caem UNIZINC User manual

UNIZINC
Installation
Guide
Doc G13 Rev 1
Date 03.09.2021

1. IMPORTANT CONSIDERATIONS
1) CHECK THE CAPACITY OF THE SUPPORTING FLOOR.
2) CHECK THE LEVELLING OF THE FLOOR.
3) SHELVING SYSTEMS MUST BE ASSEMBLED VERTICALLY.
4) INDIVIDUAL SYSTEMS, WHOSE HEIGHT EXCEED SIX TIMES THE DEPTH OF THE
SHELVING, MUST BE ANCHORED TO THE WALL (IN THE UPPER PART).
5) MINIMUM EXTENSION STRENGTH OF THE ANCHORING - 150N (15KG)
6) MARK OUT THE EXACT POSITION OF THE SHELVING ON THE FLOOR
7) ASSEMBLY TOOLS:
A) SET OF SPANNERS
B) SCREWDRIVER
C) PLIERS
D) GUM-HAMMER
E) DRIFT

1. IMPORTANT CONSIDERATIONS 2. FRAME BRACING
UNIZINC
Frame Height: 2475
Number of Braces Required: 3
Position of the Bracing upper Slot:
1. 5
2. 29
3. 61

3. UNIZINC UPRIGHTS
This image (below) shows the upright positioned the
correct way up.
Smaller cutouts immediately above the larger ones.
TOP
BOTTOM
Smaller cutouts.
Larger cutouts.

UNIZINC
Insert the plastic foot (1) in the lower part of the
upright (2)
4. PLASTIC FOOT ASSEMBLY

5. ASSEMBLY OF BRACING
Before Assembling the frames, make sure you have
settled the uprights correctly (upper and lower part)
Insert the bracing in the
internal side of the up-
right (1) and block it by
bending the tang (2) to-
wards the inside.
To ensure bracing does
not move please ensure
you use the locking clip.
(Please see image above).

UNIZINC
6. ASSEMBLY OF BEAMS
Beams are made up of a length
of metal terminated by Red
clips.
Insert the cur’s lower hooks into the back holes of the
upright (1), then turn the beam, insert the upper hooks
too and nally push down (2).
IMPORTANT: NEVER USE A HAMMER
TO ASSEMBLE.
YOU RISK DAMAGING THE BEAMS!

7. ASSEMBLY OF SHELF PANELS
Insert the shelf panel (1) in the groove of the beam (2)

UNIZINC
8. BLOCKING BEAMS
Fix the blocking beams (1) to the upright (2) with
self-tapping screws.
Use 1 blocking beam on each run and every 5 modules:
Run of 3 modules? 1 blocking beam.
Run of 8 modules? 2 blocking beams.
Run of 11 modules? 3 blocking beams.

9. GONDOLA
When connecting gondola
units together use side
clips.
Please ensure, to avoid
slipping, these are self-
tapped into place.
When connecting gondola
units together use double
feet to retain a level unit
and avoid damage to the
oor surface.

VERSATILITY
CUSTOM DESIGN
RESISTANCE
CUSTOMER CARE
