Cair Smoke+ Operating instructions

Smoke+
Interlinked Smoke Alarm
Smart Technology, Made to Care
The Smoke+ is an intelligent, discreet, compat interlinked smoke detector. It can
be easily programmed to interlinked with other Smoke+ or Heat+ sensors,
ensuing all connected devices alert when needed.
The Smoke+ provides the earliest warning of a developing fire whilst being highly
resistant to nuisance alarms.
Cair (UK) Ltd.
Hanson Lane, Halifax, West Yorkshire, HX1 4SD
T: 01422 399 155 E: sales@we-cair.com W: www.we-cair.com
Safety
Do not dismantle or alter the unit. Do not open the case.
Indoor use in dry location only.
Disposal
All electronic waste should be disposed of in accordance
with the latest legislation.
It must be disposed of within the electrical and electronic
waste stream and not be disposed of in the normal waste
stream. Recycling electrical waste products (including the
lithium batteries contained within) help to conserve
natural resources and prevent adverse effects on the
environment. Contact your supplier should you require
more information.
Declaration of Conformity
Hereby, Cair (UK) Ltd declares that the radio equipment
type Smoke Alarm is in compliance with Directive
2014/53/EU.
Programming
Guide
Batteries / Lifespan of Alarm
The smoke alarm contains a non-user replaceable lithium
battery, which should last up to 10 years, dependent upon
use and the environment in which it is located. Extended
periods in alarm mode will significantly reduce the life of
the battery. In the event of a low battery, the unit will beep
every 60 seconds. When the smoke alarm battery
becomes low, the complete smoke alarm unit must be
replaced.
Irrespective of the battery life, the smoke alarm has a fixed
10 year lifespan indicated by the date printed on the side
of the alarm. The alarm must be replaced by this date.
The radio transmitter within the pattress contains a 3V
lithium coin cell battery which is also not replaceable by
the user. Typically, the battery will last up to 5 years
dependent upon the application. When the battery
depletes, the complete transmitter unit must be replaced.
It is also recommended that the entire smoke alarm is
replaced.
Packing for shipment
The equipment containing cells or batteries must be
packed in strong rigid packaging and must be secured
against movement within the outer packaging to prevent
accidental activation. The sender’s name and return
address must be clearly visible on the outer packaging.
Operating Frequency 869.2125 MHz radiating less than 10mW (Other custom frequencies possible)
Dimensions H90 x W90 x D58 mm
Power Supply Sealed lithium battery
Transmitter Battery Life Up to 5 years
Device Life 10 years
Wireless Range Up to 600m line of sight
Compliance CE / RoHS 2 / RED
Warranty 24 months
Specifications
Programming
Guide V 1.0
V 1.0
Product Description
The Smoke+ is a discreet, compact unit which is particularly sensitive to slow, smouldering fires typically originating in
living rooms, bedrooms and hallways whilst being highly resistant to nuisance alarms. If smoke is detected, a loud
audible alert will be emitted and a radio message will be sent to the alarm receiving device. The Smoke+ is an interlinked
smoke detector, and can be connected to other Smoke+ or Heat+ devices, so that each of them alerts when one of the
devices is activated. This guide will explain how to connect and disconnect these devices.
Note: This is a supplementary guide to the manufacturer’s User Manual. Please read both documents before installing
and using the smoke alarm.
Interlinking Devices
Firstly, unpack all units to be connected and separate the sensors from the mounting plates. Place the Smoke+ and
Heat+ devices that are to be paired close together, within 0.3m. Turn Switch 1 on the PCB into the ON position for all
devices to be paired (see picture). The LEDs on all devices will flash rapidly red and orange.
Tip: A suitable tool such as a head of a pin/tweezers can be used to change the position of the switch.
To pair the devices, press Switch 2 on the PCB on one of the devices to be connected . The red LED will rapidly flash on
all devices. The detectors will be paired when the LEDs cease flashing on all units; there is normally a 12 second delay
between each
The sensors can now be positioned and secured into the mounting plate. Please make sure the tab on each device is
pushed in fully and twist to complete the connection. In order to test the pairing, press the test button on any connected
Smoke+ or Heat+ detector. The unit will beep three times then fall silent. All other detectors will sound until the test is
stopped. To stop the test, press the test button on any Smoke/Heat+ detector. The sensors will emit a series of clicks.
When all clicks cease the test is complete.
To pair another Smoke+ or Heat+, place the new device close to any device that has already been installed and put
Switch 1 into the ON position. Press the test button on a paired device. All the devices in the paired group will now
sound. The new device is paired when the red LED stops flashing.
To unpair a device, turn Switch 1 to the OFF position. Now press and hold down Switch 2. Whilst still holding down
Switch 2, return switch 1 to the ON position and then release. The LEDs will flash and the device has now been unpaired.
Note: Ensure this is carried out for each individual device you wish to unpair.
Once all devices have been paired as desired, you are now ready to assign and install the Smoke+ and Heat+ devices. To
assign the device to a an alarm receiving device, press the test button when the receiving device is in registration mode.
Important: Each individual device must be programmed to the alarm receiving unit individually.
Cair (UK) Ltd.
Hanson Lane, Halifax, West Yorkshire, HX1 4SD
T: 01422 399 155 E: sales@we-cair.com W: www.we-cair.com
Positioning & Installation
This section contains general information about positioning the alarm. Please refer to the manufacturer’s manual
included with this alarm for full information on how to position correctly. The smoke alarm should be mounted on the
ceiling in the middle of a room or hallway, and at least 300mm away from walls, light fittings, doors, windows, vents
and bathrooms/shower rooms. If it is necessary to mount it on a wall, ensure it is at least 150mm below the ceiling
and 300m away from a corner. Ensure the chosen location is also within range of the alarm receiving device and any
other connected devices. The pattress can be secured to the ceiling/wall using the enclosed fixings. Once the pattress
is mounted, the wire from the smoke alarm should be plugged into the radio interface, ensuring that the plug is
orientated correctly and a click is heard.
To assemble the smoke alarm, first ensure that the wire is folded neatly into the pattress. Align the line on the head
with the arrow on the base. then turn the head clockwise until the locking tag clicks into place. This action will also
switch the smoke alarm on. The smoke alarm can now be activated using the test button on the front surface of the
unit to ensure that it’s functioning correctly and that the radio transmitter operates. To separate the smoke alarm from
the pattress, depress the locking tag and turn the head anti-clockwise. This action will also switch the smoke alarm
off. .
Status Indications
The smoke alarm features a sounder and a red LED indicator which can be seen on the front of the unit. The flashing
LED and/or associated beeps indicate the following conditions:
●Power - One brief flash every minute with no beep confirms the unit is powered correctly
●Low Battery - One flash every minute with one beep indicates a low battery
●Test Button Jammed - A single beep every 11 seconds indicates the test button is stuck
●Fault - A double beep every minute indicates a fault or malfunction
●Test - Repeated flashing of the LED and a single series of 3 beeps
●Alarm - Repeated flashing of the LED every second and a series of 3 beeps sounding every 4 seconds
●Alarm Silenced - Brief flash every 12 seconds indicates an alarm condition if the alarm has been silenced
Testing
Testing should take place weekly to ensure correct operation, and also to check that the link to the alarm receiving
device is still working. Testing can be carried out by simply pressing and holding the test button for a few seconds. The
alarm should sound three times with a flashing LED and the radio transmitter should activate. Note: The electronic test
button provides a full test of the alarms functionality. Do not try to test the alarm using smoke, heat or naked flame as
damage will occur.
Silencing
The smoke alarm can be silenced by momentarily pressing the test button. This is ideal for non-emergency situations
where nuisance alarms may have been created, for example, by steam. The red LED will flash every 12 seconds to
remind you that the smoke alarm has been silenced and will automatically reset to quiescent mode after 10 minutes.
Low battery warnings can also be silenced. As low battery alerts often arise during the night, the audible warning can
be temporarily silenced for ten hours by momentarily pressing the test button.
Cleaning
The smoke alarm should be cleaned regularly to ensure it works properly. The pattress can be cleaned with a very
lightly damped cloth. Do not use an abrasive material, any chemical cleaning agents or any other liquids to clean the
pattress as these may damage the unit. Avoid using aerosol based cleaning agents as these may cause false alarms.
The use of a vacuum cleaner with soft brush to remove dust is advisable and will help to keep the unit working
efficiently and prevent false alarms in more dusty environments.
Programming
Guide V 1.0
Switch 3
Switch 2
Switch 1
TAB
OFF ON
