Calimet CM9-2 Installation instructions

CALIMET
GATE ACCESS CONTROL SYSTEMS
INSTALLATION AND OWNER MANUAL
V.3.1 | 2023.06.01WWW.CALIMETCO.COM
9949 HAYWARD WAY, SOUTH EL MONTE, CA 91733
TEL: [phone]
SWING LINEAR ARMS OPERATOR
CM9-2

TABLE OF CONTENTS
OVERVIEW GATE OPERATOR OVERVIEW
SAFETY
PROPERTY TYPE AND ENTRAPMENT PROTECTION
...................................................................................... 01
02 - 03
04
....................................................................................................................
................................................
INSTALLATION PREINSTALLATION
CONTROL BOX INSTALLATION
LINEAR ARM INSTALLATION
ARM POSITIONING GUIDANCE
CIRCUIT BOARD LAYOUT
DIP SWITCH FEATURES
CONTROL BOX WIRING
POWER CONNECTION
GATE OPEN DIRECTION SETTINGS
DUAL GATE WIRING AND SETUP
PHOTOCELL SENSOR INSTALLATION
PHOTOCELL SENSOR LED INDICATORS
SECONDARY PHOTOCELL SENSOR (OPTIONAL)
PHYSICAL LIMITS ADJUSTMENT
FORCE ADJUSTMENT
WARNING SIGNS INSTALLATION
EMERGENCY RELEASE LOCK
AFTER INSTALLATION
........................................................................................................ 05
06
07 - 10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
....................................................................................
..................................................................................
.....................................................................................
..............................................................................................
................................................................................................
.................................................................................................
..................................................................................................
.............................................................................
...................................................................................
..........................................................................
.....................................................................
......................................................
..................................................................................
...................................................................................................
....................................................................................................
..................................................................................
......................................................................................
ACCESSORIES
WIRING
REMOTE CONTROLS
VEHICLE LOOP DETECTORS
ACCESSORY WIRING
..................................................................................................... 26
27 - 29
30 - 32
.................................................................................
..............................................................................................
IMPORTANT
INFORMATION
CIRCUIT BOARD LIGHT STATUS CHART
TROUBLESHOOTING
MAINTENANCE
MANUFACTURER’S LIMITED WARRANTY
IMPORTANT INFORMATION AND NOTES
...................................................................... 33
34
35
36
37
.....................................................................................................
...............................................................................................................
....................................................................
.....................................................................

POWER IMPUT 110 - 120V AC, CM9-2-DCFP/DCFP-S: 7 AMPS
SYSTEM OPERATION VOLTAGE CM9-2-DCFP: 24V DC
MAXIMUM OUTPUT CURRENT 7 AMPS, FUSE 24V DC 7 AMPS
DIMENSIONS CONTROL BOX: (L x W x H)
LINAER ARM: (L x W x H)
GATE TYPE SWING LINEAR ARM
RESIDENTIAL / COMMERCIAL
1600 LBS
18 FEET
-4°F TO 140°FOPERATING TEMPERATURE
MAXIMUM GATE LENGTH
APPROXIMATELY 20 SEC FOR 90° OPENING (ADJUSTABLE)
CONTINUOUSMAXIMUM DUTY CYCLE
MAXIMUM GATE TRAVEL SPEED
INHERENT REVERSE SENSOR SYSTEM (TYPE A)
PHOTOELECTRIC SENSOR (TYPE B1)EXTERNAL ENTRAPMENT PROTECTION
INHERENT ENTRAPMENT PROTECTION
CM9-2-DCNB: NO, CM9-2-DCFP/DCFP-S: YES
KEYEMERGENCY RELEASE
SOLAR READY
I, II, III, IV
RESIDENTIAL: 5 YEARS, COMMERCIAL: 3 YEARS
GATE OPERATOR OVERVIEW
CM9-2 INSTALL ATION AND OWNER MANUAL V.3.1 | 2023.06.01 PAGE 01
WARRANTY
CM9-2-DCNB PACKAGE
CONTROL BOX (1), SWING LINEAR ARM (1), CM9-864 CONT-
ROL (2), PHOTOSENSOR AND REFLECTOR (1), PHOTOSEN-
SOR MOUNT (2), WARNING SIGN (2), NUTS AND BOLTS (1),
MOUNTING HARDWARE, USER MANUAL, WARRANTY CARD.
CM9-2-DCFP PACKAGE
CM9-2-DCNB PACKAGE, BATTERY (1), BATTERY CIRCUIT
BOARD (1)
CM9-2-DCFP-S PACKAGE
CM9-2-DCFP PACKAGE, EXTENDED SOLAR BATTERY (1),
SOLAR PANEL *2)
WHAT’S IN THE BOX
PROPERTY CLASS
APPLICATION
MAXIMUM GATE WEIGHT

SAFETY (MUST READ)
CM9-2 INSTALL ATION AND OWNER MANUAL V.3.1 | 2023.06.01 PAGE 02
Carefully read follow, and accept all safety precautions and warnings before attempting to install and use
gate swing linear arm operator, incorrect installation can lead to severe injury or death.
- The gate operator must be installed by a certified (licensed) gate technician; otherwise serious personal
injury or property damage may occur.
- Installing a gate operator may require installation of standard 110v-120v AC electrical wiring. This work
should only be performed by an experienced electrician. Miswiring could cause personal injury or death.
- Never let children operate the gate or play around the gate. Keep the remote control away from children.
- Always keep people and objects away from the gate. Cars, people, and objects should never enter when
the gate is closing.
- Verify that this operator is proper for the type, weight, and size of the gate.
- Make sure the gate has been properly installed and swings freely in both directions with no resistance.
Repair or replace all worn or damaged gate hardware prior to installation.
- Test gate operator monthly. The gate must reverse when in comes in contact with a solid object, or stop
when an object activates the non-contact sensors. after adjusting the force or travel limit, re-test the gate
operator. Failure to maintain the gate operator properly can increase the risk of injury or death.
- Use the emergency release only when the gate is not moving.
- Keep the gate and gate operator properly maintained. Read the maintenance section of this manual and
follow the maintenance schedule. Have a certified service technician make repair or install gate operator
hardware(s).
- Gate operator can use a huge amount of force to open and close the gate. Therefore, safety features
must be taken into consideration when installing and using a gate operator. Specific safety feature include:
photoelectric sensors, edge sensors (contact), moving gate warning signs, guards for exposed rollers,
screen mesh, vertical posts, and more.
- The gate must be installed in a location so that enough clearance is supplied between the gate and
adjacent structures when opening and closing to reduce the risk of entrapment.
- Entrapment is defined as when a person, vehicle, or object is caught or held in a position that increases
the risk of injury.
- Access controls intended for users must be located at least 6 feet (1.8m) away from any moving part of
the gate and where the user is prevented from reaching over, under, around, or through the gate to
operate the controls.

- A minimum of two (2) warning signs shall be installed, one on each side of the gate that is easily visible.
- Gate auto closed timer function is not recommended unless loop detectors are installed.
- The gate must have sufficient room when opening and closing. Swinging gates should open inwards and
not into public access areas. The gate must be properly installed and move freely in both directions.
- Install the gate operator only when: 1) The operator is appropirate for the construction of the gate and the
usage class of the gate, 2) All exposed pinch points are eliminated or guarded.
- For gate operators utilizing Type D protection: 1) The gate operator controls must be placed so that the
user has full view of the gate area when the gate is moving, 2) The placard shall be placed adjacent to the
controls, 3) An automatic closing device (such as timer, loop sensor, or similar devices) shall not be
employed, and 4) No other activation device shall be connected.
- The gate operator is intended for installation only on vehicular gates. Pedestrians must access a
separate entrance. The pedestrian entrance shall be designed for pedestrian usage. The gate must be
installed in a location so that pedestrians will not come in contact with the vehicular gate during the entire
path of travel of the vehicular gate.
- For gate operators utilizing a non-contact sensor, see instructions on the placement of non-contact
sensors for each Type of application, 2) Care shall be exercised to reduce the risk of nuisance tripping
such as when a vehicle, trips the sensor while the gate is still moving, and 3) One or more non-contact
sensors shall be located where the risk of entrapment or obstruction exists, such as the perimeter
reachable by a moving gate or barrier.
- For a gate operator utilizing a contact sensor: 1) one or more contact sensors shall be located at the
leading edge, trailing edge, and post mounted both inside and outside of a vehicular gate. 2) One or more
contact sensors shall be located at the bottom edge of a vehicular vertical lift gate. 3) One or more contact
sensors shall be located at the pinch point of a vehicular vertical pivot gate. 4) A hardwired contact sensor
shall be located and its wiring arranged so that the communication between the sensor and the gate
operator is not subjected to mechanical damage. 5) A wireless contact sensor such as one that transmits
radio frequency (RF) signals to the gate operator for entrapment protection functions shall be located
where the transmission of the signals are not obstructed of impeded by building structures, natural land-
scaping or similar obstructions. A wireless contact sensor shall function under the intended end-use cond.
- Controls intended to be used to reset an operator after 2 sequential activations of the entrapment
protection device(s) must be located in the line-of-sight of the gate. Outdoor or easily accessible controls
shall have a security feature to prevent unauthorized use.
SAFETY (MUST READ)
CM9-2 INSTALL ATION AND OWNER MANUAL V.3.1 | 2023.06.01 PAGE 03

PROPERTY TYPES & ENTRAPMENT PROTECTION
CM9-2 INSTALL ATION AND OWNER MANUAL V.3.1 | 2023.06.01 PAGE 04
Required Entrapment Protection
A
B1
B2
C
D
E
Class I - Residential
Intended for use in a home of one (1) to four (4) single family dwelings, garage or parking area associated
therewith
Swing Gate Requirements: Primary Device: A, C
Secondary Device (one required): A, B1, B2, C, D
Class II - Commercial
Intended for use in a commercial location or building such as a multi-family housing unit (five or more
single family units, hotel, garages, retail store or other building servicing the general public.
Swing Gate Requirements: Primary Device: A, C
Secondary Device (one required): A, B1, B2, C, D
Class III - Industrial
Intended for use in an industrial location or building such as a factory, loading dock area, or other locations
not intended to service the general public.
Swing Gate Requirements: Primary Device: A, B1, B2, C
Secondary Device (one required): A, B1, B2, D, E
Class IV - Restricted Access
Intended for use in a guarded industrial location or building such as a military base, hazardous chem sites,
or other restricted access locations, in which unauthorized access is prevented via supervision by staffs.
Swing Gate Requirements: Primary Device: A, B1, B2, C, D
Secondary Device (one required): A, B1, B2, C, D, E
NOTE: A minimum of 2 independent entrapment protection devices are required for each direction of travel.
The same type of device shall not be utilized for both the primary & secondary entrapment protection means
Use of a single device to cover both the opening & closing directions is in accordance with the requriement;
however, a single device is not required to cover both directions.
Inherent (built-in) Entrapment Protection System
Non-contact sensor such as a photosensor or equivalent
Contact sensor such as edge sensor or equivalent
Inherent adjustable clutch or pressure relief device
Actuation device requiring contrinuous pressure to maintain gate motion
Inherent Audio Alarm
-
-
-
-
-
-

PREINSTALLATION
CM9-2 INSTALL ATION AND OWNER MANUAL V.3.1 | 2023.06.01 PAGE 05
Gate Structure
Confirm that the gate operator being installed is appropriate for the gate type, weight and size. The gate
should be mounted and moving freely. There should be a little resistance in the movement of the gate. the
gate & post must be suitable for being automated. Check that the structure is sufficiently strong & stable,
and that its dimensions and weights conform to those listed in the specifications table of this document.
Any worn or damaged gate hardware must be repaired or replaced before installing the gate operator.
Vehicular gates are to be constructed and installed in accordance with the ASTM F2200 contruction
standards.
Electricity
The CM9-2 is powered by 110v-120v AC power. IF you have not already done so, and you are not using
solar power, wire a waterproof outlet near the gate following proper safety standards for your area. we’re
recommended hire a state licensed electrician to perform all your wiring tasks as well as wire in the CM9-2
swing linear arm. Make sure your electrician takes into account the voltage drop involved in running many
feet of wire to your installation location. If an insufficient gauge of wire is used, the gate operator may have
insufficient power.
The gate operator must be disconnected from the power source before the installation. This also includes
gate operator accessories.

CONTROL BOX INSTALLATION
CM9-2 INSTALL ATION AND OWNER MANUAL V.3.1 | 2023.06.01 PAGE 06
FIGURE A
FIGURE C
Drill Hole
FIGURE B
Baseboard
Unscrew
To Remove
Option 1 - Mounting with Included Plastic Hinges:
1. On the back of CM9-2, locate the 4 plastic hinges attached with a Philips screw on each corner.
2. Unscrew the Philips screws and turn the plastic hinges to the desired position and angle (FIGURE A).
3. Tighten the Philips screws to secure the plastic hinges in place.
4. Position the power box on the wall where you want to mount it and mark 4 holes.
5. Drill holes and use wall anchors to mount the power box securely.
Option 2 - Mounting Direct:
1. On the back of CM9-2, unscrew the 4 Philips screws and remove the 4 plastic hinges from the corners.
2. Open the power box and remove the 4 Philips screws (FIGURE B) on the baseboard to disconnect the
circuit board system from the control box case.
3. Drill 4 holes from the marked location (FIGURE C) on the back of the control box case, to create a mount
holes.
4. Drill holes and use wall anchors to mount the box securely, and consider using liquid shield to shield the
mounting holes for added protection.
5. Reinstall the circuit board system (baseboard) back into the case and secure it with the 4 Philips screws.

LINEAR ARM INSTALLATION (OPEN INSIDE)
Single Gate Installation Set-up Double Gate Installation Set-up
FIGURE A
CM9-2 INSTALL ATION AND OWNER MANUAL V.3.1 | 2023.06.01 PAGE 07
1. Weld the Wall Bracket to the Wall Plate to create a stable base for
the linear arm (FIGURE A).
2. Mounting the Wall Plate to the Wall: first drill holes in the desired
location on the wall, and use wall anchors to securely mount the
Wall Plate to the wall.
3. Use the included nut, washers, and bolt to connect the CM9-2 Linear
Arm to the Wall Plate. Tighten the bolt to secure the Linear Arm to the
Wall Plate (FIGURE B)
4. Position the Gate Plate to be level with the CM9-2 Linear Arm. Once
everything is leveled and measured, weld the Gate Plate to the gate,
and ensure that the plate covers up to 3 pickets on the gate (FIGURE C).
5. Connect the Gate Mount Bracket to the Linear Arm travel bolt. Adjust
the bracket until the measurements match the suggestions on page 8.
6. Weld the Gate Bracket securely to the Gate Plate, and Verify that
everything is stable and secure
Please note that welding should be done by a professional and skilled welder to ensure safety and durability.
Additionally, follow all safety guidelines and use appropriate tools and materials as specified in the product's
manual or instructions.
FIGURE C
WALL
CALIMET -CM9-2
FIGURE B
WALL
GATE
CALIMET -CM9-2

LINEAR ARM INSTALLATION (OPEN INSIDE)
CM9-2 INSTALL ATION AND OWNER MANUAL V.3.1 | 2023.06.01 PAGE 08
Refer to the illustrations below to determine the measurement of the swing linear arm operator.
Single Gate Installation Set-up Double Gate Installation Set-up
(°) A
90° 6-3/4”
90° 7-1/4”
110° 6-3/4”
110° 5-1/2”
B
7”
7-1/4”
7”
6”
C
4-4/3”
4-4/3”
4-4/3”
4-4/3”
CALIMET -CM9-2
WALL
GATE
A
B
CALIMET -CM9-2
C

WALL
GATE
CALIMET -CM9-2
FABRICATED MOUNT
WALL
CALIMET -CM9-2
FABRICATED MOUNT
LINEAR ARM INSTALLATION (OPEN OUTSIDE)
Single Gate Installation Set-up Double Gate Installation Set-up
FIGURE B
FIGURE C
FIGURE A
CM9-2 INSTALL ATION AND OWNER MANUAL V.3.1 | 2023.06.01 PAGE 09
1. Make a custom Fabrication L-Shape bracket to extence the length
of your Linear Arm operator. The size is depend on your gate.
2. Weld the Wall Bracket to the Fabrication L-Shape bracket and then
to the Wall Plate to create a stable base for the linear arm (FIGURE A).
3. Your finished Wall Plate should look like what show in FIGURE B.
4. Mounting the Wall Plate to the Wall: first drill holes in the desired
location on the wall, and use wall anchors to securely mount the
Wall Plate to the wall.
5. Use the included nut, washers, and bolt to connect the CM9-2 Linear
Arm to the Wall Plate. Tighten the bolt to secure the Linear Arm to the
Wall Plate (FIGURE C)
6. Position the Gate Plate to be level with the CM9-2 Linear Arm. Once
everything is leveled and measured, weld the Gate Plate to the gate,
and ensure that the plate covers up to 3 pickets on the gate (FIGURE D).
7. Connect the Gate Mount Bracket to the Linear Arm travel bolt. Adjust
the bracket until the measurements match the suggestions on page 10.
6. Weld the Gate Bracket securely to the Gate Plate, and Verify that
everything is stable and secure
Please note that welding should be done by a professional and skilled welder to ensure safety and durability.
Additionally, follow all safety guidelines and use appropriate tools and materials as specified in the product's
manual or instructions.
FIGURE D

A
7-1/2”
B
6”
C
4-3/4”
LINEAR ARM INSTALLATION (OPEN OUTSIDE)
Refer to the illustrations below to determine the measurement of the swing linear arm operator.
The Position of the brackets estalishes the maximum opening angle and the length of the
actuator’s linear stroke. (NOTE: Rear bracket MUST be fabricated.)
WALL
GATE
CALIMET -CM9-2
CALIMET -CM9-2
FABRICATED MOUNT
B
A
MAX STROKE = 38”
C
90° - 105°
Single Gate Installation Set-up Double Gate Installation Set-up
CM9-2 INSTALL ATION AND OWNER MANUAL V.3.1 | 2023.06.01 PAGE 10

Please use the images below for your reference:
Flexible Eyelet Bolt Features:
Adjustable Length - Extend up-to half (1/2) inch. Must have at
least half inch screwed in and connected
with the linear arm and nut must be tight.
Flexible Angle - Allow up to 10° to 15° on move up or down and
left or right.
ARM POSITIONING GUIDANCE
CM9-2 INSTALL ATION AND OWNER MANUAL V.3.1 | 2023.06.01 PAGE 11
NUT
FLEXIBLE EYELET BOLT
ADJUSTABLE BOLT
FIGURE A

Gate Operator Model: CM9-M9-2-DCNB, CM9-M9-2-DCFP, and CM9-M9-2-DCFP.S
01
02
03
04
05
06
07
08
09
10
-
-
-
-
-
-
-
-
-
-
Photocell Sensor Input
Wired Keypad / Access Control Input
Remote Control Dip Switch Setting
Remote Control Learn (Study) Setup
Solar Panel Wire Input
Backup Battery Wire Input
Auto Close Timer Knob
Delay Timer Knob
Open and Close ERD Knob
Motor Input
11
12
13
14
15
16
17
18
19
20
21
-
-
-
-
-
-
-
-
-
-
-
Common Input
Open / Close Limit Input
Loop Detector Input
Common Global Input
Electric / Solenoid Lock Input
Maglock Input
Master / Slave Dual Gate Input
Open / Close / Stop / Reset Buttons
Dip Switches Features
LED Status Lights
Speed Knob
CIRCUIT BOARD LAYOUT
CM9-2 INSTALL ATION AND OWNER MANUAL V.3.1 | 2023.06.01 PAGE 12

Gate Operator Model: CM9-M9-2-DCNB, CM9-M9-2-DCFP, and CM9-M9-2-DCFP.S
SPEED - The gate opening and closing speed can be adjusted by turning the blue knob labeled “SPEED”
on your gate opener circuit board. turning left increases the speed and turning right decreases the speed.
DIP SWITCH FEATURES
CM9-2 INSTALL ATION AND OWNER MANUAL V.3.1 | 2023.06.01 PAGE 13
OFF
ON
DP
ON TIMER
0
30
10
40 20
50
60
SEC.
DELAY
0
3
1
42
5
6
SEC.
SPEED
FIGURE A FIGURE B FIGURE C FIGURE D
Switch
Name Description
Gate Closing Delay - switch to ON position, turn timer to 1 - 6 seconds (FIGURE C).
Useful for dual gate operators with locks, requiring one gate to close first before the
other, also known as “Bipart Delay”.
Auto Close - automatically closes the gate after a timed delay. Set to ON and turn
the blue TIMER knob anywhere from 1 - 60 seconds (FIGURE B).
Anti-Tailgating System - when On, after a vehicle has cleared the safety loop, the
gate will start to close immediately. If a second vehicle crosses the loop while the
gate is closing, the gate will stop. The second vehicle must get off the loop before
the gate closes completely.
Dual Gate Installation - for the secondary gate operator only, set the #5 SLAVE
switch to ON. If single gate installation, set to OFF.
Mid-Stop - allows the remote control to stop the gate when opening or closing.
Press once to stop the gate, and press the remote again to reverse the gate.
Automatic Close Override - pressing the remote control will override the close timer
before the timer ends, allowing the gate to close early.
Gate Open Direction - set the direction of which the gate opens when viewed from
inside the property: Left or Right.
Maglock - turn on if using a magnetic lock. Wire the magnetic lock in the MAG-
LOCK input on the bottom left of the circuit board.
Slow Stop - Allows the gate to come to a slow stop when closing.

CONTROL BOX WIRING
CM9-2 INSTALL ATION AND OWNER MANUAL V.3.1 | 2023.06.01 PAGE 14
To ensure safe and proper installation, it is essential to follow these steps carefully and refer to the specific
model's user manual or manufacturer's guidelines. Here's a summarized version of the steps for connecting
the linear arm, photosensor, and power cable to the power box:
Step 1 - Connect the Linear Arm with the Power Box:
1. Unscrew the large water-resistant cable gland on the cable and insert into the pre-drilled hole located
1. on the bottom left of the power box. Hand-tighten until secure.
2. Follow the label on the wire and connect it to the circuit board as follows:
a. Motor Cable: Motor 1 (Red), Motor 2 (Black)
b. Physical Limit Cable: Common (Yellow), Common (Green), Limit 1 (Purple), Limit 2 (Grey)
c. Sound and Light Cable: MAGLOCK Port - DC24V (Orange), GND (Blue)
Step 2 - Connect the Photosensor with the Power Box:
1. Unscrew the large unused water-resistant cable gland (located on the bottom left of the power box).
2. Insert the Photosensor cable through the cable gland and hand-tighten it to secure.
3. Follow the label on the wire and connect it to the circuit board as follows:
a. Photosensor Cable: MON-CLOSE (Brown), COMMON (Blue/White), MON-24VDC (Grey)
NOTE: Some photocell sensors may have 3 or 4 wires
Before proceeding with the installation, make sure to read the entire installation manual provided by the
manufacturer, including any safety guidelines and precautions. It's also recommended to have a qualified
professional or technician handle the installation to ensure the gate opener system is correctly set up and
safe to use.
COMMON
COMMON
DC24V
GND
MOTOR 2
MOTOR 1 LIMIT 1
LIMIT 2
3 WIRES WIRING DIAGRAM 4 WIRES WIRING DIAGRAM
MON-CLOSE
COMMON
MON-24VDC
MON-CLOSE
COMMON
MON-24VDC

POWER CONNECTION
CM9-2 INSTALL ATION AND OWNER MANUAL V.3.1 | 2023.06.01 PAGE 15
1. Use UL approved electrical wires, stranded copper, connected to 110-120V AC electricity. Electrical
wires MUST have a minimum capacity for 15 AMP current. See (FIGURE A) below for the correct electri-
cal wire gauge size. Wires must be placed in a PVC or other underground conduit.
2. Turn off the AC power from the main power source circuit breaker.
3. Connect the green wire to the green wire (GROUND) wire using a wire nut (FIGURE B).
a. Alternative: connect the green wire to the earth ground rod and AC ground wire nut.
Note: The earth ground rod can be grounded to the chassis.
4. Connect the white wire to the white wire (NAUTRAL) using a wire nut (FIGURE B).
5. Connect the black wire to the black wire (HOT LINE) using a wire nut (FIGURE B).
6. All operators MUST be properly grounded in order to prevent an electrical charge. Must use a dedicated
circuit for power supply.
7. Turn ON AC power from the main power source and turn the power switch on the gate operator to the ON
position. For DCFP (backup battery) and DCFP.S (solar and batteries) model gate operators, turn the
battery switch to the ON position (FIGURE C).
Green
White
Black
Green
White
Black
110 - 120V AC Power Cable P. Box Power Cable (located in Box)
FIGURE A FIGURE B
FIGURE C
GaugeDistance
14 AWG0 - 200 FT
12 AWG201 - 400 FT
10 AWG401 - 650 FT
08 AWG651 - 1000 FT
04 AWG1001 - 2000 FT
O
i
O
i

Determine which direction your gate opens when viewd from the inside
Dip Switch Number 6 (FIGURE A) on the bottom of the gate operator circuit board controls the open
direction.
ON = open to the right
OFF = opens to the left
CLOCKWISE OPENING
OPENS TO THE RIGHT SET DIP SWITCH #6 TO “ON”
COUNTER CLOCKWISE OPENING
OPENS TO THE LEFT SET DIP SWITCH #6 TO “OFF”
GATE OPEN DIRECTION SETTINGS
CM9-2 INSTALL ATION AND OWNER MANUAL V.3.1 | 2023.06.01 PAGE 16
OFF
ON
DP
ON
FIGURE A

This setup is for dual swing gate. A single button press of the remote control can open both gates. This
requires two (2) gate operators. One gate operator is the “PRIMARY”, and the other is the “SECONDARY”.
All accessories including remote controls, photocell sensor, loop detectors, etc. must be installed/programed
on the “PRIMARY” gate operator only. Only one photocell sensor is required, and duo photocell sensor is
optional.
1. On the “SECONDARY” gate operator circuit board, set dip switch number 5 to on (FIGURE A).
2. Press the reset button on the “SECONDARY” gate operator circuit board.
3. A 18 - 222 gauge, 2 conductor, stranded, copper, electrical wire is required.
4. Locate the DATA - and DATA + green terminal on the bottom left of the circuit board (FIGURE B). Use a
flathead screwdriver to relase the 2 locks on the top on the green terminal.
5. Using the electrical wire, connect the DATA + on the primary gate opener, to the DATA + on the secondary
gate opener. Connect the DATA - on the primary gate opener to the DATA - on the secondary gate opener.
The M/S link LED light should now be lit on both ciruit boards.
6. Use a flathead screwdriver to close the two locks on the top of the green terminal.
7. Place the cable underground in an eletrical conduit. This conduit must be separate from the main 110 -
120V AC electricity conduit.
DUAL GATE WIRING AND SETUP
CM9-2 INSTALL ATION AND OWNER MANUAL V.3.1 | 2023.06.01 PAGE 17
OFF
ON
DP
ON
FIGURE A FIGURE B
DATA - DATA + DATA - DATA +
Electrical Conduit

PHOTOCELL SENSOR INSTALLATION
CM9-2 INSTALL ATION AND OWNER MANUAL V.3.1 | 2023.06.01 PAGE 18
The photocell sensor is a safety device that prevents the gate from hitting a vehicle or pedestrain when the
gate is closing. The photocell sensor emits an invisible retroreflective infrared beam that detects when
objects passes through.
1. Plug the photocell sensor cable to the back of the control box, behind the circuit board with a green input
with the label: “MON-OPEN”, “MON-CLOSE”, “COMMON”, “MON-24DC”. (Figure A)
2. Press the reset button on the control box circuit board.
3. Use the two included mounting brackets to mount the photocell sensor on a post or wall OUTSIDE your
gate, 21” from the ground.
4. Press the orange button on the photocell sensor to turn on the alignment laser.
5. Mount the reflector to the opposite side. Make sure it is level with the photocell sensor (Figure C) and the
alignment laser beam hits inside the circle of the reflector. (Figure B)
6. Press the orange button on the photocell sensor to turn off the alignment laser.
IMPORTANT!!! Alignment laser must be off (Figure D)
OUTSIDE
GATE GATE FIGURE A
FIGURE B FIGURE C FIGURE D
INSIDE
REFLECTORPHOTOSENSOR
LASER
