ANATOMY OF A FIREPLACE
Cal Flame outdoor fireplaces add a sense of enchantment, magic and nostalgia to any backyard or gar-
den. Homeowners will enjoy the beauty and dynamics that a fireplace brings to their Home Resort while
guests will appreciate the year-round nighttime entertainment. Every Cal Flame fireplace is constructed
to the highest standard, utilizing a 16-gauge galvanized steel frame and reinforced by Hardibacker tile
backer board. Your fire fixture will be a source of elegance and entertainment for years to come.
EXTENDED CHIMNEY
Cal Flame fireplaces with the wood burn-
ing option will be constructed with an ad-
ditional 18” high chimney.
FIREBOX
Fireboxes range in size,
design and construction.
They are available in
the following designs:
•22-Inch: Fiberglass.
Standard on 905.
•30-Inch: Fiberglass
with rounded firebox
base. Standard on 906,
907, 908, 909, 910, 914
and 915.
•36-Inch: Metal with
fiberglass panels and
straight firebox. Avail-
able on 906, 907, 908,
909, 910, 914 and 915.
•42-Inch: Stainless
Steel. Available wood
burning option on 907,
908, 910 and 910.
SIMULATED STONE ARCH
Add a touch of distinction with a simulated
stone arch. Available on 906, 907, 908, 909, 910,
914 and 915.
STAINLESS STEEL
BURNER
Light up the night
and drive away the
cold with a powerful
55,000 BTUs of
heat.
BACKFLASH VENTILATION
A standard heat exhaust channels exces-
sive heat upward instead of outward,
preserving the finish of your fireplace.
ON/OFF SWITCH
Every fireplace
switch utilizes a
Piezo ignition
system, which is
a battery-powered
electronic ignition.
FIRE LOGS
Decorative logs come standard with 22-, 30- and 36-inch
fireboxes. Log sizes are measured by the front largest log in
the set:
•22-Inch Firebox: 4 logs, 16-inch. Standard on 905.
•30-Inch Firebox: 6 logs, 18-inch. Standard on 906, 907, 908, 909,
910, 914 and 915.
•36-Inch Firebox: 7 logs, 24-inch. Available on firebox option on
906, 907, 908, 909, 910, 914 and 915.
LAVA ROCKS
As a standard feature
on all natural gas
or liquid propane
fireplaces, Lava rocks
accent the base of
the firebox.
GRATE
All Cal Flame fire-
places benefit from
this 18-inch grate
which supports either
standard fire logs or
real logs.
MANTLE
Decorate your fireplace
with your favorite knick-
knacks or plants. Avail-
able in Natural Stone Tile,
Porcelain Tile or Bedrock®
Panel.
EXTENDED
BOTTOM
MANTLE
Accent the base
of your fireplace
with a sophisti-
cated extended
base in front
of the firebox.
Available in Natural
Stone Tile, Porcelain
Tile or Bedrock®
Panel.
WRAPPED
BOTTOM
MANTLE
This mantle wraps around
the front and sides of the
fireplace creating more
room for personal decora-
tions. Available in Natural
Stone Tile, Porcelain Tile or
Bedrock® Panel.
LIQUID PROPANE AND
NATURAL GAS CONVERTIBLE
For your convenience, Cal Flame fireplaces
can take advantage of your choice of fuel.
WWW.CALSPAS.COM 207

FRP-906
Dimensions: L x D x H 48” x 28” x 53”
Standard Finish Stucco
Fire Box 30” Fiberglass
Burner BTU Output 55,000 BTU
18” Grate Yes
Standard Fire Logs Set with Lava Rocks 6 Piece 18”
LP/NG Convertible* *Yes
Ventilation Yes
Warranty 1 year
Shown with
extended bottom mantel
Shown with wrapped
bottom mantel
FRP-908
Dimensions: L x D x H 48” x 28” x 72”
Standard Finish Stucco
Fire Box 30” Fiberglass
Burner BTU Output 55,000 BTU
18” Grate Yes
Standard Fire Logs Set with Lava Rocks 6 Piece 18”
LP/NG Convertible* *Yes
Ventilation Yes
Warranty 1 year
Shown with
extended bottom mantel
Shown with wrapped
bottom mantel
FRP-907
Dimensions: L x D x H 48” x 28” x 72”
Standard Finish Stucco
Fire Box 30” Fiberglass
Burner BTU Output 55,000 BTU
18” Grate Yes
Standard Fire Logs Set with Lava Rocks 6 Piece 18”
LP/NG Convertible* *Yes
Ventilation Yes
Warranty 1 year
Shown with
extended bottom mantel
Shown with wrapped
bottom mantel
FRP-905
Dimensions: L x D x H 39” x 24” x 67”
Standard Finish Sandstone
Fire Box 24”
Burner BTU Output 55,000 BTU
18” Grate Yes
Standard Fire Logs Set with Lava Rocks 4 Piece 16”
LP/NG Convertible* *Yes
Ventilation Yes
Warranty 1 year
WWW.CALSPAS.COM
208

FRP-910
Dimensions: L x D x H 48” x 28” x 72”
Standard Finish Stucco
Fire Box 30” Fiberglass
Burner BTU Output 55,000 BTU
18” Grate Yes
Standard Fire Logs Set with Lava Rocks 6 Piece 18”
LP/NG Convertible* *Yes
Ventilation Yes
Warranty 1 year
Shown with
extended bottom mantel
Shown with wrapped
bottom mantel
FRP-915
Dimensions: L x D x H 78” x 28” x 72”
Standard Finish Stucco
Fire Box 30” Fiberglass with Arch
Burner BTU Output 55,000 BTU
18” Grate Yes
Standard Fire Logs Set w/Lava Rocks 6 Piece 18”
LP/NG Convertible* *Yes
Ventilation Yes
Warranty 1 year
FRP-914
Dimensions: L x D x H 78” x 28” x 53”
Standard Finish Stucco
Fire Box 30” Fiberglass with Arch
Burner BTU Output 55,000 BTU
18” Grate Yes
Standard Fire Logs Set w/Lava Rocks 6 Piece 18”
LP/NG Convertible* *Yes
Ventilation Yes
Warranty 1 year
FRP-909
Dimensions: L x D x H 48” x 28” x 72”
Standard Finish Stucco
Fire Box 30” Fiberglass
Burner BTU Output 55,000 BTU
18” Grate Yes
Standard Fire Logs Set with Lava Rocks 6 Piece 18”
LP/NG Convertible* *Yes
Ventilation Yes
Warranty 1 year
Shown with
extended bottom mantel
Shown with wrapped
bottom mantel
COLUMNS & BENCHES
These columns and benches have been designed as com-
plete, standalone units that can also be placed alongside any
of the Cal Flame fireplaces as complementary pieces. They
are available in the same colors and finishes as the fireplaces
and firepits.
COL-36S Column
Dimensions: L x D x H 18” x 24” x 36”
Standard Finish Stucco
STB-18S Bench
Dimensions: L x D x H 52” x 24” x 18”
Standard Finish Stucco
WWW.CALSPAS.COM 209

ANATOMY OF A FIREPIT
TABLETOP FIRE
For the ultimate in outdoor entertain-
ment and relaxation, tabletop firepits
can accommodate up to six guests.
The innovative FPT-G5000 features
a two-piece glass top and elegant
footrest that will add lasting beauty and
variety to your Home Resort.
Whether it’s a campfire in the woods, a bonfire at the beach or a firepit in the privacy of an outdoor Home
Resort, people have enjoyed the relaxing and meditative properties of an open fire. Cal Flame captures
that magic of fire in every firepit, which is constructed with 16-gauge galvanized steel and Hardibacker
tile backer board for support and moisture resistance. Cal Flame firepits offer lasting and vibrant night-
time entertainment that can’t be beat.
STAINLESS STEEL BURNER
The powerful burner emits 55,000 BTUs and
will easily keep everyone around the firepit
comfortable on a chilly night.
ON/OFF SWITCH
Every fireplace switch utilizes a Piezo
ignition system, which is a battery-
powered electronic ignition.
FIRE LOGS AND LAVA ROCKS
All Cal Flame firepits come equipped with a
4-piece fire log set as well as lava rocks or
give your fire rustic naturalness.
VENTILATION
Vents dissipate any gas that might get
trapped and built up inside your firepit. Cal
Flame cares about the safety of you and
your family.
LIQUID PROPANE OR
NATURAL GAS CONVERTIBLE
Use liquid propane tanks or have a natural
gas line professionally installed.
SHAPES
Firepits come in round, square, hexagonal
(6-sided) and octagonal (8-sided) shapes to
accommodate any backyard preference.
HEIGHT
Firepits are available from 18” in height to
replicate the campfire experience to 36” in
height to create a conversational area that
will accommodate full-height barstools.
The choice is yours!
WWW.CALSPAS.COM 211

FPT-S301
Dimensions: L x D x H 48” x 48” 20”
Standard Finish Stucco
Square Fire Box Yes
Burner BTU Output 55,000 BTU
Standard Fire Logs Set with Lava Rocks 4 Piece 16”
LP/NG Convertible* *Yes
Ventilation Yes
Warranty 1 year
FPT-R80
Dimensions: L x D x H 36” Round x 18”
Standard Finish Sandstone
Square Fire Box Round Tubular Burner
Burner BTU Output 55,000 BTU
Standard Fire Logs Set with Lava Rocks 4 Piece 16”
LP/NG Convertible* *Yes
Ventilation Yes
Warranty 1 year
FPT-S300
Dimensions: L x D x H 36” x 36” x 20”
Standard Finish Stucco
Square Fire Box Yes
Burner BTU Output 55,000 BTU
Standard Fire Logs Set with Lava Rocks 4 Piece 16”
LP/NG Convertible* *Yes
Ventilation Yes
Warranty 1 year
FPT-S90
Dimensions: L x D x H 42” x 42” x 18”
Standard Finish Sandstone
Square Fire Box Round Tubular Burner
Burner BTU Output 55,000 BTU
Standard Fire Logs Set with Lava Rocks 4 Piece 16”
LP/NG Convertible* *Yes
Ventilation Yes
Warranty 1 year
FPT-S302
Dimensions: L x D x H 48” x 48” x 35”
Standard Finish Stucco
Square Fire Box Yes
Burner BTU Output 55,000 BTU
Standard Fire Logs Set with Lava Rocks 4 Piece 16”
LP/NG Convertible* *Yes
Ventilation Yes
Warranty 1 year
Shown with tile top
Shown with stone top
WWW.CALSPAS.COM
Shown with stone top Shown with tile top
Shown with tile top
212

FPT-H400
Dimensions: L x D x H 36” x 36” x 20”
Standard Finish Stucco
Square Fire Box Yes
Burner BTU Output 55,000 BTU
Standard Fire Logs Set with Lava Rocks 4 Piece 16”
LP/NG Convertible* *Yes
Ventilation Yes
Warranty 1 year
FPT-H402
Dimensions: L x D x H 48” x 48” x 35”
Standard Finish Stucco
Square Fire Box Yes
Burner BTU Output 55,000 BTU
Standard Fire Logs Set with Lava Rocks 4 Piece 16”
LP/NG Convertible* *Yes
Ventilation Yes
Warranty 1 year
FPT-H401
Dimensions: L x D x H 48” x 48” x 20”
Standard Finish Stucco
Square Fire Box Yes
Burner BTU Output 55,000 BTU
Standard Fire Logs Set with Lava Rocks 4 Piece 16”
LP/NG Convertible* *Yes
Ventilation Yes
Warranty 1 year
Shown with tile top Shown with tile top
WWW.CALSPAS.COM
Shown with tile top
213

FPT-R1050
Dimensions: L x D x H 60” Round x 45”
Standard Finish Ameristone Stucco
with Porcelain Tile
Square Fire Box Yes
Burner BTU Output 55,000 BTU
Standard Fire Logs Set with Lava Rocks 4 Piece 16”
LP/NG Convertible* *Yes
Ventilation Yes
Warranty 1 year
FPT-O1050
Dimensions: L x D x H 60” x 60” x 45”
Standard Finish Ameristone Stucco
with Porcelain Tile
Square Fire Box Yes
Burner BTU Output 55,000 BTU
Standard Fire Logs Set with Lava Rocks 4 Piece 16”
LP/NG Convertible* *Yes
Ventilation Yes
Warranty 1 year
FPT-G5000
Dimensions: L x D x H 69” Round x 45”
Standard Finish TBD
Square Fire Box Yes
Burner BTU Output 55,000 BTU
Standard Fire Logs Set with Lava Rocks 4 Piece 16”
LP/NG Convertible* *Yes
Ventilation Yes
Warranty 1 year
WWW.CALSPAS.COM
214

COMBUSTED WOOD SMOKE
When wood burns, it releases
pollutants into the air, through the
chimney. Left untreated, these
fumes are harmful to the environ-
ment and your health.
STEEL BLOWER
A powerful fan is installed
above the Emission Reclama-
tion System to draw smoke
through the catalytic converter
and then expel the treated
smoke after reducing emis-
sions.
CATALYTIC CONVERTER
Noxious smoke passes
through the Emission
Reclamation System
built directly into the
chimney and the smoke
is purified through a re-
combustion process to
reduce emissions.
EXHAUST
Cleaner smoke is released into the
air—better for the environment and
better for you and your family.
Since California has the most rigorous emissions regulations in the United States, Cal Flame has part-
nered with the state’s automotive industry to reduce emissions. Forward thinking and global responsibil-
ity has enabled Cal Flame to embrace clean air and create health-conscious products for you and your
family. Experience Green Heat today!
Cal Flame goes green with Green Heat technology. This unique innovation reduces emissions in burn-
ing wood and is available on Cal Flame fireplaces with the wood burning option. Other wood burning
backyard fireplaces simply burn the logs and release untreated emissions into the environment. Cal
Flame rectifies this ecological problem with the exclusive Emission Recovery System—or Green Heat.
When the fuel is combusted, it releases its noxious by-products through the chimney, where Cal Flame
engineers have installed a unique catalytic converter. A powerful fan forces the emissions through the
catalyst before expelling them out the chimney. Tests show that this Green Heat system can reduce
emissions by at least 25%.
WWW.CALSPAS.COM
FOR YOUR LIFE
GREEN HEAT
FOR THE PLANET
215

BASE FINISHES
Integrate your fire fixture seamlessly with the
other pieces of your Cal Spas Home Resort with
your choice of Ameristone Stucco, Cultured
Stone, brick or Bedrock® Panel options.
TOP FINISHES
Your fire fixture can be accented with beauti-
ful granite, porcelain tile, natural stone tile or
Bedrock.
WRAPPED BOTTOM MANTEL
Extend the bottom mantel around
the sides of your fireplace base,
creating more space for decora-
tions and plants.
36” FIREBOX
Upgrade from a standard 30”
firebox to a larger 36” metal
firebox that comes standard with
a 7-piece 24-inch fire log set,
allowing more people to enjoy the
warmth.
42” WOOD BURNING FIREBOX
Select outdoor fireplaces can be
converted to burn wood and auto-
matically receive a 42” stainless
steel firebox.
LED LIGHTING
Make your fireplace eye-catching
even when not in use with bright
LED lights that punctuate the
night with beauty.
STEREO SYSTEM
Groove to your favorite tunes
around the fire with this iPod-
ready system and two premium
stereo speakers.
ARCH DESIGN
Customize your 30” and 36” fire-
box arch with durable and elegant
simulated stone. Arch design
depends on firebox size.
FIRE ON ICE - SHOWN AT LEFT & BELOW (FIREPIT ONLY)
Replace the standard fire log, grate and lava rock set with
scintillating tempered glass chips that will never lose its
color and is safe to the environment and your hands. We
recommend mixing and matching two bags in different
colors. Choose from Peridot, Sapphire, Malachite, Topaz
and Onyx to create your own design!
OPTIONS & FINISHES
WWW.CALSPAS.COM
EXCLUSIVE GREEN HEAT
Wood burning fireplaces can be equipped
with this smoke reclamation system for
cleaner and healthier emissions.
Peridot Sapphire Malachite Topaz Onyx
216

Printed color may vary from actual tile/stone/stucco colors and textures. Ask your dealer to view an actual sample.
WWW.CALSPAS.COM
Porcelain Tile
Natural Stone Tile
Lago Nebbia
Cinque Terre
Manarola
Citta Aventeno Kenya Ruggine
Bengali Beige
Classic Cream
Black Galaxy
Emperador Light
Arabescato
Carrara
Giallo
Veneziano
Emerald Green
Autumn
Harmony
Blue Pearl
Granite
Earth Tone
Cultured Stone
Autumn Pro-Fit
Ledgestone
Bucks Country
European Castle
Old Used Brick Chicago Used
Cultured Brick
Nantucket
Stacked
Calistoga
Weather
Cognac Country Manzanita
Cliffstone
Ameristone Stucco
Stony Creek White Ash
Midnite Storm Pearl Haze
Carmella
Sahara Gold
Bianco Catalina
Emperador Dark
Natural Steel Torino Cottian Torino Julian Venice Cappuccino
Platino Rustico
COUNTERTOP CHOICES
BASE CHOICES
Stucco
La Paz Olive Brown Pearl Gray
Woodbury Pink
River Rock
Victorian Rose
Champagne Gray
217

Fire has always attracted people with its natural ability to warm, comfort and entertain. It is nothing short of
magical. Cal Flame shares that magic with you and your family by offering the finest in outdoor fire fixtures.
How many stories will you swap with friends around an open fire on a cold winter night? How many romantic
evenings by the fire will you share with someone? How often will you find yourself lost in thought while a fire
dances before your eyes? Capture the magic of fire today. Make every moment count with Cal Flame.
WWW.CALSPAS.COM
218
