2010 Cadillac Escalade/Escalade ESV Owner Manual M
In Brief ............................................ 1-1
Instrument Panel ................................. 1-2
Initial Drive Information . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
Vehicle Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-16
Performance and Maintenance . . . . . . . . . . . . . . . . . . 1-22
Seats and Restraint System ...................... 2-1
Head Restraints . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
Front Seats ....................................... 2-4
Rear Seats ...................................... 2-10
Safety Belts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-26
Child Restraints . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-49
Airbag System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-74
Restraint System Check . . . . . . . . . . . . . . . . . . . . . . . . . 2-91
Features and Controls ............................ 3-1
Keys ............................................. 3-3
Doors and Locks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-10
Windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-18
Theft-Deterrent Systems . . . . . . . . . . . . . . . . . . . . . . . . 3-22
Starting and Operating Your Vehicle . . . . . . . . . . . . . 3-26
Mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-43
Object Detection Systems . . . . . . . . . . . . . . . . . . . . . . . 3-46
Universal Home Remote System . . . . . . . . . . . . . . . . 3-55
Storage Areas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-62
Sunroof ......................................... 3-66
Instrument Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
Instrument Panel Overview . . . . . . . . . . . . . . . . . . . . . . . 4-3
Climate Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-20
Warning Lights, Gages, and Indicators . . . . . . . . . . 4-27
Driver Information Center (DIC) . . . . . . . . . . . . . . . . . 4-41
Audio System(s) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-67

2010 Cadillac Escalade/Escalade ESV Owner Manual M
Navigation System ............................... 5-1
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2
Features and Controls . . . . . . . . . . . . . . . . . . . . . . . . . . 5-12
Navigation Audio System . . . . . . . . . . . . . . . . . . . . . . . 5-60
Voice Recognition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-86
Driving Your Vehicle .............................. 6-1
Your Driving, the Road, and the Vehicle . . . . . . . . . . 6-2
Towing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-38
Service and Appearance Care . . . . . . . . . . . . . . . . . . . 7-1
Service ........................................... 7-4
Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-7
Checking Things Under the Hood . . . . . . . . . . . . . . . 7-14
All-Wheel Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-49
Rear Axle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-50
Front Axle ....................................... 7-51
Headlamp Aiming ............................... 7-52
Bulb Replacement .............................. 7-54
Windshield Wiper Blade Replacement . . . . . . . . . . . 7-57
Tires ............................................ 7-58
Appearance Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-98
Vehicle Identification . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-107
Electrical System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-108
Capacities and Specifications . . . . . . . . . . . . . . . . . . 7-115
Maintenance Schedule . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-1
Maintenance Schedule . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-2
Customer Assistance Information ............... 9-1
Customer Assistance and Information . . . . . . . . . . . . 9-2
Reporting Safety Defects . . . . . . . . . . . . . . . . . . . . . . . . 9-16
Vehicle Data Recording and Privacy . . . . . . . . . . . . . 9-18
Index .................................... i-1

GENERAL MOTORS, GM, the GM Emblem,
CADILLAC, the CADILLAC Crest & Wreath, and the
names ESCALADE and ESV are registered trademarks
of General Motors.
This manual describes features that may or may
not be on your specific vehicle either because they are
options that you did not purchase or due to changes
subsequent to the printing of this owner manual.
Please refer to the purchase documentation relating to
your specific vehicle to confirm each of the features
found on your vehicle. For vehicles first sold in Canada,
substitute the name “General Motors of Canada
Limited”for Cadillac Motor Division wherever it appears
in this manual.
Keep this manual in the vehicle for quick reference.
Canadian Owners
Propriétaires Canadiens
A French language copy of this manual can be obtained
from your dealer/retailer or from:
On peut obtenir un exemplaire de ce guide en français
auprès du concessionnaire ou à l'adresse suivante:
Helm, Incorporated
P.O. Box 07130
Detroit, MI 48207
1-800-551-4123
Numéro de poste 6438 de langue française
www.helminc.com
Index
To quickly locate information about the vehicle, use the
index in the back of the manual. It is an alphabetical list
of what is in the manual and the page number where it
can be found.
iii
Litho in U.S.A.
Part No. 25854764 A First Printing ©2009 General Motors. All Rights Reserved.

Safety Warnings and Symbols
Warning messages found on vehicle labels and in this
manual describe hazards and what to do to avoid or
reduce them.
Danger indicates a hazard with a high level of risk
which will result in serious injury or death.
Warning or Caution indicates a hazard that could result
in injury or death.
{WARNING:
These mean there is something that could hurt
you or other people.
Notice: This means there is something that could
result in property or vehicle damage. This would not
be covered by the vehicle's warranty.
A circle with a slash
through it is a safety
symbol which means
“Do Not,” “Do not do this,”
or “Do not let this
happen.”
Vehicle Symbols
The vehicle has components and labels that use
symbols instead of text. Symbols are shown along with
the text describing the operation or information relating
to a specific component, control, message, gage,
or indicator.
M:This symbol is shown when you need to see your
owner manual for additional instructions or information.
*:This symbol is shown when you need to see a
service manual for additional instructions or information.
iv

Vehicle Symbol Chart
Here are some additional symbols that may be found on
the vehicle and what they mean. For more information
on the symbol, refer to the index.
0:Adjustable Pedals
9:Airbag Readiness Light
#:Air Conditioning
!:Antilock Brake System (ABS)
g:Audio Steering Wheel Controls or OnStar
®
$:Brake System Warning Light
":Charging System
I:Cruise Control
B:Engine Coolant Temperature
O:Exterior Lamps
#:Fog Lamps
.:Fuel Gage
+:Fuses
i:Headlamp High/Low-Beam Changer
j:LATCH System Child Restraints
*:Malfunction Indicator Lamp
::Oil Pressure
g:Outside Power Foldaway Mirrors
}:Power
/:Remote Vehicle Start
>:Safety Belt Reminders
7:Tire Pressure Monitor
_:Tow/Haul Mode
F:Traction Control
M:Windshield Washer Fluid
v

2NOTES
vi

Section 1 In Brief
Instrument Panel ................................... 1-2
Initial Drive Information ........................... 1-4
Remote Keyless Entry (RKE) System . . . . . . . . . . . 1-4
Remote Vehicle Start . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
Door Locks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5
Liftgate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
Windows ........................................ 1-7
Seat Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
Second Row Seats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-9
Third Row Seats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-9
Heated Seats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-10
Head Restraint Adjustment . . . . . . . . . . . . . . . . . . . . 1-10
Safety Belt ..................................... 1-11
Sensing System for Passenger Airbag . . . . . . . . . 1-11
Mirror Adjustment .............................. 1-12
Steering Wheel Adjustment . . . . . . . . . . . . . . . . . . . . 1-13
Interior Lighting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-13
Exterior Lighting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-14
Windshield Wiper/Washer . . . . . . . . . . . . . . . . . . . . . . 1-15
Climate Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-15
Transmission .................................. 1-16
Vehicle Features .................................. 1-16
Satellite Radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-16
Portable Audio Devices . . . . . . . . . . . . . . . . . . . . . . . . 1-17
Steering Wheel Controls . . . . . . . . . . . . . . . . . . . . . . . 1-17
Bluetooth
®
..................................... 1-18
Navigation System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-18
Driver Information Center (DIC) . . . . . . . . . . . . . . . . 1-18
Cruise Control ................................. 1-20
Side Blind Zone Alert (SBZA) . . . . . . . . . . . . . . . . . . 1-20
Rear Vision Camera (RVC) . . . . . . . . . . . . . . . . . . . . 1-21
Ultrasonic Parking Assist . . . . . . . . . . . . . . . . . . . . . . 1-21
Power Outlets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-21
Universal Remote System . . . . . . . . . . . . . . . . . . . . . 1-21
Performance and Maintenance .................. 1-22
StabiliTrak
®
.................................... 1-22
Tire Pressure Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . 1-22
Engine Oil Life System . . . . . . . . . . . . . . . . . . . . . . . . 1-23
Fuel E85 (85% Ethanol) . . . . . . . . . . . . . . . . . . . . . . . 1-23
Driving for Better Fuel Economy . . . . . . . . . . . . . . . 1-23
Roadside Service .............................. 1-24
OnStar
®
....................................... 1-24
1-1

Instrument Panel
United States version shown; Canada similar.
1-2

The main components of the instrument panel are the following:
A. Outlet Adjustment on page 4‑25.
B. Turn Signal/Multifunction Lever on page 4‑4.
C. Instrument Panel Cluster on page 4‑28.
D. Hazard Warning Flashers on page 4‑3.
E. Shift Lever and Range Selection Mode. See
Automatic Transmission Operation on page 3‑32.
F. Tow/Haul Mode on page 3‑36.
G. Driver Information Center (DIC) Buttons. See
Driver Information Center (DIC) on page 4‑41.
H. Analog Clock on page 4‑20.
I. Audio System(s) on page 4‑67.
J. StabiliTrak
®
System on page 6‑6 . Rear Park Aid
Disable Button. See Ultrasonic Rear Parking Assist
(URPA)
on page 3‑46 .
K. Tilt Wheel on page 4‑3.
L. Exterior Lamps on page 4‑11.
M. Dome Lamp Override
on page 4‑17 .Instrument
Panel Brightness
on page 4‑16 .Fog Lamps on
page 4‑16
.
N. Automatic Transfer Case Control. See Escalade
Two‐Mode Hybrid Supplement for more
information.
O. Cruise Control
on page 4‑8 .Heated Steering
Wheel
on page 4‑4 (If Equipped).
P. Horn on page 4‑3.
Q. Audio Steering Wheel Controls on page 4‑105.
R. Dual Automatic Climate Control System
on
page 4‑20
.
S. Pedal Adjust Button. See Adjustable Throttle and
Brake Pedal
on page 3‑30 . Heated Windshield
Washer Fluid Button. See Windshield Washer
on
page 4‑7
. See Power Assist Steps on page 3‑17
(If Equipped).
T. Glove Box on page 3‑62.
1-3

Initial Drive Information
This section provides a brief overview about some of
the important features that may or may not be on your
specific vehicle.
For more detailed information, refer to each of the
features which can be found later in this owner manual.
Remote Keyless Entry (RKE) System
The RKE transmitter is used to remotely lock and
unlock the doors from up to 60 m (195 feet) away from
the vehicle.
Press Kto unlock the
driver door. Press K
again within five seconds
to unlock all remaining
doors.
Press Qto lock all doors.
Lock and unlock feedback can be personalized.
Press and hold &to open or close the liftgate.
Press and hold mto open the liftglass.
Press Land release to locate the vehicle.
Press Land hold for three seconds to sound the
panic alarm.
Press Lagain to cancel the panic alarm.
See Keys
on page 3‑3 and Remote Keyless Entry
(RKE) System Operation on page 3‑4.
Remote Vehicle Start
With this feature the engine can be started from outside
of the vehicle.
Starting the Vehicle
1. Aim the RKE transmitter at the vehicle.
2. Press Q.
3. Immediately after completing Step 2, press and
hold /until the turn signal lamps flash.
When the vehicle starts, the parking lamps will turn on
and remain on as long as the engine is running. The
doors will be locked and the climate control system may
come on.
1-4

The engine will continue to run for 10 minutes.
Repeat the steps for a 10-minute time extension.
Remote start can be extended only once.
Canceling a Remote Start
To cancel a remote start:
.Aim the RKE transmitter at the vehicle and press
and hold /until the parking lamps turn off.
.Turn on the hazard warning flashers.
.Turn the ignition on and then back off.
See Remote Vehicle Start on page 3‑7.
Door Locks
There are several ways to lock and unlock the vehicle.
From outside, use the Remote Keyless Entry (RKE)
transmitter or the key in the driver door. From inside,
use the power door locks or the manual door locks.
To lock or unlock the door with the manual locks, push
down or pull up on the manual lock knob.
Power Door Locks
If available, these switches are located on the
front doors.
K:Press to unlock the doors.
Q:Remove the key from the ignition and press to
lock the doors.
For more information, see:
.Programmable Automatic Door Locks
on
page 3‑11
.
.Rear Door Security Locks on page 3‑11.
1-5

Liftgate
Power Liftgate
Use the Remote Keyless Entry (RKE) transmitter or the
power door lock switches to unlock the liftgate.
There are several ways to open and close the
power liftgate:
.Press and hold &on the RKE transmitter
until the liftgate starts moving.
.Press &on the overhead console inside
the vehicle.
.Press the touchpad switch (B) on the outside
liftgate handle to open.
.Press the lbutton next to the liftgate latch
to close.
To disable the power liftgate function, press OFF on the
overhead console.
Liftglass
There are two ways to unlatch the liftglass:
.Press the button on the underside of the underside
of the license plate applique (A).
.Press mon the RKE transmitter.
1-6

Windows
The power window
switches are located
on the driver door.
In addition, each
passenger door
has a switch for
its own window.
Press the switch to lower the window. Pull the switch up
to raise it.
For more information, see:
.Windows on page 3‑18.
.Power Windows on page 3‑19.
Seat Adjustment
Front Seats
Power Seats
The power seat controls are located on the outboard
side of the front seats.
Move the seat forward or rearward by sliding the control
forward or rearward.
Raise or lower the front or rear part of the cushion by
moving the front or rear part of the control up or down.
1-7

Raise or lower the entire seat by moving the entire
control up or down.
See Power Seats on page 2‑4.
Power Lumbar
To increase lumbar support, press and hold the front
of the control. To decrease, press and hold the rear of
the control.
To raise the height of the support, press and hold the
top of the control. To lower, press and hold the bottom
of the control.
See Power Lumbar on page 2‑5.
Power Reclining Seatbacks
To recline the seatback, tilt the top of the control
rearward.
To bring the seatback forward, tilt the top of the control
forward.
See Power Reclining Seatbacks on page 2‑8.
1-8

Memory Features
The controls for this
feature are located on the
driver door, and are used
to program and recall
memory settings for the
driver seat, outside
mirrors, steering wheel
position, and the
adjustable throttle and
brake pedal feature, if
the vehicle has it.
For more information, see Memory Features
on
page 2‑6
.
Second Row Seats
If the vehicle has a 60/40 split bench or buckets seats,
the seat(s) can be folded for additional cargo space or
folded and tumbled for easy entry and exit to the third
row seats, if the vehicle has them. If the vehicle has
bucket seats, the seatbacks can be also be reclined.
These seats will have either the manual fold and
tumble feature or the automatic seat release fold
and tumble feature.
For more information, see 60/40 Split Bench Seat
on
page 2‑10
or Bucket Seats on page 2‑15.
Third Row Seats
If the vehicle has a third row seat, the seatback(s) can
be folded and the entire seat can be tumbled,
or removed from the vehicle.
For detailed instructions, see Third Row Seat
on
page 2‑21
.
1-9

Heated Seats
Front Seats
On vehicles with heated
and cooled front seats,
the controls are located
on the climate control
panel.
{(Cooled Seat): Press to cool the entire seat.
+(Heated Seatback): Press to heat the
seatback only.
z(Heated Seat and Seatback): Press to heat the seat
and seatback.
Continue to press the desired button to cycle through
the temperature settings: high (three indicator lights),
medium (two indicator lights), low (one indicator light),
and off (no lights).
See Heated and Cooled Seats on page 2‑5.
Rear Seats
The heated rear seat
controls are located
on the Rear Sear
Audio (RSA) panel.
M(Heated Seat): Press to heat the seat cushion and to
cycle through the three temperature settings.
See Heated Seats on page 2‑10.
Head Restraint Adjustment
Do not drive until the head restraints for all
occupants are installed and adjusted properly.
For more information see Head Restraints
on
page 2‑2
.
1-10

Safety Belt
Refer to the following sections for important information
on how to use safety belts properly.
.Safety Belts: They Are for Everyone on page 2‑26.
.How to Wear Safety Belts Properly on page 2‑30.
.Lap-Shoulder Belt on page 2‑39.
.Lower Anchors and Tethers for Children (LATCH)
on page 2‑59 .
Sensing System for Passenger
Airbag
The passenger sensing system, if equipped, will turn off
the right front passenger frontal airbag under certain
conditions. The driver airbags, seat‐mounted side
impact airbags, if equipped, and roof‐rail airbags are
not affected by this.
If the vehicle has one of the indicators pictured in the
following illustrations, then the vehicle has a passenger
sensing system for the right front passenger position.
The passenger airbag status indicator, if equipped, will
be visible on the overhead console when the vehicle
is started.
United States Canada
See Passenger Sensing System
on page 2‑84 for
important information.
1-11

Mirror Adjustment
Exterior Mirrors
Vehicles with outside
power mirrors and
foldaway mirrors have
controls located on the
driver door.
1. Press (A) or (B) to select the driver or passenger
side mirror.
2. Press one of the four arrows located on the control
pad to adjust the mirror.
3. Press either (A) or (B) again to deselect the mirror.
Power Foldaway Mirrors
To fold the mirrors:
1. Press (C) to fold the mirrors out to the
driving position.
2. Press (D) to fold the mirrors in to the
folded position.
The dimming feature automatically adjusts the driver
outside mirror for the glare of the headlamps behind
your vehicle. See Automatic Dimming Rearview Mirror
on page 3‑43 for more information.
Manual Foldaway Mirrors
Manually fold the mirrors inward to prevent damage
when going through an automatic car wash. To fold,
push the mirror toward the vehicle. Push the mirror
outward, to return to its original position.
Interior Mirror
Vehicles with a manual rearview mirror can be
adjusted to see clearly behind the vehicle. Hold the
mirror in the center to move it up or down and side to
side. To reduce headlamp glare during nighttime use,
move the lever at the bottom of the mirror to the right.
Move it to the left for daytime use.
1-12

Vehicles with an automatic dimming rearview mirror.
The dimming feature reduces the glare of lights from
behind the vehicle. The dimming feature comes on
and the indicator light illuminates each time the vehicle
is started.
See Automatic Dimming Rearview Mirror
on page 3‑43
for more information.
Steering Wheel Adjustment
The power tilt wheel control is located on the left side of
the steering column.
Push the control up or down to tilt the steering wheel up
or down.
See Tilt Wheel on page 4‑3.
Interior Lighting
Dome Lamps
The dome lamps come on when any door is opened.
They turn off after all the doors are closed.
The dome lamps can also be turned on by turning
the instrument panel brightness knob, located on the
instrument panel to the left of the steering column,
clockwise to the farthest position. In this position, the
dome lamps remain on whether a door is opened
or closed.
k:The dome lamp override button is located
next to the exterior lamps control.
Press the button in and the dome lamps remain off
when a door is opened. Press the button again to
return it to the extended position so that the dome
lamps come on when a door is opened.
Reading Lamps
For vehicles with reading lamps in the overhead
console, press the button located next to the lamp to
turn it on or off.
The vehicle may also have reading lamps in other
locations. The lamps cannot be adjusted.
1-13

For more information about interior lamps, see:
.Dome Lamps on page 4‑17.
.Reading Lamps on page 4‑17.
.Instrument Panel Brightness on page 4‑16.
Exterior Lighting
The exterior lamps
control is located on the
instrument panel to the
left of the steering wheel.
9:Turns off the automatic headlamps and daytime
running lamps (DRL). Turning the headlamp control to
the off position again will turn the automatic headlamps
or DRL back on.
For vehicles first sold in Canada, the off position
only works when the vehicle is shifted into the
P (Park) position.
AUTO : Automatically turns on the headlamps at normal
brightness, along with the parking lamps and taillamps.
;:Turns on the parking lamps and taillamps.
2:Turns on the headlamps, parking lamps, and
taillamps.
For more information, see:
.Exterior Lamps on page 4‑11.
.Daytime Running Lamps (DRL) on page 4‑15.
.Fog Lamps on page 4‑16.
1-14
