet or phone technical support for
installation of water, electricity, drainage, controls
and general start-up
l After-market support system to insure that units
are properly serviced.
l Chef Support  on-line and via phone
l 208 240 volts 10,000watts 50 amps single phase
NEMA 6-50 plug 8 cord
l NSF, UL (through CSA standards)
l Unit must ship by truck, NOT UPS
l Freight class 85
Item # ____________________
Project________________________________________
Model # CAPO-403
Product Name: Countertop Combination Oven
4 Full Size Sheet Pan Capacity
Specifications:
Countertop Combination Oven.
4.6 cubic feet cooking chamber has
capacity for up to 4 full size steam table
pans or 4 full size sheet pans. Steam
& convection: roast, bake, cook & hold
or any combination. Digital controls for
easy operation. Programmable. Probe.
Variable steam Venturi drying system.
10 hour timer or continuous on. All
stainless double wall insulated
construction. 208-240 volts - Single
phase 10,000 watts 50 amps NEMA
6-50 Plug 8 cord
OPTIONAL ACCESSORIES:
XR401: : Oven Stand for CAPO-403. 7 double tiers
(adjustable width) for pans
WPR-2B: Water Pressure Regulator 2 BAR
GR1090AO: Shelf
for CAPO-403
*does not include weight of shipping skid
9 18 2006 RV05
Cadco, Ltd. Countertop Coombination Oven - 4 full size sheet pan capacity Model # CAPO-403
NEMA
6-50
Plug
Full Size
Countertop Combination Oven
Our combination ovens are made to Cadco Ltd. specifications by UNOX S.p.A., Italy u NSF, UL through CSA Standards
Cadco Model CAPO-403 = UNOX Model XAV403
Model CAPO-403 - Countertop combination oven
provides steam convection: roast, bake,
cook hold or any combination
~26 without legs

Cross corner
air flow -High speed,
automatic oscillating
reversible fan for even
cavity heating.
37
30
4
26
Steam: Water is injected directly into the baking
chamber, vaporized and changed into steam when
touching the hot heating element. Water should be
connected to the oven water inlet by a mechanical
filter and a cut-off valve. Water must have a hardness
between 0.5o-5oF in order to reduce formation of
limestone deposits inside the electro-valve and inside
the cooking chamber, and a pressure value between
0.5 - 2 bar (7.25 - 29 PSI.)
Cadco, Ltd.
Cadco, Ltd. Countertop Coombination Oven - 4 full size sheet pan capacity Model # CAPO-403
Venturi system - pulls in
cool air and pushes out
damp air, creating a dry
environment.
Item # ____________________
Project________________________________________
Model # CAPO-403
Product Name: Countertop Combination Oven
4 Full Size Sheet Pan Capacity
Front View
Back View
8 1 diam. water drain
humidity vent = 1diam;
opens on top
8 cord
vents
11to vent ctr.
16-1/2 to ctr. of water drain
NEMA 6-50
Plug
Side View
4
door open = 32-1/2
20
30-3/8
2-1/2
3
humidity
vent
(opens
on top)
door closed = 34-3/4
(Cooking
Area)
3
3
32-1/4
14-1/2
27-1/2
20
(Cooking
Area)
NEMA 6-50
Plug
Top View
Combustible Wall
Clearance Required:
Sides: 2
Rear: 4 from back
Top: 3
l CAPO-403 is made to Cadco Ltd. specifications by UNOX S.p.A.
l NSF, UL through CSA Standards
(Cadco Model CAPO-403 = UNOX Model XAV403)
l CSA File No. 202281-0-000 (UNOX) / covers Classes 2831-83 (US)
and 2831-03 (Canada)
l NSF Listed (UNOX) to ANSI/NSF Standard 4
water inlet - opens
at bottom; handles
NH 3/4 garden
hose fitting
(4-1/4 to ctr. of water inlet)
