Cadillac ESCALADE HYBRID - BROCHURE 2010 User manual

c a d i l l a c e s c a l a d e h y b r i d 
To learn more, please visit 

Escalade Hybrid RWD/4WD
Escalade Hybrid Platinum RWD/4WD

Gen IV 6.0L V8 VVT, LIVC with Active Fuel Management: 332 hp @ 5100 rpm and 367 lb.-ft. of torque @ 4100 rpm
Rear-wheel-drive system or 4WD system
Electronically variable transmission with four fixed gears
Rear locking differential
 
RWD 21/22

Cargo volume (cu. ft.)
1
– behind third-row seats/with third-row seats removed 16.9/60.3
– with second-row seats stowed and third-row seats removed 108.9
Fuel tank (gal. approx.) 26
Payload RWD/4WD (lbs.)
2
1,404/1,373
Seating 8
Trailering RWD/4WD (lbs.)
3
5,800/5,600


Four-wheel discs, antilock braking system, twin-piston front calipers
 Automatic electronic rear level control system
Xenon High-Intensity Discharge (HID) headlamps and halogen fog lamps
Coil-over-shock, front/5-link rear with magneto-rheological fluid-filled shocks and
computer-controlled real-time damping
Exterior rearview, heated, power-adjustable, power-folding, curb view assistance, LED turn-signal
indicators, puddle lamps and automatic dimming driver side
Open/close; with remote control
Computer-controlled, four-channel electronic stability
control system
 All-speed with brake and engine intervention


Includes two remote transmitters, climate control system and heated seat activation
 Power-adjustable with memory

4
Dual-stage driver and front passenger, front impact; Automatic Occupant Sensing System; driver
and front passenger seat-mounted side-impact for thorax and pelvic protection; and head-curtain side-
impact with rollover protection for all outboard passenger rows
Bose® 5.1 Cabin Surround® Sound System; AudioPilot® noise compensation technology; ten
speakers equalized to Escalade’s interior; steering wheel-mounted audio controls; independent rear-seat
audio controls with two earphone jacks
® 
5
For select phones
Tri-zone automatic electronic climate control with individual settings for driver, front
passenger and rear seating areas


6
Full-featured 8-inch-diagonal touch-screen DVD-based navigation system

7
Directions & Connections Plan with Turn-by-Turn Navigation
8
standard for the first year
In-dash DVD with roof-mounted flip-down eight-inch-diagonal screen,
two 2-channel wireless headphones, auxiliary audio/video jacks and remote game plug-in
Automatic operation when vehicle is put in Reverse
 Front seats with leather seating surfaces, heated and cooled seatbacks and cushions with
three temperature settings, 14-way power adjuster, including 4-way power lumbar; memory settings
for two drivers
 Audio system, cruise control, OnStar
7
and Hands-Free Calling
9
Power-adjustable steering column
 Includes individual sensors with specific pressures displayed in Driver
Information Center
 Driver and front passenger windows with Express-Up and -Down

10
With three trial months

Includes unique front fascia with upper and lower grilles, LED headlamps, 22-inch
11
multi-spoke
chromed aluminum wheels, exclusive Light Linen/Cocoa interior, TEHAMA
12
leather first- and second-row
seating surfaces, embroidered Cadillac insignias and unique door sills, genuine Olive Ash and Burled Walnut
wood trim, Rear-Seat Entertainment System with two 7-inch-diagonal screens integrated into the back of
the front head restraints, and heated and cooled cup holders
Gold MistBlack RavenInfrared Tintcoat Silver LiningStealth Gray
13
Black IceGalaxy Gray
13
White Diamond Tricoat

 Cargo and load capacity limited by weight and distribution.  Maximum payload capacity includes weight of driver, passengers, optional equipment and cargo.  Maximum trailer weight ratings are calculated assuming a base vehicle, plus driver. See your Cadillac
dealer for additional details.
 Always use safety belts and the correct restraint for your child’s age and size. Even in vehicles equipped with the Automatic Occupant Sensing System, children are safer when properly secured in a rear seat in the appropriate infant,
child or booster seat. Never place a rear-facing infant restraint in the front seat of any vehicle equipped with a passenger air bag. See the Owner’s Manual and child safety seat instructions for more safety information.
 Go to gm.com/bluetooth to find out which
phones are compatible with the vehicle. Map coverage available in the United States, U.S. Virgin Islands, Puerto Rico and Canada.
 Call 1-888-4ONSTAR (1-888-466-7827) or visit onstar.com for details and system limitations.  Not available in certain areas. Visit
onstar.com for coverage map.
 OnStar Hands-Free Calling requires a Hands-Free Calling-enabled vehicle, existing OnStar service contract and prepaid minutes or enrollment in a shared minutes plan. Not available in certain markets. Calls may be made to the
U.S. and Canada only.
 XM Radio requires a subscription, sold separately by XM after the first 90 days. XM Radio U.S. service only available in the 48 contiguous United States and the District of Columbia. For more information, visit gm.xmradio.com.  Use only
GM-approved tire and wheel combinations. Unapproved combinations may change the vehicle’s performance characteristics. For important tire and wheel information, go to gmaccessorieszone.com or see your dealer for details.
 The TEHAMA trademark is used
under license by General Motors.
 Not available on Platinum Edition.
GM, the GM Logo, Cadillac, the Cadillac Logo, and the slogans, emblems, vehicle model names, vehicle body designs and other marks appearing in this document are the trademarks and/or service marks of General Motors, its subsidiaries, affiliates or licensors. Bose,
Cabin Surround and AudioPilot are registered trademarks of the Bose Corp. OnStar and Directions & Connections are registered trademarks of OnStar LLC. The Bluetooth word mark is a registered trademark owned by Bluetooth SIG, Inc. and any use of such mark
by Cadillac is under license. SIRIUS, XM and all related marks and logos are trademarks of SIRIUS XM Radio Inc. and its subsidiaries. ©2010 General Motors. All rights reserved. GM reserves the right to make changes at any time and without notice in prices, colors,
materials, equipment, specifications, models and availability.
10CADEHYSPE02
ESCALADE HybriD
2010
