Caffitaly System S03 User manual

Model S03
Instruction book
Mode d'emploi
English Français

2
1
3
4
5
6
7
8
9
10
11
2
Table of contents
Introduction
Warning symbols.....................................................................................3
Your Cataly System contact ...............................................................3
Important Safeguards ............................................................................4
Caution......................................................................................................5
Instructions for the power supply cord...............................................5
Description of machine components .................................................6
Installation
First use or after a long period of disuse ............................................7
Turning on the appliance.......................................................................8
General operating indications..............................................................9
Adjusting the cup/mug height........................................................... 11
Dispensing the product
Dispensing coee.................................................................................. 12
Dispensing other beverages............................................................... 13
Programming the quantity of coee in a cup.................................. 14
Cleaning and Maintenance
Daily maintenance ................................................................................ 15
Descaling ................................................................................................ 16
Miscellaneous
Troubleshooting.................................................................................... 20
Technical data ........................................................................................ 20

3
Introduction
Your Cataly System contact
[email protected]om
Dear Customer,
Thank you for having chosen our product and for your condence in our company.
You can savour your favourite hot beverages at any time of the day with our appliance by choosing one
of the capsules that Cataly oers you. For example: An espresso, a cocoa-avoured beverage or a tea
will be ready in just a few seconds.
Warning symbols
CAUTION
This is the safety warning symbol. It is used to call your attention to possible risks of
personal injury. Abide by the safety messages provided in order to avoid possible injury
or death.
NOTE
This is the symbol used to highlight some actions that will optimise use of the appli-
ance.
Not dishwasher safe Maintenance tips
This symbol is used to highlight a WHITE light indication.
This symbol is used to highlight a RED light indication.
This symbol is used to highlight an ORANGE light indication.

4
Introduction
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always be followed to
reduce the risk of re, electric shock, and/or injury to person, including the following:
1. Read all instructions and information in this instruction book and any other literature included
in the carton referring to this product before operating or using this appliance.
2. Do not touch hot surfaces (i.e. steam wand). Use handles or knobs.
3. To protect against re, electric shock, and personal inury, do not place cord, plugs, or aplliance
in water or other liquid.
4. This appliance must be kept out of the reach of children.
5. Unplug from outlet when not in use and before cleaning.
6. Allow to cool before putting on or talking o parts, and before cleaning the appliance.
7. The use of accessory attachments not recommended by the appliance manufacturer may result
in re, electric shock, or personal injury.
8. Do not use outdoors.
9. Do not let cord hang over edge of table or counter, or touch hot surface.
10. Do not place on or near a hot gas or electric burner, or in a heated oven.
11. This machine was designed to process normal household quantities only. Not suitable for
connuous operation or commercial use.
12. Do not operate any appliance with a damaged cord or plug, if the aplliance malfunctions, or has
been damaged in any manner. Return appliance to an authorized service facility for
examination, repair, or adjustment.
13. Do not use if the water tank is not lled.
14. Always use cold water. Warn water or other liquids could casue damage to the appliance.
15. When plugging in the machine, always turn appliance“OFF”, attach power cord to the machine
rst, then plug cord into wall outlet.To disconnect, always turn appliance“OFF”, then remove
plug from wall outlet.
16. Use extreme caution when using hot steam.
17. Do not use appliance for other than intended use.
SAVE THESE INSTRUCTIONS.

5
Introduction
CAUTION
This appliance is for household use only. Any servicing, other than cleaning and user maintenance,
should be performed by an authorized service centre. Do not immerse machine in water. To reduce
the risk of re or electric, shock, do not disassemble the machine.There are no parts inside the
machine serviceable by the user. Repair should be done by authorized service personnel only.
1. Check voltage to be sure that the voltage indicated on the nameplate corresponds with your
voltage.
2. Never use warm or hot water to ll the water tank. Use cold water only.
3. Keep your hands the cord away from hot parts of the appliance during operation.
4. Never clean with scrubbing powders or harsh cleaners. Simply use a soft cloth dampened with
water.
5. For optimal taste of your coee, use puried or bottled water. Periodic descaling is still
recommended every 2-3 months.
6. Do not use caramelized or avored coee beans.
INSTRUCTIONS FOR THE POWER SUPPLY CORD
A. A short power-supply cord (or detachable power-supply cord) is to be provided to reduce risks
resulting from becoming entangled in or tripping over a langer cord.
B. Longer detachable poer-supply cords or extension cords are available and may used if care is
exercised in their use.
C. If a long detachable power-supply cord or extension cord is used:
1. The marker electrical rating of the detachable power-supply cord or extension cord should
be at least as great as the electrical rating of the appliance.
2. If the aplliance is of the grounded type, the extension cord should be a grounding-type
3-wire cord.
3 The longer cord should be arranged so that it will not drape over the counter top or table
top where it can be pulled on by children or tripped over.

6
Power cord Power on/o switch
"Multifunction"
indicator light
"Filter coee"
dispensing button
"Long coee"
dispensing button
"Espresso"
dispensing button
Drip tray
Adjustable cof-
fee dispenser
Lever for opening capsule
compartment
Used capsule
drawer
Float
Capsule compartment
Water tank
Water tank cover
Description of machine components
Introduction

5 6
1
43
2
7
First use or after a long period of disuse
Fill the tank with fresh, still water. Plug in the appliance and turn it on.
The buttons (espresso, long coee and lter
coee) and the multifunction indicator light
blink at the same time.
Place a large container under the dispensing
spout.
Press one of the coee buttons (espresso,
long coee or lter coee). Wait for the
machine to complete the priming cycle and ll
with water.The multifunction indicator light
switches o.
The buttons (espresso, long coee and lter
coee) blink at the same time; the machine is
warming up.
NOTE:
If the coee buttons and the multifunction indicator light continue to blink
after the lling procedure has ended, repeat the steps in point 5.
1

8
7
1 2
8
Turning on the appliance
2Turning on the appliance
At the end of this operation, empty out the
water from the used capsule drawer.
When the buttons (espresso, long coee,
lter coee) turn on and remain steadily
lit, rinse twice by pressing the lter coee
button.
Wait for the machine to complete the rinse
cycle.
Fill the tank with fresh, still water. Turning on
the appliance The buttons (espresso, long coee and lter
coee) blink at the same time; the machine is
warming up.When the buttons remain steadily
lit, the appliance is ready for operation.
2

1
3 4
2
9
General operating indications
The buttons (espresso, long coee and lter
coee) blink at the same time.
The water tank is empty when the multifunc-
tion indicator light blinks in RED and the
appliance emits 3 beeps followed by a single
intermittent beep.
Fill the tank with fresh, still water.
When the multifunction indicator light blinks
ORANGE and the machine emits 3 beeps, it is
recommended to perform the descaling cycle
(see Ch. 9).
When the buttons remain steadily lit, the ap-
pliance is ready for operation.
Press one of the coee buttons (espresso,
long coee or lter coee). Wait for the
machine to complete the priming cycle and
ll with water.
When the water runs out during operation
Descaling signal Heating
3

3
12
4
10
If the lever is raised while a product is being
dispensed.
General operating indications
CAUTION!
Raising the lever incorrectly while dispensing a product may cause brief
splashes of hot water.
Danger of scalding!
The multifunction indicator light blinks RED and
an intermittent beep sounds.The appliance will
immediately stop dispensing.
Close the lever. Press a button to reset the alarm.
The appliance is ready for use.
If the lever is raised
3

1
3 4
2
11
Adjusting the cup/mug height
The appliance can be adjusted for the use of
mugs or espresso cups. The appliance is initially set for the use of large cups or mugs.
To use espresso cups, manually lower the end
part of the dispensing spout In this way you can obtain the best results
when using small espresso cups.
4

1
3
2
4
5 6
12
Dispensing coee
Raise the lever to open the capsule compart-
ment. Insert the capsule, pressing it gently into place.
Close the lever rmly. Place a cup or mug under the coee dispensing
spout.
Press the desired coee button only once. The selected coee button will blink.The
appliance will stop dispensing on reaching the
programmed quantity and emit a beep.
Caution! Before you
start brewing, make sure
the capsule container is not
full.
5

78
13
Dispensing other beverages
Raise the lever to eject the used capsule into
the drawer. Close the lever.
Dispensing other beverages
Capsules for preparing beverages such as tea, chamomile tea, lter coee, etc. are available.
For their use, proceed as directed in the previous chapter; on reaching step 5, press "Filter coee".
To prepare beverages using barley capsules, cocoa drinks, etc., proceed as directed in the
previous chapter; on reaching step 5 press the "Espresso" or "Long coee" button, depending
on the desired quantity.
NOTE:
Traces of product just dispensed may remain in the circuit of the machine.
When switching from one product to another, in order to fully enjoy the avour of
the beverage we suggest rinsing the machine by pressing the coee button as if
to dispense a coee without inserting a capsule.
NOTE:
The quantity of coee dispensed can be reprogrammed according to
personal taste, and in accordance with the size of the cup or mug used.
Please refer to chapter 7 for reprogramming instructions.
6
6

5 6
1
3
2
4
14
Programming the quantity of coee in a cup
Raise the lever to open the capsule compart-
ment. Insert the capsule, pressing it gently into place.
Close the lever rmly. Place a cup or mug under the coee dispens-
ing spout depending on the type of coee you
wish to program.
Caution! Before you
start brewing, make
sure the capsule container is
not full.
On reaching the desired amount of coee in a
cup, release the button. Now the button is pro-
grammed. To reprogram the button or program
another button repeat the above steps.
The quantity of coee dispensed can be
programmed up to a maximum of 250 ml.
Press the desired coee button and keep it
pressed down.
7

21
3 4
Use a soft cloth and a neutral
detergent to clean the surfaces of the
appliance.
Do not spray the appliance with jets
of water when cleaning.
The plastic parts of the appliance are
not dishwasher safe.
15
Remove the drip tray and used capsule drawer.
Remove the grid. Empty the drip tray and rinse
it out with fresh water.
Lift the capsule drawer; empty and rinse it out.
Daily maintenance
Remove the water tank. Empty and rinse out
the tank. The water tank is NOT dishwasher
safe.
8

21
16
Descaling
Turn o the machine. Empty and rinse out the used capsule drawer
and drip tray.
When the multifunction indicator light blinks
ORANGE and the machine emits 3 beeps, it is
recommended to perform the descaling cycle,
as illustrated below.
CAREFULLY read the directions for use on the package of the descaling agent. Avoid
contact with eyes, skin and machine surfaces. Switch the appliance o during descal-
ing, and do not lift the lever.
A person must be present during the operation.
Do not use vinegar: it could damage your appliance!
It is advisable to use the Cata System descaling agent. It has been studied to com-
ply with the technical characteristics of the appliance, in full observance of consumer
safety. The descaling agent must be disposed of in compliance with manufacturer
instructions and/or with current regulations in force in the country where the appli-
ance is used.
The machine features an
advanced program that monitors
how much water is used to dis-
pense beverages.This monitoring
process provides the user with
indications as to
when the machine needs to be
descaled. Specic indications are
given in chapter 3.
9

8
5
7
6
43
17
Descaling
Place a container (at least 250 ml) under the
coee dispensing spout.
Keep the buttons pressed down (espresso and
long coee) and at the same time turn on the
machine by pressing the power on/o switch.
Make sure the lever is lowered.
As well as the
As well as the long coee
button, the
button, the multi-
function indicator light also blinks alternately
(RED and ORANGE).
(RED and ORANGE). Press the long coee
button to start the descaling cycle.
Remove and empty the water tank.
Mix the descaling agent with water as
Mix the descaling agent with water as
instructed on the package and pour the
instructed on the package and pour the
solution into the tank.
solution into the tank.
9

12
11
13 14
18
Descaling
When the cycle is complete, as well as the
When the cycle is complete, as well as the long
coee
button, the
button, the multifunction
indicator
indicator
light also blinks alternately (RED and ORANGE).
light also blinks alternately (RED and ORANGE).
Carefully rinse out the water tank and ll it
with fresh drinking water.
Empty and rinse out the used capsule drawer
and drip tray.
As well as the
As well as the long coee
button, the
button, the multi-
function indicator light also blinks alternately
(RED and ORANGE).
(RED and ORANGE). Press the long coee
button to start the rinse cycle.
10
9
The appliance dispenses the descaling solution
at intervals (5 doses with a 10 minute
pause between each one, for a total dura-
tion of about 45 minutes). During this step,
when the buttons must not be pressed,
the multifunction indicator light blinks alter-
nately (RED and ORANGE).
If the container lls up, empty it.
9

18
17
19 20
16
15
19
Descaling
Use a soft cloth and a neutral
detergent to clean the surfaces of the
appliance.
Rinse water will be run through the machine.
During this step the multifunction indicator
light blinks alternately (ORANGE and RED twice
in a row).
If the container lls up, empty it out.
When the rinse cycle is complete, in addition
When the rinse cycle is complete, in addition
to the
to the long coee
button, the
button, the multifunction
indicator light also blinks alternately (RED and
indicator light also blinks alternately (RED and
ORANGE).
ORANGE).
The machine will emit a beep.
Carefully rinse out the water tank and ll it
with fresh drinking water.
Empty and rinse out the used capsule drawer
and drip tray. Press the long coee button to quit the cycle.
9

See the data plate on the bottom of the
machine
Max. 15 bar
about 4 kg
< 70dB A
1,2 litres
ambient temperature: 10°C ÷ 40°C
170 mm 260 mm 320 mm
20
The materials and
objects in contact with
food products comply
with the requirements
of European Regulation
1935/2004.
11 Technical data
Troubleshooting - 11 Technical data
10
PROBLEM CAUSE SOLUTION
- No coee is brewed. -The water tank is empty, the
multifunction indicator light
is lit in RED.
- Fill the tank with fresh water. Press
one of the coee buttons to ll the
circuit.
-The coee is not hot
enough.
- Cold cups / mugs.
- Scale build-up in machine.
- Preheat cup / mug.
- Descale.
-The lever cannot be
lowered.
-The used capsule drawer is
full.
- Capsule stuck inside the
machine.
- Empty out the used capsule drawer.
- Remove the used capsule.
