CADSBI motion SMART Quick guide

CADSBImotion SMART
CADSBImotion SMART LED Controller –the perfect solution for
controlling addressable LED strips.
EN
Operating and safety instructions

EN
Table of contents Page 3

Table of contents
•Terminal assignment Page 4
•Legend of the image symbols used Page 6
•Introduction Page 7
•Intended use Page 7
•Scope of delivery Page 7
•Technical data Page 7
•Safety instructions Page 8
•Application Page 9
•Preparation Page 9
•Establish voltage supply Page 9
•Establish connection Page 9
•Usage Page 9
•Cleaning and maintenance Page 10
•Disposal Page 10
•Warranty Page 10
•Warranty processing Page 10
•Service Page 10
EN 5

Terminal assignment
Front view
2 3 4
1
Back view
567
Explanation
1
2
3
LED Controller
Socket for the power supply
Socket for the power supply
4LED connection socket
5Antenna connector
7Infrared receiver
connection
Accessories
6Microphone connector
8Connector plug
power supply
9Connector plug
LED strip
External antenna
10
8
10
9
DATA
EN 6

Legend of the image symbols used
Read instructions! Danger and safety symbol
Observe safety instructions!
DC current / voltage Warning!
Danger due to electric shock!
W
Watt (active power) Protection class III
• Introduction
Congratulations on the purchase of your new
high quality LED controller. These operating
instructions are an integral part of your
purchased product. It includes important
usage and safety instructions. Please
familiarize yourself with all safety and
operating instructions before using the
controller.
The product may only be used in accordance
with the technical data and specified areas of
application of this documentation.
If the product is passed on to third parties, all
documents must also be handed over.
CADSBImotion SMART LED Controller
•Intended use
This product is suitable for indoor use only.
The product's field of application is limited to
private households and is therefore not
intended for commercial use.
•Scope of delivery
1 CADSBImotion SMART LED Controller
1 Instruction manual
1 external antenna
1 2pol. Plug
1 3pol. Plug
•Technical data
Operating voltage: 24V, 12V, 5V
Max Current: 4,6 A
Max LED. Current: 4,5 A
Stand By Consumption: 3,5 W
Operating temperature: +18°C –30°C
Air Humidity: 30% - 70% (Non
condensing)
Protectionclass:
EN 7

Safety instructions
Attention! Damage caused by non-observance
of the operating instructions will void the
warranty! No liability is accepted in the event
of consequential damage! No liability is
accepted for personal injury or damage to
property caused by failure to observe the
safety instructionsor by improper handling!
oWARNING! Danger to life and accident
for infants and children!
Never leave your children unattendedwith
the packaging material. There is a risk of
injury and suffocationfrom the packaging
material. Due to underestimation of the
dangers, always keep children away from
the product.
oThis product does not belong in children's
hands. It is not a toy. The dangers arising
from handling the product cannot be
recognized by children.
oThis product can be used by children aged
from 12 years and above and persons with
reduced sensory, mental or physical
capabilities or lack of experience and
knowledge if they have been given
supervision or instruction concerning use of
the product in a safe way and understand
the hazards involved. Cleaning and
maintenance by children is not permitted.
The product is not a toy. Children must not
play with the product.
oCAUTION!DANGER OF OVERHEATING
Never operate the product in its packaging.
oTo avoid accidental damage, it is advisable
to store the product back in its packaging
after use.
oDo not pull on the connected cables and
ensure that the cables are laid without
tripping.
oYou can use the product on all normally
flammable surfaces.
oDo not attach any additional objects to the
product.
oAvoid danger to life from
electric shock!
oBefore use, make sure that the existing
operating voltage of the product matches
the required operating voltage of the LED
strips.
oCheck the product for any damage before
and after use.
oThe device must never be used if damage is
detected.
oThe product does not contain any parts that
can be serviced by the consumer.
oUse the product only with a suitable power
supply (24V, 12V or 5V ) and a suitable
LED strip (24V, 12V, 5V , maximum 4.5A)
otherwise any warranty claims will be void.
oNever open the product or insert sharp
objects is the product.
oThe product must be protected from
mechanical stress and hot surfaces.
oIn case of external cleaning, it is mandatory
to disconnectthe power supply of the
product (unplug the power supply).
oNever touch plugs or the device itself if
your hands are wet.
oDisconnect the product from the power
supply if it will not be used for a long period
of time (e. g. vacation).
oIf you are not sure or have any questions
about the product, please contact us.
oNote, the controller has a low power when
switched off. To switch off the device
completely, you must disconnect the device
from the power supply.
EN 8

Application
• Preparation
IMPORTANT! Remove all packaging
material from this product!
Connect the external antenna to the
controller via the antenna
connection socket
• Establish voltage supply
CAUTION! Avoid dangerto life from
electric shock!
Plug-in power supply:
➢Pay attention to the maximum output
voltage of the power supply! (max.
24VDC)
➢Connect your power supply unit to the
socket for the voltage supply
Power supply unit with open connection
cable:
➢Connect your power supply unit with
the supplied connector Power supply
➢Pay attention to the polarity of the
plug and the connecting cable of the
power supply!
The pin assignment can be found on
page 6. Please also pay attention to the
maximum output voltage of your
power supply! (max. 24VDC)
➢Connect the wired connector plug
to the controller
To do this, insert the power supply
connector plug into the power
supply socket.
10
1
5
2
8
8
3
• Establish connection
When you have successfully established
the power supply, you can connect to the
controller as follows:
➢Open your wireless settings (this may
differ depending on your device).
➢Search for "WLED-AP" under available
networks
➢Establish a connection with "WLED-AP
➢SSID: WLED-AP
➢Password: WLED1234
➢Then open your Internet browser
(Firefox, Internetexplorer,Edge, etc.).
➢Enter 4.3.2.1 in the address bar.
➢On the home screen, you now have
access to your controller's controls.
• Usage
A detailed list and description of the
controller's functionalities can be found at
the following links:
https://www.cadsbi-shop.de/downloads/
https://github.com/Aircoookie/WLED/wiki
APP:
IOS Android
1
8
EN 9

EN 10
• Cleaning and maintenance
CAUTION! RISK OF ELECTRIC SHOCK
First disconnect the power supply between the
controller and the power supply unit.
CAUTION! RISK OF ELECTRIC SHOCK
Due to electrical safety, never clean the
product with water or other liquids or even
immerse it in water. Do not use solvents,
gasoline or similar. The product may be
damaged in the process.
We recommend using a soft lint-free cloth or a
soft brush for cleaning.
• Disposal
•The packaging is made of recyclable
materials which you can dispose of at your
local recycling center.
•In the interest of environmental
protection, when your product has reached
the end of its service life, do not dispose of
it in the household waste. Dispose of it
properly.
•You can find out about the possibilities and
information on disposing of the discarded
product from your local municipality and
city administrationas well as from your
local recycling center.
• Warranty
•The delivered product was conscientiously
checked before delivery and carefully
produced according to strict quality
guidelines. Should you find any defects in
the product, you are entitled to legal rights
against the seller of the product. The legal
rights are not limited by our following
warranty explanation.
•This product is guaranteed for 2 years from
the date of purchase. Keep the original
sales receipt in a safe place. This serves as
proof of your purchase. The warranty
period begins on the date of purchase.
•Should a material or manufacturingdefect
occur within 2 years from the date of
purchase of this product, the product will
be repaired or replaced free of charge after
inspection by us. If the product has been
improperly used, damaged or serviced, the
warranty will be void.
•The warranty service applies exclusively to
material or manufacturingdefects.
Excluded from this warranty are product
parts that are subject to normal wear and
tear (e. g. connectors).
• Warranty processing
Please note the following information to
ensure that your request is processed quickly:
•Please have proof of purchase ready for all
inquiries, including the invoice number as
well as the item number.
Refer to the nameplate on the product for
the part number.
•If there are any functional errors or other
defects, please contact us first. You can
find the contact options below.
•A product recorded as defective can then
be returned to us, enclosing the original
purchase receipt and stating the
description of the defect and the date of
occurrence.
• Service
EN Daniel Smith & Patrick Brademann GbR
(CADSBI Smith & Brademann GbR)
Lönsstraße11
D-34125 Kassel
[email protected]

CADSBImotion SMART
Thank you for chosen CADSBI.
Enjoy your new Controller.
