Cadi SmartNODE SMN-823W User manual

1
CADI SmartSense
SmartNODE
SMN-823W User Manual

2
Table of Contents
Table of Contents ........................................................................................................................... 2
1. Introduction ................................................................................................................................ 5
2. Specifications ............................................................................................................................. 5
3. Button Usage .............................................................................................................................. 5
4. First install on soap dispenser..................................................................................................... 7
5. To change new battery................................................................................................................ 8
6. To change new soap liquid....................................................................................................... 11
7. To remove tag for cleaning (no change of liquid soap)............................................................ 11
8. Using the tag…………………………………………………………………………………..12
9. Low battery behaviour……………………………………………………………………...…13

3
Regulatory Information
For customers in U.S.A and Canada
Federal Communications Commission (FCC) Statement
15.21
Warning:
You are cautioned that changes or modifications not expressly approved by the part responsible for
compliance could void the user’s authority to operate the equipment.
15.105(b)
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
•Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
1) This device may not cause interference and
2) This device must accept any interference, including interference that may cause undesired operation of
the device.
FCC RF Radiation Exposure Statement:
1. This Transmitter must not be co-located or operating in conjunction with any other antenna
or transmitter.
2. For body worn operation, this device has been tested and meets FCC RF exposure
guidelines. When used with an accessory that contains metal may not ensure compliance
with FCC RF exposure guidelines.

4
For customers in Europe
This equipment has been tested and found to comply with the limits set out in the R&TTE Directive.
Where you see this symbol on any of our electrical products or packaging in Europe, it means that at end
of life the product or battery must be disposed of in accordance with any applicable laws or requirements
for the separate disposal of electrical equipment or batteries.
PRECAUTIONS
•Keep batteries away from children.
•Do not swallow batteries.
•Do not throw batteries into water.
•Do not throw batteries into fire.
•Do not short-circuit batteries. Battery must be fit into tag in correct orientation.
•Do not replace battery with incorrect type. Incorrect type of battery replacement may cause risk of
exposure.
•Battery should be dispose according to the instructions
Product Information
•Product model: SMN-823W
•Product name: SmartNODE
•Manufacturing site: 31 Ubi Road 1, #07-01A Aztech Building, Singapore 408694
Version Information
•This version is subject to change or upgrade without notice
•Version: A03
•Issue date: 20 Aug 2019
Declaration
Cadi Scientific Pte Ltd reserves the right to change the product described in this Operator’s Manual. All
information contained in this Operator’s Manual is subject to change without notice.

5
Warning: Use of this equipment adjacent to or stacked with other equipment should be avoided
because it could result in improper operation. If such use is necessary, this equipment and the other
equipment should be observed to verify that they are operating normally.
Warning: Portable RF communications equipment (including peripherals such as antenna cables and
external antennas) should be used no closer than 30 cm (12 inches) to any part of the ME Equipment or
ME System, including cables specified by the manufacturer. Otherwise, degradation of the performance
of this equipment could result.
Manufacturer’s declaration-electromagnetic emissions
The SMN-823W is intended for use in the electromagnetic environment (for Professional healthcare environments)
specified below.
The customer or the user of the SMN-823W should assure that it is used in such an environment.
Emission test
Compliance
Electromagnetic environment-guidance
(for Professional healthcare environments)
RF emissions CISPR 11
Group 1
The SMN-823W uses RF energy only for its internal
function. Therefore, its RF emissions are very low and are
not likely to cause any interference in nearby electronic
equipment.
RF emissions CISPR 11
Class B
The SMN-823W is suitable for use in all establishments,
including domestic establishments and those directly
connected to the public low-voltage power supply network
that supplies buildings used for domestic purposes.
Harmonic emissions
IEC 61000-3-2
Not applicable
Voltage fluctuations
/flicker emissions IEC
61000-3-3
Not applicable

6
1. Introduction
The SMN-823W is a battery operated motion sensing tag. The SMN-823W transmits LF signal upon
detection of motion to trigger close proximity communication to other tags. SMN-823W is designed to be
installed onto automatic soap dispensers to allow Hand Hygiene Compliance in hospitals and clinics.
When the SMN-823W detects motion, it will transmit a unique ID using low frequency. SMN-823W also
has wifi to allow transmittion of data to a server for monitoring of status, battery level, etc.
The button on the SMN-823W allows for maintenanpg 5ce by the user.
2. Specifications
1
Power
Non-rechargeable Li-SOCl2battery 3.6v
2
Dimensions
100x60x11mm
3
Weight
80g
4
Operating Temperature
-10°C - 50°C
5
Storage & Transport
temperature range
0°C - 30°C
6
RF (Transmit)
Wifi 802.11 b/g/n
Frequency Band
Ch1~Ch11 (2.412~2.462Ghz) (FCC)
Ch1~Ch13 (2.412~2.472) (CE)
Transmission Rate
10mins interval, or immediately upon change of location
Transmission power (ERP)
32mW
7
LF (Transmit and Receive)
125 khz
Modulation
ASK modulated
Transmission Rate
Upon motion detection
8
Interfaces
1x button
2x LEDs
9
Sensors
Motion sensor
Proximity sensor
10
Compliance
EN 300328
EN 300330
EN 301489
CISPR 32
EN60601-1-2
EN 62368
EN 62311
FCC Method-47 CFR Part 15
FCC 15 subpart B
FCC part 2.1093
3. Button Usage
Action
Logic
Description
User button WAKE->SLEEP
Save Activation Count
Used to put the tag to sleep
(off) state

7
User button SLEEP->WAKE
Initialize Activation Count
Used to initialize the soap usage
level to 0 when doing a soap
refill
Explanation: Activation Count (soap level) will be maintained until the user physically initiates a
WAKE->SLEEP->WAKE sequence using the User button. Or else, the Activation Count remains.
START
WAKE mode
User button
>5sec?
SLEEP mode
Save Activation
Count
Reset Activation
Count
User button
>5sec?
END
Y Y
NN
Action
Logic
Description
Reset button pressed
Initialize Tx count, Battery Level
Used to initialize parameters
when a fresh battery is installed
Explanation: Reset button is only accessible when changing the battery. By changing the battery,
followed by pressing the Reset button, the tag resets the Tx Count and Battery level.

8
Initialise Tx count,
Battery Level
Reset button
pressed?
START
4. First install on soap dispenser
1. Ensure the tag is in SLEEP mode (no LED blinking). If not, long press (5sec) the User button. 3
beeps are heard, Red LED blinks once.
2. Install the bracket onto the soap dispenser using double-sided tape.

9
3. Install the tag onto the bracket.
4. Long press (5sec) the User button to WAKE the tag. 3 beeps are heard, Green LED blinks once,
then starts blinking periodically.
Result:
1. Usage level of the soap (Activation Count) will be reset to 0.

10
5. To change new battery
1. Remove the tag from the dispenser (2 screws).
2. Unscrew the tag (6 screws) and remove the back cover.
3. Disconnect the existing battery.
4. Connect the new battery. Press the Reset button once (5 beeps are heard).

11
5. The tag will automatically default to WAKE mode. Confirm the tag is in WAKE mode by observing
the blinking Green LED.
6. Replace the back cover and screw.
7. Install the tag back into the bracket.

12
Result:
1. Usage level of the soap (Activation Count) will be maintained.
2. Transmit Count (wifi), and Battery Level will be reset.
6. To change new soap liquid
1. Put the tag to SLEEP mode (long press the User button until 3 beeps are heard, red LED blinks
once).
2. Long press the User button to WAKE the tag (3 beeps are heard and Green LED starts blinking).

13
Result:
1. Usage level of the soap (Activation Count) will be reset to 0.
7. To remove tag for cleaning (no change of liquid soap)
1. Remove the tag from the dispenser for cleaning.
2. Install the tag back into the bracket.

14
Result:
1. All parameters will remain as no buttons are pressed.
8. Using the tag
The tag requires both vibration and proximity sensing to successfully activate. When mounted on the
soap dispenser, when the staff puts his hand under the dispenser, the motor from the dispenser will
activate the motion sensor, at the same time, the presence of the staff’s hand will activate the proximity
sensor. Once these 2 conditions are fulfilled, the SMN-823W will send a signal to trigger the staff tag of a
successful hand wash event.

15
Vibration
Proximity
Hand wash
-
-
Unsuccessful
-
Yes
Unsuccessful
Yes
-
Unsuccessful
Yes
Yes
Successful
9. Low battery behavior

16
The tag continuously monitors the battery level. The battery capacity percentage is reported via wifi,
and the low battery status can be viewed on the LED window. The LED will blink periodically in red
instead of green. The tag will also report low battery status if it was internally restarted due to low
battery. The tag will continue to transmit wifi its status until the battery dies completely.
Symptom
LED blink
Wifi battery
capacity status
Wifi battery
status
Explanation
Battery is good
Green
Normal range
Ok
Battery capacity is good, tag has
not restarted due to low battery
Battery reaches end
of life (<10%
capacity)
Red
Low range
Low
Battery capacity is low
Tag has restarted
>10 times
Red
Normal range
Low
Tag has restarted due to low
battery
EMC compliance summary: When the Air +/- 15kV is applied, the EUT emits a "beep" four sounds, a red
light flashes, and a red light flashes for one second.
SMN-823W is not a life support system and does not cause any harm to the patient or environment. A
reset due to ESD will not affect essential performance and without basic safety consideration.
