Cadillac 2006 CTS-V User manual

Seats and Restraint Systems ........................... 1-1
Front Seats ............................................... 1-2
Rear Seats ............................................... 1-8
Safety Belts ............................................. 1-10
Child Restraints ....................................... 1-29
Airbag System ......................................... 1-50
Restraint System Check ............................ 1-65
Features and Controls ..................................... 2-1
Keys ........................................................ 2-3
Doors and Locks ....................................... 2-8
Windows ................................................. 2-14
Theft-Deterrent Systems ............................ 2-18
Starting and Operating Your Vehicle ........... 2-22
Mirrors .................................................... 2-39
OnStar
®
System ...................................... 2-43
Universal Home Remote System ................ 2-45
Storage Areas ......................................... 2-49
Sunroof .................................................. 2-51
Vehicle Personalization ............................. 2-52
Instrument Panel ............................................. 3-1
Instrument Panel Overview .......................... 3-4
Climate Controls ...................................... 3-23
Warning Lights, Gages, and Indicators ........ 3-30
Message Center ....................................... 3-47
Driver Information Center (DIC) .................. 3-53
Audio System(s) ....................................... 3-83
Driving Your Vehicle ....................................... 4-1
Your Driving, the Road, and Your Vehicle ..... 4-2
Towing ................................................... 4-37
Service and Appearance Care .......................... 5-1
Service ..................................................... 5-3
Fuel ......................................................... 5-5
Checking Things Under the Hood ............... 5-10
Rear Axle ............................................... 5-49
Headlamp Aiming ..................................... 5-50
Bulb Replacement .................................... 5-53
Windshield Wiper Blade Replacement ......... 5-56
Tires ...................................................... 5-58
Appearance Care ..................................... 5-94
Vehicle Identification ............................... 5-102
Electrical System .................................... 5-103
Capacities and Specifications ................... 5-114
Maintenance Schedule ..................................... 6-1
Maintenance Schedule ................................ 6-2
Customer Assistance and Information .............. 7-1
Customer Assistance and Information ........... 7-2
Reporting Safety Defects ........................... 7-14
Index .................................................................1
2006 Cadillac CTS/CTS-V Owner Manual M

GENERAL MOTORS, GM, the GM Emblem, CADILLAC,
the CADILLAC Crest & Wreath, and the name CTS are
registered trademarks of General Motors Corporation.
This manual includes the latest information at the time it
was printed. We reserve the right to make changes after
that time without notice. For vehicles first sold in
Canada, substitute the name “General Motors of Canada
Limited” for Cadillac Motor Car Division whenever it
appears in this manual.
Keep this manual in the vehicle, so it will be there if it is
needed while you are on the road. If the vehicle is
sold, leave this manual in the vehicle.
Canadian Owners
A French language copy of this manual can be obtained
from your dealer or from:
Helm, Incorporated
P.O. Box 07130
Detroit, MI 48207
How to Use This Manual
Many people read the owner manual from beginning to
end when they first receive their new vehicle. If this
is done, it can help you learn about the features
and controls for the vehicle. Pictures and words work
together in the owner manual to explain things.
Index
A good place to quickly locate information about the
vehicle is the Index in the back of the manual. It is an
alphabetical list of what is in the manual and the
page number where it can be found.
Litho in U.S.A.
Part No. 06CTS A First Printing
©
2005 General Motors Corporation. All Rights Reserved.
ii

Safety Warnings and Symbols
There are a number of safety cautions in this book. We
use a box and the word CAUTION to tell about things
that could hurt you if you were to ignore the warning.
{CAUTION:
These mean there is something that could hurt
you or other people.
In the caution area, we tell you what the hazard is.
Then we tell you what to do to help avoid or reduce the
hazard. Please read these cautions. If you do not,
you or others could be hurt.
You will also find a circle
with a slash through it in
this book. This safety
symbol means “Do Not,”
“Do Not do this” or “Do Not
let this happen.”
iii

Vehicle Damage Warnings
Also, in this manual you will find these notices:
Notice: These mean there is something that could
damage your vehicle.
A notice tells about something that can damage the
vehicle. Many times, this damage would not be covered
by your vehicle’s warranty, and it could be costly. But
the notice will tell what to do to help avoid the damage.
When you read other manuals, you might see
CAUTION and NOTICE warnings in different colors or
in different words.
There are also warning labels on the vehicle. They use
the same words, CAUTION or NOTICE.
Vehicle Symbols
The vehicle has components and labels that use
symbols instead of text. Symbols are shown along with
the text describing the operation or information
relating to a specific component, control, message,
gage, or indicator.
If you need help figuring out a specific name of a
component, gage, or indicator, reference the following
topics:
•Seats and Restraint Systems in Section 1
•Features and Controls in Section 2
•Instrument Panel Overview in Section 3
•Climate Controls in Section 3
•Warning Lights, Gages, and Indicators in Section 3
•Audio System(s) in Section 3
•Engine Compartment Overview in Section 5
iv

These are some examples of symbols that may be found on the vehicle:
v

✍NOTES
vi

Front Seats ......................................................1-2
Manual Seats ................................................1-2
Power Seats ..................................................1-3
Power Lumbar ...............................................1-3
Heated Seats .................................................1-4
Reclining Seatbacks ........................................1-4
Head Restraints .............................................1-7
Rear Seats .......................................................1-8
Split Folding Rear Seat ...................................1-8
Safety Belts ...................................................1-10
Safety Belts: They Are for Everyone ................1-10
Questions and Answers About Safety Belts ......1-14
How to Wear Safety Belts Properly .................1-15
Driver Position ..............................................1-15
Safety Belt Use During Pregnancy ..................1-21
Right Front Passenger Position .......................1-22
Rear Seat Passengers ..................................1-22
Rear Safety Belt Comfort Guides ....................1-25
Safety Belt Pretensioners ...............................1-28
Safety Belt Extender .....................................1-28
Child Restraints .............................................1-29
Older Children ..............................................1-29
Infants and Young Children ............................1-32
Child Restraint Systems .................................1-35
Where to Put the Restraint .............................1-38
Lower Anchors and Tethers for
Children (LATCH) ......................................1-39
Securing a Child Restraint in a Rear
Seat Position ............................................1-44
Securing a Child Restraint in the Right Front
Seat Position ............................................1-47
Airbag System ...............................................1-50
Where Are the Airbags? ................................1-53
When Should an Airbag Inflate? .....................1-57
What Makes an Airbag Inflate? .......................1-58
How Does an Airbag Restrain? ......................1-58
What Will You See After an Airbag Inflates? .....1-59
Passenger Sensing System ............................1-60
Servicing Your Airbag-Equipped Vehicle ...........1-64
Adding Equipment to Your Airbag-Equipped
Vehicle ....................................................1-64
Restraint System Check ..................................1-65
Checking the Restraint Systems ......................1-65
Replacing Restraint System Parts
After a Crash ............................................1-66
Section 1 Seats and Restraint Systems
1-1

Front Seats
Manual Seats
{CAUTION:
If the seatback is not locked, it could move
forward in a sudden stop or crash. That could
cause injury to the person sitting there. Always
push and pull on the seatback to be sure it is
locked.
Your vehicle may have manual seats. To adjust the
seat, lift the bar under the front of the seat to unlock it.
Slide the seat to where you want it and release the
bar. Try to move the seat back and forth with your body
to be sure the seat is locked in place.
1-2

Power Seats
If your vehicle has power seats, the controls are located
on the outboard side of the front seat cushions.
•Move the front of the horizontal control up or down
to raise or lower the front part of the cushion.
•Move the rear of the horizontal control up or down
to raise or lower the rear part of the cushion.
•Lift up or push down on the center of the horizontal
control to move the seat cushion up or down.
•To move the seat forward or rearward, slide the
horizontal control forward or rearward.
The vertical control is used for reclining your seatback.
See Reclining Seatbacks on page 1-4 for more
information.
Power Lumbar
Your vehicle may have this
feature. The driver’s and
passenger’s seatback
lumbar support can be
adjusted by moving the
control located on the
outboard side of the seat
cushions.
To increase or decrease support, hold the control
forward or rearward. Keep in mind that as your seating
position changes, as it may during long trips, so should
the position of your lumbar support. Adjust the seat
as needed.
1-3

Heated Seats
If your vehicle is equipped
with heated front seats, the
buttons are located on
the climate control panel.
There is one button for the driver and one for the front
passenger. Each button has three settings, LO, HI
and off. The active setting appears on the climate control
panel display. The LO setting warms the seatback
and cushion until the seat approximates normal body
temperature. The HI setting has a slightly higher
temperature.
To turn on the heated seats, press the button once.
The seat will heat to the HI setting. Press the button
again to switch to the LO setting. Pressing the button
a third time turns the system off.
The heated seats can only be used when the ignition is
turned on. When the vehicle is turned off, the heated
seats automatically turn off. If you wish to have the
heated seats on once the vehicle is restarted, press the
button again.
Reclining Seatbacks
If your front passenger’s seat has a manual reclining
seatback, the lever is located on the outboard side of
the seat.
Lift the lever to release the seatback, then move the
seatback to where you want it. Release the lever to lock
the seatback in place.
Manual Recline Lever
1-4

{CAUTION:
If the seatback is not locked, it could move
forward in a sudden stop or crash. That could
cause injury to the person sitting there. Always
push and pull on the seatback to be sure it is
locked.
To return the seatback to the upright position, pull up on
the lever without applying pressure to the seatback.
If your vehicle has power reclining seatbacks, the
control is located on the outboard side of the front seats.
Press the top of the vertical control forward or rearward
to adjust the seatback angle.
Power Recliner
1-5

Do not have a seatback reclined if your vehicle is
moving.
{CAUTION:
Sitting in a reclined position when your vehicle
is in motion can be dangerous. Even if you
buckle up, your safety belts cannot do their
job when you are reclined like this.
The shoulder belt cannot do its job. In a crash,
you could go into it, receiving neck or other
injuries.
The lap belt cannot do its job either. In a crash
the belt could go up over your abdomen. The
belt forces would be there, not at your pelvic
bones. This could cause serious internal
injuries.
For proper protection when the vehicle is in
motion, have the seatback upright. Then sit
well back in the seat and wear your safety belt
properly.
1-6

Head Restraints
The front seat head
restraints can be adjusted
up and down. Pull up
on the head restraint to
raise it. Press the
button located at the
bottom of the head
restraint and push the
head restraint down
to lower it.
Both the front and rear head restraints tilt forward and
rearward, also. Adjust your head restraint so that the top of the restraint
is closest to the top of your head. This position reduces
the chance of a neck injury in a crash.
You can remove the rear head restraints. Press the
button located on top of the seatback and pull up on the
head restraint to remove it.
1-7

Rear Seats
Split Folding Rear Seat
Your vehicle may have a split folding rear seat. A split
folding rear seat allows you to carry long cargo by
folding down part or all of the rear seat. Before you can
fold the rear seatback, you need to unlatch the center
seatbelt buckle.
Use the following steps to lower one or both of the rear
seatbacks: 1. Insert a tool with a
small tip into the slot
as shown to unlatch the
seatbelt buckle. Then
move the belt to the
side so it is not in
your way.
2. There is a tab located
on the outboard sides
of the seatback.
Pull forward on the tab
to unlock the seatback.
3. Fold the seatback down. This will allow you direct
access to the trunk.
4. Repeat Steps 2 and 3 to fold down the other
seatback.
1-8

{CAUTION:
If the seatback is not locked, it could move
forward in a sudden stop or crash. That could
cause injury to the person sitting there. Always
push and pull on the seatback to be sure it is
locked.
{CAUTION:
A safety belt that is improperly routed, not
properly attached, or twisted will not provide
the protection needed in a crash. The person
wearing the belt could be seriously injured.
After raising the rear seatback, always check
to be sure that the safety belts are properly
routed and attached, and are not twisted.
To return the seatback to the upright position, do the
following:
1. Lift the seatback up and push it back into place.
2. Reconnect the center
safety belt latch plate to
the buckle as shown.
3. Make sure the seatback is locked into place by
pushing and pulling on it.
4. Repeat Steps 1 and 3 for the other seatback.
When the seatback is not in use, it should be kept in
the upright, locked position.
1-9

Safety Belts
Safety Belts: They Are for Everyone
This part of the manual tells you how to use safety
belts properly. It also tells you some things you should
not do with safety belts.
{CAUTION:
Do not let anyone ride where he or she cannot
wear a safety belt properly. If you are in a
crash and you are not wearing a safety belt,
your injuries can be much worse. You can hit
things inside the vehicle or be ejected from it.
You can be seriously injured or killed. In the
same crash, you might not be, if you are
buckled up. Always fasten your safety belt,
and check that your passengers’ belts are
fastened properly too.
{CAUTION:
It is extremely dangerous to ride in a cargo
area, inside or outside of a vehicle. In a
collision, people riding in these areas are more
likely to be seriously injured or killed. Do not
allow people to ride in any area of your vehicle
that is not equipped with seats and safety
belts. Be sure everyone in your vehicle is in a
seat and using a safety belt properly.
Your vehicle has a light
that comes on as a
reminder to buckle up.
See Safety Belt Reminder
Light on page 3-34.
1-10

In most states and in all Canadian provinces, the law
says to wear safety belts. Here is why: They work.
You never know if you will be in a crash. If you do have
a crash, you do not know if it will be a bad one.
A few crashes are mild, and some crashes can be so
serious that even buckled up, a person would not
survive. But most crashes are in between. In many of
them, people who buckle up can survive and sometimes
walk away. Without belts they could have been badly
hurt or killed.
After more than 30 years of safety belts in vehicles, the
facts are clear. In most crashes buckling up does
matter...a lot!
Why Safety Belts Work
When you ride in or on anything, you go as fast as
it goes.
Take the simplest vehicle. Suppose it is just a seat
on wheels.
1-11

Put someone on it. Get it up to speed. Then stop the vehicle. The rider
does not stop.
1-12

The person keeps going until stopped by something. In
a real vehicle, it could be the windshield... or the instrument panel...
1-13

or the safety belts!
With safety belts, you slow down as the vehicle does.
You get more time to stop. You stop over more distance,
and your strongest bones take the forces. That is why
safety belts make such good sense.
Questions and Answers About
Safety Belts
Q: Will I be trapped in the vehicle after an accident
if I am wearing a safety belt?
A: You could be — whether you are wearing a safety
belt or not. But you can unbuckle a safety belt,
even if you are upside down. And your chance of
being conscious during and after an accident, so
you can unbuckle and get out, is much greater
if you are belted.
Q: If my vehicle has airbags, why should I have to
wear safety belts?
A: Airbags are in many vehicles today and will be in
most of them in the future. But they are
supplemental systems only; so they work with
safety belts — not instead of them. Every airbag
system ever offered for sale has required the use of
safety belts. Even if you are in a vehicle that has
airbags, you still have to buckle up to get the most
protection. That is true not only in frontal collisions,
but especially in side and other collisions.
1-14
