Use & Care Manual
5/19/2011 RV04
8
CTW-6
CBF-4M
CTW-4M
CBT-2B
CBT-2
CTS-4
CTB-2
CTW-2
TIPS ON TOASTING
1) If you notice uneven toasting, simply verify if the proper selector s itch has
been chosen.
2) Also, if the toaster has not been preheated, the first fe toasting cycles ill
not provide proper or even toasting of your muffin, toast or bagel. By simply
preheating before initial use, or after the toaster has not been used for a period
of time, uneven toasting ill be eliminated.
CLEANING
After each use e recommend lightly iping your toaster off ith a soft damp
cloth. This ill help prevent spills from discoloring the stainless steel. At the end
of the day ipe gently and remove the pull-out crumb tray and ipe do n. To
remove stuck-on crumbs from the elements, a soft pastry brush can be used.
WARRANT
Cadco, Ltd. arrants that this Dualit Toaster be free from defects in material
and orkmanship for a period of one year from date of purchase. (The KoverTecTM
elements have a t o year arranty from date of toaster purchase. See easy
replacement instructions on page 6.) Warranty provides repair of unit or shipping
replacement elements to customer, as applicable. A copy of your original purchase
receipt is required for proof of purchase date. This arranty does not cover
consequential damage of any kind or damages resulting from accident, misuse,
abuse, or external service or repair attempts by unauthorized personnel. Inquiries
concerning this arranty and the use and maintenance of this unit should be
directed to Cadco, Ltd.
Please note: This Dualit Toaster is a carry-in service item; Cadco will
not pay for on-site service or travel time. Customer is responsible for
packaging the unit securely and shipping it to Cadco*for service, along ith
a copy of original purchase receipt, a description of the problem, and your name,
shipping address and phone number. If shipping the unit for service, e recommend
that you insure it for its original purchase price. Cadco is not responsible for
damage or loss of unit in transit to service location.
*When returning a unit to Cadco, Ltd. for warranty repair, please call
[phone] first for a Return Authorization Number. Return Authorization
Number MUST be written on outside of carton to track the unit and avoid
service delays. *Ship to: Cadco, Ltd., Attn: REPAIR, 145 Colebrook River
Road, Winsted, CT 06098. Warranty covers repairing the unit and returning
it to customer.
Warranty is applicable only in USA.
IMPORTANT NOTES: (Information to have before calling for service.)
Model No.:____________ Date of Purchase: _____________________
Toaster voltage: ____120 Volt ____208 volt ____220 volt
Place of Purchase: _____________________________________________
To expedite all warranty claims please keep your dated sales receipt from
place of purchase.

Congratulations on your purchase of a Cadco Dualit Toaster!
IMPORTANT SAFEGUARDS
To reduce the risk of personal injury or property damage when using
electrical appliances, basic safety precautions should always be
followed, including the following:
1. READ ALL INSTRUCTIONS BEFORE USE.
2. DO NOT touch hot surfaces! Use handles or knobs.
3. To protect against electrical shock, DO NOT immerse any part of this product
in ater or other liquid.
4. Close supervision is necessary hen any appliance is used by or near
children.
5. Unplug from outlet hen not in use and before cleaning. Allo to cool
completely before putting on or taking off parts, and before cleaning or storing
the appliance.
6. DO NOT operate any appliance ith a damaged cord or plug or after the
appliance malfunctions or has been damaged in any manner. Return the
appliance to the Cadco Factory Service Department (call 860-738-2500 first)
for examination, repair or adjustment, or call for nearest service location.
7. The use of accessory attachments not recommended by the appliance
manufacturer may cause injury.
8. Do not use outdoors.
9. Do not let cord hang over edge of table or counter or touch hot surfaces.
10. Do not place on or near a hot gas or electric burner or in a heated oven, or near
ranges, stoves, or fryers.
12. Do not use appliance for other than intended use.
13. Oversize food, metal foil packages, or utensils must not be inserted in a
toaster as they involve a risk of fire or electrical shock.
14. A fire may occur if toasters are covered or touching flammable material, including
curtains, draperies, alls and the like hen in operation.
15.
Do not attempt to dislodge food hen toaster is plugged in. Do not insert knives
or other foreign objects into slots. This ill cause damage to the elements.
16. Do not clean ith metal scouring pads. They can scratch and ruin the finish
of your unit. Pieces can also break off the pad and touch electrical parts,
creating a shock hazard.
17. Unplug the toaster hen not in use.
SAVE THESE INSTRUCTIONS
NOTE: A short power supply cord (or cord set) has been provided to reduce
the hazards resulting from becoming entangled or tripping.
Longer cord sets or extension cords may be used if care is properly exercised
in their use. If a long cord set or extension cord is used,
1. The marked electrical rating of the cord set or extension cord should be at
least as great as the electrical rating of the appliance, and should be grounded
type 3- ire cord.
2. The longer cord should be arranged so that it ill not be drape over the counter
top or table top here it can be pulled on by children or tripped over accidentally.
NOTE: Each toaster has been fitted ith one adjustable foot. This compensates
for uneven counter surfaces.
2
(Has selector switch for 2,4, or 6 slot operation)
Note: This model uses 2 end elements &
5 center elements
T-25008 - 6-slot center element, covered
mica,208/220 volt
T-25009 - 6-slot end element, covered mica,
208/220 volt
T-25012 - Timer ith knob
7
All our current toaster models feature
KoverTec Heavy Duty Mica Covered Elements
(They should not be combined with the older mica
or black ceramic elements in the same toaster.)
(1.25 wide slots; Timer activates oth slots at once)
These models use 4 end elements / no center elements
T-25002- 2-slot end element, covered mica, 120 volt
T-25012 - Manual Timer ith knob
(Has selector switch for 1 or 2 slot operation)
These models use 2 end elements & 1 center element
T-25001 - 2-slot center element, covered mica,120 volt
T-25002 - 2-slot end element, covered mica, 120 volt
T-25012 - Manual Timer ith knob
2-Slot Standard Toasters: CTB-2, CTW-2
2-Slot Bagel Toasters: CBT-2, CBT-2B
6-Slot Standard Toaster: CTW-6
4-Slot Standard Toasters: CTW-4M, CTS-4
(Has selector switch for 2 or 4 slot operation)
These models use 2 end elements & 3 center elements
T-25003 - 4-slot center element, covered mica, 120 volt
T-25004 - 4-slot end element, covered mica, 120 volt
T-25005 - 4-slot center element, covered mica,
208/220 volt
T-25006 - 4 -slot end element, covered mica,
208/220 volt
T-25012 - Manual Timer ith knob
4-Slot Buffet Toaster: CBF-4M
(Has 2 timers for individual 2-slot operation)
This model uses 4 end elements & 2 center elements
T-25001 - 2-slot center element, covered mica, 120 volt
T-25060 - end element, covered mica, 120 volt
T-25050 - Manual Timer ith knob & bell

ELEMENT REPLACEMENT
There ill be times hen you need to replace your toaster's elements. This
does not mean your toaster is defective. With many contributing factors, such
as electrical iring, amount of usage, po er surges, and even normal ear and
tear, elements can fail.
If any of your patented KoverTec elements fail ithin the first t o years after
toaster purchase, Cadco ill gladly send the replacement elements to you, free
of charge. By simply follo ing the instructions on this page, you ill be toasting
again, easily, and in less than five minutes!
**UNPLUG TOA TER BEFORE REPLACING ELEMENT !**
1. Remove Crumb Tray at bottom of toaster.
2. Determine hich element(s) are not orking. (See diagrams on facing page.)
This step is the most critical to remember; the end elements have less
attage than the center elements due to the fact that they only toast one
side of the bread. The elements are clearly marked as center or end elements.
3. Setting the toaster on a cloth, turn toaster up-side do n.
4. Unscre and remove the rubber feet.
5. Unscre and remove the base plate.
6. Loosen the 2 nuts holding elements in place.
7. Note the position of the
connecting links before
removing the retaining
scre s.
8. Lightly bend back the
Element Retaining Strip
and remove the damaged
element by lifting.
9. Replace ith a ne element
by lo ering element in place.
10. Fasten connecting links (nuts)
into place.
12. Slide retaining strip back into place
and tighten nuts.
13. Scre base plate back on.
14. Scre feet back into place.
6
IMPORTANT NOTE: Replacing Cadcos Dualit Toaster Elements
When replacing toaster elements, please note that the Element Retaining Strip
goes on the top of the older mica elements, but it goes in the top side notches
of the newer KoverTec Mica elements.
Older
Mica Element
Top side notch
Top of
element
Ne er
KoverTec Element
3
TABLE OF CONTENTS
Four-Slot Buffet Toaster (CBF-4M) Instructions ............................................ 3
Four-Slot Standard Toasters (CTS-4 & CTW-4M) Instructions......................... 4
Six-Slot Standard Toasters (CTW-6) Instructions ........................................... 4
T o-Slot Standard Toasters (CTW-2 & CTB-2) Instructions ............................ 4
T o-Slot Bagel Toaster (CBT-2 & CBT-2B) Instructions ................................... 4
Element Replacement (All Models) .................................................................. 6
Tips on Toasting................................................................................................ 8
Cleaning Instructions ...................................................................................... 8
Warranty Information ........................................................................................ 8
A. Manual timer dials (left one controls left 2 slots; right one controls right 2 slots)
B. Ejector knobs (each knob lo ers or ejects toast from the 2 slots above it)
C. Pull-out crumb tray
Manual timer
dial
Features dual controls for independent 2-slot operation
INSTRUCTIONS FOR 4-SLOT BUFFET TOASTER
1) Prior to the initial use or after the toaster has not been used for a period of
time (60-90 minutes) it is important to preheat your toaster. This avoids
uneven toasting and ill provide a more efficient toasting throughout the
day. To preheat before your buffet line opens, turn BOTH manual timer dials
on. Preheat for at least 1 - 2 minutes.
2) After preheating, lift up the appropriate ejector knob, see B above, placing
bread in proper slots. Turn the corresponding timer dial to the desired
darkness setting, see A above. By turning the timer dial on, your toasting
cycle will begin immediately.
3) The left timer dial should be used hen toasting 1 or 2 slices of product in
the left slots. The right timer dial should be used hen toasting 1 or 2 slices
of product in the right slots.
4) When the timer reaches zero, a series of light beeps ill indicate that the
toasting cycle is complete. You can interrupt the toasting cycle at any time
by lo ering the ejector knob for the desired slots. This ill also enable you
to check the product for doneness ithout shutting the toaster off or interrupting
the toasting cycle.
5) To eject the toast, press lightly do n on the appropriate ejector knob. The
toast ill remain in the slots until you do this (a keep- arm feature appreciated
in the commercial industry.)
C
Ejector knob area label
A
A
B
120 volts / 1750 atts / 14.5 amps / single phase
4-SLOT BUFFET TOASTER - CBF-4M
Up to
Toast
Down to
Serve
Up to
Toast
Down to
Serve TM
D
a
r
k
-
M
e
d
-
L
i
g
h
t
T
u
r
n
t
o
T
o
a
s
t
0

l Slot dimensions: W:1, H:5, L:5
Fits bread and standard size bagels
l 2 or 4 slot selector s itch
l Timer knob (turns unit on)
l Pull-out crumb tray
l Ejector knob
4
4-SLOT STANDARD TOASTERS - CTW-4M & CTS-4
l Slot dimensions: W:1, H:5, L:5
Fits bread and standard size bagels
l 2, 4 or 6 slot selector s itch
l Timer knob (turns unit on)
l Pull-out crumb tray
l Ejector knob
6-SLOT STANDARD TOASTERS - CTW-6
208/220 volts models available; single phase
2-SLOT STANDARD TOASTERS - CTB-2 & CTW-2
l Slot dimensions: W:1, H:5, L:5
Fits bread and standard size bagels
l 1 or 2 slot selector s itch
l Timer knob (turns unit on)
l Ejector knob
l Pull-out crumb tray
120 volts / 1250 atts / 10.5 amps / single phase
2-SLOT BAGEL TOASTERS - CBT-2 & CBT-2B
120 volts / 208 volts / 220 volts models available; single phase
l Slot dimensions: W:1.25, H:5, L:5
Fits bread and larger size bagels
l Timer knob (turns unit on)
l Pull-out crumb tray
l Ejector knob
l NOTE: This model does not have a selector
s itch; both slots heat hen unit is turned on
120 volts / 1200 atts / 10 amps / single phase
1) Prior to the initial use or after the toaster has not been used for a period
of time (60-90 minutes), it is important to PREHEAT your toaster. This
avoids uneven toasting and will provide more efficient toasting throughout
the day. To preheat, press the slot selector switch to the maximum
number of slots, and turn the timer dial to the desired setting. Preheat
for at least 1 - 2 minutes.
2) After preheating, lift up the Ejector Knob and place bread in proper slots.
Select proper setting of selector s itch for the number of slices being toasted,
(see 3) belo ) and turn the timer dial to the desired shade.
IMPORTANT: By turning the timer dial on, your toasting cycle will begin
immediately. Once the toasting has begun you should notice the neon light
ill illuminate. Please note that the higher the timer number, the darker the
toast ill be.
3) Selector s itch settings vary by model:
l 4-Slot Standard Toasters:
-Selector I I should be pressed hen toasting 1 or 2 slices of product. Make
sure to use the far left toaster slots.
-Selector I I I I should be pressed hen toasting 3 or 4 slices.
l 6-Slot Standard Toasters:
-Selector I I should be pressed hen toasting 1 or 2 slices of product. Make
sure to use the far left toaster slots.
-Selector I I I I should be pressed hen toasting 3 or 4 slices. Make sure
to use the 3 or 4 left toaster slots.
-Selector I I I I I I should be pressed hen toasting 5 or 6 slices of product.
l 2-Slot Standard Toasters:
-Selector I should be pressed hen toasting 1 slice of product. Make sure
to use the far left toaster slot.
-Selector Il should be pressed hen toasting 2 slices of product.
l 2-Slot Bagel Toasters:
This model does not have a selector switch. Turning on the toaster
with the timer knob will heat both slots.
4) When the timer reaches zero and hen the ticking stops, the toasting cycle
is complete. The neon light ill also s itch off. You may interrupt the toasting
to check the progress at any time during the cycle by lo ering the ejector
knob. This ill raise the toast in the slot to check the product for doneness
ithout shutting the toaster off. (This ill not change or reset the toasting
time as set by the timer.) After checking progress, raise the ejector knob to
lo er the toast in the slot to complete the toasting cycle.
5) To eject the toast or bagel, simply press lightly do n on the ejector knob. The
toast ill remain in the slots until you do this (a keep arm feature appreciated
in the commercial industry.)
5
GENERAL OPERATING INSTRUCTIONS
ALL MODEL EXCEPT CBF-4M BUFFET TOA TER
(note, if you have the discontinued Models:
CTB-4E, CTS-4E, or CSTW-2, see separate manuals)
