Caliber RCD 120BT Assembly instructions

RCD 120BT
MANUAL
o(#o

RCD 120BT MANUAL
Installation. ............................................... .02.
Additional information ................................. 04
General operations......................................05
Radio operations.........................................09
CD/SD/MMC/USB Operations ..................... 11
MP3 WMA overview.....................................16
Specification.................................................17
Before playing discs ..................................... 18
Trouble shooting............................................19
BLUETOOTH
15
...............................................
RDS operation.............................................14

RCD 120BT MANUAL
30
0
PRECAUTIONS
Cho ose the moun ting location whe re the unit wi ll not interfer e wi th the normal
driving function of the driver.
Bef ore final ly instal ling the uni t, conne ct the wiring tempor ar ily and make sure
it is all connected up properly and the unit and the system work properly.
Use onl y the par ts incl uded wi th the uni t to ens ure proper inst al lation. The use
of unauthorized parts can cause malfunctions.
Con sul t wi th you r ne ar es t de al er if installat ion requi res the drilling of holes or
other modifications of the vehicle.
Install the unit where it does not get in the driver's way and cannot injure the
passenger if there is a sudden stop. Like an emergency stop.
If installation angle exceeds 30 from horizontal, the unit mi ght not give its
optimum performance.
Avoid installing the unit where it would be subject to high temperature, such
as from direct sunlight, or from hot air, form the heater, or where it would be
subject to dust, dirt or excessive vibration. Do not expose this equipment
to rain or moisture.
DIN FRONT-MOUNT (Method A)
Installing the unit
1. Dashboard
2. Holder
After inserting the holder into
the dashboard, select the
appropriate tab according to
the thickness of the dashboard
material and bend them
inwards to secure the holder in
(Fig. 1)
place.
3. Screw
INSTALLATION
(Fig. 1)
12
3

RCD 120BT oMANUAL
INPUT THE SD CARD
The SD oblique angle keeps
rightward exposure, put into
the SD slot and press it again
to eject.
1. Dashboard
2. Nut (5mm)
3. Spring Washer
4. Screw (5 x 25mm)
5. Screw
2.Insert fingers into the groove in the
front of fram e and pul l out to rem ove
the fram e. (When reatt achi ng the
frame, point the side with a groove
dow nwards and attach it.)
3.Leve r
Insert the leve rs sup plied with the
uni t into the grooves at both sides of
the uni t and show n in figure unti l they
click. Pulling the levers makes possible
to re move the unit fro m th e dashboard.
DIN REAR-MOUNT (Method B)
Installation using the screw holes on
the sides of the unit
Fastening the unit to the factory
radio mounting bracket:
1. Select a position where the screw
holes of the bracket and the
screw holes of the main unit
become aligned (are fitted), and
tighten the screws at 2 places on
each side. Use either truss screws
(5 x 5mm) or flush surface screws
(4 x 5mm)
2. Screw
3. Dashboard or Console
INSTALLATION
6. Strap
Be sure to use the strap to
secure the back of the unit in
place. The strap can be bent by
hand to the desired angle.
7. Plain Washer
2
3
2
2
1
3
(Fig.3)
Removing the unit
1
2
3
4
5
6
7
(Fig.2)

RCD 120BT oMANUAL
ADDITIONAL INFORMATION
RE AR Lc h LINE OUT
RE AR Rc h LINE OUT
BLUE
WHITE
WHITE/BLACK
GREEN
GREEN/BLACK
RED YELLOW
BLACK
GREY
GREY/BLACK
VIOLET
VIOLET/BLACK
B. T. ANT EN NA

RCD 120BT oMANUAL
MU BND
2/INT 3/RPT 4/R DM1/
MENU
DISP
MODE
AMS
GENERAL OPERATIONS
FRONT PANEL LAYOUT
1. Power / Mode / Next / Previous Button
3. Menu / Volume Button
5. Display Button
11. Play / Pause & Preset Button 1
2. Release Button
12. Intro & Preset Button 2
6. LCD Display
13. Repeat & Preset Button 3
10. Automatically memory storing
14. Random & Preset Button 4
15. Preset Button 5
16. Preset Button 6
19. USB connecter
8. Reset Button
17. Eject knob
18. CD Slot
7. Flashing LED
20. SD/MMC Slot
21. AUX IN JACK
18
17
20
7 8
2 3
45
19
6
9
11 12 13 14 15 16
21
10
1
9. Band/ switch /ID3 select
4. Mute / Button

RCD 120BT oMANUAL
GENERAL OPERATIONS
GENERAL OPERATIONS
FRONT PANEL RELEASE
Press REL button (2) to detach the removable front panel
SOUND ADJUSTMENT
Turn on (3) can adjust the desired volume quality.
A).Press MENU button (3) will change in the following order.
Option:
Volume control/MENU
Rotating this knob, you can adjust VOL/BASS/TREB/BAL/FAD . To select the
functions, press the VOL knob shortly until the desired functions are shown on the
display.
Increase or decrease the volume by turn the VOL knob right or left. These buttons
can be used to adjust the BASS, TREBLE, BALANCE and FADER.
VOL BAS TRE BAL FAD
(Volume)(Bass)(Treble)(Balance)(Fader)
BASS
Press MENU/VOL button(3) one time. Adjust bass level by using MENU/VOL(3)Knob.
TREBLE
Press MENU/VOL button(3) two times. Adjust treble level by using MENU/VOL(3)
Knob
BALANCE
Press MENU/VOL button(3) three times. Adjust sound balance between left and
right speakers by using MENU/VOL(3)Knob .
POWER /MOD conversion
2.Under power off status,short press is power on,
Under power on status,short press is switching mode,long press is power off.
MENU/VOL
MENU

RCD 120BT oMANUAL
GENERAL OPERATIONS
MENU/VOL
MENU/VOL
MENU/VOL
LOUD OFF/ON DEMO OFF/ON
DSP OFF/ON AEM OFF/ON BEEP ON/OFF
MONO/STEREODX/LOCALVOL ADT/LASTAREA EUR/USA SEEK

RCD 120BT oMANUAL
GENERAL OPERATIONS
LIQUID CRYSTAL DISPLAY
Exhibit current frequency and activated functions on the display (6).
FLASHING LED
DISPLAY
Press DISP button (5) to operate as the conversion of each display mode as follow:
- Time is displayed for 5sec when DISP key is pressed, and it returns to its
previous display ( Folder, File name...) unless DISP key is pressed again.
3) From the clock mode, when DISP Key is pressed for longer than 1sec,
clock mode switches to clock Adjusting mode and the clock display
begins flashing. At this time clock can be changed by pressing (+/-),
or the ENCODER VOLUME.
When ACC off ,take out the front panel from main unit that the LED (7) will be flashing.

RCD 120BT oMANUAL
GENERAL OPERATIONS
MENU/VOL
MENU/VOL
MENU/VOL
LOUD OFF/ON DEMO OFF/ON
DSP OFF/ON AEM OFF/ON BEEP ON/OFF
MONO/STEREODX/LOCALVOL ADT/LASTAREA EUR/USA SEEK
